Belden grass valley VERTIGO XG User manual

Installation and Quick Start Guide
M848-2705-200
2016-11-03
VERTIGO XG
ADVANCED HD/SD GRAPHICS PROCESSOR
VX-Vertigo-XG21-e
VX-Vertigo-XG22-e

ii
Notices
Copyright and Trademark Notice
Copyright © 2016, Grass Valley Canada. All rights reserved.
Belden, Belden Sending All The Right Signals, and the Belden logo are trademarks or
registered trademarks of Belden Inc. or its affiliated companies in the United States and
other jurisdictions. Grass Valley, Miranda, Vertigo XG, Vertigo Suite are trademarks or
registered trademarks of Grass Valley Canada. Belden Inc., Grass Valley Canada, and other
parties may also have trademark rights in other terms used herein.
Terms and Conditions
Please read the following terms and conditions carefully. By using Vertigo XG
documentation, you agree to the following terms and conditions.
Grass Valley hereby grants permission and license to owners of Vertigo XGs to use their
product manuals for their own internal business use. Manuals for Grass Valley products may
not be reproduced or transmitted in any form or by any means, electronic or mechanical,
including photocopying and recording, for any purpose unless specifically authorized in
writing by Grass Valley.
A Grass Valley manual may have been revised to reflect changes made to the product
during its manufacturing life. Thus, different versions of a manual may exist for any given
product. Care should be taken to ensure that one obtains the proper manual version for a
specific product serial number.
Information in this document is subject to change without notice and does not represent a
commitment on the part of Grass Valley.
Warranty information is available in the Support section of the Grass Valley Web Site
(www.grassvalley.com).
Title Vertigo XG Installation and Quick Start Guide
Part Number M848-2705-200
Revision 2016-11-03, 15:15

iii
Vertigo XG
Installation and Quick Start Guide
Important Safeguards and Notices
This section provides important safety guidelines for operators and service personnel.
Specific warnings and cautions appear throughout the manual where they apply. Please
read and follow this important information, especially those instructions related to the risk
of electric shock or injury to persons.
Symbols and Their Meanings
Indicates that dangerous high voltage is present within the equipment
enclosure that may be of sufficient magnitude to constitute a risk of electric
shock.
Indicates that the user, operator or service technician should refer to the product
manuals for important operating, maintenance, or service instructions.
This is a prompt to note the fuse rating when replacing fuses. The fuse
referenced in the text must be replaced with one having the ratings indicated.
Identifies a protective grounding terminal which must be connected to earth
ground prior to making any other equipment connections.
Identifies an external protective grounding terminal which may be connected to
earth ground as a supplement to an internal grounding terminal.
Indicates that static sensitive components are present, which may be damaged
by electrostatic discharge. Use anti-static procedures, equipment and surfaces
during servicing.
Indicates that the equipment has more than one power supply cord, and that all
power supply cords must be disconnected before servicing to avoid electric
shock.
The presence of this symbol in or on Grass Valley equipment means that it has
been tested and certified as complying with applicable Canadian Standard
Association (CSA) regulations and recommendations for USA/Canada.
The presence of this symbol in or on Grass Valley equipment means that it has
been tested and certified as complying with applicable Underwriters Laboratory
(UL) regulations and recommendations for USA/Canada.
The presence of this symbol in or on Grass Valley equipment means that it has
been tested and certified as complying with applicable Intertek Testing Services
regulations and recommendations for USA/Canada.

