Behringer EUROLIGHT LD6230 User manual

Version 1.1 October 2003
Users Manual
ENGLISH
EUROLIGHT LD6230

2
EUROLIGHT LD6230
This symbol, wherever it appears, alerts you to the
presence of uninsulated dangerous voltage inside
the enclosurevoltage that may be sufficient to
constitute a risk of shock.
This symbol, wherever it appears, alerts you to
important operating and maintenance instructions
in the accompanying literature. Please read the
manual.
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: The units installation and initial operation must be
done under the supervision of a qualified
professional (see NSTALLAT ON NSTRUCT ONS).
To reduce the risk of electric shock, do not remove
the top cover (or the rear section). No user
serviceable parts inside; refer servicing to qualified
personnel.
WARNING: To reduce the risk of fire or electric shock, do not
expose this appliance to rain and moisture.
DETAILED SAFETY INSTRUCTIONS:
1) Read these instructi ns.
2) Keep these instructi ns.
3) Heed all warnings.
4) F ll w all instructi ns.
5) D n t use this device near water.
6) Clean nly with a dry cl th.
7) D n t bl ck any ventilati n penings. Install in
acc rdance with the manufacturers instructi ns.
8) D n t install near any heat s urces such as radiat rs,
heat registers, st ves, r ther apparatus (including
amplifiers) that pr duce heat.
9) D n t defeat the safety purp se f the p larized r
gr unding-type plug. A p larized plug has tw blades
with ne wider than the ther. A gr unding type plug
has tw blades and a third gr unding pr ng. The wide
blade r the third pr ng are pr vided f r y ur safety. If
the pr vided plug d es n t fit int y ur utlet, c nsult
an electrician f r replacement f the bs lete utlet.
10) Pr tect the p wer c rd fr m being walked n r
pinched particularly at plugs, extensi n c rds, and the
p int at which they exit the unit.
11) Only use attachments/access ries specified by the
manufacturer.
12) Use nly with the cart, stand, trip d, bracket, r table
specified by the manufacturer, r s ld with the device.
When a cart is used, use cauti n when m ving the cart/
device c mbinati n t av id injury fr m stumbling ver
it.
13) Unplug this device during lightning st rms r when
n t used f r l ng peri ds f time.
14) Refer all servicing t qualified service pers nnel.
Servicing is required when the unit has been damaged
in any way, such as p wer supply c rd r plug is
damaged, liquid has been spilled r bjects have fallen
int the device, the unit has been exp sed t rain r
m isture, d es n t perate n rmally, r has been
dr pped.

3
EUROLIGHT LD6230
LD6230
EUROLIGHT
Professional 6-channel DMX/analog controlled di er pack
s6-channel DMX/analog controlled dimmer pack ith up to 10 A output per channel
s3-phase mains supply (1 phase possible at lo er output po er)
sDMX512 standard interface for digital control
sAdditional 8-pole DIN connector for analog control (0 - 10 V)
sAdjustable preheat and limiter function to prolong bulb life
sPrecise curve function enables selection of different fade modes
sS itch option for simple on/off control of each channel
sAutomatic digital input check to detect DMX signal errors
sManual mode for dimming capability ithout an external lighting console
sAuto store function saves all settings after leaving configuration mode
s3-digit display and dedicated control LEDs for better indication in dark environment
sHARTING® and CEE connection options (connectors not included)
sUltra-rugged construction ensures long life, even under the most demanding conditions
sDesigned in Germany. Manufactured under ISO9000 certified management system

4
EUROLIGHT LD6230
TABLE OF CONTENTS
1. INTRODUCTION ......................................................... 5
1.1 Before you get started ................................................... 5
1.1.1 Shipment ............................................................... 5
1.1.2 nitial operation ...................................................... 5
1.1.3 Rack installation .................................................... 5
1.1.4 Warranty .............................................................. 5
1.2 The users manual .......................................................... 5
2. CONTROL ELEMENTS ............................................... 6
2.1 Configuration mode ........................................................ 7
2.1.1 ADDRESS ............................................................. 7
2.1.2 ASS GN ................................................................ 7
2.1.3 PREHEAT .............................................................. 7
2.1.4 L M TER ................................................................. 7
2.1.5 CURVE .................................................................. 7
2.2 DMX mode ....................................................................... 7
2.2.1 DMX512 ................................................................ 8
2.3 ANALOG mode ............................................................... 8
2.4 MANUAL mode ............................................................... 8
3. APPLICATIONS .......................................................... 8
4. INSTALLATION AND INITIAL OPERATION ................. 9
4.1 Digital DMX connector .................................................... 9
4.2 Analog connector ........................................................... 9
4.3 EEP (eprom check) ......................................................... 9
4.4 Phase allocation ............................................................. 9
5. SPECIFICATIONS ....................................................... 9
6. WARRANTY .............................................................. 10
FOREWORD
Dear customer,
welcome to the team of
BEHR NGER users, and
thank you very much for
expressing your confi-
dence in us by pur-
chasing the EUROL GHT
LD6230.
