OmniView® Secure KVM Switch

Protect classified computers with a NIAP-listed
USB KVM switch
Designed specifically for secure military and government installations, the OmniView Secure KVM Switch lets you control multiple
USB computers from a single USB console. This product ensures the integrity of your data by safely switching among classified
and unclassified computers. The OmniView Secure KVM Switch is listed by NIAP, and is pending NIAP Common Criteria validation
to EAL 4.*
Available in 2- and 4-port models, the Switch features a dedicated processor per computer port. This keeps each computer
separate and secure at all times, and prevents data transfer among them. The device has no memory buffer or data-storage
capability, making it impossible for your keystrokes and other data to unintentionally transfer as you switch between computers.
Other Features
• Rugged, metal enclosure – provides stability and
allows Switch to be placed beneath monitor or other
desk item
• Dedicated port selector per computer – allows
users to switch easily from one computer to the next
• LED indicators – provide easy identification of which
computer is being accessed
• Compact design – allows for desktop or 1U
rack-mountable installation**
• USB support – provides support for USB-compatible
computers, keyboards, and mice
• High video resolution – supports video resolutions of
up to 1920x1440@75Hz
• 3-Year Warranty and free technical support
Dedicated processor per computer port Keeps classified and unclassified computers separated; protects
classified data and prevents data transfer among computers
No memory buffer Prevents unintentional transfer of keystrokes or other data when
switching between computers
No hot keys or on-screen display Prevents data from being stored on KVM Switch
Non-reprogrammable firmware Prevents tampering with KVM logic
Circuits soldered directly to circuit board Prevents tampering with components
Tamper-evident tape on enclosure Indicates that KVM Switch has been compromised; assures
security when intact
SECURITY FEATURES
Made in the USA of imported parts
Unclassified ComputersClassified Computers
User Console
OmniView
Secure KVM Switch
The OmniView Secure
KVM Switch lets you
safely control up to
four classified and
unclassified USB
computers from a
single USB console
(4-port model shown).

Package Contents
OmniView Secure KVM Switch
5V DC, 3A Power Adapter
User Manual
Quick Installation Guide
Specifi cations
*This product is listed by the National Information Assurance Partnership (NIAP). It is currently undergoing evaluation testing by a
Common Criteria Testing Laboratory for validation to EAL 4 (Evaluation Assurance Level 4).
**Requires optional Rack-Mount Kit (Belkin part number F1D005).
***The Switch includes a 5-volt, 3-Amp power adapter, but only requires a minimum of 2.5 Amps.
Model No. F1DN102U F1DN104U
No. of Users Supported 1 1
No. of Computers Supported 2 4
Enclosure Metal with plastic faceplate Metal with plastic faceplate
Port Selectors 2 4
LED Indicators 2 4
Dimensions 11 (W) x 1.75 (H) x 6 (L) in.
(279 x 45 x 150mm)
11 (W) x 1.75 (H) x 6 (L) in.
(279 x 45 x 150mm)
Weight 2.5 lbs. (1.1kg.) 2.5 lbs. (1.1kg.)
Power/Environment
Power Requirements 5V DC, 2.5A (minimum) power adapter***
AC Input 100 to 240VAC
Operating Temperature 32° to 104° F (0 to 40° C)
Storage Temperature -4° to 140° F (-20 to 60° C)
Hardware Supported
Monitors VGA
Keyboards/Mice USB
Video Resolution Up to 1920x1440 @ 75Hz
Operating Systems
Windows® 2000, XP, Server 2003
Mac OS® X v10.3 and above
Red Hat® Linux Desktop®, Red Hat Enterprise Linux WS
Ports
Console HDDB15 female (VGA), USB Type A
Computers HDDB15 male (VGA), USB Type B
Power DC jack
Warranty
3 years
LED Indicators
LED Indicators
Dedicated Port
Selectors
Rugged Metal Enclosure
USB/VGA Console Support
USB/VGA Computer Support
Desktop or
Rack-Mount
Installation
F1DN104U

Recommended Belkin Products:
© 2007 Belkin International, Inc. All rights reserved. All trade names are registered trademarks of respective manufacturers listed. Mac OS is a
trademark of Apple Computer, Inc., registered in the U.S. and other countries. Windows is either a registered trademark or trademark of Microsoft
Corporation in the United States and/or other countries. 26PB309
Part Number Description MSRP
F1DN102U OmniView Secure 2-Port KVM Switch $299
F1DN104U OmniView Secure 4-Port KVM Switch $399
Belkin All-In-One USB KVM Cable Kit
Offers the highest quality possible to ensure optimal data and
video transmission. One Cable Kit is required per connected
computer. Available in 6-, 10-, and 15-foot lengths.
(F3X1962bXX)
(XX = cable length in feet)
Rack-Mount Kit
Mounts your OmniView Secure KVM Switch to any 19-inch
server rack
(F1D005)
