Beam BlueEvolution S User manual

Look foward to it.
960080.003
User Manual
digi

2
Look foward to it.
Industry
From carpets to upholstery
The beam BlueEvolution cleans almost
any surface – streak-free and deep.
Retail
Gleaming sales areas
Tough dirt and odours vanish in no time
at all. Health
Hygienic surfaces
The hot steam thoroughly cleans your practice
rooms with little effort and a big impact for your
patients.
Restaurants
No scrubbing, no chemicals
The beam BlueEvolution also dissolves fat
in hard-to-reach places – with no strong
cleaning products.
Clean desks
Door handles, conference tables, floors, kitchen
areas – the
beam BlueEvolution guarantees
a clean, germ-free work environment.
Offices
Gyms, saunas and spas
It's good for people to sweat. And thanks to the
beam BlueEvolution it's no longer a problem
for others. All equipment and contact
surfaces can be cleaned perfectly.
Wellness
And many more possibilities for use ...
The revolution in commercial cleaning
The BlueEvolution is more flexible than any other professional steam cleaner. Both
the steam and suction power have 3 settings. You can also regulate the hot water
inflow continuously using a control valve, which allows you to set the soaking effect
on the device individually.
Full power for a greater clean.
Kind to the environment.
The BlueEvolution is kinder to the environment than almost any other cleaning system. It is only
filled with clear water and minimises water consumption thanks to the steam pressure. There is no
need for any harmful or really aggressive chemicals.
The applications of the BlueEvolution are practically limitless. The BlueEvolution really comes into
its own in areas of high public traffic. Even large areas can be cleaned efficiently and quickly with
little effort. Pathogens don't stand a chance!
Make steam
Cleaning revolution for all industries
HACCP qualification certifies the highest cleaning power

3
Look foward to it.
➊Driving handle
➋Locking screw driving handle
➌Locking lever driving handle
➍Display
➎ Socket steam suction hose
➏ Drain plug water tank
➐Drain plug hot water module
➑Control valve hot water module
➒Filler holes
➓ Accessories box
AON/OFF button boiler
BON/OFF button suction
CON/OFF button hot water module
DOptical display suction mode
EService indicator - probe cap
FIndicator water low
GIron symbol
HDisplay operating pressure
IOperating temperature symbol
LHeating symbol
MSteam symbol
NHot water module
Description of equipment
A B C
DEFGH
I L M N
➓
➊
➋
➌
➍
➎
➏
➒
➑
➐