Writing this foreword
for you gives me great
pleasure, because it
represents the culmi-
nation of many months
of hard work delivered
by our engineering team
to achieve a very ambi-
tious goal: to present an
outstanding dimmer pack
whose flexibility makes
it ideally suited for con-
cert and theatre applications as well as film and TV productions.
The task of designing the new LD6230 certainly meant a great
deal of responsibility, which we assumed by focusing on you,
the discerning user and musician. Meeting your expectations
also meant a lot of work and night shifts. But it was fun, too.
Developing a product usually brings a lot of people together, and
what a great feeling it is when all who participated in such a
project can be proud of what theyve achieved.
t is our philosophy to share our enjoyment with you, because
you are the most important member of the BEHR NGER team.
With your highly competent suggestions for new products youve
made a significant contribution to shaping our company and making
it successful. n return, we guarantee you uncompromising quality
as well as excellent technical and audio properties at an extremely
reasonable price. All of this will enable you to give free rein to
your creativity without being hampered by budget constraints.
We are often asked how we manage to produce such high-
quality devices at such unbelievably low prices. The answer is
quite simple: its you, our customers! Many satisfied customers
mean large sales volumes enabling us to get better purchasing
terms for components, etc. snt it only fair to pass this benefit on
to you? Because we know that your success is our success
too!
would like to thank all of you who have made the EUROL GHT
LD6230 possible. You have all made your own personal
contributions, from the developers to the many other employees
at this company, and to you, the BEHR NGER user.
My friends, its been worth the effort!
Thank you very much,
Uli Behringer

5
EUROLIGHT LD6230
1. INTRODUCTION
1. INTRODUCTION
As a BEHR NGER EUROL GHT LD6230 owner, you have a high-
end dimmer pack at your hands. t was designed to answer to
the high demands of lighting professionals working in television,
theatres and live events, and is therefore universally applicable.
The EUROL GHT LD6230 provides all necessary features for
controlling your light show, yet it is clearly laid out and easy to
use. t gives you the choice between analog and digital DMX
control. Comprehensive LEDs let you easily detect signal problems
so you can effortlessly eliminate them as soon as they occur.
+The f ll wing users manual is intended t
familiarize y u with the units c ntr l elements, s
that y u can master all the functi ns. After having
th r ughly read the users manual, st re it at a safe
place f r future reference. INSTALLATION
INSTRUCTIONS supplement the users manual and
are included in the shipment.
+A qualified pr fessi nal needs t be present during
the units installati n and initial perati n. M re
inf rmati n ab ut this t pic is c vered under
INSTALLATION INSTRUCTIONS.
1.1 Before you get started
1.1.1 Ship ent
The LD6230 was carefully packed at the assembly plant to
assure secure transport. Should the condition of the cardboard
box suggest that damage may have occurred please inspect the
unit immediately and look for physical indications of damage.
+Damaged units sh uld NEVER be sent directly t us.
Please inf rm the dealer fr m wh m y u acquired
the unit immediately as well as the transp rtati n
c mpany fr m which y u t k delivery. Otherwise,
all claims f r replacement/repair may be rendered
invalid.
