Jason.L Switch Dry Bar Table Frame User manual

Note: Please ignore any pre-drilled holes or nut inserts that maybe present in your top(s). They will not match your
particular table/desk base and woods screws will be required to be screwed directly into the underside of the top.
Note: It is important to fully tighten all bolts and screws before attaching the top(s) so that the frame
is suciently rigid. Failure to do this may aect stability once the tops are attached.
Tools Required: Power screwdriver.
INSTALLATION GUIDE
Switch Dry Bar
Table Frame
Size: 2400x1200mm
Page 1 of 5
Need help!
Call us on
1300 527 665
www.jasonl.com.au

Table Top x2
(1200x1200mm)
Leg x6
Leg Bracket x6
Beam L Bracket x8
Beam T-Bracket x2
Long Beam x4 (920mm)
Short Beam x3 (580mm)
L-Bracket x14
1
2
3
4
5
6
7
8
Hex Nut x6
L-Bracket screws x14
Hex Head screws x16
M8x25mm Dome Head x6
9
10
11
12
COMPONENTS
SCREWS
Page 2 of 5
INSTALLATION GUIDE
Switch Dry Bar
Table Frame
Size: 2400x1200mm
Need help!
Call us on
1300 527 665
www.jasonl.com.au
7
6
4
8
10 12
2
1
9
T-beam
bracket
L-beam
bracket
L-beam
bracket
11
3

Page 3 of 5
INSTALLATION GUIDE
Switch Dry Bar
Table Frame
Size: 2400x1200mm
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Join 2 L-Bracket through each Long Beam
and 2 L-Bracket through each Short Beam.
Join Leg Brackets to each Leg using screws to secure them, as follow.
Securely connect each Beam to each Beam Bracket. Screw to secure. Insert Hex Nut on each Beam Bracket.
01
03 04
02

Page 4 of 5
INSTALLATION GUIDE
Switch Dry Bar
Table Frame
Size: 2400x1200mm
Need help!
Call us on
1300 527 665
www.jasonl.com.au
06
For the T central leg, attach as presented, using T Beam Bracket.
Position as presented, and proceed to screw to ensure each corner of the frame.
05
If this bolt does not drop into the joint
use the Allen key to screw it all the way
in so that it creates its own thread.
This will ensure a nice, tight joint.

Page 5 of 5
INSTALLATION GUIDE
Switch Dry Bar
Table Frame
Size: 2400x1200mm
Need help!
Call us on
1300 527 665
www.jasonl.com.au
Directly screw into table tops, using L-Bracket
screws through each L-Bracket.
07
Note: It is important to fully tighten all bolts and
screws before attaching the top(s) so that the frame is
suciently rigid. Failure to do this may aect stability
once the tops are attached.
