Belkin P73890EA-A User manual

P73890ea-A F5U222ea
Belkin Hi-Speed USB 2.0 Notebook Card
Carte USB 2.0 haute vitesse
pour portable Belkin
Belkin USB 2.0
Hi-Speed Notebook-Karte
Belkin Hi-Speed
USB 2.0 Notebookkaart
Scheda per notebook
Belkin Hi-Speed USB 2.0
Tarjeta de ordenador portátil
USB 2.0 de alta velocidad de Belkin
Fr
De
En
It
Es
Ne
P73890-A_F5U222ea_man.qxd 9/30/02 3:48 PM Page 1

P73890-A_F5U222ea_man.qxd 9/30/02 3:48 PM Page 2

English . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Français (Europe) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Deutche . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Nederlands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .55
Italiano . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73
Español . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .91
Introduction
Fr
De
En
It
Es
Ne
P73890-A_F5U222ea_man.qxd 9/30/02 3:48 PM Page 3

P73890-A_F5U222ea_man.qxd 9/30/02 3:48 PM Page 4

Introduction
Welcome to Belkin Hi-Speed Connectivity!
Thank you for purchasing the Belkin Hi-Speed USB 2.0
Notebook Card (the Card).
Now you can upgrade your computer to the latest USB
technology. You will be able to take advantage of a host of
new Hi-Speed USB 2.0 products!
Your USB 2.0 products—including hard drives, scanners,
printers, video cameras, and more—will all work much faster
than ever before. Your current USB devices will continue to
work as they always have and, in some cases, even better
with this Card. Follow the simple installation instructions in
this manual to get your Card up and working—then enjoy
the speed and convenience of Belkin!
1
En
P73890-A_F5U222ea_man.qxd 9/30/02 3:48 PM Page 1

Features
2
• Two Hi-Speed USB 2.0 ports
• Simultaneous connection capability for low-, full-,
and high-speed devices
• Auto-detection of new devices as they are connected,
along with the speed of each device
• Backward-compatibility with USB 1.1 devices
• Full compliance with USB specifications
• Plug-and-Play technology
• Works without power supply with most USB devices
P73890-A_F5U222ea_man.qxd 9/30/02 3:48 PM Page 2

• Open Host Controller Interface- (OHCI) compliant (USB
1.1 Host Controller)
• Enhanced Host Controller Interface- (EHCI) compliant (USB
2.0 Host Controller)
• PCI revision 2.1-compliant
• Current: 2A max
• USB revision 2.0-compliant
• 3.5mm DC power jack
• Power Supply
Input: 100–240VAC
Output: 5 VDC 3A
Power Supply Polarity
Package Contents
• Belkin Hi-Speed USB 2.0 Notebook Card
• User Manual
• Installation CD
• Power Supply
Specifications
3
En
P73890-A_F5U222ea_man.qxd 9/30/02 3:48 PM Page 3

System Requirements
4
• 266MHz Pentium®II processor
• 32MB RAM
• PC-compatible laptop computer with available 32-bit Type II
CardBus slot
• Windows®98 SE, 2000, Me, or XP operating system
Operating System Compatibility
Operating System USB 1.x USB 2.0
Support Support
Windows 98 SE Yes Yes
Windows 2000 Yes Yes
Windows Me Yes Yes
Windows XP Yes Yes
P73890-A_F5U222ea_man.qxd 9/30/02 3:48 PM Page 4

Installation
Please refer to the section that corresponds to your version
of Windows operating system.
Note: The included power supply is not needed for
bus-powered USB devices such as keyboards and mice,
or self-powered USB devices such as hard drives, printers,
etc. Bus-powered devices that draw large amounts of
power directly from the USB bus, such as webcams and
certain scanners, will require the use of the power supply.
Installation Procedure for Windows 98 SE
This installation procedure will install two USB 1.1 OHCI
controllers and one USB 2.0 EHCI host controller.
1. Insert the F5U222 installation CD into your CD-ROM
drive. After a few moments the main menu will
auto-start and display the available installation options.
2. Select “Install USB 2.0 Driver”.
3. The setup utility will now install a CardBus eject utility
for your USB 2.0 CardBus adapter. Take note of the
information provided regarding the eject utility, then
click “Next” to continue.
4. After the driver is installed, select “Yes, I want to restart
my computer now.” Click “Close”.
5. After Windows restarts, locate your laptop computer’s
CardBus slot.
6. Insert the Card into the slot. Apply pressure as needed
until it is fully seated.
7. After inserting the Card, Windows will detect the
“NEC USB Open Host Controller” and the “Add New
Hardware Wizard” dialog box will open. Click “Next”.
5
En
P73890-A_F5U222ea_man.qxd 9/30/02 3:48 PM Page 5

