Thank you for purchasing the Belkin Components OmniView™PRO KVM switch.
Controlling 16 PCs from one keyboard, mouse and monitor has never been easier!
The OmniView™PRO gives you the ultimate in control. Compatible with AT and PS/2
style computers, it is loaded with features such as On-Screen Display, Integrated
Mouse Conversion Technology and separate DB25 daisy-chain ports. It has
complete keyboard and mouse emulation for error-free boot-ups, plus Microsoft®
Intellimouse®support. The OmniView™PRO is also designed to handle the most
demanding resolutions up to 1600 x 1200, without any noticeable degradation in image
quality. Switching can be done through the advanced On-Screen Display Menu,
convenient front-panel pushbutton, or keyboard hot-key commands. And if you wish
to control a Macintosh®computer, simply add the Belkin MAC®Adapter™for even more
system control. To control a SUN workstation, use a Belkin SUN adapter. The OmniView™
PRO truly gives you ultimate control over all of your systems.
1
Introduction
F1D116_OSD_AM_man.qxd 4/20/00 4:07 PM Page 1

•Allows a user to control sixteen computers from one keyboard, mouse and monitor
•On-Screen Display menu gives the user a visual interface for naming and selecting
computers
•Integrated Mouse Conversion Technology allows connection of AT-style computers
that have serial mouse ports while using a PS/2 mouse only at the console
•Keyboard and mouse emulation for error-free boot-ups
•Microsoft®Intellimouse®support and emulation
•Up to 1600 x 1200 resolution support
•DB25 daisy-chain ports - allows control over as many as 256 computers through
16 banks of OmniView™PRO units
•Supports both AT and PS/2 style keyboards (AT requires AT-PS/2 adapter)
•Supports VGA, SVGA and Multisync monitors
•Uses inexpensive and commonly found standard cables
•On-Screen Display, pushbutton or keyboard Hot key command switching
•AutoScan mode for even more convenience
•Audible feedback when switching
•Recalls CAPS LOCK, NUM LOCK and SCROLL LOCK keys' status for each computer
automatically
•Front-panel status LEDs
•Works with OmniView™PS/2 MAC Adapters™ and SUN Adapters
•No software required
•One year product warranty
Package Contents:
OmniView™PRO 16-Port F1D116-OSD
12VDC, 1000mA power supply F1D108-PWR
This manual P73233
Registration card P72009
Two rackmount brackets F1D116-BRKT
with mounting screws
Four combo mouse adapters F1D116xMSE
2
Features
F1D116_OSD_AM_man.qxd 4/20/00 4:07 PM Page 2

En
3
Technical Specifications
Console Connectors:
Keyboard: 6 pin MiniDIN
Mouse: 6 pin MiniDIN (for PS/2 mouse)
Monitor: HDDB15 female
Computer Port Connectors:
Keyboard: 6 pin MiniDIN
Mouse: 6 pin MiniDIN (combo; PS/2 and serial mouse)
Monitor: HDDB15 male
Dimensions:
Width: 17.5" (444.5 mm)
Height: 3.5" (88.9 mm)
Depth: 8.0" (203.2 mm)
Weight: 10 lbs. (4.54 kg) est.
Operating Temp: 32 to 104 deg. F (0~40 deg. C)
Storage Temp: -4 to 140 deg. F (-20 ~ 60 deg. C)
Humidity: 0~80% RH, non-condensing
F1D116_OSD_AM_man.qxd 4/20/00 4:07 PM Page 3

FRONT PANEL
REAR PANEL
Power
Switch
Port Select Button
Bank Select/Scan Button
Current Active
Bank Display
Current Active
Port Displays
4
Product Detail
SLAVE INPUT
DB25 daisy-chain port master input/slave output DB25 daisy-chain port
Current Active
Bank Display Current Active
Port Display
Bank Select/Scan Button Port
Select/Scan
Button
Power
Switch
PC Port Connectors
DC power
jack.
DIP
Switches Keyboard
Connector
P/S 2 Mouse
Connector Keyboard
Output Combo (PS/2 mouse or
serial mouse) output
VGA signal
output
VGA Monitor Connector
F1D116_OSD_AM_man.qxd 4/20/00 4:07 PM Page 4