4
Look foward to it.
Important Advice for Users
Congratulations on the purchase of this beam product.
Your choice confirms your strong technical knowledge and your excellent taste.
Ultimately, you have chosen a high-tech product, which has been manufactured
using only materials of the highest quality.
Please take the time to read the User Manual carefully before starting your new
appliance and keep the Manual to hand so that you can refer to it in the future.
This Manual contains the information you need for proper use, correct operation,
appropriate cleaning, care and maintenance of the appliance.
It is essential that you are familiar with and follow the instructions in the Manual
to ensure risk-free use, as well as your own safety during operation, cleaning,
care and maintenance. This User Manual cannot foresee every conceivable use
of the appliance.
If you would like more information or if specific problems arise that are not
covered in sufficient detail in this User Manual, then please contact beam GmbH
directly to request the necessary information.
1. Description of equipment
The beam BlueEvolution impresses thanks to its ease of use, sophisticated tech-
nology and diverse range of applications. It sets new standards in terms of hygi-
ene and cleaning, makes the job much easier and saves time, drastically reduces
the use of harmful cleaning agents that are bad for the environment, and ensures
perfect cleanliness and a healthy feel-good ambience.
2. Purpose of use
The beam BlueEvolution can be used for thorough cleaning of surfaces and ob-
jects and to clear unpleasant odours from the air indoors.
3. Safety instructions
3.1 Safety warnings for the UV-C lamp UV
Warning! This appliance contains a UV emitter. Do not look directly into the
source of light.
Warning! Do not switch on the UV light if it is outside the appliance's protective
housing. The appliance may emit harmful UV-C radiation if not used
properly. Even small doses of UV-C radiation may cause damage to
eyes and skin. Users are NOT permitted to replace the UV-C lamp.
3.2 Warnings
• The appliance may only be operated by people who are familiar with its use.
Remember that the steam jet may cause damage if used incorrectly.
• The appliance must not be used by children. Children do not understand the
risks that may arise when dealing with electrical equipment and, therefore,
children must never be left unattended with such equipment.
• Never use a faulty appliance or an appliance with a damaged power cable.
• Do not put cleaning agents, perfume or other chemical substances into the
tank.
• Warning! Do not suction flammable or explosive substances or hot ash!
• Never immerse the appliance in water or other liquids. Never spray the appli-
ance with water.
• Never touch the steam jet. Risk of burning!
• Never aim the steam jet at people or animals. Nor at electrical sockets, con-
nections or equipment. Risk of burning!
• Do not use the appliance if other people are present in the working area.
• Refrain from any unsafe working methods.
• Do not use the steam jet for direct cleaning of electronic equipment (e.g. com-
puters, televisions, telephones etc.).
• Before cleaning ovens, fridges etc. always disconnect the power first to ensure
these are switched off. You must follow the manufacturers' specific instruc-
tions.
• Warning! The appliance may not be used to clean items that contain asbestos
or other harmful substances.
• Caution! In the following instances steam may not be used or may only be
used with the greatest care: on objects made from leather, Alcantara, velours
or other sensitive materials, on waxed or painted surfaces, polished wood sur-
faces and for direct contact with bonding agents or silicone. Please always
follow the manufacturer's instructions. For sensitive materials carry out a test
first on a sample or on an inconspicuous, concealed area. Always start on the
lowest setting. Pre-heat windows or other glass surfaces with a low steam
setting from a distance of approx. 30 cm and clean in combination with suc-
tion.
3.3 Precautionary measures
• Operation of the appliance is subject to national regulations.
• Always ensure the appliance is in proper working order before starting up.
• Perform regular checks on the power cable, plug and steam suction hose for
damage or signs of wear.
• Do not start the appliance if the steam suction hose or power cable are da-
maged.
• Place the appliance on a stable and level surface. Never place it on warm or
hot surfaces. Choose somewhere that is not accessible to children or pets.
• Do not position the appliance in direct proximity to heat sources (fires, heaters
or other heat-emitting objects).
• Position the appliance somewhere with good air circulation to prevent over-
heating.
• Never expose the appliance to the weather (rain, snow, frost etc.).
• Never touch the appliance, plug or electrical cables with wet hands or feet.
• Do not bend, squeeze or run over the steam suction hose.
• Never pull on the power cable or on the appliance itself when disconnecting
the mains plug.
• Protect the power cable from heat sources, steam and oil, and from damage
by avoiding pulling, squeezing or running over the cable.
• Never leave the appliance unattended when it is connected to the mains.
• To prevent unauthorised use of the appliance, ensure all switches are off and
the power is disconnected during breaks.
• Always disconnect from the mains before cleaning and maintenance work.
• Only perform maintenance work that is described in the User Manual. Only use
original spare parts and accessories.
• Do not undertake any technical modifications on the appliance.
• Never repair or open the appliance yourself. Repairs may only be performed
by authorised personnel.
• Take the appropriate precautions when using acidic descaling agents. Protect
sensitive surfaces, especially natural stone and wood, from spray and droplets.
• Some drops of condensation may form at the start of steam cleaning – wipe
these up with a cloth.
INFO: To minimise the occurrence of condensation (caused when the steam
hose and attachments are not at operating temperature) it is recom-
mended that you allow the steam to flow for a few seconds on the
maximum setting before starting the cleaning work. This ensures the
steam hose and attachments heat up more quickly.

