Beko VCC 20716 WD User manual

VCC 20716 WD
Vacuum Cleaner
User Manual
EN TH
01M-8839823200-4017-01
01M-8839833200-4017-01

Please read this user manual first!
Dear Customer,
Thank you for prefering a Beko product. We hope that you get the best results from
your product which has been manufactured with high quality and state-of-the-art
technology. Therefore, please read this entire user manual and all other accompanying
documents carefully before using the product and keep it as a reference for future use.
If you handover the product to someone else, give the user manual as well. Follow all
warnings and information in the user manual.
Explanation of symbols
Throughout this user manual the following symbols are used:
C
Important information or useful hints
about usage.
A
Warning for hazardous situations with
regard to life and property.
Protection class for electric shock.
This product has been produced in environmentally friendly, modern facilities.
Complies with the WEEE Regulation. Does not contain PCB.
Made in P.R.C.

Vacuum cleaner / User manual 3 / EN
CONTENTS
ENGLISH 4-10
 11-19

4 / EN Vacuum cleaner / User manual
This section contains safety
instructions that will help
protect from risk of personal
injury or property damage.
Failure to follow these
instructions invalidates the
granted warranty.
1.1 General safety
•Ths applance comples wth
the nternatonal securty
standards.
•Ths applance can be used by
the chldrenwho areat theage
of 8 or over and by the people
who have lmted physcal,
sensory or mental capacty or
who do not have knowledge
and experence, provded
that they are supervsed
or they understand the
nstructons wth regard to
safe use of the product and
potental dangers. Chldren
should not play wth the
applance. Cleanng and
mantenance works should
not be performed by chldren
unless they are supervsed by
an adult.
•Do not use t f the power
cable or the applance tself
s damaged. Contact an
authorzed servce.
•Your mans power supply
should comply wth the
nformaton suppled on the
ratng plate of the applance.
•The mans supply of the
applance must be secured
wth a mnmum 16 A fuse.
•Do not use the applance wth
an extenson cord.
•In order to prevent the power
cable from gettng damaged,
make sure that t doesn’t get
stuck, twsted or rub aganst
sharp surfaces.
•Do not touch the applance or
ts plug when t s plugged f
your hands are damp or wet.
•Do not pull the power
cable when unpluggng the
applance.
•Do not vacuum flammable
materals and when
vacuumng cgarette ashes
make sure that t got cold.
1Important safety and envronmental nstructons

Vacuum cleaner / User manual 5 / EN
•Do not vacuum water or other
lqud materals.
•Protect the applance from
ran, humdty and heat
sources.
•Never use the applance
n or near to combustble
or nflammable places and
materals.
•Unplug the applance before
cleanng and mantenance.
•Do not dp the applance or ts
cable n water to clean t.
•Check the hose of the
applance regularly. Do not
use f t s damaged and
contact an authorzed servce.
•Do not attempt to dsmantle
the applance.
•Only use the orgnal parts or
parts recommended by the
manufacturer.
•If heavly used for cleanng
dust such as cement or grout
the dust ndcator wll lt
earler then expected, n such
case replace the dust bag
even t s empty.
•Do not use the applance
wthout flters; otherwse t
can get damaged.
•When vacuumng the stars,
the applance should be
located below the user.
•If your store the package
materal, keep t out of the
reach of chldren.
1Important safety and envronmental nstructons

6 / EN Vacuum cleaner / User manual
1.2 Complance wth the WEEE
Drectve and Dsposng of the
Waste Product
Ths product comples wth EU WEEE Drectve
(2012/19/EU). Ths product bears a classfcaton
symbol for waste electrcal and electronc
equpment (WEEE).
Ths product has been manufactured
wth hgh qualty parts and materals
whch can be reused and are sutable
for recyclng. Do not dspose of the
waste product wth normal domestc
and other wastes at the end of ts servce lfe.
Take t to the collecton center for the recyclng of
electrcal and electronc equpment. Please
consult your local authortes to learn about these
collecton centers.
1.3 Complance wth RoHS
Drectve
The product you have purchased comples wth EU
RoHS Drectve (2011/65/EU). It does not contan
harmful and prohbted materals specfed n the
Drectve.
1.4 Package nformaton
Packagng materals of the product are
manufactured from recyclable
materals n accordance wth our
Natonal Envronment Regulatons. Do
not dspose of the packagng materals together
wth the domestc or other wastes. Take them to
the packagng materal collecton ponts
desgnated by the local authortes.
1Important safety and envronmental nstructons