Installation (continued)
6
8. Select “Search for the best driver for your device
(Recommended)” and click “Next”.
9. Uncheck all the boxes and click “Next”.
10. Windows will locate the drivers for “NEC USB Open Host
Controller”. Click “Next”.
(Windows may prompt you to insert the Windows OS
installation CD. If so, insert the CD into the CD-ROM drive
and continue the installation procedure).
11. Installation of the “NEC USB Open Host Controller” will
now complete. Click “Finish”.
12. The “Add New Hardware” wizard will repeat the
installation process for the second OHCI host controller.
13. Repeat steps 8-11.
14. Windows will now detect “Belkin USB 2.0 Hi-Speed Host
Controller”. Click “Next”.
15. Windows will locate the required drivers and complete
installation of the “Belkin USB 2.0 Hi-Speed Host
Controller” and “USB 2.0 Root Hub Device”.
Installation of the Card is now complete.
Verifying Proper Installation (Windows 98 SE)
Check the “Windows Device Manager” to confirm that your PCI
Card has been properly installed.
1. Right-click on “My Computer” and select “Properties”.
2. Select the “Device Manager” tab.
3. Click on the plus sign (+) next to “Universal Serial
Bus Controllers”.
P73890-A_F5U222ea_man.qxd 9/30/02 3:48 PM Page 6

7
Installation (continued)
The “Universal Serial Bus Controllers” list will now include
two “NEC USB Open Host Controller” entries, one “Belkin
USB 2.0 Hi-Speed Host Controller” entry, one “USB 2.0 Root
Hub Device” entry, and two “USB Root Hub” entries.
Note: If your computer features built-in USB ports, or if
you have other USB PCI controller cards installed, you will
see additional USB controller and root hub entries.
Installation Procedure for Windows Me
This installation procedure will successfully install two USB
1.1 OHCI controllers and one USB 2.0 EHCI host controller.
1. Insert the F5U222 installation CD into your CD-ROM
drive. After a few moments the main menu will
auto-start.
2. Select “Install USB 2.0 Driver”.
3. The setup utility will now install a CardBus eject utility
for your USB 2.0 CardBus adapter. Take note of the
information provided regarding the eject utility, then
click “Next” to continue.
4. After the driver is installed select “Yes, I want to restart
my computer now.” Click “Close”.
5. After Windows restarts, locate your laptop computer’s
CardBus slot.
6. Insert the Card into the slot. Apply pressure as needed
until it is fully seated.
En
P73890-A_F5U222ea_man.qxd 9/30/02 3:48 PM Page 7

8
7. After the Card is inserted, Windows will detect “NEC
USB Open Host Controller (E13+)” and “Belkin USB 2.0
Hi-Speed Host Controller”. The required driver support
will be automatically installed. No user input is required.
8. After installation of the USB host controllers, Windows will
detect “USB Root Hub” and automatically install the
required driver support. This will repeat one more time.
9. Restart your computer to complete the
installation procedure.
Verifying Proper Installation (Windows Me)
After installation, check the Windows Device Manager to
confirm that the Card has been properly installed.
1. Right-click on “My Computer” and select “Properties”.
2. Select the “Device Manager” tab.
3. Click on the plus sign (+) next to “Universal Serial
Bus Controllers”.
The “Universal Serial Bus Controllers” list will now include two
“NEC USB Open Host Controller (E13+)” entries, one “Belkin
USB 2.0 Hi-Speed Host Controller” entry, one “USB 2.0 Root
Hub Device” entry, and two “USB Root Hub” entries.
Note: If your computer features built-in USB ports, or if you
have other USB PCI controller cards installed, you will see
additional USB Controller and root hub entries.
Installation (continued)
P73890-A_F5U222ea_man.qxd 9/30/02 3:48 PM Page 8

Installation Procedure for Windows 2000
This installation procedure will install two USB 1.1 OHCI
controllers and one USB 2.0 EHCI host controller.
1. Insert the F5U222 installation CD into your CD-ROM
drive. After a few moments the main menu will
auto-start.
2. After the driver is installed, select “Yes, I want to restart
my computer now.” Click “Close”.
3. After Windows restarts, locate your laptop computer’s
CardBus slot.
4. Insert the Card into the slot. Apply pressure as needed
until it is fully seated.
5. After the Card is inserted, all required drivers will be
automatically installed. After the installation is complete,
you may be prompted to click “Finish” and to restart.
Verifying Proper Installation (Windows 2000)
After installation is complete, check the Windows Device
Manager to confirm that all components of the Card have
been properly installed.
1. Right-click on “My Computer”.
2. Select “Properties”.
3. Select the “Hardware” tab and click on the “Device
Manager” button.
4. Click the plus sign (+) next to “Universal Serial
Bus Controllers”.
9
Installation (continued) En
P73890-A_F5U222ea_man.qxd 9/30/02 3:48 PM Page 9