iv
Notices
Warnings
A warning indicates a possible hazard to personnel, which may cause injury or
death. Observe the following general warnings when using or working on this
equipment:
• Appropriately listed/certified mains supply power cords must be used for the
connection of the equipment to the mains voltage at either 120 V AC or 240 V AC.
• This product relies on the building's installation for short-circuit (over-current)
protection. Ensure that a fuse or circuit breaker for 120 V AC or 240 V AC is used on the
phase conductors.
• Any instructions in this manual that require opening the equipment cover or enclosure
are for use by qualified service personnel only.
• Do not operate the equipment in wet or damp conditions.
• This equipment is grounded through the grounding conductor of the power cords. To
avoid electrical shock, plug the power cords into a properly wired receptacle before
connecting the equipment inputs or outputs.
• Route power cords and other cables so they are not likely to be damaged. Properly
support heavy cable bundles to avoid connector damage.
• Disconnect power before cleaning the equipment. Do not use liquid or aerosol
cleaners; use only a damp cloth.
• Dangerous voltages may exist at several points in this equipment. To avoid injury, do
not touch exposed connections and components while power is on.
• High leakage current may be present. Earth connection of product is essential before
connecting power.
• Prior to servicing, remove jewelry such as rings, watches, and other metallic objects.
• To avoid fire hazard, use only the fuse type and rating specified in the service
instructions for this product, or on the equipment.
• To avoid explosion, do not operate this equipment in an explosive atmosphere.
• Use proper lift points. Do not use door latches to lift or move equipment.
• Avoid mechanical hazards. Allow all rotating devices to come to a stop before servicing.
• Have qualified service personnel perform safety checks after any service.
Cautions
A caution indicates a possible hazard to equipment that could result in equipment
damage. Observe the following cautions when operating or working on this
equipment:
• This equipment is meant to be installed in a restricted access location.
The presence of this symbol in or on Grass Valley product means that it complies
with all applicable European Union (CE) directives.
The presence of this symbol in or on Grass Valley product means that it complies
with safety of laser product applicable standards.

v
Vertigo XG
Installation and Quick Start Guide
• When installing this equipment, do not attach the power cord to building surfaces.
• Products that have no on/off switch, and use an external power supply must be
installed in proximity to a main power outlet that is easily accessible.
• Use the correct voltage setting. If this product lacks auto-ranging power supplies,
before applying power ensure that each power supply is set to match the power
source.
• Provide proper ventilation. To prevent product overheating, provide equipment
ventilation in accordance with the installation instructions.
• Do not operate with suspected equipment failure. If you suspect product damage or
equipment failure, have the equipment inspected by qualified service personnel.
• To reduce the risk of electric shock, do not perform any servicing other than that
contained in the operating instructions unless you are qualified to do so. Refer all
servicing to qualified service personnel. Servicing should be done in a static-free
environment.
• This unit may have more than one power supply cord. Disconnect all power supply
cords before servicing to avoid electric shock.
• Follow static precautions at all times when handling this equipment.
Electrostatic Discharge (ESD) Protection
Electrostatic discharge occurs when electronic components are improperly
handled and can result in intermittent failure or complete damage adversely
affecting an electrical circuit. When you remove and replace any card from a frame
always follow ESD-prevention procedures:
• Ensure that the frame is electrically connected to earth ground through the power cord
or any other means if available.
• Wear an ESD wrist strap ensuring that it makes good skin contact. Connect the
grounding clip to an unpainted surface of the chassis frame to safely ground unwanted
ESD voltages. If no wrist strap is available, ground yourself by touching the unpainted
metal part of the chassis.
• For safety, periodically check the resistance value of the antistatic strap, which should
be between 1 and 10 megohms.
• When temporarily storing a card make sure it is placed in an ESD bag.
• Cards in an earth grounded metal frame or casing do not require any special ESD
protection.
Battery Handling
This product includes a backup battery. There is a danger of explosion if the battery
is replaced incorrectly. Replace the battery only with the same or equivalent type
recommended by the manufacturer. Dispose of used batteries according to the
manufacturer’s instructions. Before disposing of your Grass Valley equipment, please
review the Disposal and Recycling Information appendix.