1.1.2 Initial operation
Please make sure the unit is provided with sufficient ventilation,
and never place the EUROL GHT on top of an amplifier or in the
vicinity of a heater to avoid the risk of overheating.
+Please make sure that the unit is gr unded at all
times. F r y ur wn pr tecti n, y u sh uld never
tamper with the gr unding f the cable r the unit
itself.
+T av id damage t y ur equipment, always make
sure y ur dimmer pack is disc nnected fr m the
mains bef re y u c nnect r disc nnect sp tlights
r ther lighting paraphernalia.
+Make sure that nly sufficiently qualified pers ns
install and perate y ur LD6230. T av id damage r
altering f its perf rmance thr ugh electr static
discharge, make sure that all pe ple handling the
LD6230 are pr perly gr unded b th during and after
the installati n.
1.1.3 Rack installation
The LD6230 requires two height units (2 HU) when installed in
a 19-inch rack. Please make sure to leave an extra 4 inches
(10 cm) of space behind the unit for wiring.
Please use M6 machine screws and nuts to install your LD6230
into a rack.
1.1.4 Warranty
Please take a few minutes and send us the completely filled
out warranty card within 14 days of the date of purchase. You
may also register online at www.behringer.com. The serial
number of your EUROL GHT LD6230 ( ) needed for registration
is located at the rear panel of the unit. Failure to register your
product may void future warranty claims.
1.2 The users manual
The users manual is designed to give you both an overview
of the controls, as well as detailed information on how to use
them. n order to help you understand the links between the
controls, we have arranged them in groups according to their
function. f you need to know more about specific issues, please
visit our website at http://www.behringer.com.

6
EUROLIGHT LD6230
2. CONTROL ELEMENTS
When your LD6230 works in DMX mode, use the 5-pole
DMX512 IN-XLR connector to connect DMX512 control
signals (see ch. 2.2 DMX mode and ch. 4.1 Digital DMX
connector).
You can relay the DMX control signal to additional dimmer
packs by using the 5-pole DMX512 OUT XLR connector. f
the dimmer is at the terminal end of a DMX chain, place a
terminator at the DMX output of the dimmer pack to avoid
signal bounce (use a terminator with the resistance of 120 Ω
between pins 2 and 3).
You can connect an analog 0 - 10 V control signal to the
8-pole ANALOG IN D N connector (see ch. 2.3 ANALOG
mode and ch. 4.2 Analog connector).
This is the cable slot for connecting your lighting equipment
(see NSTALLAT ON NSTRUCT ONS).
This is the cable slot for the power supply (see
NSTALLAT ON NSTRUCT ONS).
The cooling fan is located here.
SERIAL NUMBER. Please take a few minutes and send us
the completely filled out warranty card within 14 days of
the date of purchase. Otherwise, warranty claims may be
rendered invalid. You may also register online at
www.behringer.com.
Fig. 2.2: EUROLIGHT LD6230s r ar pan l
Ventilation openings are located on the front panel. Their
position at the front assures that hot air does not enter the
inside of your rack, causing equipment failure or damage.
+T ensure that y ur dimmer pack runs sm thly
even under full l ad, y u have t make sure that
there is en ugh distance t ther heat-emitting
equipment.
There is an automated fuse for each of the six dimmer
circles. These fuses engage in the event of overload or
short circuit.
Use the CHANNEL key to shift between the six dimmer
channels. When used in combination with the CONF G key
(see ), you can select different operating modes (DMX,
ANALOG and MANUAL).
Use the UP and DOWN keys to navigate through individual
menus.
The CONFIG key is used to activate the configuration
mode (see ch. 2.1) and to select individual menus. When
used in combination with the CHANNEL key (see ), you
can select different operating modes.
The LEDs to the left of the display have two purposes:
supply phase status indication (L1, L2 und L3) and indication
of the operating mode you selected (DMX, ANALOG and
MANUAL).
The 3-digit DISPLAY shows the values to be edited.
