3-form Dello SimpleSpec 200.86 User manual

For more information, please visit 3-form.com or call 800.726.0126
JUNE 2019 | MANRTG20008 | REV 002 © 2019 3form, Inc. All rights reserved.
Dello SimpleSpec 200.86tm Installation Manual
Ready To Go

Contents Overview
(2)
3mm Cable
Stainless Steel: 315-723
Black Oxide: 3-15-2006
(6)
Single Panel Connector for ⅜"
Stainless Steel: 3151999
Black Oxide: 3-15-2002
=
(2)
1" Shelf Holder KIT
Stainless Steel: 315-754K
Black Oxide: 3152018
+
1" Shelf Holder
SS: 315-754
BO: 3-15-2018
(2)
M6  12mm
Set Screw
315-776
(2)
=
(2)
Cable Coupler KIT
Stainless Steel: 3-15-1639-K
Black Oxide: 3-15-2004-K
+
Cable Coupler
with Cover Plate
SS: 3151639
BO: 3-15-2004
(2)
M8 Thread
Rod, 25mm
3151754
(2)
(2) =
Cable Tensioner
with Cover Plate KIT
Stainless Steel: 3151636K
Black Oxide: 3152005K
+
Cable Tensioner
with Cover Plate
SS: 3151636
BO: 3152005
(2)
M8 Thread
Rod, 25mm
3151754
(2)
(1)
⅜" Varia Panel
(2) =
Suspend Anchoring KIT
3-15-7000-K
+ +
M8 Threaded
Wood Insert
3150791
(2)
M8 Concrete
Anchor
3153011A
(2)
M8 Threaded
Rod, 50mm
3153032A
(2) +
M8 Thread
Rod, 25mm
3151754
(2)
M8 Toggle
Bolt Anchor
3150734
(2) +
2
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2019 | MANRTG20008 | REV 002 © 2019 3form, Inc. All rights reserved.
Dello SimpleSpec 200.86tm Installation Manual
Ready To Go

For Each Additional Panel
Contents Overview cont...
(×1) Varia Panel
(×1) 3mm Cable (SS: 3-15-0723; BO: 3-15-2006)
(×1) Cable Coupler KIT (SS: 3-15-1639-K; BO: 3-15-2004-K)
(×1) Cable Tensioner with Cover Plate KIT (SS: 3151636K; BO: 3152005K)
(×2) Suspend Anchoring KIT 3157000K
(×1) 1" Shelf Holder KIT (SS: 3150754K; BO: 3152018)
(×3) Double Panel Connector for ⅜"
Stainless Steel: 3152001
Black Oxide: 3152003
3
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2019 | MANRTG20008 | REV 002 © 2019 3form, Inc. All rights reserved.
Dello SimpleSpec 200.86tm Installation Manual
Ready To Go

Overview
The 200.86 partition comes from the 3form Suspend Hardware System. This is a suspended side-fastening partition for concrete
and wood with smooth connectors and a Drop Ceiling cover. This elegant solution would be a great addition to any space.
*1 Panel is standard and additional panels are optional
3mm Cable
SS: 3150723
BO: 3152006
Cable Coupler KIT
SS: 3151639-K
BO: 3-15-2004-K
Cable Tensioner
with Cover Plate KIT
SS: 3151636K
BO: 3152005K
48" × 96" max
Varia Panel
⅜" Gauge
1" Shelf Holder KIT
SS: 3150754-K
BO: 3-15-2018
Single Panel
Connector
for ⅜"
SS: 3151999
BO: 3152002
48"
(1219mm)
96"
(2439mm)
max 14'
floor to ceiling
50⅜"
(1280mm)
4
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2019 | MANRTG20008 | REV 002 © 2019 3form, Inc. All rights reserved.
Dello SimpleSpec 200.86tm Installation Manual
Ready To Go

Installation
Required Tools
Drill Metric Allen
Wrenches
Concrete or
Wood Bit
Cable Cutters Plumb-bobSuper Glue
Drill Ø10mm hole, minimum 65mm
deep.
Remove drilling debris with a blowout
bulb or with compressed air.
With screw in anchor (315311A), use a
hammer to insert anchor.
1Install Ceiling Anchor for the First Cable Assembly
*If anchoring in concrete follow Steps 1a-f, if anchoring in drywall follow Steps 1g-l. if anchoring in wood follow Steps 1m-n.
b c
aConcrete Installation
5
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2019 | MANRTG20008 | REV 002 © 2019 3form, Inc. All rights reserved.
Dello SimpleSpec 200.86tm Installation Manual
Ready To Go

