Belkin F1DJ102Puk Installation instructions

2-Port KVM Switch
Control two computers using one video monitor
and a PS/2 keyboard and mouse
3-Year Manufacturer’s
Warranty and
Free Technical Support
PS/2
• Includes 2 KVM
cables kits
• Offers a complete
compact solution
• Features hot
key switching
• Supports video
resolutions up to
1920x1440@65Hz
P44846uk_F1DJ102Puk_pkg.qxd 30-09-2003 11:15 Page 1

Our KVM Switch (the Switch) is an affordable switching solution that saves workspace while giving you
control of two PS/2 computers from one console. It frees up desktop space and draws power off the
keyboard, eliminating the need for a power supply. The Switch includes such features as mouse and
keyboard emulation, to ensure smooth boot up and operation, as well as hot key functionality so you
can switch ports easily through simple keyboard commands. The unit supports high-quality video
resolution of up to 1920x1440@65Hz (through a 200MHz video bandwidth) when used with coaxial
VGA cabling. Its auto-scanning functionality, LED indicators, and PC99 color connectors make operation
and organization easy.
Benefits:
•Includes automatic scanning function
•Supports multiple operating systems
•Requires no power supply
•Offers keyboard and mouse emulation
•Comes with a Belkin Three-Year Manufacturer’s
Warranty and Free Technical Support
Product Specifications
Part No.:
F1DJ102Puk
Power:
Optional 9V DC, 600mA AC adapter
with center-pin positive polarity
PCs Supported:
2
Keyboard Emulation:
PS/2
Mouse Emulation:
PS/2 and Serial (with use of adapter)
Monitors Supported:
VGA and SVGA, MultiSync®, LCD
(with use of adapter cable)
Max Resolution:
1940x1440@65Hz
Keyboard Input:
6-pin miniDIN (PS/2)
Mouse Input:
6-pin miniDIN (PS/2)
VGA Port:
15-pin HDDB type
LED Indicators:
2
Enclosure:
Plastic
Dimensions:
(H) 1.125 x (W) 7.0 x (D) 3.75 inches
Weight:
9oz.
Operating Temp:
32° to 104° F
Storage Temp:
-4° to 140° F
Humidity:
0-80% RH, non-condensing
Warranty:
3 Year
Operating Systems
Windows® 3.x, 95, 98, 2000, Me, NT®, XP,
DOS, Linux®, Novell®, NetWare® 4.x, 5.x
Package Contents
2-Port KVM Switch
User Manual
Quick Installation Guide
Registration Card
Recommended Cables
F1D9000-XX (PS/2 Style)
(-XX denotes the length in feet)
Optional Power Supply
F1D065-PWR (9V DC, 600mA AC)
722868 49744 9
F1DJ102PukB
Made in China
© 2003 Belkin Corporation. All rights reserved.
All trade names are registered trademarks of
respective manufacturers listed.
P44846uk
Belkin Corporation
310.898.1100
Compton • CA • USA
Belkin Components, Ltd.
[phone]
Rushden • United Kingdom
Belkin Components B.V.
[phone]
Schiphol-Rijk • The
Netherlands
Belkin GmbH
[phone]
München • Germany
N10117
2-Port KVM Switch
Control two computers using one video monitor
and a PS/2 keyboard and mouse
PS/2
Includes
2 KVM
Cable Kits