The LEDs to the right of the display relate to the individual
menus in the configuration mode. Depending on the selected
function, the corresponding LED lights up.
2. CONTROL ELEMENTS
Various LD6230 control elements are described in this chapter. All controls and connectors are described in detail, and you also
get useful advice on how to use them in different applications.
Fig. 2.1: EUROLIGHT LD6230s front pan l

7
EUROLIGHT LD6230
2. CONTROL ELEMENTS
2.1 Configuration mode
The important pre adjustments necessary for running the
dimmer pack are done in the configuration mode. Keeping the
CONFIG key pressed for roughly two seconds gets you into
the configuration menu. Once you are in the configuration mode,
keep using the CONF G key to navigate through individual
functions, which are indicated with their respective LEDs located
to the right of the display. To get out of the configuration mode,
keep the CONF G pressed again for roughly two seconds.
+All adjustments made in c nfigurati n m de are
aut matically st red when y u exit, and remain
st red even when y u p wer the LD6230 n r ff.
2.1.1 ADDRESS
As soon as you get to the configuration mode, the ADDRESS
LED lights up. n this menu, you assign DMX basic channels (1 to
507) to the six dimmer channels. This address determines the
DMX channel at which control commands are executed. Since
you are dealing with a 6-channel dimmer, a maximum of six
consecutive DMX channels can be interpreted as control signals,
depending on the assignments in the ASS GN menu (see ch.
2.1.2). f the start address value is 001, then the dimmer reacts
to the first six channels of the DMX data stream. f you, for
example, set the start address value to 024, then the dimmer
reacts to the channels 024 to 029 correspondingly. f several
units use the same DMX address, then they also receive the
same control commands.
To select the desired DMX channels, use the UP and DOWN
keys. When you keep one of these keys pressed while tapping
the other one simultaneously, this lets you navigate through the
channels in increments of 10 channels at a time.
2.1.2 ASSIGN
When you press the CONF G key once again, you get to the
ASS GN menu (ASSIGN LED lights up). n this menu you can
make four different input channel/dimmer channel assignments.
Possible configurations:
1-6: All six outputs are dependent on the setting of channel 1.
2-3: Outputs 1-3 are dependent on the setting of channel 1,
and outputs 4-6 are dependent on the setting of channel 2.
3-2: Outputs 1 and 2 are dependent on the setting of channel 1,
outputs 3 and 4 are dependent on the setting of channel 2,
and outputs 5 and 6 are dependent on the setting of
channel 3.
6-1: All six outputs are separately dependent on the
respective six channels (1-6).
f you select one of the first three configuration options, you can
for example form headlight groups that reproduce the same
identical program since they are controlled through just one
channel.
After you address DMX channels and assign input and dimmer
channels, you should check if each dimmer circle reacts to the
desired DMX control signal by moving the corresponding faders
on the lighting console.
2.1.3 PREHEAT
When you press the CONF G key once again, you get to the
PREHEAT menu (the PREHEAT LED lights up). Use the UP and
DOWN keys to enter the preheat value (0 to 15). This preheat
value is then continuously run to the headlights, thus lowering
the start-up current requirement and prolonging filament life. The
preheat value you enter is valid for all six channels. However,
the PREHEAT function cann t be used in switch mode (see ch.
2.1.5).
2.1.4 LIMITER
When you press the CONF G key once again, you get to the
L M TER menu (the LIMITER LED lights up). Use the CONF G key
to navigate through all six channels. Here you can set the upper
limit for the control signal of each individual channel. Set the
threshold value (16 to 99) by using the UP and DOWN keys. The
L M TER function too prolongs the life of your light equipment.
Limiting the upper range of control voltage protects from voltage
oscillations and overdrive.
2.1.5 CURVE
When you press the CONF G key once again, you get to the
CURVE menu (the CURVE LED lights up). There are five possible
ways to set up the transmission characteristic of your dimmer
pack. You can determine how control voltage (i.e. fader
movement on the mixing console) is transmitted to the lighting
equipment. Step through the six channels indicated on the left-
hand digit on the display by pressing the CONF G key. Define the
transmission characteristic for each channel separately by using
the UP key.
