Bebe Care PORTA CASA Quick reference guide

IMPORTANT:
RETAIN FOR FUTURE REFERENCE,
READ CAREFULLY
PORTA CASA COT BED MODEL # 091567

Read all instructions before assembly and use of the cot. Keep instructions for future
use.
ADULT ASSEMBLY REQUIRED:
DUETO THE PRESENCE OF SMALL PARTS DURING ASSEMBLY,KEEP OUT OF REACH OF
CHILDREN UNTIL ASSEMBLY IS COMPLETE.
TO PREVENT FALLS,THE MATTRESS BASE OFTHIS COT SHOULD BE ADJUSTEDTOTHE
LOWEST POSITION BEFORETHE CHILD CAN SIT UP.
RECOMMENDED MATTRESS SIZE:
1300MM LONG X 690 MM WIDE X 100-150 MMTHICK.
FOLLOWTHE MANUFACTURER’S ASSEMBLY INSTRUCTIONSTO ENSURE THE SAFETY
FEATURES OFTHE COT ARE NOT COMPROMISED.
SAFETY PRECAUTIONS
WARNING
This cot has been manufactured for one child only,with a maximum weight of 18kgs in cot conguration.
When the mattress base is assembled in the lower position, ensure the higher cot base holes are covered
tightly with the lling bolts supplied.This is to prevent nger entrapment,swallowing and inhalation hazards.
ENSURE the cot is placed at a reasonable distance from curtains,blinds,heaters and power points.
ENSURE the cot is completely assembled and check that all parts are securely tightened before placing the
child into the cot.
ENSURE medication,string,elastic,small toys or small items such as money etc are always kept out of the
child’s reach when in the cot.
DO NOT over tighten bolts/screws.
ENSURE that the child is clear of any moving parts when adjusting the cot.
For warranty purposes,keep your sales receipt to provide proof of purchase.
RECOMMENDED MATTRESS SIZE (SOLD SEPARATELY):
THIS COT HAS BEEN MANUFACTURED FOR USE WITH A MATTRESS WHICH MEASURES 1300MM LONG BY 690
MM WIDE AND 100-150 MM IN THICKNESS.
The width and length are specied because it is important that the gaps between the mattress and the sides
and ends of the cot will not exceed 40 mm when the mattress is pushed to one side or end,and 20mm when
the mattress is centred in the cot.
This is to minimise the risk of a child’s limb becoming caught in the gap.
The thickness of the mattress has been specied to ensure that the depth of the cot is greater than 500 mm
with the mattress base in the lower position to minimise the risk of a child climbing or falling out of the cot.

Due to variations in the style and design of our products, the photographs and illustrations shown in this instruction
manual are generic, therefore product fabrics, colour and design may vary from images shown. CNP Brands reserves
the right to alter product specifications without notice as a result of our ongoing policy of product improvement.
Contents
Assembly contents list
Assembly / Operating instructions
How to care for your Porta Casa Cot Bed
Congratulations on your purchase of the Porta Casa Cot Bed.
This product has been designed and developed with safety, comfort
and functionality in mind. Please take the time to read this manual
carefully before using this product and keep it in a safe place for
future reference.
CONGRATULATIONS

ASSEMBLY CONTENTS
Check what you have received...
You have received 1 box. Please check the contents of the box against the list
below. If anything is missing, please contact Customer Service.
In Australia, contact CNP Brands on 1300 667 137, in New
Zealand contact Wainhouse Distribution on 0800 567 5000.
Supplied loose in box:
End Panel
(Left)
End Panel
(Right)
x 1
x 1
x 1
x 1
x 1
x 1
x 2
x 1
Fixed Panel
Mattress Base
Drop Side Panel
Lower Support Rail
Feet
Mattress Retainer
Panel
Recommended use with 115282-003 Inner Spring Mattress - White.

ASSEMBLY CONTENTS
Assembly Kit:
58mm Bolt
(Assembly bolt for
fixed panel)
25mm Bolt
(Assembly bolt for
bottom feet)
35mm Bolt
Filling Bolt & Nut
(Pre-assembled)
x 4
x 8
x 8
x 6 x 2
x 4
x 2
x 2
Allen Key
Wooden Dowel
(Pre-assembled)
Drop Side Guide
and Bolt
Drop Side Locating
Pin

ASSEMBLY / OPERATING INSTRUCTIONS
To prepare End Panels...
1
2
3
Screw the drop side round plastic
guides into each end panel with the
threaded bolt.
Screw the locating guide pins into
position.
Screw in the lower support panel
cam lock pins in to end panels.
Attach the end panels to the fixed side panel
using four x 58mm bolts.
Tighten bolts until firm.
Lay the cot down on the fixed side.
Assemble the mattress base panel by carefully
placing it between the end panels and using
four x 35mm bolts to connect through the end
panel into the mattress base.
Tighten bolts until firm.
It is advisable that two people assemble the cot in the room in which it is to be
used.
As small parts are involved in assembly, children should be kept clear of the
assembly area.
Dispose of all packaging material immediately after the cot is assembled.
Identify all parts and components.
Clear an area on the floor for assembly and place a sheet on the floor to ensure
the cot is not scratched during assembly.
1a.
1b.
1c.
2a.
2b.
3a.
3b.
3c.
a.
b.
c.
d.
e.
DO NOT OVERTIGHTEN BOLTS.OVERTIGHTENING BOLTS CAN CAUSE PANELSTO CRACK.
WARNING

