Belkin F5U304 User manual

Introduction
User Manual
USB Plus Hub

Table of Contents
Introduction
Features .........................................................................................................................................1
Package Contents .....................................................................................................................2
Technical Specifications ........................................................................................................2
Installation ...........................................................................................................................................3
Information .........................................................................................................................................5

Introduction
Introduction | 01
Congratulations and thank you for purchasing the Belkin USB Plus Hub. The Hub
provides four downstream USB ports that offer backward-compatible, Plug-and-Play
connectivity with all USB devices, including USB 1.1 (or low- and full-speed) devices, as
well as with USB 2.0 (or high-speed) devices. This includes such peripherals as scanners,
printers, mass-storage devices, and high-resolution cameras. The Hub is self-powered,
which allows you to cascade devices with additional hubs, so that up to 127 USB devices
may be connected to a single port.
The Hub lets you connect your peripherals through the back or top ports. Reserve the
top ports for flash drives and MP3 players while using the back ports for stationary
devices. The cable-management feature lets you easily remember which cables
correspond to each device. The Hub also provides a status LED for each individual port
and a master power LED.
Features
• Compliant with Universal Serial Bus specification 2.0 (data rate 1.5/12/480Mbps)
• Backward-compatible with Universal Serial Bus specification 1.1 (data rate
1.5/12Mbps)
• Compatible with Windows® 98 SE, Me, 2000, XP, and Vista™
• Approved by USB Implementers Forum (USB-IF)
• Support for Plug-and-Play specifications
• Support for “hot swapping” of USB devices
• Individual port-status-indicator LEDs
• Four 480Mbps downstream ports
• Fully compatible with USB 1.1 and USB 2.0 devices
• Multiple hubs may be stacked on top of one another
• Cord-management feature keeps cables organized in one location

Package Contents
• USB Plus Hub
• AC Power Adapter
• User Manual
• USB Device Cable
Technical Specifications
Upstream Ports: 1
Downstream Ports: 4
Per-Port Voltage: DC +5V
Per-Port Current: 500mA (max) (self-powered mode)
Power Mode: Self-powered/bus-powered
Operating Temperature: 5° C ~ 40° C
Storage Temperature: -20° C ~ 60° C
Enclosure: ABS
Power Supply:
Output: DC 6V, 2.1A
Plug Size: 3.5mm (outer)
1.0mm (center)
Plug Polarity: Center-pin positive
Main-Power-LED Color Definitions
Off: Not operational
Amber: Operational
Port-Status-LED Color Definitions
Off: Not operational
Green: Fully operational
Introduction | 02
Introduction

Installation | 03
Important Note: Please do not connect any USB devices to the Hub until instructed to
do so in step 4 of this installation procedure.
1. Plug the AC adapter into a wall outlet or surge protector. Plug the DC connector into
the DC power jack found on the rear of the Hub.
Note: The Hub may be used without the power supply when connecting low-power
devices such as keyboards and mice.
2. Plug the flat end of the provided USB device cable into the downstream port of your
computer, or downstream port of another hub, then plug the mini-USB connector on
the device cable into the upstream port on the rear of the Hub.
Installation

Installation
Installation
| 04
Important Note: The Hub must be connected to a USB 2.0-compliant host in order
to function in high-speed mode (480Mbps data rate). If the Hub is connected to a
USB 1.1-compliant host, it will operate only in low-speed or full-speed mode
(1.5Mbps/12Mbps).
3. Windows will now detect your Hub and install the required driver support. (The
Windows “Install New Hardware Wizard” may prompt you to provide your Windows
Installation CD to complete the driver installation process.)
Important Note: High-speed hub drivers are included with most USB 2.0 PCI
upgrade cards, and are preinstalled along with the PCI card drivers. If you purchased
an upgrade card prior to the release of high-speed hub support, please check with
your PCI card vendor for an updated USB 2.0 driver. The Belkin USB 2.0 driver
supports all competitive cards based on the NEC host controller with the exception
of Adaptec.
4. Plug the USB A connector of the USB device, or an additional hub, into any of the
downstream ports of the Hub.
Important Note: When moving a device from one port on the Hub to another, it may
be necessary to reinstall the USB drivers for that device.

Operating Instructions | 05
Information
FCC Statement
DECLARATION OF CONFORMITY WITH FCC RULES FOR
ELECTROMAGNETIC COMPATIBILITY
We, Belkin Corporation, of 501 West Walnut Street, Compton, CA 90220, declare under
our sole responsibility that the product:
F5U304
to which this declaration relates:
Complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation. This equipment may only be operated indoors. Operation outdoors is in
violation of 47 U.S.C. 301 and could subject the operator to serious legal penalties.
CE Declaration of Conformity
We, Belkin Corporation, declare under our sole responsibility that the F5U304, to which
this declaration relates, is in conformity with Generic Emissions Standard EN55022:1998
Class B, EN50081-1, and with Generic Immunity Standard EN50082-1:1992.
Belkin Corporation Limited Lifetime Product Warranty
What this warranty covers.
Belkin Corporation warrants to the original purchaser of this Belkin product that the
product shall be free of defects in design, assembly, material, or workmanship.
What the period of coverage is.
Belkin Corporation warrants the Belkin product for the lifetime of the product.