LINEAR (L):
This transmission characteristic linearly increases or decreases
control voltages in all segments of fader movement. When you
move a fader on the lighting console, the headlight intensity
changes directly proportionate to the fader movement.
EXPONENTIAL ( 1):
n this case, the transmission curve is irregular. When you
move the fader on the lighting console uniformly upwards, the
voltage in the lower third of the faders range of movement
increases linearly, whereas the transmission characteristic
beyond the first third of the faders range of motion becomes
more pronouncedly (exponentially) progressive with each
increment of fader motion.
LOGARITHMIC ( 2):
This transmission characteristic is also irregular. n the upper
third of the faders range of motion the voltage changes linearly,
whereas the transmission characteristic in the lower two thirds
gets more pronouncedly degressive with each increment of fader
motion. The logarithmic transmission curve is the opposite of the
exponential curve.
SWITCH OPERATION (US = Unlimited Switch):
n this mode you can use the dimmer circle as a switch. This
way, you can use your LD6230 to control fog machines, motors
and various other effects. When the control voltage reaches
50% or more of a previously specified value, the channel is
switched on. When the control voltage falls below 50%, the
channel is switched off again. L M TER and PREHEAT functions
cann t be used in this mode.
SWITCH OPERATION (LS = Limited Switch):
n SW TCH OPERAT ON (LS) the limiter function can be used.
+Transmissi n curves can be separately adjusted
f r each individual channel n the EUROLIGHT LD6230.
2.2 DMX mode
Your LD6230 is automatically in DMX mode as soon as the
power is up (DMX LED lights up). Navigate through different
modes by using the CHANNEL key while simultaneously pressing
the CONF G key. Your LD6230 receives the DMX signal via the
DMX512 N connector, and this signal can be forwarded to
additional dimmer packs using the DMX512 OUT connector in
order to process additional channels. DMX512 N and DMX512
OUT are 5-pole XLR connectors and are located on the rear
panel.

8
EUROLIGHT LD6230
3. APPLICATIONS
2.2.1 DMX512
Data transmission in the field of lighting equipment refers to
transmitting control information from the lighting console via the
dimmer to the headlights, scanners and similar equipment. This
process takes place by using the digital DMX512 control signal
that was developed at the US TT (United States nstitute for
Theatre Technology). nformation is no longer represented through
analog voltage values; instead, digital data sets are used. n
contrast to analog data transmission, digital signals can simply
be patched together: each piece of information has an address
to which it belongs. Additionally, the following goes for digital
signals: when they arrive at their destination, they have the
correct value since there is no loss of quality associated with
analog signals.
Of course, problems may arise here as well. Very often, the
reason for faulty transmissions lies in deploying wrong
connectors or connectors other than those prescribed by the
norm. Using wrong cables also may lead to faulty data
transmission. We therefore only recommend using cables that
are intended for use with digital audio technology.
The DMX standard contains 512 digital light channels that are
controlled using a common data cable. However, a maximum of
32 different pieces of equipment can be connected to any one
cable since the cable at some point becomes overburdened
(due to shared controlling of all end equipment). Still, each piece
of equipment can evaluate as much data as you wish. To connect
additional pieces of equipment, you need a so-called splitter or a
booster to amplify or to regenerate the DMX signal.
DMX512 is a compatible norm and requires only one data cable
since all signal recipients are freely addressable, so you avoid
having cable salad issues. Once all pieces of equipment are
correctly connected and addressed, a DMX system typically
works completely trouble-free.
2.3 ANAL G mode
n addition to the digital DMX mode, your EUROL GHT LD6230
dimmer pack also lets you work in ANALOG mode. You get to
this mode by pressing the MODE key while the CONF G key is
pressed (the ANALOG LED lights up). The analog control signal
(0 - 10 V) is transfered to the dimmer pack via an 8-pole D N
connector located on the rear panel. This way, you can use the
LD6230 with analog control equipment.
n ANALOG mode, each dimmer channel has a control cable
(or a core pair) of its own. The control signal runs through this
cable. The output voltage of the dimmer is proportionate to the
control cable signal. As a rule, 0% is represented by a voltage of
0 V, 50% is represented by a voltage of 5 V and 100% is
represented by a voltage of 10 V.