10
The “Universal Serial Bus Controllers” list will now include two
“NEC USB Open Host Controller” entries, one “Belkin USB 2.0
Hi-Speed Host Controller” entry, one “USB 2.0 Root Hub
Device” entry, and two “USB Root Hub” entries.
Note: If your computer features built-in USB ports, or if you
have other USB PCI controllers installed, you will see
additional root hub entries.
Installation Procedure for Windows XP
This installation procedure will successfully install two USB 1.1
OHCI controllers and one USB 2.0 EHCI host controller.
Important Note: There are two methods of installing the
required USB 2.0 drivers in Windows XP.
If you have an Internet connection:
Windows XP will check the Windows update website and
download the most recent version of Microsoft USB 2.0
support drivers. Please proceed to the “Without Internet
Connection” section.
If you do not have an Internet connection:
USB 2.0 drivers will be installed from the Belkin F5U222
installation CD. Please proceed to the “Without Internet
Connection” section.
Installation (continued)
P73890-A_F5U222ea_man.qxd 9/30/02 3:48 PM Page 10

11
With Internet Connection
1. Insert the Card into the slot. Apply pressure as needed
until it is fully seated.
2. Windows will now search for drivers for the “NEC PCI to
USB Enhanced Host Controller B1”, and the “New
Hardware Wizard” will start. Select “Install the software
automatically (Recommended)”. Click “Next”. Windows
XP will check the Windows update website and
download the most recent version of Microsoft USB 2.0
support drivers.
The installation procedure is now complete.
Without Internet Connection
1. Insert the F5U222 installation CD into your CD-ROM
drive. After a few moments, the main menu will
auto-start.
2. Select “Install USB 2.0 Driver”.
3. Windows will now display the following message:
“The software you are installing has not passed
Windows logo testing”. Ignore this message and select
“Continue Anyway”.
4. Windows will now prompt you to restart your computer.
Select “Yes, I want to restart my computer now”.
Click “Close”.
5. After Windows restarts, locate your laptop computer’s
CardBus slot.
6. Insert the Card into the slot. Apply pressure as needed
until it is fully seated.
Installation (continued) En
P73890-A_F5U222ea_man.qxd 9/30/02 3:48 PM Page 11

Installation (continued)
12
7. After the Card is inserted, Windows will install drivers for
the “Universal Serial Bus Controller”.
8. Windows will now detect “Belkin USB 2.0 Hi-Speed Host
Controller” and the “New Hardware Wizard” will start.
Select “Install the software automatically
(Recommended)”. Click “Next”.
9. Drivers for the “Belkin USB 2.0 Hi-Speed Host Controller”
will now be located. Windows will display the following
message: “The software you are installing has not passed
Windows logo testing”. Ignore this message and select
“Continue Anyway”.
10. Installation of the “Belkin USB 2.0 Hi-Speed Host
Controller” will now be completed. Click “Finish”.
11. Windows will now detect the “USB 2.0 Root Hub Device”.
Click “Next”.
12. Drivers for the “USB 2.0 Root Hub Device” will now be
located. Windows will display the following message:
“The software you are installing has not passed
Windows logo testing”. Ignore this message and select
“Continue Anyway”.
13. Installation of the “USB 2.0 Root Hub Device” is now
complete. Click “Finish”.
The installation procedure is now complete.
Verifying Proper Installation (Windows XP)
After installation, check the Device Manager to confirm that the
Card has been properly installed.
P73890-A_F5U222ea_man.qxd 9/30/02 3:48 PM Page 12

1. Right-click on “My Computer”.
2. Select “Properties”.
3. Select the “Hardware” tab and click on the “Device
Manager” button.
4. Click the plus sign (+) next to “Universal Serial
Bus Controllers”.
The “Universal Serial Bus Controllers” list will now include
two “NEC USB Open Host Controller” entries, one
“Belkin USB 2.0 Hi-Speed Host Controller” entry, one
“USB 2.0 Root Hub Device” entry, and two “USB Root
Hub” entries.
Note: If your computer features built-in USB ports, or if
you have other USB PCI controllers installed, you will
see additional root hub entries.
Installing a Hi-Speed USB 2.0 Hub
Note: During installation of a Belkin Hi-Speed USB 2.0
Notebook Card driver, a Hi-Speed USB 2.0 Hub driver
is also installed. When you attach a Hi-Speed USB 2.0
Hub to your Card for the first time, follow the
procedure described below.
1. Turn on your computer.
2. Plug the power adapter (ships with the hub) into the
hub and into a wall outlet.
3. Connect the flat end of the USB cable supplied with
the hub to your computer and the square end of the
cable to the upstream port of the hub.
13
Installation (continued) En
P73890-A_F5U222ea_man.qxd 9/30/02 3:48 PM Page 13