Installation
e fd
Place a washer under the screw head. Torque the screw to 15 Nm. Remove screw.
Metal
Studs
Metal
Studs
h ig
Drill ؾ" (19mm) hole. Minimum
clearance behind wall = 1⅞" (48mm)
Position the metal channel parallel
with the plastic legs. Insert the metal
channel through the drilled hole into
the wall cavity.
Pull the metal channel irmly against the
inner wall cavity by tugging the plastic
pull ring.
Hollow Substrate Installation
1Install Ceiling Anchor for the First Cable Assembly cont...
6
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2019 | MANRTG20008 | REV 002 © 2019 3form, Inc. All rights reserved.
Dello SimpleSpec 200.86tm Installation Manual
Ready To Go

k lj
Slide the plastic cap forward along the
legs until it is seated lush to the work
surface.
Snap the plastic legs o lush at the
plastic cap by pushing outward.
Note: Maximum torque on screw or rod
is 5 ft-lb.
Installation
1Install Ceiling Anchor for the First Cable Assembly cont...
3-15-1754
3-15-0791
SS: 3-15-1639
BO: 3-15-2004
n om
Drill Ø⁄" (Ø11.1mm) hole, minimum
20mm deep.
Use an Allen wrench to install the M8
Threaded Insert (315-791).
Wood Installation
7
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2019 | MANRTG20008 | REV 002 © 2019 3form, Inc. All rights reserved.
Dello SimpleSpec 200.86tm Installation Manual
Ready To Go

Installation
2Install Floor Anchor for the First Cable Assembly
b
c
a
3-15-1754
3-15-3011A
SS: 3-15-1636
BO: 3-15-2005
Attach the Cable Tensioner (SS: 3151636;
BO: 3152005) to the loor anchor with the included
M8 Threaded Rod (3151754).
Hang plumb-bob to mark anchoring point on loor. If anchoring in concrete follow Steps 1a-f,
if anchoring in wood follow Steps 1g-h.
8
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2019 | MANRTG20008 | REV 002 © 2019 3form, Inc. All rights reserved.
Dello SimpleSpec 200.86tm Installation Manual
Ready To Go

Installation
3Attach First Cable Assembly
a b
e
c
fd
SS: 3-15-0723
BO: 3-15-2006
SS: 3-15-1639
BO: 3-15-2004
SS: 3-15-1639
BO: 3-15-2004
2-3x
SS: 3-15-0723
BO: 3-15-2006
Do not tighten yet!
Pull excess cable through the side
exit on the tensioner.
Unscrew the cap.
150-200 lbs
225 + lbs
max weight
per cable
Maximum Weight = 225 lbs
Maximum Tension = 400 lbs
Hollow Substrate:
Max Tension + Weight < 70lbs
9
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2019 | MANRTG20008 | REV 002 © 2019 3form, Inc. All rights reserved.
Dello SimpleSpec 200.86tm Installation Manual
Ready To Go

4Dry-Fit Panel and Measure
Installation
Set Screws
(×2)
SS: 3-15-1999
BO: 3-15-2002
(x2) Set Screws
aDo not tighten set screws! bDo not tighten set screws!
10
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2019 | MANRTG20008 | REV 002 © 2019 3form, Inc. All rights reserved.
Dello SimpleSpec 200.86tm Installation Manual
Ready To Go

dc
4Dry-Fit Panel and Measure cont...
Installation
Set Screws (×2)
Set Screws (×2)
SS: 3-15-1999
BO: 3-15-2002
Do not tighten set screws!
11
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2019 | MANRTG20008 | REV 002 © 2019 3form, Inc. All rights reserved.
Dello SimpleSpec 200.86tm Installation Manual
Ready To Go

Set Screws
(×2)
e
4Dry-Fit Panel and Measure cont...
Installation
Remove Panel
12
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2019 | MANRTG20008 | REV 002 © 2019 3form, Inc. All rights reserved.
Dello SimpleSpec 200.86tm Installation Manual
Ready To Go

Installation
5Anchor Second Cable Assembly
ba Repeat Steps 13 for the Second Cable Assembly. Repeat Step 4 and then Steps 13
for each additional panel.
6Attach the Panel
6" max
Set Screws (×2)
bPosition the panel to desired location and ensure it
is level. Tighten set screws to the panel on top side
brackets only.
aPosition the top Side Brackets (SS: 3151999;
BO: 3152002) 6" below the desired location of the
top of the panel. Tighten set screws to the cable (top
side brackets only).
13
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2019 | MANRTG20008 | REV 002 © 2019 3form, Inc. All rights reserved.
Dello SimpleSpec 200.86tm Installation Manual
Ready To Go

Installation
6Attach the Panel cont..
4"
Set Screws (×2)
Set Screws (×2)
SS: 3-15-1999
BO: 3-15-2002
dc Critical Tensioning Step!
Wait to re-tension the cables as weight of the panel is
applied. Re-tension the cables, pulling excess cable
through the tensioner, and tighten using Allen wrench
through tensioner as shown in 6c.
Tighten set screws on lower side brackets once cables
have been tensioned. This will prevent gapping in
tension on the cables.
14
For more information, please visit 3-form.com or call 800.726.0126
JUNE 2019 | MANRTG20008 | REV 002 © 2019 3form, Inc. All rights reserved.
Dello SimpleSpec 200.86tm Installation Manual
Ready To Go

7Finish Tensioner Assembly
Installation
1
2
aCut cable and put a drop of super glue at end of cut cable to keep from fraying.