Troubleshooting
Troubleshooting
| 06
What will we do to correct problems?
Product Warranty.
Belkin will repair or replace, at its option, any defective product free of charge (except
for shipping charges for the product).
What is not covered by this warranty?
All above warranties are null and void if the Belkin product is not provided to Belkin
Corporation for inspection upon Belkin’s request at the sole expense of the purchaser, or
if Belkin Corporation determines that the Belkin product has been improperly installed,
altered in any way, or tampered with. The Belkin Product Warranty does not protect
against acts of God (other than lightning) such as flood, earthquake, war, vandalism,
theft, normal-use wear and tear, erosion, depletion, obsolescence, abuse, damage due
to low voltage disturbances (i.e. brownouts or sags), non-authorized program, or system
equipment modification or alteration.
How to get service.
To get service for your Belkin product you must take the following steps:
1. Contact Belkin Corporation at 501 W. Walnut St., Compton CA 90220, Attn: Customer
Service, or call (800)-223-5546, within 15 days of the Occurrence. Be prepared to
provide the following information:
a. The part number of the Belkin product.
b. Where you purchased the product.
c. When you purchased the product.
d. Copy of original receipt.
2. Your Belkin Customer Service Representative will then instruct you on how to
forward your receipt and Belkin product and how to proceed with your claim.

Information | 07
Information
Belkin Corporation reserves the right to review the damaged Belkin product. All costs of
shipping the Belkin product to Belkin Corporation for inspection shall be borne solely by
the purchaser. If Belkin determines, in its sole discretion, that it is impractical to ship the
damaged equipment to Belkin Corporation, Belkin may designate, in its sole discretion,
an equipment repair facility to inspect and estimate the cost to repair such equipment.
The cost, if any, of shipping the equipment to and from such repair facility and of such
estimate shall be borne solely by the purchaser. Damaged equipment must remain
available for inspection until the claim is finalized. Whenever claims are settled, Belkin
Corporation reserves the right to be subrogated under any existing insurance policies
the purchaser may have.
How state law relates to the warranty.
THIS WARRANTY CONTAINS THE SOLE WARRANTY OF BELKIN CORPORATION, THERE
ARE NO OTHER WARRANTIES, EXPRESSED OR, EXCEPT AS REQUIRED BY LAW, IMPLIED,
INCLUDING THE IMPLIED WARRANTY OR CONDITION OF QUALITY, MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE, AND SUCH IMPLIED WARRANTIES, IF ANY, ARE
LIMITED IN DURATION TO THE TERM OF THIS WARRANTY.
Some states do not allow limitations on how long an implied warranty lasts, so the
above limitations may not apply to you.
IN NO EVENT SHALL BELKIN CORPORATION BE LIABLE FOR INCIDENTAL, SPECIAL,
DIRECT, INDIRECT, CONSEQUENTIAL OR MULTIPLE DAMAGES SUCH AS, BUT NOT LIMITED
TO, LOST BUSINESS OR PROFITS ARISING OUT OF THE SALE OR USE OF ANY BELKIN
PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
This warranty gives you specific legal rights, and you may also have other rights, which
may vary from state to state. Some states do not allow the exclusion or limitation of
incidental, consequential, or other damages, so the above limitations may not apply
to you.

F5U304 P75342
Belkin Tech Support
US: 310-898-1100, ext. 2263
800-223-5546, ext. 2263
UK: 0845 607 77 87
Australia: 1800 235 546
New Zealand: 0800 235 546
Singapore: 800 616 1790
Europe: www.belkin.com/support
Belkin Corporation
501 West Walnut Street
Los Angeles, CA 90220, USA
310-898-1100
310-898-1111 fax
Belkin Ltd.
Express Business Park, Shipton Way
Rushden, NN10 6GL, United Kingdom
[phone]
[phone] fax
Belkin B.V.
Boeing Avenue 333
1119 PH Schiphol-Rijk, The Netherlands
[phone]
[phone] fax
Belkin Ltd.
4 Pioneer Avenue
Tuggerah Business Park
Tuggerah, NSW 2259, Australia
[phone]
[phone] fax
© 2006 Belkin Corporation. All rights reserved. All trade names are registered trademarks of respective
manufacturers listed. Windows and Windows Vista are either registered trademarks or trademarks of
Microsoft Corporation in the United States and/or other countries.