14
4. Windows will automatically detect the hub and start the
“Add New Hardware Wizard”. The wizard will search for
drivers for a “Generic USB Hub on USB 2.0 Bus”.
Click “Next”.
(If the search results list drivers for a “Generic USB Hub”
instead, cancel the wizard, go back to Device Manager
and confirm that the Belkin 2.0 drivers have been properly
installed.)
5. Choose “Search for the best driver for your device
(Recommended)”. Click “Next” to continue.
6. Windows will now search the driver database on your
hard drive. Remove the check mark from all boxes and
click “Next”.
7. Windows will locate the driver for “Generic USB Hub on
USB 2.0 Bus”. Click “Next”.
8. Click “Finish”. Installation of your hub is now complete.
Installation (continued)
P73890-A_F5U222ea_man.qxd 9/30/02 3:48 PM Page 14

15
FCC Statement
DECLARATION OF CONFORMITY WITH FCC RULES FOR
ELECTROMAGNETIC COMPATIBILITY
We, Belkin Components, of 501 West Walnut Street, Compton, CA 90220,
declare under our sole responsibility that the product:
F5U222
to which this declaration relates:
Complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may
cause undesired operation.
CE Declaration of Conformity
We, Belkin Components, declare under our sole responsibility that the F5U222, to which
this declaration relates, is in conformity with Generic Emissions Standard EN55022, EN55024,
and EN61000-3-2, EN61000-3-3 with Generic Immunity Standard.
ICES Statement
This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de
la classe B est conforme à la norme NMB-003 du Canada.
Belkin Components Limited Lifetime Product Warranty
Belkin Components warrants this product against defects in materials and workmanship for its
lifetime. If a defect is discovered, Belkin will, at its option, repair or replace the product at no
charge provided it is returned during the warranty period, with transportation charges
prepaid, to the authorized Belkin dealer from whom you purchased the product. Proof of
purchase may be required.
This warranty does not apply if the product has been damaged by accident, abuse, misuse, or
misapplication; if the product has been modified without the written permission of Belkin; or
if any Belkin serial number has been removed or defaced.
THE WARRANTY AND REMEDIES SET FORTH ABOVE ARE EXCLUSIVE IN LIEU OF ALL OTHERS,
WHETHER ORAL OR WRITTEN, EXPRESSED OR IMPLIED. BELKIN SPECIFICALLY DISCLAIMS
ANY AND ALL IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION, WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
No Belkin dealer, agent, or employee is authorized to make any modification, extension,
or addition to this warranty.
BELKIN IS NOT RESPONSIBLE FOR SPECIAL, INCIDENTAL, OR CONSEQUENTIAL
DAMAGES RESULTING FROM ANY BREACH OF WARRANTY, OR UNDER ANY OTHER
LEGAL THEORY, INCLUDING BUT NOT LIMITED TO LOST PROFITS, DOWNTIME,
GOODWILL, DAMAGE TO OR REPROGRAMMING, OR REPRODUCING ANY PROGRAM OR
DATA STORED IN OR USED WITH BELKIN PRODUCTS.
Information En
P73890-A_F5U222ea_man.qxd 9/30/02 3:48 PM Page 15

Belkin Components B.V.
Starparc Building • Boeing Avenue 333
1119 PH Schiphol-Rijk • The Netherlands
Tel: [phone]
Fax: [phone]
Belkin Components, Ltd.
Express Business Part
Shipton Way • Rushden • NN10 6GL • United Kingdom
Tel: [phone]
Fax: [phone]
Belkin Corporation
501 West Walnut Street
Compton • CA • 90220 • USA
Tel: [phone]
Fax: [phone]
Belkin Components, Ltd.
7 Bowen Crescent • West Gosford
NSW 2250 • Australia
Tel: [phone]
Fax: [phone]
© 2002 Belkin Corporation. All rights reserved.
All trade names are registered trademarks of respective manufacturers listed. P73890ea-A
Belkin Tech Support
US: 310.898.1100 ext. 2263
800.223.5546 ext. 2263
Europe: 00 800 223 55 460
Australia: 1800 666 040
P73890-A_F5U222ea_man.qxd 9/30/02 3:48 PM Page 16