+When the dimmer pack receives a zer signal level
at the input end, the utput signal level sh uld
c rresp ndingly be at its minimum. When the
dimmer pack receives a maximum signal level at
the input end, the utput signal level sh uld be at
its maximum.
2.4 MANUAL mode
To power up your lighting equipment, the EUROL GHT dimmer
pack can be used even without an external lighting console
when in MANUAL mode (MANUAL LED lights up). n this mode,
all settings are automatically saved every two seconds and can
be recalled even after powering the LD6230 off and then on
again. As with other operating modes, you get to MANUAL mode
by pressing the CHANNEL key while the CONF G key is kept
pressed.
The left display digit indicates the channel selected with the
CHANNEL key. The next two digits to its right indicate the level of
the control signal, with values from 0 to 99. Use the UP and
DOWN keys to adjust the control signal value.
3. APPLICATIONS
Lighting equipment is an integral part of almost every
performance event and venue. Be it concerts, theatre or musical
acts, clubs or even presentations and exhibits, they all benefit
from good visuals in order to leave a lasting impression on the
audience.
n general, lighting either creates a certain feeling or emphasizes
the mood created through music or dramaturgic composition.
Creating a lighting setup is a demanding and creative endeavour,
since it is much more than merely making a set of lights go on and
off. To do this, you need a dependable, multi-functional set of
tools. The EUROL GHT LD6230 offers a maximum on functionality
and is the perfect expansion for a lighting console, preferably
the BEHR NGER EUROL GHT LC2412.
Thanks to digital DMX controlling, using multiple dimmer packs
lets you implement demanding lighting setups, since you can
control up to 32 components with only one DMX connection.
These components dont necessarily have to be headlights; in
switch mode, you can also control fog machines, pyrotechnic
equipment or motors. This makes the LD6230 much more than
just a piece of lighting equipment.
The following illustration shows a connection example with
two EUROL GHT LD6230s, a BEHR NGER EUROL GHT LC2412
and BEHR NGER ULTRAPAR UP1000 headlights, whereby 12
light channels can be run. The first dimmer pack is controlled
with the digital DMX control signal, the second one with an analog
signal. f both dimmer packs are controlled with the DMX control
signal, the second dimmer pack needs to receive the control
signal via the first dimmer pack:
Fig. 3.1: Conn ction xampl with th EUROLIGHT LC2412
and th ULTRAPAR UP1000 h adlights
f you need more light channels, connect extra dimmer packs
for processing your control signals.

9
EUROLIGHT LD6230
5. SPECIFICATIONS
4. CONNECTORS AND INITIAL
OPERATION
4.1 Digital DMX connector
The DMX512 N and DMX512 OUT connectors are made in
accordance with the international DMX512 standard. 5-pole XLR
connectors are used, whereby controllers and DMX senders
feature female connectors, while receiver equipment such as
dimmer packs feature male connectors.
Fig. 4.1: Pin assignm nt of a 5-pin XLR conn ctor
You should stick to the pin assignment shown in above
illustration even when two reserve pins 4 and 5 are used for a
second connection (a separate sender and receiver unit).
Often, 3-pole XLR connectors are also used for transmitting
digital control signals, since these connectors simplify using the
wiring already at the users disposal and are also less expensive
than 5-pole connectors. However, these connectors are
substandard and may not carry the DMX512 insignia.
4.2 Analog connector
An 8-pole D N connector is used as the input connection for an
analog control signal (0-10 V).
3,1 &+$11(/
11
22
33
44
55
66
7NC
8 GROUND
Tab. 4.1: Pin assignm nt of an 8-pin DIN conn ctor
4.3 EEP (eprom check)
An eprom (Erasable Programmable Read Only Memory) is an
electronic device that contains programs or data needed to
operate a piece of equipment. Once you burn data onto an
eprom, it cant get lost, even when you power down your
equipment.
