LCB-24IP LED COLORUNIT 8X3W
TRI DMX
MANUAL

‐2‐

Thank you for purchasing our company products.
Please read these instructions carefully to enjoy optimum performance and a longer service life before
you start to use.
CONTENTS
Unpacking Inspections.............................................................................................................2
Unpacking instructions......................................................................................................2
Checking the contents of the carton:................................................................................2
Safety Instructions....................................................................................................................2
Functions Introductions............................................................................................................3
Main Functions .................................................................................................................3
System menu....................................................................................................................4
Operating instructions.......................................................................................................5
DMX channels...................................................................................................................6
Maintenance.............................................................................................................................7
Specification.............................................................................................................................7
UNPACKING INSPECTIONS
Unpacking instructions
Please unpack the carton and check the goods carefully when you receive it , if discover
packing damage, shortage or quality problem, please notify the shipper and reject the goods.
Before using this product, please read the instructions carefully and keep it in a safe place for
future reference.
Checking the contents of the carton:
The product, Power cord, Instruction Manual, Mounting Brackets + screws
SAFETY INSTRUCTIONS
Safety and regulatory power socket with high quality output should be used .
Always connect the product to a grounded circuit to avoid the risk of electrocution.
Never put tiny metal objects such as a screwdriver, iron wire and coins, etc. into the internal or
stretch into the machine in case of short circuit .
Please make sure to connect the proper voltage and do not higher or lower than that stated on
the decal or rear panel of the product .
Avoid hitting, crashing or squeezing with other objects in transportation. Never carry the
product from the power cord or any moving part . Always use the hanging / mounting bracket
or the handles.
Never pull or tug on the cord and change it for another one , stop using it when it is damaged
or becomes hot .
Stop using the product once there is sparks when connecting with the power plug .
Make sure there are no flammable materials close to the fixture while operating . Always install
it in a location with adequate ventilation.
Never replace the lighting source with different specification and rating when the original one
is damaged.

‐3‐

Make sure to power off before replacing the light source or the fuse. Never do it while it is on.
The ambient temperature is no more than 40°C(104°F) .
Never clean the fixture by water, thinner or other dissolved agent .
Stop using the product in case of a serious operating problem and send it to our maintenance
agent immediately. Never repair by non-professional workers .
Avoid direct eye exposure to the light source while the product is on.
SPECIFICATION
No. of LEDs 8x 3W Tricolor
DMX channels 3, 7, 10, 12 or 16
DMX connection 3-pin XLR
IP Rating IP65
Power Supply 100-240Vac / 50Hz
Consumption 30W
Dimensions 520 x 112 x 84mm (LxWxH)
Weight 3.7kg
MAINTENANCE
The unit should be cleaned periodically to ensure the optimum performance, the smudginess can
decrease the life of light and the output of light is affected by the dust which can make the machine
overheating. In general, make the maintenance at least two times a month. Be sure to power off the
unit before cleaning .
Do not clean until the unit recovers normal temperature since high temperature for using, use the lens
tissue or soft cotton cloth with alcohol to wipe gently.
Cleaning frequency depends on the environment in which the fixture operates, damp, smoky or dirty
surrounding can cause greater accumulation of dirt on the optics. Never rub or press strongly on the
panel.
FUNCTIONS INTRODUCTIONS
Main Functions
3, 7, 10,12 or 16 DMX channels .
Standalone, DMX, master/slave mode .
8x 3W Tri-colour LEDs
With static colors, strobe, dimmer, color mixing and changing effects.
Electronic dimming 0 – 100%
Waterproof IP65

‐4‐

System menu

‐5‐

DMX Address – Set the DMX address
Press MENU, press the UP or DOWN button until “Addr” is displayed, press ENTER.
“Axxx” will now be displayed, (“xxx” represents the displayed address). Press the UP or DOWN button
to find the desired address. Press ENTER to confirm
Channel mode – Select the desired channel mode
Press MENU, press the UP or DOWN button until “Chnd” is displayed, press ENTER
“X Ch” will now be displayed, (“X” represents the displayed channel mode). Press the UP or DOWN
button to find the desired channel mode. Press ENTER to confirm.
Auto mode – This menu will let you select the desired auto mode.
Press MENU, press the UP or DOWN button until “Auto” is displayed, press ENTER.
There are 3 auto modes, press the UP or DOWN button to select the desired mode, press ENTER to
confirm.
Color mode – Select the desired color mode
Press MENU, press the UP or DOWN button until “CoLo” is displayed, press ENTER.
“Colx” or ATF will now be displayed, (“X” represents a number between 1 – 9). Press the UP or DOWN
button to find the desired color mode. Press ENTER to confirm.
ATF: Make your own color by mixing and adjusting the Red, Blue and Green color.
Slave mode – In this mode the unit functions as a slave
Press MENU, press the UP or DOWN button until “Slav” is displayed, press ENTER.
“Sla” will now be displayed, Slave mode is confirmed. The unit will now act as a slave in Auto, sound
and chase mode.
Version – Will display the software version of the unit.
Press MENU, press the UP or DOWN button until “ver” is displayed, press ENTER.
The software version of the unit will be displayed. Press MENU to leave this function
Operation Instructions
DMX connection.
Master / Slave connection.


‐6‐

DMX Channels:

‐7‐

CE Declaration of Conformity
Importer: TRONIOS BV
Bedrijvenpark Twente 415
7602 KM - ALMELO
Tel : [phone]
Fax : [phone]
The Netherlands
Product number: 150.554
Product Description: LCB-24IP LED Colorunit 8x 3W Tri DMX
Regulatory Requirement: EN 60598-1/-2-17
EN 55015
EN 61547
EN 61000-3-2/-3-3
The product meets the requirements stated in the above mentioned Standards.
13-12-2012
Signature :

‐8‐

