Bell Phones Excursion 36240 User manual

36240 English I/B Version 11259B-1
OWNER＿＿S MANUAL#36240 VER. 11269B-1
PAGE: 0English Canadian Version
Excursion®
36240
Congratulations on your selection of the Excursion®
39240 from Northwestern Bell Phones. This quality
2.4GHz cordless telephone, like all Genuine BELL®
products, has been designed to give you many years of
continuous service and represents the best value for
your money. It requires little maintenance and is easy to

36240 English I/B version 11259B-1
111259B-1
OWNER＿＿S MANUAL#36240 VER. 11259B-1
PAGE: 1English version
setup and operate.
IMPORTANT SERVICE INFORMATION
Read this manual before attempting to setup or use this instrument. It contains
important information regarding safe installation and use. Keep this manual for future
reference. Also save the carton, packing andproof of purchase to simplify and
accelerate any needed action. If you need assistance or service in Canada, call
Sonigem Products Inc. at [phone] or [phone] between 8:30 a.m. and 5:00
p.m. Eastern Standard Time, Monday through Friday. You can also visit our web site
at: http://www.nwbphones.com for technical support and information on our other
products.
WARNING
To prevent fire or shock hazard, do not expose this product to rain or any type of
excess moisture. If accidentally dropped into water, the adapter should immediately
be unplugged from the wall along with the telephone line cord.
THIS SYMBOL IS INTENDED TO ALERT THE USER OF THE PRESENCE OF
IMPORTANT OPERATING AND MAINTENANCE (SERVICING) INSTRUCTIONS IN

36240 English I/B version 11259B-1
11259B-1 2
OWNER＿＿S MANUAL#36240 VER. 11259B-1
PAGE: 2English Canadian Version
THE OWNER'S MANUAL.
CARTON CONTENTS
HANDSET BASE UNIT RECHARGEABLE Ni-Cd
BATTERY PACK
ADAPTER
(9VDC, 300mA)
TELEPHONE
LINE CORD
(Short & Long)
WALL MOUNT
BRACKET BELT CLIP
USER’ S MANUAL WARRANTY CARD ACCESSORY
ORDER FORM
Ｍｏｄｅｌ Ｎｏ：
Ｓｅｒｉａｌ Ｎｏ：
Ｍｏｄｅｌ Ｎｏ：
Ｓｅｒｉａｌ Ｎｏ：
Excursion

36240

36240 English I/B version 11259B-1
311259B-1
OWNER＿＿S MANUAL#36240 VER. 11259B-1
PAGE: 3English version
SAVE THESEINSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
When using your telephone equipment, basic safety precautions should always be
followed to reduce the risk of fire, electric shock, and injury to persons, including the
following:
1. Read and understand all instructions.
2. Follow all warnings and instructions marked on the product.
3. Unplug this product from the wall outlet before cleaning. Do not use liquid
cleaners or aerosol cleaners. Use a damp cloth for cleaning.
4. Do not use this product near water, for example, near a bathtub, wash bowl,
kitchen sink, or laundry tub, in a wet basement or near a swimming pool.
5. Do not place this product on an unstable cart, stand, or table. The product may
fall, causing serious damage to the product.
6. Slots and openings in the cabinet at the back or bottom are provided for
ventilation, to protect it from overheating. These openings should never be blocked
or covered. The openings should never be blocked by placing the product on the
bed, sofa, rug, or other similar surface. This product should never be placed near
or over a radiator or heat register. This product should not be placed in a built-in
installation unless proper ventilation is provided.
7. This product should be operated only from the type of power source indicated on
the marking label. If you are not sure of the type of power supply to your home,
consult your dealer or local power company.
8. Do not allow anything to rest on the power cord. Do not locate this product where
the cord will be abused by persons walking on it.
9. Do not overload wall outlets and extension cords as this can result in the risk of
fire or electric shock.
10. Never push objects of any kind into this product through cabinet slots as they
may touch dangerous voltage points or short out parts that could result in a risk
of fire or electric shock. Never spill liquid of any kind on the product.
11. To reduce the risk of electric shock, do not disassemble this product, but take it
to a qualified service contractor when some service or repair work is required.
Opening or removing covers may expose you to dangerous voltages or other
risks. Incorrect reassembly can cause electric shock when the appliance is
subsequently used.
12. Unplug this product from the wall outlet and refer servicing to qualified service
personnel under the following conditions:
A. When the power supply cord or plug is damaged or frayed.
B. If liquid has been spilled into the product.
C. If the product has been exposed to rain or water.
D. If the product does not operate normally by following the operating
instructions. Adjust only those controls that are covered by the operating
instructions. Improper adjustments of other controls may result in damage
and will often require extensive work by a qualified technician to restore the
product to normal operation.