vi
Notices
Cautions for LCD and TFT Displays
Excessive usage may harm your vision. Rest for 10 minutes for every 30 minutes of
usage.
If the LCD or TFT glass is broken, handle glass fragments with care when disposing
of them. If any fluid leaks out of a damaged glass cell, be careful not to get the liquid crystal
fluid in your mouth or skin. If the liquid crystal touches your skin or clothes, wash it off
immediately using soap and water. Never swallow the fluid. The toxicity is extremely low
but caution should be exercised at all times.
Mesures de sécurité et avis importants
La présente section fournit des consignes de sécurité importantes pour les opérateurs et le
personnel de service. Des avertissements ou mises en garde spécifiques figurent dans le
manuel, dans les sections où ils s’appliquent. Prenez le temps de bien lire les consignes et
assurez-vous de les respecter, en particulier celles qui sont destinées à prévenir les
décharges électriques ou les blessures.
Signification des symboles utilisés
Signale la présence d’une tension élevée et dangereuse dans le boîtier de
l’équipement ; cette tension peut être suffisante pour constituer un risque de
décharge électrique.
Avertit l'utilisateur, l’opérateur ou le technicien de maintenance que des
instructions importantes relatives à l'utilisation et à l'entretien se trouvent dans
la documentation accompagnant l’équipement.
Invite l'utilisateur, l’opérateur ou le technicien de maintenance à prendre note du
calibre du fusible lors du remplacement de ce dernier. Le fusible auquel il est fait
référence dans le texte doit être remplacé par un fusible du même calibre.
Identifie une borne de mise à la terre de protection. Il faut relier cette borne à la
terre avant d’effectuer toute autre connexion à l’équipement.
Identifie une borne de mise à la terre externe qui peut être connectée en tant
que borne de mise à la terre supplémentaire.
Signale la présence de composants sensibles à l’électricité statique et qui sont
susceptibles d’être endommagés par une décharge électrostatique. Utilisez des
procédures, des équipements et des surfaces antistatiques durant les
interventions d’entretien.
Le symbole ci-contre signifie que l’appareil comporte plus d’un cordon
d'alimentation et qu’il faut débrancher tous les cordons d'alimentation avant
toute opération d’entretien, afin de prévenir les chocs électriques.

vii
Vertigo XG
Installation and Quick Start Guide
Avertissements
Les avertissements signalent des conditions ou des pratiques susceptibles
d’occasionner des blessures graves, voire fatales. Veuillez vous familiariser avec les
avertissements d’ordre général ci-dessous :
• Un cordon d’alimentation dûment homologué doit être utilisé pour connecter
l’appareil à une tension de secteur de 120 V CA ou 240 V CA.
• La protection de ce produit contre les courts-circuits (surintensités) dépend de
l’installation électrique du bâtiment. Assurez-vous qu'un fusible ou un disjoncteur pour
120 V CA ou 240 V CA est utilisé sur les conducteurs de phase.
• Dans le présent manuel, toutes les instructions qui nécessitent d’ouvrir le couvercle de
l’équipement sont destinées exclusivement au personnel technique qualifié.
• N’utilisez pas cet appareil dans un environnement humide.
• Cet équipement est mis à la terre par le conducteur de mise à la terre des cordons
d’alimentation. Pour éviter les chocs électriques, branchez les cordons d’alimentation
sur une prise correctement câblée avant de brancher les entrées et sorties de
l’équipement.
• Acheminez les cordons d’alimentation et autres câbles de façon à ce qu’ils ne risquent
pas d’être endommagés. Supportez correctement les enroulements de câbles afin de
ne pas endommager les connecteurs.
• Coupez l’alimentation avant de nettoyer l’équipement. Ne pas utiliser de nettoyants
liquides ou en aérosol. Utilisez uniquement un chiffon humide.
• Des tensions dangereuses peuvent exister en plusieurs points dans cet équipement.
Pour éviter toute blessure, ne touchez pas aux connexions ou aux composants exposés
lorsque l’appareil est sous tension.
La marque C-CSA-US certifie que l’appareil visé a été testé par l'Association
canadienne de normalisation (CSA) et reconnu conforme aux exigences
applicables en matière de sécurité électrique en vigueur au Canada et aux États-
Unis.
La marque C-UL-US certifie que l’appareil visé a été testé par Underwriters
Laboratory (UL) et reconnu conforme aux exigences applicables en matière de
sécurité électrique en vigueur au Canada et aux États-Unis.
La marque ETL Listed d’Intertek pour le marché Nord-Américain certifie que
l’appareil visé a été testé par Intertek et reconnu conforme aux exigences
applicables en matière de sécurité électrique en vigueur au Canada et aux États-
Unis.
Le marquage CE indique que l’appareil visé est conforme aux exigences
essentielles des directives applicables de l’Union européenne en matière de
sécurité électrique, de compatibilité électromagnétique et de conformité
environnementale.
Le symbole ci-contre sur un appareil Grass Valley ou à l’intérieur de l’appareil
indique qu’il est conforme aux normes applicables en matière de sécurité laser.

