Belkin F1DN002R User manual

SECURE DESKTOP
CONTROLLER UNIT (DCU)

THE PROBLEM
How can a user be extended
from his secure KVM?

THE CHALLENGE
Simple desktop appliance
to control a Secure KVM

1 2 3 4 KVM Switch
Computers
User’s desktop
Computer Room
DCU
Audio Mouse
Keyboard
Display
CAC Reader
4
3
2
1
F1DN002R
Channel
CAC
1 Internet
2 Secure AF
3 Classified ERP
4 Navy OP
CAC
THE BELKIN SECURE DESKTOP CONTROLLER UNIT (DCU)
Simple remote control device
for Belkin Secure KVM and KM

THE BELKIN SOLUTION
Belkin Secure DCU (F1DN002R and F1DN003R)
• Remote Control of a Secure KVM and KM
• Clearly show the active computer
• Easily switch between channels
F1DN002R F1DN003R

BELKIN SECURE KVM SWITCHES
The Belkin Secure DCU is a remote control device used in conjunction with Belkin Secure KVM
and KM Switches. Belkin Secure DCU models F1DN002R can connect to Belkin Secure KVM
and KM Switches with up to four channels, and model F1DN003R can also connect to KVMs
with 8 or 16 channels.
Every Belkin Secure DCU connects to the clearly labeled DCU port on the back of the Secure KVM.
DCU Model F1DN002R
F1DN104P
DCU Port
DCU Port
F1DN108C
DCU Model F1DN003R
DCU Port
DCU Port

REMOTE CONTROL OF KVM
Problem:
• Operator may tamper with KVM, computer or network connections
• Desktop is cluttered with many appliances
Solution:
• Distance Secure KVM from computer users
• Separate working environment from computers
and communication
• De-clutter the working environment to optimize operator efficiency
• Concentrate computing resources in a protected environment, away from tampering, physical
damage or harsh environments

SITUATIONAL AWARENESS
Problem:
• Hard to identify the active computer on a KVM
• Easy to confuse separate working environments
Solution:
• Programmable easy to read text
and color indicates currently active
connected computer

IDENTIFY COMPUTER RESOURCES
Problem:
• Operator is confused by up to 16 connected computers
• Same user can access secure and unsecure networks
Solution:
• Configure custom name and color
for each computer resource
• Secure KVM separates secure
and unsecure networks
Computers
Computer Room
1
2
3
4
5
6
7
8
9 10 11 12
13
14
15
16
KVM Switch
User’s desktop
Audio Mouse
Keyboard
Display
CAC Reader
DCU
F1DN003R
Channel
CAC
9 Internet
10 Secure AF
11 Classified
12 Navy OP
CAC
F1DN003R
Channel
CAC
9 Internet
10 Secure AF
11 Classified
12 Navy OP
CAC

SYNCHRONIZE COMPUTERS WITH PERIPHERALS
Problem:
• USB device controlled separately from computer
• Active computer and peripheral do not synchronize
• Web camera continues sending a video feed
to an inactive computer, after the operator
switches computers on the KVM
Solution:
• DCU synchronizes KVM channel
with corresponding USB device
1 2 3 4
User’s desktop
Computer Room
DCU
MouseKeyboard
WebCam
KVM
USB Switch
Computers
Display Display
4
3
2
1
F1DN002R
Channel
CAC
1 Internet
2 Secure AF
3 Classified ERP
4 Navy OP
CAC

WHY IS THE BELKIN SECURE DCU THE PERFECT SOLUTION
Ideal in a high performance, high security environment:
• High Performance work:
◦User quickly glances to identify the active
KVM channel
◦Easy to identify, administrator programmable
channel name and color
• High-security environment:
◦Users cannot physically access computing
resources
◦Computers, KVMs, and communication
infrastructure in locked and safe environment
◦User can only select KVM channels available
in DCU
1 2 3 4 KVM Switch
Computers
User’s desktop
Computer Room
DCU
Audio Mouse
Keyboard
Display
CAC Reader
4
3
2
1
F1DN002R
Channel
CAC
1 Internet
2 Secure AF
3 Classified ERP
4 Navy OP
CAC

EASY TO CONNECT
Easy connection:
• Single cable connects Secure DCU to Secure KVM
• No hubs, switches or routers
• Tamper-proof connection disables
Secure DCU when disconnected
from Secure KVM
• Special cable connects
to remote computer or
Secure USB Switch
External Keyboard
USB Switch or Computer
Secure KVM
Unlock SD Card
F1DN002/3R

