Belkin F5U222V User manual

P73890 F5U222
Belkin USB 2.0
Hi-Speed CardBus Card

Introduction
Welcome to USB 2.0!
Thank you for purchasing the Belkin USB 2.0 Hi-Speed
CardBus Card. Now you can upgrade your computer with the
latest USB technology. You will be able to take advantage of
a host of new high-speed USB 2.0 products that will be
introduced soon. USB 2.0 products–including hard drives,
scanners, printers, and video cameras–will all work much
faster than ever before. Your current USB devices will
continue to work as they always have, and in some cases
even better. Follow the simple installation instructions in this
manual to get your CardBus Card up and running, then enjoy
the speed and convenience of USB.
1

Features
2
• Three USB host adapters integrated into a single CardBus
Card, one USB 2.0 EHCI host controller providing 480Mbps of
USB bandwidth, and two USB 1.1 OHCI host controllers
providing 12Mbps of USB bandwidth each
• Two downstream high-speed USB ports
• Simultaneous connection capability of low-, full-, and
high-speed devices
• Auto-detection of new devices as they are connected, as well
as the speed of each new device
• Backward-compatibility with USB 1.1 devices
• Full compliance with USB specifications
• Plug-and-Play technology
• A Belkin Lifetime Warranty

• Open Host Controller Interface- (OHCI-) compliant
(USB 1.1 Host Controller)
• Enhanced Host Controller Interface- (EHCI-) compliant
(USB 2.0 Host Controller)
• PCI revision 2.1-compliant
• Current: 500mA per port
• USB revision 2.0-compliant
• 3.5mm DC power jack
• Power Supply
Input 100-120 VAC
Output 5 VDC 2.4 A
• Power Supply Polarity
Package Contents
• Belkin USB 2.0 Hi-Speed CardBus Card
• Optional 5-volt, 2.4-Amp power supply
• User Manual
• Driver Installation CD-ROM
Specifications
3

System Requirements
4
• PC-compatible laptop computer with available 32-bit
Type II CardBus slot
• Windows®98 SE, 2000, Me, or XP operating system
Operating System Compatibility
Operating System USB 1.x USB 2.0
Support Support
Windows 98 SE Yes Yes
Windows 2000 Yes Yes
Windows Me Yes Yes
Windows XP Yes Yes

Installation
Please refer to the section that corresponds to your Windows
operating system (OS).
Installation Procedure for Windows 98 SE OS
This procedure will install two USB 1.1 host controllers and
one USB 2.0 enhanced host controller.
(1) Plug the provided power supply into an AC wall outlet
or surge protector, then insert the DC power connector
into the power jack on the CardBus Card.
(2) Locate your laptop computer's CardBus slot.
(3) Insert the CardBus Card into the slot. Apply pressure
as needed until it is fully seated.
(4) Turn on power and start the Windows OS.
(5) Insert the Belkin USB 2.0 driver installation CD into
your computer's CD-ROM drive.
(6) The Windows OS will detect “NEC USB Open Host
Controller” and the “Add New Hardware Wizard”
dialog box will open. Click “Next”.
(7) Select “Search for the best driver for your device”
and click “Next”.
(8) Uncheck all the boxes and click “Next”.
(9) The Windows OS will find the driver for “NEC USB
Open Host Controller”. Click “Next”.
(10) The Windows OS may ask you for the Windows OS
installation CD. If asked, insert the CD into the CD-ROM
drive and follow the prompts.
(11) After the Windows OS installs the required drivers,
installation of the first USB 1.1 host controller is
complete. Click “Finish”.
5

Installation (continued)
6
(12) The “Add New Hardware” wizard will repeat the
installation process for the second USB 1.1 host controller.
(13) After installation of the two USB 1.1 host controllers, the
Windows OS will detect “PCI Universal Serial Bus”. This is
the USB 2.0 EHCI host controller.
(14) The “Add New Hardware Wizard” dialog box will open.
Click “Next”.
(15) Select “Search for the best driver for your device”
and click “Next”.
(16) Check the “CD-ROM drive” box. Click “Next”.
(17) The Windows OS will locate the driver for “Belkin USB
2.0 Hi-Speed Host Controller”. Click “Next”.
(18) The Windows OS will now install the enhanced host
controller driver. Click “Finish”.
(19) After installation of the USB host controllers, the Windows
OS will detect “USB Root Hub” and automatically install
the required driver support. This will repeat for each of
the two USB OHCI host controllers.
Installation is now complete.

