Ledge Surface & Support Kit - Without Cable Box (ZNFK - Shelving Depth)
Section:
Description: Page No:
Date:
Rev. No: 1
LEDGE SURFACE & SUPPORT KIT INSTALLATION - WITHOUT CABLE BOX
ENCLOSURES
May 2019 1 of 7
ZNS_104a
zones Installation Guides
NOTE: Semi-Supported Screen (ZNFWS) shown as an example.
Ledge Surface & Support Kit (ZNFK36034SN) shown as an example.
F1
H1
G1
C
B
B
C

Part and Product Identification
A1 - Ledge Surface- 17" Deep
(C07-2096)
36" Height x1
42" Height x1
Section:
Description: Page No:
Date:
Rev. No: 1
LEDGE SURFACE & SUPPORT KIT INSTALLATION - WITHOUT CABLE BOX
ENCLOSURES
May 2019 2 of 7
ZNS_104a
A2 - Ledge Surface- 15" Deep
(C07-2098)
36" Height x1
42" Height x2
LEFT
RIGHT
D- Flush Plate Kit (X06-0434)
36" Height x2
42" Height x3
* Not applicable to 16, 36, 100 sq. ft.
F2 - Cantilever Notch Cover
(A16-4608) x 1
F3 - 8-32 x 1/4 Oval
Point Hex
Socket Set Screw
(E01-1149) x4
D2 - #10 x 0.875" LG.
Screw, Quad Pin
Washer
(E07-0077) x 2
D1 - Flush Plate
(X06-0434) x 1
F4 - 1/4-20x3/4" Machine
Screw,Quad, Truss
(E01-2010) x 2
E - Structural Flush Plate
(X06-0434)
36" Height x2
42" Height x3 * Not applicable to 16 & 36 sq. ft.
E1 - District Flush Plate
(A15-7632) x 1
E2 - #10 x 0.875" LG.
Screw, Quad Pin
Washer
(E07-0077) x 12
F - Cantilever Assy. (N09-6725) x 2
F1 - Cantilever
Assembly.
(N09-6725) x 1
D3 - 1/4-20x3/4"
Machine Screw,
Quad, Truss
(E01-2010) x 2
G- Leg Assembly (N09-7104)
16, 36, 64 sq. ft. x2
100 sq. ft. x3
G1 - Leg Assembly- Shelf
(N09-7398) x 1
G3 - #10 x 0.875" LG. Screw,
Quad Pin Washer
(E07-0077) x 2 per Brkt.
G2 - Screw #8 x 5/8 LG. Flat
Quadrex HD Wood Screw
(E04-0103) x 2 per Leg plate
H- Shelf Support Cantilever Assembly (N09-7100)
16, 36, 64 sq. ft. x2
100 sq. ft. x3
H1- Cantilever Assembly-
Shelf Support
(N09-7100) x 1
36" Height 42" Height
H2 - Cantilever Notch Cover
(A16-4608) x 1 Per Cantilever
H3 - 8-32 x 1/4 Oval
Point Hex
Socket Set Screw
(E01-1149) x4
H4 - 1/4-20x3/4"
Machine Screw,
Quad, Truss
(E01-2010)
36" Height x4
42" Height x6
36" Height 42" Height
zones Installation Guides
A - Ledge Surface
16 & 36 sq. ft.
B - Ledge Surface- 17" Deep
(C07-2097) 64 & 100 sq. ft
36" Height x1
42" Height x1
C - Ledge Surface- 15" Deep
(C07-2099) 64 & 100 sq. ft.
36" Height x1
42" Height x2
LEFT
RIGHT
TOP
BOTTOM
BOTTOM
TOP

Section:
Description: Page No:
Date:
INSTALL CANTILEVERS TO SCREEN
May 2019 3 of 7
ZNS_104a
LEDGE SURFACE & SUPPORT KIT INSTALLATION - WITHOUT CABLE BOX
ENCLOSURES
STEP 1: Place the Cantilevers on Vertical Trims, one by one. Make sure Cantilevers are sitting on the top of the bottom trims. Tighten all the four set screws on the Cantilevers with allen key as
shown.
zones Installation Guides
F1
H1
F1
F3
F1
Allen
Key
F3

STEP 3: Locate the Pilot Holes and Assemble the Ledge Surfaces together with the help of
second Flush Plate with the Screws provided.
NOTE: Repeat the Step for other Ledge Surfaces if applicable.
STEP 2: Flip the Left and Right Ledge Surfaces upside down. Locate the Pilot Holes and
Assemble the Ledge surfaces together with the help of Flush Plate and screws provided.
NOTE: Repeat the Step for other Ledge Surfaces if applicable.
Section:
Description: Page No:
Date:
ASSEMBLE LEDGE SURFACES ASSEMBLE LEDGE SURFACES
ZNS_104a
4 of 7
May 2019
LEDGE SURFACE & SUPPORT KIT INSTALLATION - WITHOUT CABLE BOX
ENCLOSURES
zones Installation Guides
CPilot Holes
C
D1
D2 D3
D3
D2
D1
C
C
C
C
E2
E1
C
E2
E1
C
NOTE: Ensure that the Ledge Surface
is placed on a clean surface.

Section:
Description: Page No:
Date:
PLACE NOTCH COVERS
May 2019 5 of 7
ZNS_104a
LEDGE SURFACE AND SUPPORT KIT INSTALLATION - WITHOUT CABLE BOX
ENCLOSURES
STEP 4: Place the Notch covers on the Cantilever Brackets as shown before installing the Ledge Surfaces.
H2
F2
F2
F1
zones Installation Guides
NOTE: Notch Covers are placed only on the Top
Brackets of the Cantilever Assembly.
NOTE: Notch Covers are placed only on the Top Brackets of the Cantilever Assembly.

STEP 6: Install the Upper Ledge Surface Assembly onto the Cantilevers by using the Machine
Screws provided.
NOTE: Repeat the Step for other Ledge Surfaces if applicable.
STEP 5: Install the Bottom Ledge Surface Assembly onto the Cantilevers first by using the
Machine Screws provided.
NOTE: Repeat the Step for other Ledge Surfaces if applicable.
Section:
Description: Page No:
Date:
INSTALL LEDGE SURFACE ASSEMBLY INSTALL LEDGE SURFACE ASSEMBLY
ZNS_104a
6 of 7
May 2019
LEDGE SURFACE & SUPPORT KIT INSTALLATION - WITHOUT CABLE BOX
ENCLOSURES
C
C
C
H4
H1
H4
F4
F1
H4
B
B
B
F4
F1
H1
H4
H1
zones Installation Guides

Section:
Description: Page No:
Date:
INSTALL LEG ASSEMBLY
May 2019 7 of 7
ZNS_104a
LEDGE SURFACE & SUPPORT KIT INSTALLATION - WITHOUT CABLE BOX
ENCLOSURES
STEP 7: Install the Leg Assembly to the Ledge Surfaces by locating the Pilot Holes as shown. Fasten the Leg Assembly to the Ledge Surface Assemblies by using the Screws provided.
NOTE: When installing Leg Assembly, #8 Wood Screws (G2) are used only for the Top Ledge Surface & #10 Wood Screws (G3) are used for the Bottom Ledge Surfaces.
zones Installation Guides
G1 G3
G2
G1
G3
G2
Pilot Holes
Pilot Holes
Pilot Holes
Pilot
Holes
NOTE: When installing Leg Assembly, #8 Wood Screws (G2)
are used only for the Top Ledge Surface & #10 Wood
Screws (G3) are used for the Bottom Ledge Surfaces.