EASY TO CONFIGURE
Configure with Secure Desktop Controller Administrator Kit:
• Configure name, color and language of each channel
• Connect external USB keyboard with Mini-USB adapter
• Unlock configuration with Unlock SD card
• Save, distribute and load configuration files on SD card
Conguration
KVM
Unlock SD card
Channel Color Configuration
Channel Name Configuration
External Keyboard
Mini-USB
Adapter Cable
DCU
F1DN003R
Customize 1 Channel
Language
Color
Name
Exit
US
External Keyboard
Mini-USB
Adapter Cable
DCU
1234567890
Q W E R T Y U I O P
A S D F G H J K L
Z X C V B N M
F1DN003R
Customize 1 Channel
Language
Color
Name
Exit
US
Secure AF
1 2 3 4
1 2 3 4
Channel Color Configuration
Channel Name Configuration
External Keyboard
Mini-USB
Adapter Cable
DCU
F1DN003R
Customize 1 Channel
Language
Color
Name
Exit
US
External Keyboard
Mini-USB
Adapter Cable
DCU
1234567890
Q W E R T Y U I O P
A S D F G H J K L
Z X C V B N M
F1DN003R
Customize 1 Channel
Language
Color
Name
Exit
US
Secure AF
1 2 3 4
1 2 3 4

KEY FEATURES AND BENEFITS…
• Only product of its kind
The Belkin Secure DCU is the only available
remote control for a Secure KVM Switch
• 4 to 16-port Capability
F1DN002R supports up to 4 ports.
F1DN003R supports up to 16 ports
• Easy Configuration and Distribution
Easy configuration menu and option
selection. Save configuration files to SD
card and load to other Secure DCUs
• Support for Belkin KVM Switches
Belkin DCU is supported by most of Belkin’s
Advanced Secure KVM switches:
◦Windowing KVM
F1DN204M-3
◦KM Switches
F1DN104K-3, F1DN108K-3
◦Advanced KVM Switches
F1DN108F-3, F1DN108C-3, F1DN116C-3

KEY FEATURES AND BENEFITS…
• Remote Control
Control your Secure KVM Switch and
computers remotely, reducing desktop
clutter, increasing work space, and
enhancing security
• Synchronize Peripherals
Synchronize Secure KVM with Secure USB
Switch, automatically connecting a common
peripheral to the active computer
• Secure Installation
Install Secure KVMs up to 50 feet away,
restricting access to sensitive resources
• Anti-Tamper Features
Tear off packaging, tamper-evident label
and active anti-tampering mechanism
verify that the Secure DCU remains secure
and protected

FREQUENTLY ASKED QUESTIONS
• What is the difference between a DCU and a KVM?
KVMs are designed to switch between active computers, allowing the user to only see and manage one
target device at a time. The Secure DCU controls the KVM remotely. The computers, mouse, keyboard
and displays all connect to the KVM, but the DCU controls the KVM’s functions. The Secure DCU
sits on the user’s desktop, but the Secure KVM can be up to 50 ft. away from user access, protecting
critical resources.
• When should a Belkin Secure DCU be used?
A Secure DCU should be used when performance and
reduced operator error are important. A quick glance shows the active channel. The user changes
channels with a simple push of a button.
The Secure DCU also provides additional security. All computer hardware, connections and
communication can be located up to 50 ft. away from the user, who can only access the keyboard,
mouse, display and Secure DCU.

FREQUENTLY ASKED QUESTIONS
• How many computers can I control?
Belkin Secure DCU models F1DN002R can control up to 4 computers. Model F1DN003R can control up
to 16 computers. F1DN002/3R can connect to 1 Secure KVM
and to 1 Secure USB Switch.
• How far can the Secure DCU be from the Secure KVM?
The Belkin Secure DCU connects to the Secure KVM using a special 6 ft. or 50 ft. cable.
• Are Belkin DCUs as secure as Belkin KVM Switches?
Yes, they create an even more secure environment than Secure KVMs alone. The Belkin Secure DCU
complements the award winning Belkin Secure KVM product line, and is equipped with the same high security
features: Active Always-On Anti-Tampering, Heavy-Duty Tamper-Resistant Enclosure, Tamper Evident Label,
USB Port Protection, Non- Reprogrammable Firmware, and more. Isolating the working environment from the
KVM and its connected computers provides extra protection to critical computing resources.

FREQUENTLY ASKED QUESTIONS
• Does the Belkin Secure DCU require software drivers?
No. The Belkin Secure DCUs do not connect to any computers. They only connect to Belkin Secure
KVMs and Secure USB Switch.
• Can I use a Secure DCU with multiple-display computers?
Yes. The Belkin Secure DCU can connect to any of Belkin’s Secure KVM, KM and Windowing KVM
switch.

BACK UP SLIDES

CHAINING SECURE USB SWITCH AND SECURE KVM THROUGH DCU
• Belkin Secure USB Switch enables connecting a single shared USB device with up to 4
computers.
• Belkin Secure DCU connects to both Secure KVM and USB Switches, selecting the same
channel on both devices.
• The Belkin Secure DCU is the only solution that maintains security by automatically
connecting the USB device only with the computer selected by the KVM switch.
AUX Port
KVM Port
DCU
DCU Port
USB Switch Back
DCU Port
KVM Switch Back