viii
Notices
• Avant de procéder à toute opération d’entretien ou de dépannage, enlevez tous vos
bijoux (notamment vos bagues, votre montre et autres objets métalliques).
• Pour éviter tout risque d’incendie, utilisez uniquement les fusibles du type et du calibre
indiqués sur l’équipement ou dans la documentation qui l’accompagne.
• Ne pas utiliser cet appareil dans une atmosphère explosive.
• Présence possible de courants de fuite. Un raccordement à la masse est indispensable
avant la mise sous tension.
• Après tout travail d’entretien ou de réparation, faites effectuer des contrôles de sécurité
par le personnel technique qualifié.
Mises en garde
Les mises en garde signalent des conditions ou des pratiques susceptibles
d’endommager l’équipement. Veuillez vous familiariser avec les mises en garde ci-
dessous :
• L’appareil est conçu pour être installé dans un endroit à accès restreint.
• Au moment d’installer l’équipement, ne fixez pas les cordons d’alimentation aux
surfaces intérieures de l’édifice.
• Les produits qui n'ont pas d’interrupteur marche-arrêt et qui disposent d’une source
d’alimentation externe doivent être installés à proximité d'une prise de courant facile
d’accès.
• Si l’équipement n’est pas pourvu d’un modules d’alimentation auto-adaptables, vérifiez
la configuration de chacun des modules d'alimentation avant de les mettre sous
tension.
• Assurez une ventilation adéquate. Pour éviter toute surchauffe du produit, assurez une
ventilation de l’équipement conformément aux instructions d’installation.
• N’utilisez pas l’équipement si vous suspectez un dysfonctionnement du produit. Faites-
le inspecter par un technicien qualifié.
• Pour réduire le risque de choc électrique, n'effectuez pas de réparations autres que
celles qui sont décrites dans le présent manuel, sauf si vous êtes qualifié pour le faire.
Confiez les réparations à un technicien qualifié. La maintenance doit se réaliser dans un
milieu libre d’électricité statique.
• L’appareil peut comporter plus d’un cordon d'alimentation. Afin de prévenir les chocs
électriques, débrancher tous les cordons d'alimentation avant toute opération
d’entretien.
• Veillez à toujours prendre les mesures de protection antistatique appropriées quand
vous manipulez l’équipement.
Protection contre les décharges électrostatiques (DES)
Une décharge électrostatique peut se produire lorsque des composants
électroniques ne sont pas manipulés de manière adéquate, ce qui peut entraîner
des défaillances intermittentes ou endommager irrémédiablement un circuit
électrique. Au moment de remplacer une carte dans un châssis, prenez toujours les
mesures de protection antistatique appropriées :

ix
Vertigo XG
Installation and Quick Start Guide
• Assurez-vous que le châssis est relié électriquement à la terre par le cordon
d'alimentation ou tout autre moyen disponible.
• Portez un bracelet antistatique et assurez-vous qu'il est bien en contact avec la peau.
Connectez la pince de masse à une surface non peinte du châssis pour détourner à la
terre toute tension électrostatique indésirable. En l’absence de bracelet antistatique,
déchargez l’électricité statique de votre corps en touchant une surface métallique non
peinte du châssis.
• Pour plus de sécurité, vérifiez périodiquement la valeur de résistance du bracelet
antistatique. Elle doit se situer entre 1 et 10 mégohms.
• Si vous devez mettre une carte de côté, assurez-vous de la ranger dans un sac
protecteur antistatique.
• Les cartes qui sont reliées à un châssis ou boîtier métallique mis à la terre ne
nécessitent pas de protection antistatique spéciale.
Remplacement et élimination des piles
L’appareil renferme une pile. Pour réduire le risque d’explosion, vérifiez la polarité et
ne remplacez la pile que par une pile du même type, recommandée par le fabricant.
Mettez les piles usagées au rebut conformément aux directives du fabricant. Avant
de vous défaire de l’équipement, assurez-vous d’avoir lu l’appendice Disposal and Recycling
Information.
Précautions pour les écrans LCD et TFT
Regarder l’écran pendant une trop longue période de temps peut nuire à votre
vision. Prenez une pause de 10 minutes, après 30 minutes d’utilisation.
Si l'écran LCD ou TFT est brisé, manipulez les fragments de verre avec précaution au
moment de vous en débarrasser. veillez à ce que le cristal liquide n'entre pas en contact
avec la peau ou la bouche. En cas de contact avec la peau ou les vêtements, laver
immédiatement à l'eau savonneuse. Ne jamais ingérer le liquide. La toxicité est
extrêmement faible, mais la prudence demeure de mise en tout temps.
Recycling
Visit www.grassvalley.com for recycling information.
Certification and Compliance
Safety Compliance
This equipment complies with the requirements of CSA/UL/IEC/EN 60950-1, 2nd
Ed. + AM1, Safety of information technology equipment.
The power cords supplied with this equipment meet the appropriate national
standards for the country of destination.