36240 English I/B version 11259B-1
11259B-1 4
OWNER＿＿S MANUAL#36240 VER. 11259B-1
PAGE: 4English Canadian Version
E. If the product has been dropped or the cabinet has been damaged.
F. If the product exhibits a distinctive change in performance.
13. Avoid using a telephone (other than a cordless type) during an electrical storm.
There may be a remote risk of electric shock from lightning.
14. Do not use the telephone to report a gas leak in the vicinity of the leak.
SAVE THESEINSTRUCTIONS
BATTERY SAFETY INSTRUCTION
CAUTION :
To reduce the risk of fire or injury to persons, read and follow these instructions:
1. Use only the following type and size of handset battery pack:
Cordless Telephone Battery Pack
DC3.6V, 850mAh, Ni-Cd Battery Pack
Manufacturer: Max Power Electronics Ltd.
Model No.: 10312FO
2. Do not dispose of the battery in a fire. The cell may explode. Check with local
codes for possible special disposal instructions.
3. Do not open or mutilate the battery. Released electrolyte is corrosive and may
cause damage to the eyes or skin. It may be toxic if swallowed.
4. Exercise care in handling the battery in order not to short the battery with
conducting material such as rings, bracelets and keys. The battery or conductor
may overheat and cause burns.
5. Recharge only the battery provided with or identified for use with this product. The
battery may leak corrosive electrolyte or explode if it is not the correct type.
6. Do not attempt to rejuvenate the battery provided with or identified for use with
this product by heating them. Sudden release of the battery electrolyte may
occur causing burns or irritation to eyes or skin.
7. When inserting the batteries into this product, the proper polarity or direction
must be observed. Reverse insertion of batteries can cause charging that may
result in leakage or explosion.
8. Remove the batteries from this product if the product will not be used for a long
period of time (several months or more) since during this time the battery could
leak in the product.
9. Discard ead”ｂatteries as soon as possible since ead＿ ｂatteries are more
likely to leak in a product.
10. Do not store this product, or the battery provided with or identified for use with this
product, in high-temperature areas. Batteries that are stored in a freezer or
refrigerator for the purpose of extending shelf life should be stabilized at room

36240 English I/B version 11259B-1
511259B-1
OWNER＿＿S MANUAL#36240 VER. 11259B-1
PAGE: 5English version
temperature prior to use after cold storage.
11. Disconnect telephone lines before installing batteries.
SAVE THESE INSTRUCTIONS
INSTALLATION PRECAUTIONS
1. Never install telephone wiring during a lightning storm.
2. Never install telephone jacks in wet locations unless the jack is specifically
designed for wet locations.
3. Never touch uninsulated telephone wires or terminals unless the telephone line
has been disconnected at the network interface.
4. Use caution when installing or modifying telephone lines.
INDUSTRY CANADA CERTIFIED
RINGER EQUIVALENCE NUMBER
NOTICE: The ringer equivalence number (REN) assigned to each terminal device
provides an indication of the maximum number of terminals allowed to be connected to
a telephone interface. The termination on an interface may consist of any combination
of devices subject only to the requirement that the sum of the ringer equivalence
numbers of all the devices does not exceed 5.
INDUSTRY CANADA NOTICE
NOTICE: The Industry Canada label identifies certified equipment. This certification
means that the equipment meets certain telecommunications network protective,
operational and safety requirements. The Department does not guarantee the
equipment will operate to the operator's satisfaction.
Before installing this equipment, users should ensure that it is permissible to be
connected to the facilities of the local telecommunications company.
The equipment must also be installed using an approved method of connection. The
customer should be aware that compliance with the above conditions may not prevent
degradation of service in some situations.
Repairs to certified equipment should be made by an authorized Canadian
maintenance facility designated by the supplier. Any repairs or alterations made by
the user to this equipment, or equipment malfunctions, may give the
telecommunications company cause to request the user to disconnect the equipment.
Users should ensure for their own protection that the electrical ground connections of
the power utility, telephone lines and internal metallic water pipe system, if present,
are connected together. This precaution may be particularly important in rural areas.