7
Installation (continued)
Verifying Proper Installation (Windows 98/98 SE OS)
Check the “Windows Device Manager” to verify that your
CardBus Card has been properly installed.
(1) Right-click on “My Computer” and select “Properties”.
(2) Select the “Device Manager” tab.
(3) Click on the plus sign (+) next to “Universal Serial
Bus Controllers”.
The “Device Manager” list will now include two “NEC
USB Open Host Controller” entries, one “Belkin USB 2.0
Hi-Speed Host Controller” entry, and two additional “USB
Root Hub” entries.
Installation Procedure for Windows 2000 OS
This installation procedure will install two USB 1.1 host
controllers and one USB 2.0 enhanced host controller.
(1) Plug the provided power supply into an AC wall outlet or
surge protector, then insert the DC power connector into
the power jack on the CardBus Card.
(2) Locate your laptop computer’s CardBus slot.
(3) Insert the CardBus Card into the slot. Apply pressure
as needed until it is fully seated.
(4) Turn on power and start the Windows OS.
(5) Insert the Belkin USB 2.0 driver installation CD into your
computer’s CD-ROM drive.

8
(6) After loading, the Windows OS will detect “NEC PCI to
USB Open Host Controller”. The required driver support
will be automatically installed. No user input is required.
This will repeat one more time.
(7) The Windows OS will detect “Universal Serial Bus (USB)
Controller”. This is the USB 2.0 EHCI host controller. The
“Found New Hardware Wizard” window will appear. Select
“Search for a suitable driver for my device (recommended)”
and click “Next”.
(8) Check the “CD-ROM drive” box. Click “Next”.
(9) The Windows OS will find “Belkin USB 2.0 Hi-Speed Host
Controller”. Click “Next”.
(10)The Windows OS will now install the enhanced host
controller driver. Click “Finish”.
Installation is now complete.
Verifying Proper Installation (Windows 2000 OS)
After installation, check the “Windows Device Manager” to
verify that your CardBus Card has been properly installed.
(1) Right-click on “My Computer”.
(2) Select “Properties”.
(3) Select the “Hardware” tab and click on the “Device
Manager” button.
(4) Click the plus sign (+) next to “Universal Serial
Bus Controllers”.
Installation (continued)

The “Device Manager” list will now include two “NEC
USB Open Host Controller” entries, one “Belkin USB 2.0
Hi-Speed Host Controller” entry, and two additional “USB
Root Hub” entries.
Installation Procedure for Windows Me OS
This installation procedure will install two USB 1.1 host
controllers and one USB 2.0 enhanced host controller.
(1) Plug the provided power supply into an AC wall outlet or
surge protector, then insert the DC power connector into
the power jack on the CardBus Card.
(2) Locate your laptop computer’s CardBus slot.
(3) Insert your CardBus Card into the slot. Apply pressure
as needed until it is fully seated.
(4) Turn on power and start the Windows OS.
(5) Insert the Belkin USB 2.0 driver installation CD into your
computer’s CD-ROM drive.
(6) After loading, the Windows OS will detect “NEC USB
Open Host Controller (E13+)”. The required driver
support will be automatically installed. No user input
is required.
(7) The Windows OS will detect “PCI Universal Serial Bus”.
This is the USB 2.0 EHCI controller. The “Add New
Hardware Wizard” window will appear.
(8) Select “Automatic search for a better driver
(recommended)”. Click “Next”.
(9) Check the “CD-ROM drive” box. Click “Next”.
9
Installation (continued)

10
(10)The Windows OS will locate the driver for “Belkin USB
2.0 Hi-Speed Host Controller”. Click “Next”.
(11)The Windows OS will now install the USB 2.0 enhanced
host controller driver. Click “Finish”.
(12)The Windows OS will detect “NEC USB Open Host
Controller (E13+)”. The required driver support will be
automatically installed. No user input is required.
(13)After installation of the USB host controllers, the Windows
OS will detect “USB Root Hub” and automatically install the
required driver support. This will repeat one more time.
Installation is now complete.
Verifying Proper Installation (Windows Me OS)
After installation, check the “Windows Device Manager” to
verify that the CardBus Card has been properly installed.
(1) Right-click on “My Computer” and select “Properties”.
(2) Select the “Device Manager” tab.
(3) Click on the plus sign (+) next to “Universal Serial
Bus Controllers”.
The “Device Manager” list will now include two “NEC USB
Open Host Controller (E13+)” entries, one “Belkin USB 2.0
Hi-Speed Host Controller” entry, and two additional “USB
Root Hub” entries.
Installation (continued)