x
Notices
Safety of Laser Modules
This equipment incorporates modules containing Class 1 lasers. These modules
are certified by the manufacturer to comply with:
– IEC/EN 60825-1 Safety of laser products
– IEC 60950-1 Safety of information technology equipment
Electromagnetic Compatibility
This equipment has been tested for verification of compliance with FCC Part 15,
Subpart B requirements for class A digital devices.
This equipment has been tested and found to comply with the requirements of
the EMC directive 2004/108/EC:
• EN 55022 Class A Radiated and conducted emissions
• EN 61000-3-2 Limits for harmonic current emissions
• EN 61000-3-3 Limitation of voltage fluctuations and flicker
• EN 61000-4-2 Electrostatic discharge immunity
• EN 61000-4-3 Radiated, radio-frequency, electromagnetic field immunity
• EN 61000-4-4 Electrical fast transient immunity
• EN 61000-4-5 Surge transient immunity
• EN 61000-4-6 Conducted disturbances immunity
• EN 61000-4-8 Power frequency magnetic field immunity
• EN 61000-4-11 Voltage dips, short interruptions and voltage variations
immunity
Note: This equipment has been tested and found to comply with the limits
for a Class A digital device, pursuant to Part 15 of the FCC rules. These limits
are designed to provide reasonable protection against harmful interference
when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy, and, if
not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.

xi
Table of Contents
1Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
2Overview of the Vertigo XG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Vertigo XG Chassis. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Front Panel Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Rear Panel Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Vertigo XG Signal Path and Rendering Processes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Video Input/Output Channels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Audio Input/Output Channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Ancillary Data Processing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .13
Graphics Processing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Clip Player and Media Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
3Installation and Quick Start Instructions . . . . . . . . . . . . . . . . 15
Unpacking and Verifying the Vertigo XG Shipped Items. . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Mounting the Vertigo XG Chassis in a Rack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Cabling the Vertigo XG Unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Starting the Vertigo XG . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Assigning a New IP Address to the Vertigo XG Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Verifying the Installation and Setup by Previewing the Playout. . . . . . . . . . . . . . . . . . . . .22
Completing the Quick Start Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Contact Us . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

xii
Table of Contents

1
Introduction
This guide provides basic Vertigo XG product information, as well as an orientation of its
hardware components. This guides also provides instructions for performing a first-time
installation of the Vertigo XG device, as well as initial setup tasks to get the device up and
running.
New Vertigo XG devices are factory configured for standard rendering and playout
workflows. Configuring the Vertigo XG settings for advanced workflows is normally
performed by qualified network administrators or Grass Valley’s Integration Specialists.
Information and instructions for implementing advanced configurations is beyond the
scope of this document, but are covered in the Vertigo XG Configuration Guide. Please visit
the Documentation Library on the Grass Valley Web site (www.grassvalley.com) for the
latest documentation updates.