36240 English I/B version 11259B-1
11259B-1 6
OWNER＿＿S MANUAL#36240 VER. 11259B-1
PAGE: 6English Canadian Version
CAUTION : Users should not attempt to make such connections
themselves, but should contact the appropriate electric inspection authority, or
electrician, as appropriate.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and,
(2) this device must accept any interference received, including interference that
may cause desired operation. Privacy of communications may not be ensured
when using this phone.
Changes or modifications not expressly approved in writing by Northwestern Bell
Phones may void the user's authority to operate this equipment.
Some cordless phones operate at frequencies that may cause interference to
nearby TVs and VCRs; to minimize or prevent such interference, the base of the
cordless phone should not be placed near or on top of a TV or VCR; and, if
interference is experienced, moving the cordless telephone farther away from the
TV or VCR will often reduce or eliminate the interference.
ADAPTER:
Use only with Class 2 Transformer 9VDC output 300 mA.

36240 English I/B version 11259B-1
711259B-1
OWNER＿＿S MANUAL#36240 VER. 11259B-1
PAGE: 7English version
EXCURSION®36240 CONTROLS DIAGRAM
Receiver
IN USE/BATT LOW LED
Indicator
TALK Button
SCAN Button
VOL +
(Volume Up)
Button
VOL -
(Volume Up)
Button
Microphone
Charge
Terminals
RING OFF LED
Indicator
RING on / off
Button
TONE (*) Button
FLASH Button
MEMO Button
RE/PA Button
MUTE Button
CHG (Charge)
LED Indicator IN USE LED
Indicator
PAGE
Button
Retainer Tab
Charge
Terminals
Bottom View
T/P (Tone/Pulse)
Switch
Rear View
DC Adapter
Jack Tel Line Jack

36240 English I/B version 11259B-1
11259B-1 8
OWNER＿＿S MANUAL#36240 VER. 11259B-1
PAGE: 8English Canadian Version
DESCRIPTION
CONTROLS’LOCATION AND FUNCTION
(Figure 1)
HANDSET CONTROLS
1. RING OFF LED Indicator: Lights when ringer off mode is set.
2. TALK Button: Press to answer an incoming call or to place a call. Press to end
a call.
3. RING on / off Button: Turns the handset ringer on or off when press and hold for
2 seconds.
4. TONE ( * ) Button: Used to temporarily change the dialing mode from pulse to
tone for rotary service user. Provides tone function to access special services
such as phone banking services.
5. FLASH Button: Momentarily hangs up the phone to access custom calling
features such as Call Waiting or Three-Way Calling provided by your local phone
company.
6. MEMO (Memory) Button: Used for storing / retrieving phone numbers to / from
the 10 Memory Dialing Directory.
7. RE / PA (Redial / Pause) Button: Automatically dials the last number called up
to 24 digits. Also used to insert a 4 seconds delay between dialed numbers in
PABX systems or long distance services.
8. MUTE Button: Press to temporarily disable the handset microphone.
9. Charge Contacts: Used for charging the handset battery.
10. Microphone: Used for speaking with callers.
16
15
3
14
12
11
10
9
1
2
4
5
6
7
8
13