During the power-up procedure of your LD6230, the eprom is
checked, that is, the LD6230 looks for false values (plausibility
control). f irregularities occur during the eprom initialisation,
factory default values are loaded.
+T erase the c ntents f the epr m and l ad fact ry
defaults, keep b th middle keys (UP and DOWN)
pressed while p wering up y ur LD6230.
4.4 Phase allocation
The LEDs L1, L2 and L3 ( ) indicate phase condition. L1
refers to channels 1 and 2, L2 refers to channels 3 and 4, and L3
refers to channels 5 and 6. The LEDs show if correct voltage is
applied to your EUROL GHT LD6230. f the voltage is not correct
(i.e. too high or too low), the corresponding LED(s) begin to blink.
Since the dimmers circuitry is powered by all three phases, the
dimmer remains functioning even if two out of three phases
malfunction. However, to guarantee trouble-free operation,
always attempt to correct phase problems as soon as they are
discovered.
5. SPECIFICATIONS
Channels
Number 6
Load per channel 0.2 A min./10 A max.
Maximal load per channel 10 A using a 3-phase connector
Frequency 50/60 Hz
Inputs
Power supply 3-phase connector, internal
terminal block/PG cable screw
joint, CEE connector (optional
installation by qualified
professional)
Analog 0 to +10 V via 8-pin D N
Digital DMX512 via 5-pin XLR
Outputs
Digital DMX512 via 5-pin XLR
Load nternal terminal block/PG cable
screw joint, HART NG® (optional
installation by qualified
professional)
System fuses
Load securing per channel 10 A cable protection switch
(type C)
Control section fuse 2 x T 100 mA H/250 V (EU)
1 x T 160 mA H/250 V (EU)
2 x T 160 mA H/250 V (UL)
1 x T 315 mA H/250 V (UL)
P wer supply
Voltage USA/Canada
120 V~, 60 Hz
Europe/U.K./Australia
240 V~, 50 Hz
Maximum power consumption 3 x 20 A
Dimensi ns/Weight
Dimensions (H x W x D) approx. 3 1/3" (84.3 mm)
x 19" (482.6 mm)
x 15 9/10" (403.8 mm)
Weight approx. 20.3 lbs. (9.2 kg)
BEHRINGER continuously strives to assure the highest quality standards
possible. Required modifications may be implemented without prior notice.
echnical data and the appearance of the unit may deviate from the above
values and/or illustrations.

10
EUROLIGHT LD6230
6. WARRANTY
The information contained in this manual is subject to change without notice. No part of this manual may be reproduced or
transmitted in any form or by any means, electronic or mechanical, including photocopying and recording of any kind, for any
purpose, without the express written permission of BEHR NGER Spezielle Studiotechnik GmbH.
BEHR NGER is a registered trademark. HART NG® is a registered trademark of the respective owner, which is in no way
associated or affiliated with BEHR NGER. ALL R GHTS RESERVED. © 2003 BEHR NGER Spezielle Studiotechnik GmbH.
BEHR NGER Spezielle Studiotechnik GmbH, Hanns-Martin-Schleyer-Str. 36-38, 47877 Willich-Münchheide , Germany
Tel. [phone], Fax [phone]
6. WARRANTY
§ 1 WARRANTY CARD/ONLINE REGISTRATION
To be protected by the extended warranty, the buyer must
complete and return the enclosed warranty card within 14 days
of the date of purchase to BEHR NGER Spezielle Studiotechnik
GmbH, in accordance with the conditions stipulated in § 3. Failure
to return the card in due time (date as per postmark) will void any
extended warranty claims. Based on the conditions herein, the
buyer may also choose to use the online registration option via
the nternet (www.behringer.com or www.behringer.de).
