BED BATH & Beyond EMBRACE PRO Installation and operating instructions

ERGONOMIC CHAIR (CUSHION)
USER MANUAL & INSTALLATION GUIDE
EMBRACE PRO

WARNING
This product is designed for sitting only. Do not stand on the seat.
Do not use this product unless all bolts and parts are firmly tightened.
If any parts are missing, damaged or worn, repair the product with the
replacement parts from manufacturer.
Do not sit on the armrest of this product.
This product is designed to seat only one person at a time.
Children under 10 may require assistance and supervision to use this product.
Failure to follow these instructions may result in serious injury.
Please ensure you have all the components and tools listed.
Please contact Omnidesk Customer Service if you are missing any.
PARTS
A B C I x3+1 (M8x25MM)
L x4+1 (M8x60MM)
K x6+1 (M6x30MM)
J x2+1 (M6x22MM)
N x6 (ø6x14x1.5MM)
O x7 (ø8x17x1.5MM)
P x7 (M8)
M x1
D
E F G x2 H x5
RL
2
Ix3+1（M8*40MM）
H
A B C
x5
D
EFG
R
L
J
K
x4+1（M6*22MM）
Qx1
x6+1（M6*35MM）
O
X6 (M6X14X1.2MM)
L
X3 (M8X17X1.2MM)
Mx3 (M8)

3
ASSEMBLY
Flip the base upside down and insert the
castors into the base.
STEP 1.
Insert the gas lift into the base.
STEP 2.
Tighten the aligned bolts and washers into
holes on the base using a screwdriver.
Push the handle and the mechanism
towards the arrow direction so the screw
holes are visible.
STEP 3. STEP 4.
H
F
E
K N M
G
C
C
F
E
B
G
G
K
O

ASSEMBLY
Align and tighten the bolts, spring lock
washers and washers into holes on the base
using a screwdriver.
Place three screws and corresponding
washers at the points shown below to bind
the chair back to the seat.
Place two bolts and corresponding washers
into the chair and tighten.
STEP 5. STEP 6.
STEP 7. STEP 8.
Lower the seat on to the gas lift.
M
L P O L P O
M
A
I P O
M
4
Keep the holes in the metal bar in line with
the plywood before assembling the back,
then tighten the screws that are diagonal to
each other halfway
Tighten another two screws in the metal bar.
I
M
L
Assemble the back wire control into the wire control
adapter on the upper seat frame
Step 2
Tear the tape,Insert
the wire control into
the slot
Step 3
Tighten the nut clockwise
and push the plastic part
back into the seat frame
Pull the plastic part
out of the seat
frame
Step 1
Step 4
Assembly
complete
1
2
1
2
2
1
2
1
1
2
1
2
2
1
2
1
JJ

5
ASSEMBLY
Place the headrest at the top of the seat back.
STEP 9.
B
J
FUNCTION GUIDE
Adjust the headrest angle up
to 45 degrees.
Adjust the headrest height
within a 70mm range.
Place the headrest at the top of the seat backLower the seat on to the gas lift
D
STEP 10.

Armrest pad can rotate left
and right.
Armrest pad can slide back
and forth.
Press the tabs under the
armrests to adjust them up
and down.
FUNCTION GUIDE
Pull the handle up to adjust the
seat height.
This handle controls angle of the
back of the chair.
6

7
FUNCTION GUIDE
Ais locked position.
Bis unlocked position.
60mm front and back.
Pushing the handle up allows
the seat cushion to move
forward up to 60mm.
Release the handle and the seat
is locked.
Rotate the handle clockwise to
increase the back tilt tension.
To decrease the back tilt tension,
rotate the handle
counter-clockwise.
A
B
Flip the handle clockwise to
activate the seat tilt function.
Lock in to the preferred seat
position by flipping the handle
counter-clockwise.
Stretching the lower part
of the back basket forward
can reduce the height of
the backrest

7
FUNCTION GUIDE
Ais locked position.
Bis unlocked position.
60mm front and back.
Pushing the handle up allows
the seat cushion to move
forward up to 60mm.
Release the handle and the seat
is locked.
Rotate the handle clockwise to
increase the back tilt tension.
To decrease the back tilt tension,
rotate the handle
counter-clockwise.
A
B
Flip the handle clockwise to
activate the seat tilt function.
Lock in to the preferred seat
position by flipping the handle
counter-clockwise.
When the wrench is pulled
outward, the backrest can be
adjusted at a small angle
8
Lift the backrest up to raise
the height of the backrest
90°-105°