11
Installation Procedure for Windows XP OS
(1) Plug the provided power supply into an AC wall outlet or
surge protector, then insert the DC power connector into
the power jack on the CardBus Card.
(2) Locate your laptop computer’s CardBus slot.
(3) Insert your CardBus Card into the slot. Apply pressure as
needed until it is fully seated.
(4) Turn on power and start the Windows OS.
(5) Insert the Belkin USB 2.0 driver installation CD into your
computer’s CD-ROM drive.
(6) After loading, the Windows OS will detect “NEC PCI to
USB Open Host Controller”. The required driver support
will be automatically installed. No user input is required.
This will repeat one more time.
(7) The Windows OS will detect “Universal Serial Bus”.
Choose “Install the software automatically
(recommended)”. Click “Next”.
(8) The Windows OS will locate the driver for “Belkin
USB 2.0 Hi-Speed Host Controller”. The Windows OS
may display a message indicating that the driver that you
are installing has not passed “Windows Logo testing”.
Click “Continue Anyway”.
(9) The Windows OS will now install the enhanced host
controller driver. Click “Finish”.
(10)The Windows OS will detect “USB Root Hub”. The
required driver support will be automatically installed.
This will repeat two times.
Installation is now complete.
Installation (continued)

Installation (continued)
12
Verifying Proper Installation (Windows XP OS)
After installation, check the “Windows Device Manager” to
confirm that the CardBus Card has been properly installed.
(1) Right-click on “My Computer”.
(2) Select “Properties”.
(3) Select the “Hardware” tab and click on the “Device
Manager” button.
(4) Click the plus sign (+) next to “Universal Serial
Bus Controllers”.
The “Device Manager” list will now include two “NEC
USB Open Host Controller” entries, one “Belkin USB 2.0
Hi-Speed Host Controller” entry, and two additional “USB
Root Hub” entries.
Before ejecting the CardBus Card from your laptop’s CardBus
slot, you must use the PC card utility provided by your laptop
manufacturer to disable the CardBus Card. Failure to follow this
step may cause your operating system to freeze, requiring a
system restart. An icon representing the PC card utility program
will normally be found in the system tray found in the lower
right-hand corner of the Windows display, or in the Windows
Control Panel.
Safe Removal of the CardBus
Card from your Laptop

Information
FCC Statement
DECLARATION OF CONFORMITY WITH FCC RULES FOR
ELECTROMAGNETIC COMPATIBILITY
We, Belkin Components, of 501 West Walnut Street, Compton, CA 90220,
declare under our sole responsibility that the product:
F5U222
to which this declaration relates:
Complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this
device must accept any interference received, including interference that may
cause undesired operation.
CE Declaration of Conformity
We, Belkin Components, declare under our sole responsibility that the F5U222, to which
this declaration relates, is in conformity with Generic Emissions Standard EN55022, EN55024,
and EN61000-3-2, EN61000-3-3 with Generic Immunity Standard.
ICES Statement
This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de
la classe B est conforme à la norme NMB-003 du Canada.
Belkin Components Limited Lifetime Product Warranty
Belkin Components warrants this product against defects in materials and workmanship for its
lifetime. If a defect is discovered, Belkin will, at its option, repair or replace the product at no
charge provided it is returned during the warranty period, with transportation charges
prepaid, to the authorized Belkin dealer from whom you purchased the product. Proof of
purchase may be required.
This warranty does not apply if the product has been damaged by accident, abuse, misuse, or
misapplication; if the product has been modified without the written permission of Belkin; or
if any Belkin serial number has been removed or defaced.
THE WARRANTY AND REMEDIES SET FORTH ABOVE ARE EXCLUSIVE IN LIEU OF ALL OTHERS,
WHETHER ORAL OR WRITTEN, EXPRESSED OR IMPLIED. BELKIN SPECIFICALLY DISCLAIMS
ANY AND ALL IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION, WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
No Belkin dealer, agent, or employee is authorized to make any modification, extension,
or addition to this warranty.
BELKIN IS NOT RESPONSIBLE FOR SPECIAL, INCIDENTAL, OR CONSEQUENTIAL
DAMAGES RESULTING FROM ANY BREACH OF WARRANTY, OR UNDER ANY OTHER
LEGAL THEORY, INCLUDING BUT NOT LIMITED TO LOST PROFITS, DOWNTIME,
GOODWILL, DAMAGE TO OR REPROGRAMMING, OR REPRODUCING ANY PROGRAM OR
DATA STORED IN OR USED WITH BELKIN PRODUCTS.

© 2001 Belkin Components. All rights reserved.
All trade names are registered trademarks of respective manufacturers listed. P73890
Belkin Components B.V.
Starparc Building • Boeing Avenue 333
1119 PH Schiphol-Rijk • The Netherlands
Tel: [phone]
Fax: [phone]
Belkin Components, Ltd.
Unit 13 • Gatelodge Close • Round Spinney
Northampton • Northants • NN3 8RX • United Kingdom
Tel: [phone]
Fax: [phone]
Belkin Components
501 West Walnut Street
Compton • CA • 90220 • USA
Tel: [phone]
Fax: [phone]
Belkin Components, Ltd.
7 Bowen Cresent • West Gosford
NSW 2250 • Australia
Tel: [phone]
Fax: [phone]
