Getting to know the Belkin Thunderbolt™ 3
Express Dock HD, F4U095
The Belkin Thunderbolt™ 3 Express Dock HD, F4U095 is an all-in-one docking solution that
connects all your peripherals and powers your computer with a single cable. It can daisy chain up to
five (5) Thunderbolt™ devices from the dock and can connect eight (8) separate devices using a
Thunderbolt™ cable. This dock has 40 Gbps speed that is twice the bandwidth of Thunderbolt™ 2
and 8x faster than USB 3.0.
Product Features
Three (3) USB-A 3.0
Two (2) Thunderbolt™ 3 (USB-C)
One (1) Gigabit Ethernet
One (1) DisplayPort™
Audio port (in / out)
Audio port (out)
One (1) Thunderbolt™ 3 cable
170 W Power Adapter
Supports Ghost Charging
Dual 4K video output (DisplayPort™, Thunderbolt™ 3 (USB-C))
85 W Power Delivery (PD) powers your computer through .5 m Thunderbolt™ (40 Gbps)
cable
2-Year Limited Warranty
LED Behavior
Connection Status–LED indicator in front of the express dock
Green if host device is plugged-in correctly
Amber if nothing is plugged in

Package Inclusions
Belkin Thunderbolt™ Express Dock HD
Belkin Thunderbolt™ 3 Cable
Power Adapter
Setting up the Belkin Thunderbolt™ 3
Express Dock HD, F4U095
The Belkin Thunderbolt™ 3 Express Dock HD, F4U095 is an all-in-one docking solution that
connects all your peripherals and powers your computer with a single cable. This article will guide
you on how to install the Belkin F4U095.
NOTE: Make sure that your host device (laptop or computer) has the latest driver information. Visit
the host device manufacturer’s website to make sure you have the latest updates.
Step 1:
Connect the AC power cable to the included power supply unit.
Step 2:
Plug the power supply into the wall.
Step 3:
Plug the power supply into the Belkin Thunderbolt™ 3 Express Dock HD.
NOTE: Before connecting the dock to your computer, connect all your preferred devices to the
Ethernet, Audio, USB 3.0, DisplayPort™ and Thunderbolt™ 3 ports. You may use one of the
Thunderbolt™ 3 ports for your devices but make sure that the remaining Thunderbolt™ port must be
left open to connect the dock to your computer.
Step 4:
Connect one end of the Thunderbolt™ cable into the open Thunderbolt™ 3 port on the dock.
Step 5:
Plug the other end of the cable into your computer.
Step 6:
Turn ON your computer.
