Belkin THUMB HUB F5U218-MOB User manual

F5U218-MOB
Hi-Speed USB 2.0 Thumb Hub
User Manual
Add 4 additional Hi-Speed USB 2.0 ports to your notebook

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . .3
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
TABLE OF CONTENTS

1
Congratulations and thank you for purchasing the Belkin
Hi-Speed USB 2.0 Thumb Hub (the Hub). The Hub provides four
downstream USB ports that are compatible with both USB 1.1
(low- and full-speed) devices, as well as with Hi-Speed USB 2.0
(high-speed) devices.
This means that the Hub is backward-compatible with all of your
current USB 1.1 devices as well as with the new generation of
Hi-Speed USB 2.0 devices. This may include such peripherals as
scanners, printers, mass storage devices, and high-resolution
cameras. The Hub is self-powered, which allows the cascading of
devices with additional hubs, so that up to 127 USB devices can
be connected to a single port. For additional information, please
refer to the Technical Specifications section.
INTRODUCTION

2
Features
• Compliant with Universal Serial Bus specification 2.0
(data rate 1.5/12/480Mbps)
• Backward-compatible with Universal Serial Bus specification 1.1
(data rate 1.5/12Mbps)
• Compatible with Windows® 98 SE, Me, 2000, and XP
• Approved by USB Implementers Forum (USB-IF)
• Plug-and-Play technology
• Hot-swappable with USB devices
• Over-current detection and protection
• Four 480Mbps downstream ports
• Fully compatible with USB 1.1 and USB 2.0 devices
• Operates without power supply when used with low-power devices
such as standard keyboards* and mice
• Compact, slim-line design
• 9 in. USB extension cable included
*Note: Keyboards that are equipped with built-in USB hubs require more than
100mA to operate. If connecting one of these keyboards to the Hub,
be sure to use the included power supply.
Package Contents
• Hi-Speed USB 2.0 Thumb Hub
• AC Power Adapter
• USB extension cable
• User Manual
INTRODUCTION

3
Technical Specifications
Upstream Ports 1
Downstream Ports 4
Per-Port Voltage DC +5V
Per-Port Current 500mA (max) (Self-Powered mode)
100mA (max) (Bus-Powered mode)
Power Mode Self-Powered/Bus-Powered
Operating Temperature 5º C ~ 40º C
Storage Temperature -2º C ~ 60º C
Enclosure Plastic
Power Supply
Output: DC 5V 2.1A
Plug Size: 3.5mm (outer)
1.0mm (center)
10mm (length)
Plug Polarity: Center Positive
Main Power LED Color
Definitions:
Off Not Operational
Red Operational
INTRODUCTION

4
INSTALLATION
1. Plug the AC adapter into a wall outlet or surge suppressor. Plug the DC
connector into the DC power jack found on the side of the Hub (see Fig. 1).
A red light on the Hub should come on indicating that the Hub is getting
power from the power supply, or from the USB port (if the Hub is being
operated without the power supply).
Note: The Hub may be used without the power supply when connecting low-power
devices such as standard keyboards and mice.
2. Next, connect your Thumb Hub either to a 2.0- or 1.1-compliant USB
connection on your PC, either through the extension cable or directly to
the PC.
Important Note: The Hub must be connected to a USB 2.0-compliant host in
order to function in high-speed mode (480Mbps data rate). If the Hub is
connected to a USB 1.1-compliant host, it will operate only in low-speed or
full-speed mode (1.5Mbps/12Mbps).
3. Your Windows operating system will now detect your Hub and install the
required driver support. (The Windows “Install New Hardware Wizard” may
prompt you to provide your Windows Installation CD to complete the driver
installation process).

5
INSTALLATION
Important Note: Hi-Speed USB 2.0 hub drivers are included with most USB 2.0
PCI upgrade cards, and are pre-installed along with the PCI card drivers. If you
purchased an upgrade card prior to the release of Hi-Speed USB 2.0 hub support,
please check with your PCI card vendor for an updated USB 2.0 driver. The Belkin
Hi-Speed USB 2.0 driver supports all competitive cards based on the NEC host
controller with the exception of Adaptec. The most recent Belkin driver is available
at www.belkin.com.
4. Plug the USB A connector of the USB device, or an additional hub, into any
of the downstream ports of the Hub (see Fig. 4).
Important Note: When plugging a USB device into the Hub for the first time, it
may be necessary to reinstall the USB drivers for that device. Likewise, if you move
the device to another port on the Hub, it may be necessary to reinstall the drivers.

6
INFORMATION
FCC Statement
DECLARATION OF CONFORMITY WITH FCC RULES FOR
ELECTROMAGNETIC COMPATIBILITY
We, Belkin Corporation, of 501 West Walnut Street, Compton, CA 90220, declare under our
sole responsibility that the product:
F5U218-MOB
to which this declaration relates:
Complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation.
CE Declaration of Conformity
We, Belkin Corporation, declare under our sole responsibility that the F5U218-MOB, to which this
declaration relates, is in conformity with Generic Emissions Standard EN 55022:1998 Class B,
EN50081-1 and with Generic Immunity Standard EN50082-1 1992.
Belkin Corporation Limited Lifetime Product Warranty
Belkin Corporation warrants this product against defects in materials and workmanship for its lifetime.
If a defect is discovered, Belkin will, at its option, repair or replace the product at no charge provided
it is returned during the warranty period, with transportation charges prepaid, to the authorized
Belkin dealer from whom you purchased the product. Proof of purchase may be required.
This warranty does not apply if the product has been damaged by accident, abuse, misuse, or
misapplication; if the product has been modified without the written permission of Belkin; or if any
Belkin serial number has been removed or defaced.
THE WARRANTY AND REMEDIES SET FORTH ABOVE ARE EXCLUSIVE IN LIEU OF ALL OTHERS, WHETHER ORAL
OR WRITTEN, EXPRESSED OR IMPLIED. BELKIN SPECIFICALLY DISCLAIMS ANY AND ALL IMPLIED WARRANTIES,
INCLUDING, WITHOUT LIMITATION, WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE.
No Belkin dealer, agent, or employee is authorized to make any modification, extension,
or addition to this warranty.
BELKIN IS NOT RESPONSIBLE FOR SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES RESULTING
FROM ANY BREACH OF WARRANTY, OR UNDER ANY OTHER LEGAL THEORY, INCLUDING BUT NOT LIMITED
TO LOST PROFITS, DOWNTIME, GOODWILL, DAMAGE TO OR REPROGRAMMING OR REPRODUCING ANY
PROGRAM OR DATA STORED IN OR USED WITH BELKIN PRODUCTS.

© 2003 Belkin Corporation. All rights reserved.
All trade names are registered trademarks of respective manufacturers listed.
P74459
Belkin Components B.V.
Starparc Building • Boeing Avenue 333
1119 PH Schiphol-Rijk • The Netherlands
Tel: [phone]
Fax: [phone]
Belkin Components, Ltd.
Express Business Park • Shipton Way
Rushden • NN10 6GL • United Kingdom
Tel: [phone]
Fax: [phone]
Belkin Corporation
501 West Walnut Street
Compton • CA • 90220 • USA
Tel: [phone]
Fax: [phone]
Belkin, Ltd.
7 Bowen Crescent • West Gosford
NSW 2250 • Australia
Tel: [phone]
Fax: [phone]
Belkin Tech Support
US: 310.898.1100 ext. 2263
800.223.5546 ext. 2263
Europe: 00 800 223 55 460
Australia: 1800 666 040