5
Look foward to it.
Assembly / preparation
Assembly of the driving handle and
accessories box
Attach the handle using the two fixing knobs. Tighten them
by turning clockwise.
Engage the two locking levers so the handle is secured pro-
perly.
Insert the accessories box
Fill the reservoir O
Fill the hot water module P
• Open the cap O and fill the water tank with normal tap
water using the funnel.
• Re-close the tank cap.
• Fill the tank P for the hot water module, likewise with
normal tap water. If your water is particularly hard, you
may also use distilled water mixed with tap water in this
tank.
• Re-close the tank cap.
The following combined functions are
possible depending on the application
area:
• Steam cleaning
• Steam cleaning with hot water
• Suction
• Suction and steam cleaning (steam suction)
• Suction and steam cleaning with hot water function
P O

6
Look foward to it.
Assembly / preparation
Filling the filter bowl
Your appliance is fitted with a hygienic water filter. You must
fill the filter bowl with water before starting, in order to bind
the extracted dirt in the water and to clean the suctioned air
in the water bath as well.
• Loosen the clips on the right and left of the filter bowl and
remove from its slot.
• Open the cover on the filter bowl by pushing off the rele-
vant clips.
• Fill with tap water up to the MAX. level indicated, using the
integrated siphon within the filter bowl (approx. 2.0 litres).
• Re-insert the filter bowl, ensuring the switch cam on the
cover is in the correct position.
WARNING:
The appliance can suck in up to approx. 1.5 litres of liquid.
If you exceed this amount, the fill level sensor will stop suc-
tion automatically and LED D (page 2) on the display will
flash.
INFO:
If you only wish to suction liquid, such as accidental water
spills, it is not necessary to fill the appliance's filter bowl with
water.
When sucking liquids, the MAX. capacity in the container is
approx. 4 litres.
Inserting the steam suction hose
• Insert the connector of the steam suction hose into the
socket until you hear the click of the safety hook.
• To remove the hose from the appliance, press release but-
ton A and pull on the connector.
A

7
Look foward to it.
Start-up steam
Insert the plug into an earthed socket. The display turns on
and there is power.
The display goes to OFF. (Standby)
Press button. Aon the display. The appliance switches on
and begins to heat.
The symbol Lfor heating flashes on the display during the
heat-up phase (approx. 5 minutes).
The symbol stops flashing once the temperature is reached.
You can now use the steam function.
INFO:
The heating symbol flashes during operation to indicate that
the appliance is reheating to deliver sufficient pressure and
temperature.
Switching off the appliance
Press button Ato switch off the appliance. The appliance
switches off after approx. 10 seconds. OFF is shown on the
display. (Standby)
Steam function
Hold down steam lever Pon the handle to emit steam.
You can set the steam mode by pressing buttons
T2
+ or
T2
on the side of the handle.
There are 3 steam modes to choose from:
Mode 1 = minimal steam volume, use on sensitive sur-
faces like wood, parquet, upholstery etc.
Mode 2 = medium steam volume, use on windows, glass,
tiles, stone etc.
Mode 3 = maximum steam volume, use on all resistant
surfaces that have previously been scrubbed
with cleaning agents and water, such as tiles,
granite, stainless steel etc.
The mode is indicated with 1-2-3 on the display Mon the
symbol for steam.
WARNING:
Water droplets may occur on first use, which may be due to
incomplete heat stabilisation in the housing. For this reason,
we recommend aiming the first steam jet at a cloth until an
even flow of steam is achieved.
INFO:
For sensitive materials carry out a test first on a sample
or on an inconspicuous, concealed area. Always start with
mode 1 (minimal steam volume).
AL M
P
T2

8
Look foward to it.
Start-up steam with hot water module Start-up suction
The soaking effect and, thus, cleaning performance can be
increased for heavy soiling by switching the hot water mo-
dule to steam.
INFO:
Do not use on sensitive surfaces or materials.
Switching on “hot water module”
Press button Con the control panel to activate the hot wa-
ter module. The symbol Non the display begins to flash.
Pressing button
T4
on the handle for the hot water module
switches the function on and symbol Non the display stays
illuminated.
Always use button
T4
on the handle to switch the hot water
module on and off.
The “hot water module”
flow-through volume can be
adjusted on the control valve
(+/-), which is located under
the control panel.
Suction
Press button Bon the display to activate suction.
LED Dfor suction turns red. (Suction mode 3 = max.)
Press button
T3
on the handle to switch on suction.
Briefly press button
T5
+ or
T5
on the side to vary suction
power.
MIN = LED Dturns green
MED = LED Dturns orange
MAX = LED Dturns red
Press button
T3
briefly to turn suction off again.
INFO:
As there is liquid in the hose and in the extension pipes du-
ring suction operation, the sucker should not disconnected
immediately after cleaning finishes.
A short delay (approx. 30 seconds) is required.
B
D
C
N
T3
T4
T5
The "hot water module" flow-through can be adjusted, by
pressing the button (C) in 10% increments. This is indicated
between 010 and 100 in the display.
Display shows 010 = 10% minimum amount of hot water
Display shows 100 = 100% maximum amount of hot water