En
Make sure you have the right cables!
The OmniView™PRO requires cables to connect the sixteen computers you will be
controlling. Below are the Belkin part numbers and their descriptions. We recommend
purchasing Cable Kits based on the type of mouse port your computer uses. One cable
kit has all the cables you need to connect one computer to the OmniView™PRO 16-
Port:
PS/2 Cable Kit - A3X983
Includes:
•2 x F2N036-06
•1 x F3H981-06
(see below for descriptions of each)
AT Cable Kit - A3X1848
Includes:
•1 x F3A510-06
•1 x F3H981-06
•1 x F2N209-06-T
•1 x F2N017
(see below for descriptions of each)
Individual Cables and Adapters:
•PS/2 cable for keyboard and mouse ports
6 pin MiniDIN male/male
Part# F2N036-XX
•High-resolution/high-refresh rate VGA cable for monitor port
HDDB15 male/female with thumbscrews
Part# F3H981-XX
•Serial extension cable for serial mouse
DB9 male/female with thumbscrews
Part# F2N209-XX-T
•AT keyboard cable for AT-style keyboard port
5 pin DIN male/male
Part# F3A510-XX
•AT to PS/2 keyboard adapter
5 pin DIN female/6 pin MiniDIN male
Part# F2N017
Other Cables and Adapters:
•Standard VGA cable for monitor port
HDDB15 male/female with thumbscrews
Part# F2N025-XX-T
• PS/2 to AT keyboard adapter - for use with a computer having an AT-style keyboard port
6 pin MiniDIN female/ 5 pin DIN male
Part# F2N018
NOTE: The “-XX” in the part number represents the length in feet.
For cable kits in longer lengths, please contact your Belkin Sales Representative.
5
6 pin MiniDIN
HDDB15
5 pin
DIN Female
6 pin
MiniDIN
Male
6 pin MiniDIN
DIN Female
5 pin
DIN Male
Note:
Cable kits are also available
with standard VGA cables
(F2N025-XX-T) under part
numbers:
A3X982 - PS/2 Cable Kit
A3X939 - AT Cable Kit
F1D116_OSD_AM_man.qxd 4/20/00 4:07 PM Page 5

6
Single-unit operation or Daisy-chained operation
The OmniView™PRO has the capability to be daisy-chained to 15 more units (for a total
of 16), giving the user control over a maximum of 256 computers!
Each OmniView™PRO unit is defined as a “BANK.” See diagram above for more
information. BANK numbers range from 0 to F (hexadecimal), for a total of 16 BANKs.
BANK 0 is the MASTER bank, while banks 1 through F are slave banks. The MASTER
bank is the unit that connects to the console keyboard, mouse, and monitor.
The DIP switches must be set correctly for proper identification and usage. See the next
section for the actual settings. If you are using the OmniView™PRO in a single-unit
configuration, it must be set as the MASTER (BANK 0). If it is to be used as a slave
unit, then it must be set to any unused unique bank number from 1 through F.
BANK 0 (MASTER)
BANK 1 (SLAVE)
BANK 2 (SLAVE)
BANK F (SLAVE)
ETC... ETC...
F1D116_OSD_AM_man.qxd 4/20/00 4:07 PM Page 6

En
7
1. Set the DIP switches. If you have only one OmniView™PRO, use the MASTER
bank setting. If the OmniView™PRO you are using will be daisy-chained off
another unit, use a unique slave setting. Please refer to the previous section
for more information.
DIP SWITCH #
3456
ON ON ON ON BANK 0 MASTER
OFF ON ON ON BANK 1 slave
ON OFF ON ON BANK 2 slave
OFF OFF ON ON BANK 3 slave
ON ON OFF ON BANK 4 slave
OFF ON OFF ON BANK 5 slave
ON OFF OFF ON BANK 6 slave
OFF OFF OFF ON BANK 7 slave
ON ON ON OFF BANK 8 slave
OFF ON ON OFF BANK 9 slave
ON OFF ON OFF BANK A slave
OFF OFF ON OFF BANK B slave
ON ON OFF OFF BANK C slave
OFF ON OFF OFF BANK D slave
ON OFF OFF OFF BANK E slave
OFF OFF OFF OFF BANK F slave
NOTE: “ON” is down
2. Find a convenient place to put your OmniView™PRO. Its 19" form factor makes it
ideal for 19" racks. When mounting to a rack, attach the included brackets to the
sides of the OmniView™PRO. Take note of the length of your cables so that your
computers, OmniView™PRO, keyboard, mouse, and monitor are distanced properly.
PLEASE FOLLOW THIS INSTALLATION PROCEDURE EXACTLY. NOT DOING SO MAY
RESULT IN KEYBOARD AND/OR MOUSE ERRORS, OR FAULTY OPERATION.
WARNING: Before attempting to connect anything to the OmniView™
PRO or the computers, make sure everything is powered off. Plugging and
unplugging cables may cause irreversible damage to your computers and
the OmniView™PRO. Belkin Components will not be held responsible for
damage caused.
Hardware Installation
BANK ADDRESS