Vacuum cleaner / User manual 7 / EN
2.1 Overvew
The values whch are declared n the markngs affxed on your product or the other prnted documents suppled wth t represent the values whch
were obtaned n the laboratores pursuant to the pertnent standards. These values may vary accordng to the usage of the applance and ambent
condtons.
2Your vacuum cleaner
1. Front cover
2. Rear cover
3. On/Off button
4. Cord rewndng button
5. Supply cord
6. Rear wheel
7. Hard floor/carpet nozzle
8. Hose
9. 2 pcs. plastc extenson tubes
10. Lower body
11. Rotatng wheel
12. Dust bag full ndcator
2.2 Techncal data
Power supply :
220-240 V~, 50/60 Hz
Power max : 1600 W
Dust capacity : 2,0 L
Radius of operation : 8m
Net weight : 3,9 kg
Rghts to make techncal and desgn changes are
reserved.
1
10 11
7
9
2 4
5
8
6
12
3

8 / EN Vacuum cleaner / User manual
3How to Use
3.1 Intended use
The applance was desgned to be used n houses,
and s not ft for ndustral use.
3.2 Assemblng the applance
Insert the hose in the coupling on the appliance
and press as far as it will go.
3.4 Usng the cleanng tools
•Two poston carpet/floor brush
Pos.1: to clean hard floors, bristles out.
Pos.2: to clean carpets and rugs, bristles in.
•Crevce tool
Ideal for removng dust from fabrc, furnture
books, curtans, frames and clothng.
3.5 Instructons
Before usng the applance, extract the power
cable completely and plug nto the mans. To
rewnd the cable, unplug and press the cable wnd
button.
3.6 Operaton
To turn the vacuum cleaner on, lghtly press the
ON/OFF button.

Vacuum cleaner / User manual 9 / EN
4Cleanng and mantenance
Swtch off and unplug the applance ,before
cleanng t.
AWARNING:
Never use gasolne,
solvent, abrasve cleanng agents,
metal objects or hard brushes to
clean the applance.
4.1 Dust bag full ndcator
The dust bag full ndcator warns when the dust
bag needs changng or the vacuum hose s blocked.
4.2 Replacng the dust bag
To change the paper dust bag, pull the bag
compartment openng lever and lft the cover.
Remove the dust bag holder and throw away
the old bag. Insert the new bag n place of the
old one and put the dust bag holder back n the
compartment.
Close the cover wth slght pressure. You should
change the dust bag frequently when vacuumng
up very fne drt such as flour, talcum powder, etc.
To avod the applance gvng off unpleasant
smells, you should replace the dust bag at least
twce a year.
C
The applance has a safety devce
whch prevents the dust bag
compartment cover beng closed
when there s no dust bag n place.
4.3 Motor protecton flter
To extend the workng lfe of the applance and
protect the motor, t s vtal to keep the motor
protecton flter clean.
To access the flter, open the dust bag
compartment, exract the dust bag and remove
the flter holder.
If the flter s not excessvely drty, smply remove
the dust.
If the flter s very drty, wash by hand n cold or
warm water.

10 / EN Vacuum cleaner / User manual
Make sure the flter s dry before puttng t back n
the applance.
When replacng the flter, make sure t s
postoned correctly.
AWARNING:
Never wash the flter
n the washng machne or dry wth
a hardryer.
4.4 Ar outlet flter
Remove the rear grll, take out the sponge flter
and when vsbly drty, clean t. You should clean
the flter at least every 5 dust bag changes.
AWARNING:
Never use the
applance wthout the flter.
4.5 Parkng poston
The applance s
provded wth a parkng
base at the bottom to
enable t to be put away
safely and tdly n the
parkng poston. If you
have to nterrupt
cleanng for a bref
perod, the applance has
a convenent hose “parkng” system.
Insert the bracket on the
brush jont nto the
housng on the bottom
of the applance. Insert
the bracket on the brush
jont nto the housng n
the parkng base at the
rear of the applance.
A
WARNING: Malfuncton of the
applance (low power, unusual
nose or complete breakdown)
could be caused by obstructed
nozzles or hoses or faulty electrcal
components.
Check the nozzles, dust bag and
motor protecton flter.
If ths does not resolve the problem,
take the applance to an authorsed
servce centre.
4.6 Storage
•If you do not ntend to use the applance for a
long tme, store t carefully.
•Pull the applance's plug out.
•Keep the applance out of the reach of chldren.
4Cleanng and mantenance





 
 
  