9
Look foward to it.
Nylon brush attachment
Item no.: 802105
Standard accessories and use
Steam suction hose
Item no.: 9618
Extension pipe
Item no.: 9615
Extension pipe
Item no.: 9615
Extraction nozzle, 238 mm
Item no.: 9620
Extraction nozzle, 126 mm
Item no.: 9621
Rubber lip with brush attachment
Item no.: 80202
Rubber lip with brush attachment
Item no.: 802102
Rubber lip insert
Item no.: 80201
Rubber lip attachment
Item no.: 802101
Brush attachment
Item no.: 80203
Upholstery, mattresses
and carpet cleaning.
Upholstery, mattresses,
car seats, doormats and
vehicle interior cleaning
Glass surfaces,
windows (display windows),
mirrors
Glass surfaces, windows
and mirrors
Hard floors, e.g.:
tiles, granite, marble, wood, PVC,
laminate, etc.
Almost all surfaces,
window frames,
sills, interior doors,
kitchen cupboards,
synthetic surfaces, etc.
On sensitive surfaces, e.g. parquet,
use steam mode 1
Do not use hot water module
Pre-cleaning of heavily
soiled surfaces, rubber or synthetic
doormats, etc.
Pre-cleaning of heavily
soiled surfaces, windows,
rubber or synthetic doormats, etc.
NO ATTACHMENT
NO ATTACHMENT
Not for sensitive surfaces

10
Look foward to it.
Floor nozzle,, w = 400 mm
Item no.: 8022
Floor nozzle with adapter
can be used directly on the handle
or with extension pipes.
Standard accessories and use
Rubber lip insert
Item no.: 802201
Adapter
Item no.: 802210
Brush insert
Item no.: 802202
Glide insert
Item no.: 802203
Hard floors, e.g.:
tiles, granite, catering
and industrial floors, marble,
wood, PVC, laminate, etc.
Pre-cleaning of heavily
soiled surfaces, rubber or
synthetic doormats, etc.
Improves cleaning
on stubborn dirt.
Improves cleaning on
stubborn dirt.
The steam can be changed
from spot-jet to three-jet
by attaching to
the three-jet nozzle
and turning the brush.
Can be used with
or without the spot-jet nozzle
and the three-jet nozzle.
For dry suction
the joint nozzles can be used
directly on the pipe
or steam suction hose.
Warning! Do not use on
sensitive surfaces or glass!
Warning! Do not use on
sensitive surfaces or glass!
Carpets, mats, dry suction
(without steam)
Spot-jet nozzle
Item no.: 9612 Round brush set small
Item no.: 96400
Round brush large
Item no.: 7109
Corner brush
Item no.: 7110
Joint nozzle narrow
Item no.: 8010
Joint nozzle broad
Item no.: 8011
Spot-jet nozzle long
Item no.: 9613
Spot-jet nozzle
Item no.: 8012
Three-jet nozzle
Item no.: 8001
Warning:
Always adjust the steam volume and accessories for the surfaces you are cleaning!

11
Look foward to it.
Reports
Maximum fill level in the filter bowl
If the suctioned dirt in the filter bowl reaches the maximum
level, the fill level sensors ensure that suction stops automa-
tically.
LED Don the display begins to flash.
To continue with cleaning work:
• Remove the filter bowl, empty and fill with tap water up
to the MAX. level indicated, using the integrated siphon
within the filter bowl (approx. 2.0 litres)
• Re-insert the filter bowl, ensuring it is in the correct posi-
tion.
WARNING:
Regularly remove and clean the installation parts from the
filter bowl in the event of heavy soiling. Return to the correct
position afterwards.
Water shortage reservoir
A lack of water in the reservoir Ois indicated by sym-
bol Fflashing on the display and by a simultaneous acou-
stic signal. To restart work, fill the tank as described in the
section on “Filling reservoir O.
Water shortage hot water module
A lack of water in the hot water module is indicated by sym-
bol Non the display, which now flashes rather than being
permanently illuminated. There is also an acoustic signal. To
refill the tank with water, follow the instructions in the sec-
tion on “Filling hot water module P.
D
F
N

