Multay Mistral MST01 User manual

Thank you for buying our product
PRE-ASSEMBLY PREPARATION
1.Please check the pack contents before attempting this product.
A full checklist of component is given in this leaflet. If any component are missing, please contact
the retailer from whom you bought this product.
2.This product is , it should be assembled as near as possible to the point of use.
TAKE CARE WITH LIFTING to avoid personal in jury and (or) damage to the product.
3.This product takes approximately 45 minutes to assemble with 2 people.
4.This product already contain fitting which should be :
“ KEPT AWAY FROM YOUNG CHILDREN “
5.Read this leaflet in full before commencing assembly.
heavy
Step By Step Assembly Instructions
Mistral Bed 151cm / 181 cm
( MST01 )
Assembly Instruction

HARDWARE IDENTIFICATION
ITEM DESCRIPTION Qty
A
B
C
HEADBOARD
FOOTBOARD
SIDE RAILS
2
1
1
DSLATS 42
ESLATS SUPPORT 1
FBOLT CONNECTING RAIL (Embedded in side rail) 8
HEADBOARD
SLAT
SIDE RAIL
SLAT SUPPORT
FOOTBOARD
BOLT
CONNECTING RAILS
Mistral Bed 151cm / 181 cm
( MST01 )
Assembly Instruction

Step - Remove Bolt Connecting rail from the Side Rail by hand.
1
Fitting : Threaded Bolt
Step - Locate the side rails onto the threaded bolt protruding from the Headboard.
Locate round washer and nut onto the threaded bolt and secure by hand at first.
Tighten evenly using the open end spanner (Not provided)
2
THREADED BOLT
ROUND WASHER
NUT
SPANNER
BOLT
CONNECTING RAILS
- Screw the eight threaded bolt into the Headboard an Footboard then tighten by hand.
Mistral Bed 151cm / 181 cm
( MST01 )
Assembly Instruction

Step - Locate the side rails onto the threaded bolt protruding from the Footboard.
Locate round washer and nut onto the threaded bolt and secure by hand at first.
Tighten evenly using the open end spanner (Not provided)
3
Step - Locate the Slat Support into the wooden brackets.
4
SLAT SUPPORT
Mistral Bed 151cm / 181 cm
( MST01 )
Assembly Instruction

Step - Locate the Slats onto side rail cleat then push fit the plastic cup slat onto either holes
of the Side Rails and Slat support. Repeat this step with the other slat holes.
The assembly in now complete.
5
SLAT
PLASTIC CAP
SLAT (Wooden)
