Bell'O PVS4206HG User manual

PVS4206HG
AUDIO/VIDEO TELEVISIO SYSTEM
ASSEMBLY INSTRUCTI NS

Bell’O International Corp. will not be responsible for failure to assemble as directed or for the improper assembly, use or handling of this stand.
FOR YOUR AFETY, PLEA E FOLLOW THE E PRECAUTION :
! D N T PLACE ITEMS N THE SHELVES WHICH EXCEED THE MAXIMUM WEIGHT LIMITS F 125 LBS. F R T P SHELF,
50 LBS. F R THE MIDDLE SHELF, AND 75 LBS. F R THE B TT M SHELF.
ALWAYS PLACE THE HEAVIEST
C MP NENTS N THE B TT M SHELF.
! ALWAYS REMOVE THE TV A D OTHER EQUIPME T FROM THE FUR ITURE PRIOR TO MOVI G THE ASSEMBLED U IT.
! DO OT MOVE THE ASSEMBLED FUR ITURE AFTER THE GLASS SHELVES HAVE BEE I STALLED, A D/OR
WHE THERE IS EQUIPME T LOCATED O THE FUR ITURE AS THIS MAY CAUSE THE SHELVES A D OTHER
ITEMS TO BECOME U SECURED A D FALL.
! WHE I USE, THIS FUR ITURE MUST BE PLACED O A FLAT, SOLID A D LEVEL SURFACE.
! DO OT LEA O THE TV WHE IT IS O THE TV STA D.
! DO OT CLIMB OR STEP O THE STA D.
! DO OT BA G I TO OR PLACE YOUR OW WEIGHT O THE GLASS SHELVES.

PA TS LIST
#
M1
M2
M3
M4
M5
M7
M8
M9
M10
M6
1
1
1
1
1
1
1
8
1
1
Quantity
Part
#
M11
M12
M13
M14
M15
M17
M18
M19
M20
M16
3
2
2
2
4
4
1
1
2
4
Quantity
Part
25 mm
40 mm
35 mm
15 mm

FIG. 1
M1
M10
M3
M2
1. ATTACH the Top Shelf Support Frame (M3) to the Left Leg (M1) and to the Right Leg (M2) as
shown using four 35 mm Bolts (M10).
ASSEMBLY INST UCTIONS
N TE: 2 PEOPLE ARE RECOMME DED TO ASSEMBLE THIS FUR ITURE. TO AVOID DAMAGE DURI G ASSEMBLY, IT SHOULD BE ASSEMBLED O A
SOFT SURFACE.

FIG. 2
M11
M1
M2
M5
M12
M12
M13
M4
2. ATTACH the Rear Stabilizing Bar (M5) to the Left Leg (M1) and to the Right Leg (M2) using four 40 mm Bolts (M11) as shown.
Tighten fully.
3. PLACE three Rubber Shelf Rings (M13), evenly spaced, on the Middle Shelf Support Bar (M4).
4. ATTACH the Middle Shelf Support Bar (M4) to the Left Leg (M1) and to the Right Leg (M2) using two 25 mm Bolts (M12) as shown.
Tighten fully.
M11

M10
M10
M6
M1
M2
M3
M5
FIG. 3
5. ATTACH the Rear CMS®(Cable Management System) Post (M6) to the Rear Stabilizing Bar (M5) and to the Top Shelf Support
Frame (M3) as shown using four 35 mm Bolts (M10). Tighten all fully.
6. Carefully M VE the stand to the location it will occupy before attempting to add the Glass Shelves.
NOTE: The stand MU T be on a flat surface and level before adding the Glass helves or any components. There are leveling
feet under the Left and Right Legs (M1 & M2) and Rear tabilizing Bar (M5). TURN to adjust to ensure the stand is level.

7. INSERT two Suction Pads (M16) into the holes at the base of the Left and Right Leg (M1 & M2).
8. Carefully PLACE the Bottom Glass Shelf (M9) down onto the lowest support lip on the Rear CMS®Post (M6) and make sure it is securely placed on both
Suction Pads (M16). SECURE the Bottom Glass Shelf into place with a Plastic T-Pin (M15).
9. Carefully PLACE the Middle Glass Shelf (M8) down onto the upper support lip on the Rear CMS®Post (M6) and make sure it is securely placed on the Middle
Shelf Support Bar (M4). SECURE the Middle Glass Shelf into place with a Plastic T-Pin (M15).
NOTE: The Plastic T-Pins (M15) will help to keep the shelf in the correct position and help to prevent accidental movement of the helves. They are NOT
intended to LOCK the helves into place. Always remove the Glass helves and all other items before attempting to move the stand.
10. Carefully ATTACH the Top Glass Shelf (M7) to the stand assembly and SECURE the Shelf using two 15 mm Bolts (M14) as shown.
Be carefull not to overtighten.
NOTE: The Top Glass helf (M7) MU T be level before attempting to place a TV or components on it. There are leveling pads along the front edge
of the Top helf upport Frame (M3). TURN the leveling pads to ensure the Top Glass helf is well supported and level.
M14
M16
M16
M1
M6
M2
M9
M8
M15
M7
M3
FIG. 4

FIG. 5
M17
M17
M6
M18
11. For each lower Glass Shelf, INSTALL the L-Brackets (M17) as shown above using the Small Screws (M18).
Make sure the L-Brackets are above the Glass Shelves.