12
Look foward to it.
Shutting down
To ensure the functionality, cleanliness and hygiene of the
appliance and accessories, follow this procedure to shut
down the appliance:
1) Remove the filter bowl, empty out the water and re-insert.
2) Set the suction mode to MIN (LED Dturns green) by
pressing button T5 on the handle.
3a) Cleaning of steam hose and accessory parts In suction
mode 1, flush approx. 2 litres of cleaning fluid with a mild
alkaline cleaning solution through the used accessory
parts (steam hose, extension pipes etc.) to clean them.
3b) Disinfecting the steam hose and accessory parts We
recommend you flush a VAH-listed, peroxide-based sur-
face disinfectant through the accessory parts in suction
mode 1.
See the manufacturers' information for application times.
INFO:
Repeat the rinsing process with clear water if there is a lot
of foam.
Alternatively, the steam suction hose can also be cleaned
using a suitably sized sponge soaked in disinfectant.
4) Empty the filter bowl, clean and re-insert without cover.
5) Switch off the functions you have selected by pressing the
relevant buttons on the display. The appliance switches
off after approx. 10 seconds. OFF is then shown on the
display.
6) Disconnect from the mains power by pulling out the plug.
7) Pull the steam suction hose out of the appliance for it to
dry out.
8) Store the appliance with open filter bowl in a well ventila-
ted and frost-free room.
T5

14
Look foward to it.
12
Technical data
Technical data
beam BlueEvolution S
Order no.: 960000
Electrical connection
Nominal voltage 230 V AC 50 Hz
Total output 3500 W
Boiler nominal consumption 2100 W + 1300 W
(Boiler made from stainless
steel INOX Aisi 304)
Automatic refill system Yes, 2 litres
Steam temperature max. 160 °C
Steam pressure max. 6.0 bar
Motor nominal consumption 1200 W
Water filter max. fill level approx. 3.3 litres
Water filter difference min. to max approx. 1.3 litres
Underpressure 2100 mm H O
Length steam suction hose approx. 3.2 metres
Weight approx. 26.2 Kg
Size (l x w x h) 580 x 380 x 930 mm
Safety test CE
incl. hot water module 2 litres for the stubbornest dirt
beam reserves the right to make technical changes or chan-
ges to accessories in the course of further development.
Order spare parts and accessories
conveniently from our online shop:
www.beam.de
beam GmbH · Illertalstraße 3 · 89281 Altenstadt/Iller, Germany
Tel.: [phone] · Fax: [phone]
Look foward to it.

Error….
Cause
Remedy
Suction switches off, you hear an
acoustic signal and LED (D) flashes
on the display
Filter bowl full
Empty the filter bowl and refill with fresh tap
water up to the Max. fill level
Fluff, fibres or hair in the filter bowl
Empty the filter bowl, clean out the hair and
fluff and refill with fresh tap water up to the
Max. fill level
Foam in the filter bowl
Empty the filter bowl and refill with fresh tap
water up to the Max. fill level.
Tip: To minimise foam build-up, add 3 drops
of non-acidic oil (e.g.: sewing machine or
light vegetable oil) to the filter bowl
There is little or no steam and no hot
water
Limescale in hot water modul
Perform “Hot water descaling”
(Service/Maintenance –Part 1)
Steam very wet
Limescale in boiler and probe cap
Check the probe cap and perform “Boiler
descaling” (Service/Maintenance – Part 2)
Hot water is switched on
Briefly press button (T4) on the handle or
button (C) on the display
There is no hot water
Hot water not switched on
Briefly press button (C) on the display and
then button (T4) on the handle
Reservoir tank (P) is empty
Fill reservoir tank (P) hot water with clear tap
water
Suction is not working
Filter bowl not in position
Re-insert filter bowl. Important: the lug on the
cover must sit in the guide on the appliance
Not switched on on the display
Press briefly on button (B) on the display;
suction can then be switched on using button
(T3) on the handle
No suction
HEPA filter dirty
Replace HEPA filter
Foreign body or dirt in the hose or
accessory
Check hose and accessory and clean as
required

