Behringer ULTRALINK ulm300USB User manual

Quick Start Guide
ULTRALINK ULM300USB
High-Performance 2.4 GHz Digital Wireless
System with Handheld Microphone and
Dual-Mode USB Receiver

ULTRALINK ULM300USB
Hook-Up
XENYX QX2442USB
Laptop
B115MP3

ULTRALINK ULM300USB Controls
Type of product: Wireless Microphone
ULM300USB Controls
1. USB connector
2. POWER/STATUS LED
3. VOLUME UP Button (—Power on/-Volume up/-Unmute)
4. VOLUME DOWN Button (-Volume down/—Mute/
—Power o from Mute)
NOTE:“—” (long dash) = long press; “-” (hyphen) = short press.
LED Status Key
The following table describes LED behavior on both the microphone and
the USB wireless receiver:
Activity LED Color LED Behavior
No Signal Amber Flashes on/o slowly
Connected, Active Green Solid
Connected, Muted Green Flashes on/o quickly
Connected, Active,
Low Battery Green/Red Alternating colors
Connected, Muted,
Low Battery Green/Red Alternating colors, ashes on/o
ULM300USB Getting Started
1. Plug the USB wireless receiver to the designated USB socket on
wireless-enabled BEHRINGER mixers, powered speakers or other
compatible products, or to a USB port on a computer. The POWER/
STATUS LED on the receiver will slowly ash amber.
2. Press and hold the VOLUME UP button on the wireless microphone
to switch it on and commence transmission. Both the LEDs on the
wireless microphone and USB wireless receiver will light solid green
once connected.
3. Once switched on, the wireless microphone will be set at its previous
operating volume level. Use the VOLUME UP and VOLUME DOWN
buttons to adjust the volume.
4. A long press of the VOLUME DOWN button will put the wireless
microphone into mute. The mute condition is indicated by rapid
green ashing of the LED. If the user does not unmute within
10 minutes, the wireless microphone will power down to save
battery life.
5. A further long press of the VOLUME DOWN button when in mute will
switch o the wireless microphone.
6. A short press of the VOLUME UP button will unmute the wireless
microphone. When the wireless microphone is unmuted, it will
return to the previous volume level.
NOTE: The connection range between speaker and Bluetooth streaming
device may decrease if Bluetooth streaming and wireless microphones are
used simultaneously.
(2)
(3)
(4)
(2) (1)
Model: ULM300D
Model: ULM300M

Specication
RF output < 10 dBm (10 mW)
Operating range 60 m (200 ft)*
Dynamic range 93 dB, A-weighted**
Equivalent input noise -120 dBu
Frequency response 10 Hz – 20 kHz, ±1 dB**
(wireless link)
Sampling rate 48 kHz
Resolution 24-bit
Encoding 4-bit ADPCM (192 kbps)
Latency 14.3 ms
RF frequency 2.4 GHz ISM band
(2.404~2.468 GHz,
17 channels)
USB current consumption 70 mA @ 5 VDC
Battery type 2 x AA (LR6)
Alkaline cells
Battery life > 24 hrs
Dimensions (H x W x D)
Microphone 260 x 53 x 53 mm
(10.2 x 2.1 x 2.1")
Wireless receiver 8.5 x 76 x 22 mm
(0.3 x 3.0 x 0.9")
Weight
Microphone 0.3 kg (0.7 lbs)
Wireless receiver 0.01 kg (0.02 lbs)
*Achievable range will be dependent on nearby sources of RF interference and/or
line of sight obstacles.
**Measured from analog input to analog output at maximum level.

