Bea Lpr36 series User manual

75.5701.04 LPR36 20180913 Page 1 of 4

BATTERY REPLACEMENT:

300 MHz - A23 12-volt

433 MHz - CR2032 3-volt

900 MHz - CR2032 3-volt

LPR36

75.5701.04 LPR36 20180913 Page 1 of 4

Low-prole push plates

10LPR36-HW (hard-wired)

10LPR36-900 / 10LPR36-433 / 10LPR36-300 (wireless)

ENGLISH

DESCRIPTION

1. Top end cap

2. Plate assembly

3. Bottom end cap

Page 2 of 4 75.5701.04 LPR36 20180913

PRECAUTIONS

CLEANING

Page 2 of 4 75.5701.04 LPR36 20180913

NOTES:

1. The junction box and the installation of the junction box must be in accordance with National Electric Code (NEC) or local

codes.

READ BEFORE BEGINNING INSTALLATION/PROGRAMMING/SET-UP

MOUNTING INFORMATION

Only trained and qualiﬁed

personnel are recommended

to install and set up the

sensor.

The warranty is invalid if

unauthorized repairs are

made or attempted by

unauthorized personnel.

Always test the

proper operation of

the installation before

leaving the premises.

The door control system

and the header cover

proﬁle must be correctly

grounded.

The hard-wired version of this product may only be wall-mounted. A junction box1

must ﬁrst be mounted ﬂush with the wall and approx. 3” below (centered) the top

of the plate assembly.

The wireless version of this product may either be mounted to a wall or a bollard.

To clean the plates, use only a damp, non-abrasive cloth. Regular cleaning with harsh solvents or

abrasive materials may cause deterioration of the paint coating. Ensure the user is aware of this

procedure.

Shut off all power going to header before attempting any wiring procedures.

Maintain a clean and safe environment when working in public areas.

Constantly be aware of pedestrian trafﬁc around the door area.

Always stop pedestrian trafﬁc through the doorway when performing tests that may result in unexpected

reactions by the door.

ESD (electrostatic discharge): Circuit boards are vulnerable to damage by electrostatic discharge. Before

handling any board, ensure you dissipate your body’s ESD charge.

Always check placement of all wiring before powering up to ensure that moving door parts will not catch

any wires and cause damage to equipment.

Ensure compliance with all applicable safety standards (i.e. ANSI A156.10) upon completion of installation.

DO NOT attempt any internal repair of the components. All repairs and/or component replacements must be

performed by BEA, Inc. Unauthorized disassembly or repair:

1. May jeopardize personal safety and may expose one to the risk of electrical shock.

2. May adversely affect the safe and reliable performance of the product resulting in a voided warranty.

Prior to mounting the plate, ensure the two (2) in-transit locking screws are removed from

the back of the plate. These screws are not required for installation.

Mounting the plate on an uneven surface will cause the switching mechanism to hold the

circuit closed at all times.

75.5701.04 LPR36 20180913 Page 3 of 475.5701.04 LPR36 20180913 Page 3 of 4

NOTES:

1. If installing a wireless version, allow the top end cap assembly to hang loosely by the cable during set-up. Do not unwire.

2. Image shown has the plate and end cap removed for illustration purposes.

3. To avoid activation issues, do not push excess wire(s) into the plate assembly during reassembly.

MOUNTING

1 2 3

5 6

7 8

To install the push plate, ﬁrst

remove the top end cap by

removing its screw covers and

then screws.

After removing the top end

cap, remove the top and

bottom locking hole screws.1

Do not remove the face plate during mounting.

To complete a wireless set-up

(or change the battery), refer

to the applicable Wireless

Transmitter & Receiver User’s

Guide.

To bollard-mount (wireless

versions only), attach the

switch to the bollard using a

10-24 x 0.75 mounting screw

and nylon spacer.

To secure the bottom plate

assembly, ﬁrst slide the front

plate upwards, and then insert

a top end cap screw into the

threshold to hold.

Secure the plate assembly with

the bottom mounting screw.

Remove top end screw from

base and slide down.

Replace the top end cap with

provided screws and reinstall

the screw covers.

Make necessary wiring

connections.2Ensure excess

wire(s) is(are) kept inside the

junction box, if used.3

Install an appropriate anchor

through the top mounting

hole.

Page 4 of 4 75.5701.04 LPR36 20180913

TECHNICAL SPECIFICATIONS

SWITCH SUB-ASSEMBLY

Contact conﬁguration: SPST N.O.

Switching voltage: 0.1 – 50 VDC

Switching capacity: 1 W

Switching current: 0.005 – 100 ma DC

Operating temperature: -32 – 212 °F (-35 – 100 °C)

PUSH PLATE ASSEMBLY

Base material: 6063 aluminum

Face plate material: 304 stainless steel

Switch actuator material: nylon 66

End cap material: UL94 ABS

Hardware material: stainless steel

Speciﬁcations are subject to change without prior notice.

All values measured in speciﬁc conditions.

Page 4 of 4 75.5701.04 LPR36 20180913

BEA, the sensor manufacturer, cannot be held responsible for incorrect installations or inappropriate adjustments of the sensor/device; therefore, BEA

does not guarantee any use of the sensor outside of its intended purpose.

BEA strongly recommends that installation and service technicians be AAADM-certiﬁed for pedestrian doors, IDA-certiﬁed for doors/gates, and factory-

trained for the type of door/gate system.

Installers and service personnel are responsible for executing a risk assessment following each installation/service performed, ensuring that the sensor