§ 2 WARRANTY
1. BEHR NGER (BEHR NGER Spezielle Studiotechnik GmbH
including all BEHR NGER subsidiaries listed on the enclosed page,
except BEHR NGER Japan) warrants the mechanical and
electronic components of this product to be free of defects in
material and workmanship for a period of one (1) year* from the
original date of purchase, in accordance with the warranty
regulations described below. f the product shows any defects
within the specified warranty period that are not excluded from
this warranty as described under § 4, BEHR NGER shall, at its
discretion, either replace or repair the product using suitable
new or reconditioned parts. n the case that other parts are used
which constitute an improvement, BEHR NGER may, at its
discretion, charge the customer for the additional cost of these
parts.
2. f the warranty claim proves to be justified, the product will
be returned to the user freight prepaid.
3. Warranty claims other than those indicated above are
expressly excluded.
§ 3 RETURN AUTHORIZATION NUMBER
1. To obtain warranty service, the buyer (or his authorized
dealer) must call BEHR NGER (see enclosed list) during normal
business hours BEFORE returning the product. All inquiries must
be accompanied by a description of the problem. BEHR NGER
will then issue a return authorization number.
2. Subsequently, the product must be returned in its original
shipping carton, together with the return authorization number to
the address indicated by BEHR NGER.
3. Shipments without freight prepaid will not be accepted.
§ 4 WARRANTY REGULATIONS
1. Warranty services will be furnished only if the product is
accompanied by a copy of the original retail dealers invoice.
Any product deemed eligible for repair or replacement under the
terms of this warranty will be repaired or replaced.
2. f the product needs to be modified or adapted in order to
comply with applicable technical or safety standards on a national
or local level, in any country which is not the country for which
the product was originally developed and manufactured, this
modification/adaptation shall not be considered a defect in
materials or workmanship. The warranty does not cover any
such modification/adaptation, irrespective of whether it was
carried out properly or not. Under the terms of this warranty,
BEHR NGER shall not be held responsible for any cost resulting
from such a modification/adaptation.
3. Free inspections and maintenance/repair work are expressly
excluded from this warranty, in particular, if caused by improper
handling of the product by the user. This also applies to defects
caused by normal wear and tear, in particular, of faders,
crossfaders, potentiometers, keys/buttons, tubes and similar
parts.
4. Damages/defects caused by the following conditions are
not covered by this warranty:
simproper handling, neglect or failure to operate the unit in
compliance with the instructions given in BEHR NGER user
or service manuals.
sconnection or operation of the unit in any way that does not
comply with the technical or safety regulations applicable in
the country where the product is used.
sdamages/defects caused by force majeure or any other
condition that is beyond the control of BEHR NGER.
5. Any repair or opening of the unit carried out by unauthorized
personnel (user included) will void the warranty.
6. f an inspection of the product by BEHR NGER shows that
the defect in question is not covered by the warranty, the
inspection costs are payable by the customer.
7. Products which do not meet the terms of this warranty will
be repaired exclusively at the buyers expense. BEHR NGER will
inform the buyer of any such circumstance. f the buyer fails to
submit a written repair order within 6 weeks after notification,
BEHR NGER will return the unit C.O.D. with a separate invoice
for freight and packing. Such costs will also be invoiced
separately when the buyer has sent in a written repair order.
§ 5 WARRANTY TRANSFERABILITY
This warranty is extended exclusively to the original buyer
(customer of retail dealer) and is not transferable to anyone
who may subsequently purchase this product. No other person
(retail dealer, etc.) shall be entitled to give any warranty promise
on behalf of BEHR NGER.
§ 6 CLAIM FOR DAMAGES
Failure of BEHR NGER to provide proper warranty service shall
not entitle the buyer to claim (consequential) damages. n no
event shall the liability of BEHR NGER exceed the invoiced value
of the product.
§ 7 OTHER WARRANTY RIGHTS AND NATIONAL LAW
1. This warranty does not exclude or limit the buyers statutory
rights provided by national law, in particular, any such rights
against the seller that arise from a legally effective purchase
contract.
2. The warranty regulations mentioned herein are applicable
unless they constitute an infringement of national warranty law.
* Customers in the European Union please contact BEHR NGER
Germany Support for further details.