2
Introduction

3
Overview of the Vertigo XG
The Vertigo XG is a full-featured HD/SD graphics processor that provides high performance
single or dual channel graphics rendering and video playback performance. The Vertigo XG
is ideal for a wide range of advanced real-time broadcast applications, like HD/SD dual-
casting with independent graphics for HD and SD, and single channel applications
demanding sophisticated, multi-channel branding and promotional graphics.
The Vertigo XG is available in two (2) standard models:
Both models of the Vertigo XG have the following features and capabilities:
• 3 RU rack mount chassis
• 2 video input channels
• 1 video output channel (XG21-e) or 2 video output channels (XG22-e)
• SD and HD video support
• 1 TB of video and audio storage, which is expandable to 2 TB
• 16 embedded audio channels per SDI stream
• Discrete AES audio channels - up to 8 in and 16 out (XG21-e) or 2 x 16 out (XG22-e)
• Independent DVEs on each video input
•Tri-modehardwareVideobypasses
• VAnc + VBI extraction processing and insertion or VAnc/VBI pass through
• Unlimited virtual layers that can be controlled independently
• Real-time control of live data sources with automatic on-air updates
• True Type/Unicode character support
• One seat of Xplay is included with each channel of the Vertigo XG purchased which
integrates the following features and functionality:
• Automation interface via RS-232, RS-422 (option) and TCP/IP
• Xplay’s graphical interface used for manual control of playlists
• “As run” logging
VX-Vertigo-XG21-e Vertigo XG single channel graphics engine (2 inputs, 1 output) used
for downstream branding.
VX-Vertigo-XG22-e Vertigo XG dual channel graphics engine (2 inputs, 2 outputs) used
for downstream simulcast branding.

4
Overview of the Vertigo XG
Vertigo XG Chassis
The following hardware options are available to both models of the Vertigo XG:
Vertigo XG Chassis
The Vertigo XG unit is a 3RU rackmount rendering platform that incorporates redundant
fans, two power supplies, and 1 TB RAID1-enabled storage (optional 2 TB RAID10
expansion).
The only visible difference between the two models of the Vertigo XG is that the single
channel model (XG21-e) has only one (1) discrete AES audio connector, while the dual
channel model (XG22-e) has two (2) discrete AES audio connectors.
In some cases, the positioning of the connectors on the Vertigo XG’s rear panel differs
depending upon the hardware options installed. See page 4 for a list of the Vertigo XG’s
hardware options.
The following table summarizes the Vertigo XG’s physical dimensions and power
consumption:
Consult the following sections to familiarize yourself with the Vertigo XG’s front and rear
panel components:
•Front Panel Components, on page 5
•Rear Panel Components, on page 7
VX-RS422-2-e 2 port RS-422 card
The RS-422 card provides an interface upon which the
Vertigo XG can communicate with automation systems.
VX-GPI-8-e GPI card
The GPI card allows for control of the Vertigo XG via GPI
triggers. The card allows for up to 8 GPI in and 8 GPI out.
VX-TC-e Time Code card
The Time Code card allows you to lock the Vertigo XG’s
system clock to an external timecode.
VX-2TB-UPG 1 TB RAID10 Expansion option (2 x 1TB)
Increases the usable storage from 1TB to 2TB.
Chassis Form: 3U rackmount chassis
Height: 5.2” (132mm)
Width: 17.7” (450mm)
Depth: 25.5” (648mm)
Power consumption AC input: 100 - 240V, 50 - 60Hz
Consumption: 4.05 - 1.73A
Power: 410 max.
Temperature Ambient temperature: 35 C
Note: This shall be the maximum internal temperature
within the rack in which the Vertigo XG unit is installed.
°

5
Vertigo XG
Installation and Quick Start Guide
Front Panel Components
The Vertigo XG’s front panel provides convenient access to the hard drives, a CD/DVD ROM
drive, and a control panel containing six LEDs and two buttons for system monitoring and
operation.
Power Failure Indicates a power supply module has failed, which is accompanied
by an audible alarm. A backup power supply module will take the
load and keep the system running, but the failed module will need
to be replaced. This red LED should be off when the system is
operating normally.
Overheat / Fan Fail When this red LED flashes, it indicates a fan failure. When it is
constantly illuminated (solid on), it indicates an overheat condition,
which may be caused by cables obstructing the airflow in the system
or the ambient room temperature being too warm. Check the
routing of cables and make sure that all fans are present and
operating normally. You should also check to make sure that the
chassis covers are installed properly. Finally, verify that the heatsinks
are installed properly. This LED will remain flashing or on as long as
the above mentioned conditions exist.
LAN2 A flashing green LAN2 LED indicates network activity on LAN2.
CD/DVD
Hard Drives Floppy
Drive
ROM Drive
POWER
Overheat
/ Fan Fail
Power Failure LAN 2
LAN 1
HDD
Activity
Power
Indicator

6
Overview of the Vertigo XG
Front Panel Components
LAN1 A flashing green LAN1 LED indicates network activity on LAN2.
HDD Activity This flashing amber LED indicates IDE channel activity.
Power Indicator (LED) Indicates that power is being supplied to the system’s power supply
units. This green LED should normally be illuminated when the
system is in operation.
Reset The Reset button reboots the system.
Power Button This is the main power button, which is used to apply or turn off the
main system power. Turning off this button removes the main power,
but keeps standby power supplied to the system.

