Beamever HELA FLEX WHT User manual

The ambient temperature between -35°C~55°C to ensure the best working
performance of HELA FLEX WHT.
Must ensure the person who must be
qualified, full-of experienced in electrical
and construction. And must meet
relative regulation and standards to
install luminaire.
Before installing this product, please visit
the product page at www.beamever.com
for the latest installation instructions.
Please do the regularly check for
ensuring maintain the protection
requirement, e.g.,either connection is still
steady & safe.
HELA FLEX WHT
Installation Instructions
w
w
w
.
b
e
a
m
e
v
e
r
.
c
o
m
w
w
w
.
b
e
a
m
e
v
e
r
.
c
o
m

1.Please use power supply with constant
voltage DC24V to feed luminaires. Max Running
Length is 12M at one point power feed and
make sure no less than 21.5V to supply it.
Besides, if exceed 12M, please split into
multiple circuit branch.
2.The total power of each circuit branch cannot
be more than 80% of the total power of the
power supply.
3.Ensure that main power supply is off before
installing or wiring a luminaire.
5.Luminaires working environment should be
ventilated and clear, can not be covered with
items, please do regular cleaning to avoid dust
accumulation, also important to the regular
inspection of each connector is abnormal, each
sealing interface whether still meet protection
requirements, whether the join wire still
working and so on.
4.Please ensure the male and female
connectors connected correctly and no short
circuit before power on.
Verify the electrical plan and all necessary surge protection requirements.
Stainless Wire Installation
(If you chooses stainless-wire installation, we will have
assembled the luminaires with stainless wires before
shipment.)
Aluminum Profile Installation
(Aluminum profile includes the cover and mounting
base )
Installation Options
Step 1: To put the luminaires to the pre-arranged
installation position.
Step 2: To fix the two ends of the stainless wire.
Step 3: Ensure they are steadying and connect safety
with each other between lights and stainless wire.
Step 1: Apply screws for steadying aluminum
mounting base in required-position.
Step 2: Place the luminaires into aluminum mounting
base.
Step 3: Clip cover into the mounting base

Do not twist or loop cable
Do not over stretch cable
Use caution when installing luminaire nodes
Additional Notes
Please note specifications are subject to change without notice, and all information contained within
this instruction manual is provided in good faith. No representation or warranty as to the accuracy or
completeness of the information included herein is given and any liability for any action in reliance thereon is
disclaimed.
lt is very important to ensure
the safety and integrity of the
accessories. Do not twist or loop
with the cable easily. Because it is
very dangerous, which can cause
accessories damage and potential
personal safety.
Cables are important for a durable
and safe lighting project. So please
don't play around or over-stretch
cable. This might cause any damage
to the cable, and affect the lighting
effect.
Stainless Mounting Clip Installation
Step 1: Place luminaires and clips in the required-
position.
Step 2: Apply screws for steadying lights within
correct positions.
Step 3: Ensure all clips, lights, and screws are stable.
In the replacement and maintenance of products, make sure to cut off all the power before
start maintenance, in order to prevent electric shock or short circuit. After troubleshooting,
it is necessary to correctly install the various components to ensure that the electrical and
structural requirements meet the original requirements and then connect power.