LEGAL DISCLAIMER
MUSIC Group accepts no liability for any loss which may be
suered by any person who relies either wholly or in part upon
any description, photograph, or statement contained herein.
Technical specications, appearances and other information are
subject to change without notice. All trademarks are the property
of their respective owners. MIDAS, KLARK TEKNIK, LAB GRUPPEN,
LAKE, TANNOY, TURBOSOUND, TC ELECTRONIC, TC HELICON,
BEHRINGER, BUGERA and DDA are trademarks or registered
trademarks of MUSIC Group IP Ltd. © MUSIC Group IP Ltd. 2016
All rights reserved.
LIMITED WARRANTY
For the applicable warranty terms and conditions
and additional information regarding MUSIC Group’s
Limited Warranty, please see complete details online at
music-group.com/warranty.
NEGACIÓN LEGAL
MUSIC Group no admite ningún tipo de responsabilidad por
cualquier daño o pérdida que pudiera sufrir cualquier persona
por conar total o parcialmente en la descripciones, fotografías o
armaciones contenidas en este documento. Las especicaciones
técnicas, imágenes y otras informaciones contenidas en este
documento están sujetas a modicaciones sin previo aviso.
Todas las marcas comerciales que aparecen aquí son propiedad
de sus respectivos dueños. MIDAS, KLARK TEKNIK, LAB GRUPPEN,
LAKE, TANNOY, TURBOSOUND, TC ELECTRONIC, TC HELICON,
BEHRINGER, BUGERA y DDA son marcas comerciales o marcas
registradas de MUSIC Group IP Ltd. © MUSIC Group IP Ltd.
2016 Reservados todos los derechos.
GARANTÍA LIMITADA
Si quiere conocer los detalles y condiciones aplicables de la
garantía así como información adicional sobre la Garantía
limitada de MUSIC Group, consulte online toda la información
en la web music-group.com/warranty.
DÉNI LÉGAL
MUSIC Group ne peut être tenu pour responsable pour toute
perte pouvant être subie par toute personne se ant en partie
ou en totalité à toute description, photographie ou armation
contenue dans ce document. Les caractéristiques, l’apparence
et d’autres informations peuvent faire l’objet de modications
sans notication. Toutes les marques appartiennent à leurs
propriétaires respectifs. MIDAS, KLARK TEKNIK, LAB GRUPPEN,
LAKE, TANNOY, TURBOSOUND, TC ELECTRONIC, TC HELICON,
BEHRINGER, BUGERA et DDA sont des marques ou marques
déposées de MUSIC Group IP Ltd. © MUSIC Group IP Ltd.
2016 Tous droits réservés.
GARANTIE LIMITÉE
Pour connaître les termes et conditions de garantie applicables,
ainsi que les informations supplémentaires et détaillées sur
la Garantie Limitée de MUSIC Group, consultez le site Internet
music-group.com/warranty.

HAFTUNGSAUSSCHLUSS
MUSIC Group übernimmt keine Haftung für Verluste,
die Personen entstanden sind, die sich ganz oder teilweise
auf hier enthaltene Beschreibungen, Fotos oder Aussagen
verlassen haben. Technische Daten, Erscheinungsbild und
andere Informationen können ohne vorherige Ankündigung
geändert werden. Alle Warenzeichen sind Eigentum der
jeweiligen Inhaber. MIDAS, KLARK TEKNIK, LAB GRUPPEN, LAKE,
TANNOY, TURBOSOUND, TC ELECTRONIC, TC HELICON, BEHRINGER,
BUGERA und DDA sind Warenzeichen oder eingetragene
Warenzeichen der MUSIC Group IP Ltd. © MUSIC Group IP Ltd.
2016 Alle Rechte vorbehalten.
BESCHRÄNKTE GARANTIE
Die geltenden Garantiebedingungen und zusätzliche
Informationen bezüglich der von MUSIC Group
gewährten beschränkten Garantie nden Sie online unter
music-group.com/warranty.
LEGAL RENUNCIANTE
O MUSIC Group não se responsabiliza por perda alguma que
possa ser sofrida por qualquer pessoa que dependa, seja de
maneira completa ou parcial, de qualquer descrição, fotograa,
ou declaração aqui contidas. Dados técnicos, aparências e
outras informações estão sujeitas a modicações sem aviso
prévio. Todas as marcas são propriedade de seus respectivos
donos. MIDAS, KLARK TEKNIK, LAB GRUPPEN, LAKE, TANNOY,
TURBOSOUND, TC ELECTRONIC, TC HELICON, BEHRINGER, BUGERA
e DDA são marcas ou marcas registradas do MUSIC Group IP Ltd.
© MUSIC Group IP Ltd. 2016 Todos direitos reservados.
GARANTIA LIMITADA
Para obter os termos de garantia aplicáveis e condições e
informações adicionais a respeito da garantia limitada do
MUSIC Group, favor vericar detalhes na íntegra através do
website music-group.com/warranty.

FEDERAL COMMUNICATIONS
COMMISSION COMPLIANCE
INFORMATION
Responsible Party Name: MUSIC Group Services
NV Inc.
Address: 5270 Procyon Street
Las Vegas, NV 89118
USA
Phone Number: [phone]
ULM300D
complies with the FCC rules as mentioned in the
followingparagraph:
This equipment has been tested and found to comply with
the limits for a ClassB digital device, pursuant to part
15 of the FCC Rules. Theselimits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is
no guarantee that interference will not occur in a particular
installation. Ifthis equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment o and on, the user is encouraged
to try to correct the interference by one or more of the
followingmeasures:
•
• Reorient or relocate the receiving antenna
•
• Increase the separation between the equipment
andreceiver
•
• Connect the equipment into an outlet on a circuit dierent
from that to which the receiver is connected
•
• Consult the dealer or an experienced radio/TV technician
forhelp
This device complies with Part 15 of the FCC rules. Operation is
subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
includinginterference that may cause undesiredoperation.
This device complies with FCC radiation exposure limits set
forth for an uncontrolled environment.
Important information:
Changes or modications to the equipment not expressly
approved by MUSIC Group can void the user’s authority to use
the equipment.
Operation in the 2.4 GHz ISM (Industrial, Scientic, Medical)
frequencyband may be subject to interference from other
transmitting equipment operating in this band. Inthe
event of such interference, please verify and reassign
the transmitting channels of any potentially interfering
transmittingequipment.
ULM300D