7
Vertigo XG
Installation and Quick Start Guide
Rear Panel Components
The Vertigo XG’s rear panel provides convenient access to the video card’s I/O connector,
which provides 4 SD/HD SDI video outputs, a reference signal input, and AES audio
input/output. The rear panel also provides access to the graphics card connector, as well as
various I/O ports (RS-422, USB, Ethernet...etc.).
Fig. 2-1: The Vertigo XG’s rear panel components (XG22-e model)
Power Supply Modules (2)
RS-422 Connectors
USB 2.0
Network Ethernet
Connectors (2)
SDI Video Card
Connectors (4)
I/O Connector
Graphics Card
System Fans (2)
Serial
RS-232 Ports (2)
Mouse
Keyboard
Connectors
(option)
Audio I/O Ports
(Disabled)
Discrete Audio
Connectors (2)
(option)
Connector
Connector
GPI Card Connector
(option)
Time Code
Card
LTC
IN
LTC
IN
Note: In some cases, the positioning of the connectors on the Vertigo
XG’s rear panel differs depending upon the hardware options
installed. See page 4 for a list of the Vertigo XG’s hardware options.
Mouse & Keyboard
connectors
The two (2) PS/2 connectors on the rear panel allow you to connect a
mouse and keyboard to the Vertigo XG device. These peripherals are
required during the device’s initial configuration, which involves
using the Vertigo XG’s desktop applications, including Dashboard.
Note that if the mouse or keyboard has a UBS connector, you can
connect them to the USB 2.0 connectors on the front or rear panels
of the Vertigo XG device.
USB 2.0 Connectors The four (4) USB 2.0 connectors on the rear panel allow you to
connect peripheral devices (e.g. keyboard, mouse, flash drive...etc) to
the Vertigo XG.

8
Overview of the Vertigo XG
Rear Panel Components
Serial RS-232 Port The two (2) RS-232 connectors provide two control ports upon
which the automation system’s serial cables are connected. It is
through this connection that the automation system communicates
and controls the Vertigo XG using automation protocol commands.
Network Ethernet
Connectors
The two (2) Network Ethernet connectors are teamed and allow you
to connect the Vertigo XG device to the Local Area Network (LAN).
NIC Teaming is a networking concept where multiple network
adapters within a computer are combined in parallel to provide
redundancy for the network interface. On an Vertigo XG device, the
two Local Area Connection network adapters are teamed together
(connect 2 cables to the 2 NIC cards at the same time) to form a third
virtual adapter. In the event of an adapter, cable or switch failure, the
network interface fails over to the healthy adapter.
When the individual Local Area Network adapters are teamed
together the individual Local Area Network adapters are not
accessible or configurable. Only the teamed virtual adapter, called
Vertigo, can be configured.
If you only have 1 cable connected, then the teaming will still be in
effect but all traffic will be over that one cable. If that NIC fail, you will
have to manually move the cable to the other NIC.
Audio I/O ports These six (6) audio I/O ports are not supported by the Vertigo XG
since external audio input and output is provided by the Discrete
EAS option (see Audio Input/Output Channels, on page 13).
Graphics Card’s DVI
Connectors
The graphics card’s DVI and DisplayPort connectors allow you to
connect the Vertigo XG device to DVI monitor. A monitor is only
required during the device’s initial configuration, so as to display
Vertigo XG’s desktop applications, including XG Dashboard.
Note that although there are three connectors, the Vertigo XG can
display to only one monitor. Therefore, it does matter which of the
connectors the monitor’s cable is connected to.
Use the adapter (below) if you would rather connect a VGA monitor.