Entkalkungsanleitung B
Use this table to document service and maintenance work performed, in order to improve overview
and control.
Date Comment Performed by:
Hotwater module discaling
Boiler discaling
Filter change
Additional work
Hotwater module discaling
Boiler discaling
Filter change
Additional work
Hotwater module discaling
Boiler discaling
Filter change
Additional work
Hotwater module discaling
Boiler discaling
Filter change
Additional work
Hotwater module discaling
Boiler discaling
Filter change
Additional work
Hotwater module discaling
Boiler discaling
Filter change
Additional work
Service/Maintenance
Service/Maintenance table

Entkalkungsanleitung B
Use this table to document service and maintenance work performed, in order to improve overview
and control.
Date Comment Performed by:
Hotwater module discaling
Boiler discaling
Filter change
Additional work
Hotwater module discaling
Boiler discaling
Filter change
Additional work
Hotwater module discaling
Boiler discaling
Filter change
Additional work
Hotwater module discaling
Boiler discaling
Filter change
Additional work
Hotwater module discaling
Boiler discaling
Filter change
Additional work
Hotwater module discaling
Boiler discaling
Filter change
Additional work
Service/Maintenance
Service/Maintenance table

Service/Maintenance Part 
Hot water module descaling

Entkalkungsanleitung B
Use of the hot water module causes lime scale to form over time depending on the hardness of the
water used. To prevent a fault caused by lime scale in the steam hose we recommend that you
descale regularly.
Warning! Descalers can be harmful. Read the information on the descaler packaging and follow the
safety instructions.
Descalers or vinegar may cause damage to surfaces. Wipe up drops immediately. Only use suitable
and recommended descalers.
1. Preparation
Remove the sound-proofing casing on the underside
of the appliance. To remove, loosen the middle fixing
screw by hand, which will enable you to fold down,
detach and remove the sound-proofing casing.
Place a suitable container under the appliance and open
the drain plug by turning it to the left with the included
Inbus key (label yellow ring “Hot Water Extraction”). Drain
the reservoir and then screw the drain plug back in and
tighten slightly.
Descaling instructions hot water module
Up to 2 litres of water may flow from the drain plug if the reservoir is full.
The steam hose does not have to be descaled if you use decalcified water.
Error, cause remedy
… no steam or hot water is produced when the steam lever is pressed.
Check whether the hose nozzle in the steam suction hose connector is dogged with
lime scale. If it is, proceed as follows:

2. Descaling
Mix 0.2 litres of vinegar essence and 0.3 litres of tap
water in a measuring cup.
Open the cap for hot water “Hot Water Extraction” and
pour in the vinegar mixture.
Insert the steam suction hose into the appliance.
Now connect the appliance to the mains and press
button (A) on the display. The appliance switches on
and begins to heat. Now press button (C) to activate
the hot water module. The symbol (N) begins to flash.
Set the control valve for hot water to max. (+) by turning
fully to the left.
Button (T2) - Button (T4)
Press button (T2) –select minimum steam mode. Press
button (T4) to switch on the hot water module.
Hold the handle over a suitably sized container to catch
the mixture. Now press steam lever (P) until all the
vinegar-water mix has rinsed through. Press the lever
at short intervals if there is heavy limescale. This
increases the impact duration of the mixture and the
lime scale is dissolved.
Hot water module descaling
Symbol (N) Button (A) Button (C)
Warning: Descalers can be harmful. Vinegar and descalers can damage contact
surfaces. Wipe up drops immediately.
Steam lever
(P)

3. Rinsing
Pour 0.5 litres of clear tap water into the reservoir “Hot
Water Extraction”. Hold the handle over a suitably sized
container to catch the mixture. Now press steam lever
(P) until all the water has rinsed through.
Repeat the procedure to rinse out any limescale and
vinegar residue.
Hot water module discaling
Your appliance is now ready for use again.