ASSEMBLY / OPERATING INSTRUCTIONS
To attach Lower Support Rail...
To fit the Drop Side Panel...
1
1
2
Remove one upper mattress base bolt.
Locate the dowel into the end panel and secure
rail with a 35mm bolt.
Do not secure the other end of the lower support
rail yet.
Place the drop side between the end panels, making
sure the small slot in the drop side panel track is
facing toward the mattress base. (As shown)
Align and insert the round guide plastic (on the end
panel) at the top of the track in the drop side panel.
1a.
1b.
1c.
1a.
2a.
PLEASE NOTE! Fitting the drop side panel is easier with 2 people.

ASSEMBLY / OPERATING INSTRUCTIONS
To fit the Drop Side Panel continued...
To attach Feet to Base...
3
1
2
4
Slide the drop side up to allow the locating pin to
match up with the small track on the drop side.
Move end panel outwards and release when it
locates in the track.
Repeat for other end.
Use eight x 25mm bolts to connect the feet
between the fixed side and the lower support
rail.
Ensure the feet are facing towards the end of the
cot.
Turn the cot back on to its feet and tighten all bolts
until firm.
Remember to replace mattress base bolt, insert
and tighten 35mm bolt to lower support panel.
3a.
3b.
3c.
1a.
1b.
2a.
4a.
WARNING! Do not over tighten bolts. Over tightening bolts can cause panels to
crack.
The cot is now ready for use.

ASSEMBLY / OPERATING INSTRUCTIONS
To operate Drop Side Panel...
Mattress Base Heights...
1
2
To Lower Drop Side Panel
Lift the drop side panel in the centre and push
lower rail inwards with your leg, allowing it to
lower into place.
Mattress base in High Position
The base height is set for when your baby is young and cannot sit up
unaided.
Mattress base in Low Position.
This is the normal position for an active baby who can sit up unaided.
To Raise Drop Side Panel
Lift the drop side panel in the centre and raise
up until it locks in to place.
1a.
2a.

ASSEMBLY / OPERATING INSTRUCTIONS
To lower Mattress Base Height...
To convert to Cot/Bed Mode...
1
1
2
2
Remove the two filling bolts and nuts from each
of the end panels.
Lay down the cot on the fixed side panel.
Loosen both upper mattress base bolts 6 turns.
Lay the cot down with drop side facing up.
Remove lower support rail bolt on one end of
the cot.
Carefully move end panel outwards to release
the locating pin from the track.
Repeat for other side.
With both locating pins released, slide the drop
side panel down to release the plastic guide at
the end of the track.
Lift drop side panel off.
Remove the four mattress base bolts from the
end panels.
Carefully slide the base to match the lower
holes and replace mattress base bolts.
1a.
1b.
1a.
1b.
2a.
2b.
2c.
2d.
2e.
2a.
2b.
PLEASE NOTE! Re-t lling bolt and nut to the higher base positions to
prevent possible nger entrapment.

ASSEMBLY / OPERATING INSTRUCTIONS
To convert to Cot/Bed Mode continued...
3
4
5
6
7
Unscrew plastic guides and remove locating pins
from both end panels.
Remove one upper mattress base bolt.
Remove lower support panel bolt from the same
end.
Remove filler bolts and nuts from the edge of the
end panels.
Insert the mattress retainer dowel into the end
panel.
Secure with 1 x 35mm bolt.
With the opposite end, move the end panel
outwards to allow the mattress retainer dowel to
locate in the end panel.
Secure with 1 x 35mm bolt.
Replace the upper mattress base bolt and tighten.
Turn cot back on to its feet.
Check all bolts and cam locks for firmness.
3a.
3b.
3c.
4a.
4b.
4c.
5a.
5b.
6a.
7a.
7b.
The cot bed is now ready for use.

HOW TO CARE FOR YOUR BEBE CARE COT
Cleaning
Maintenance
This product has been designed and developed with safety, comfort and
functionality in mind. Please take the time to read this manual carefully before
using this product and keep it in a safe place for future reference.
To ensure the long-lasting use of your cot, wipe down with a damp cloth and
use a mild soap solution if necessary. Do not use abrasive cleaners. Always
store product in a clean dry place.
Always check parts regularly for tightness of screws, nuts and other fasteners
– tighten or replace if required. To maintain the safety of your cot, seek
prompt repairs for bent, torn, worn or broken parts. Use only those parts and
accessories approved by CNP Brands.
If you have any difficulties in assembling the cot, please contact our Service
Department.
In Australia, contact CNP Brands on 1300 667 137, in New Zealand contact
Wainhouse Distribution on 0800 567 5000.