Dedicate Your Life to Music

Product Information Document
High-Performance 2.4 GHz Digital Wireless
System with Handheld Microphone and
Dual-Mode USB Receiver
Wireless Microphone Systems
ULTRALINK
ULM300USB
*Warranty details can be found at music-group.com.
Interference-Free Performance
Our state-of-the-art transmitter and receiver
operate in the 2.4 GHz frequency band, which
is well out of the way of TV stations and
cell phone towers, two of the main culprits
that wreak havoc in the wireless zone. And
because it is digitally encrypted, your signal
gets through in all its pristine, high-denition
quality, without the random artifacts that
often plague other wireless systems.
Once again we broke the aordability
barrier – with our new ULTRALINK
ULM300USB Wireless Microphone
System. Now you are free to work the
room to your heart’s content, without
the hassle and restriction of cables
underfoot. Highest-quality sound is
provided by the dynamic hand-held
mic thanks to the built-in transmitter,
which operates in the license-free
2.4 GHz range. The dedicated ULM
receiver not only connects to your PC/Mac computer’s USB port for
recording directly into your favorite DAW application, but also works with a
wide range of BEHRINGER “Wireless-Ready” mixers and powered speakers
– for the ultimate in versatility.
#Package of ULM300M handheld
microphone and ULM300D
dual-mode USB receiver
#High-quality microphone capsule
for dedicated vocal applications
#Ultra-compact USB receiver with
dual mode analog/digital
audio interface
#Digital 2.4 GHz wireless connectivity
oers superior sound quality
#Maximum range 200 feet / 60 m
#Integrated volume up and down
buttons on handheld microphone
#Panic mute feature on microphone
#Receiver powered via USB interface
#Auto-sensing of analog or USB
digital audio connection
#2.4 GHz ISM band operation
allows license-free use on a
worldwide basis
#3-Year Warranty Program*
#Designed and engineered
in Germany

2 of 4
Product Information Document
High-Performance 2.4 GHz Digital Wireless
System with Handheld Microphone and
Dual-Mode USB Receiver
Wireless Microphone Systems
ULTRALINK
ULM300USB
Extended Battery Life
Replacing batteries in wireless mics can get expensive really fast – and having them die in the
middle of your set can be a real showstopper! That’s why we devoted extra time in developing
the ULM300USB to ensure that battery life was extended as much as possible. You get an honest
24 hours of performance time from a pair of AA alkaline batteries, which are available virtually
anywhere on the planet.
Ready for the World
Operating in the 2.4 GHz band allows your ULM300USB Wireless Microphone System to be used
across the globe without any special licensing requirements.
Convenient Control
We wanted the ULM300USB to be ultra-easy to operate, so we gave each mic easy-to-understand
and operate Volume buttons right on the microphone body. And should you accidentally
wander into the “Feedback Zone”, we included a handy Panic Mute function that engages when
you press and hold the Volume Down button.

3 of 4
3 o
f 4
Product Information Document
High-Performance 2.4 GHz Digital Wireless
System with Handheld Microphone and
Dual-Mode USB Receiver
Wireless Microphone Systems
ULTRALINK
ULM300USB
Extraordinary Value
The ULM300USB Wireless Microphone System is only available from BEHRINGER, the premier
audio manufacturer recognized worldwide for outstanding build quality and exceptional value.
Visit your local authorized dealer today and see just how easy – and aordable it is to hop on the
ULM300USB wireless bandwagon.
You Are Covered
We always strive to provide the best possible Customer Experience. Our products are made in our
own MUSIC Group factory using state-of-the-art automation, enhanced production workows
and quality assurance labs with the most sophisticated test equipment available in the world. As
a result, we have one of the lowest product failure rates in the industry, and we condently back
it up with a generous 3-Year Warranty program.

For service, support or more information contact the TURBOSOUND location nearest you:
Europe
MUSIC Group Services UK
Tel: [phone]
Email: [email protected]
USA/Canada
MUSIC Group Services NV Inc.
Tel: [phone]
Email: [email protected]
Japan
MUSIC Group Services JP K.K.
Tel: [phone]
Email: [email protected]
MUSIC Group accepts no liability for any loss which may be suered by any person who relies either wholly or in part upon any description, photograph, or statement contained herein.
Technical specications, appearances and other information are subject to change without notice. All trademarks are the property of their respective owners. MIDAS, KLARK TEKNIK,
LAB GRUPPEN, LAKE, TANNOY, TURBOSOUND, TC ELECTRONIC, TC HELICON, BEHRINGER, BUGERA and DDA are trademarks or registered trademarks of MUSIC Group IP Ltd.
© MUSIC Group IP Ltd. 2016 All rights reserved.
Product Information Document
High-Performance 2.4 GHz Digital Wireless
System with Handheld Microphone and
Dual-Mode USB Receiver
Wireless Microphone Systems
ULTRALINK
ULM300USB