36240 English I/B version 11259B-1
911259B-1
OWNER＿＿S MANUAL#36240 VER. 11259B-1
PAGE: 9English version
11. VOL -(Volume Down) Button: Allows you to decrease the handset volume.
12. VOL -(Volume Up) Button: Allows you to increase the handset volume.
13. Headset Jack: For headset connection with hands free conversation.
14. SCAN Button: Allows you to change channels if the current channel is noisy or
having interference from other sources.
15. IN USE / BATT LOW LED Indicator: Flashes when an incoming call is received
and during paging condition. During TALK mode, the IN USE LED indicator
remains lit steadily. The BATT LOW LED indicator blinks when the handset
battery power is low. It also flashes when MUTE button is pressed.
16. Receiver: Allows you to hear calls.
(Figure 2)
BASE UNIT CONTROLS
1. 9VDC Adapter Jack: Ajack located on the rear side of the base unit used for
connecting the adapter to the base unit.
2. TEL LINE Jack: Accepts line cord to make connection with modular type
telephone outlet.
3. T / P (Tone / Pulse) Switch: Allows you to switch the dialing mode to either
Tone or Pulse dialing.
4. CHG (Charge) LED Indicator: Turns on when the base is charging the handset.
Turns off when the handset is removed from its cradle
5. Charge Terminals: Used for charging handset battery. We recommend that you
clean these contacts periodically with an alcohol-moistened cloth or cotton swab.
6. IN USE LED Indicator: Lights up steadily when the phone is being used.
Flashes when an incoming call is received and during paging condition.
7. PAGE Button: Allows you to locate the handset when it is not on the base unit.
8. Retainer Tab: Allows the handset to hang from the base unit when the base unit
is placed in the wall mount position.
Rear View
Rear View
12
3
45
6
7
8

36240 English I/B version 11259B-1
11259B-1 10
OWNER＿＿S MANUAL#36240 VER. 11259B-1
PAGE: 10 English Canadian Version
MOUNTING POSITION
DESKTOP USE:
Connect the telephone line cord to the TEL LINE
jack on the rear of the baseunit and connect the
opposite end to the telephone modular jack.
(Figure 3
WALL USE :
A. WITH A STANDARD AT&T OR GTE MODULAR WALL JACK
1. Install the wall mount bracket at the position as shown in Figure 4.
1. Connect the short telephone line cord to the TEL LINE jack on rear of the base
unit.
2. Connect the opposite end of the telephone line cord to the modular wall jack.
3. Align the wall mounting slots with the studs located on the modular wall plate and
slide the base down to lock in place.
(Figure 4)
NOTE: If you do not have a standard modular wall jack, find a qualified technician to
mount one on the wall.
B. WALL MOUNTING (No Standard Wall Jack)
1. Drill two holes with a vertical distance between the two marked
positions of 315/16”(100 mm) as shown in Figure 5.
2. Drive a screw into each of the holes. Tighten them to the end
of the screw line, only leaving the smooth part of the screw
head outside the wall.
3. Hang the unit onto the screws, then slide it down firmly to fasten the base
Base Unit
(Side view)
Wall Mount
Bracket
Wall Mouting
Solts
Telehone
Modular Wall
Jack
Studs

36240 English I/B version 11259B-1
11 11259B-1
OWNER＿＿S MANUAL#36240 VER. 11259B-1
PAGE: 11 English version
securely. (Figure 5)
BASE RETAINER TAB
If the base unit is to be placed in the wall mount position, the base retainer tab allows
the handset to hang onto the base unit.
(Figure 6)
BELT CLIP INSTRUCTION
Clamp the belt clip at the back of the handset as shown in Figure 7.
(Figure 7)
CONNECTING THE HEADSET
For hands free conversation, a headset (not included) is connected to the headset jack
as shown in Figure 8. The handset receiver and microphone are disabled when the
headset is connected.
(Figure 8)
Retainer Tab
HeadsetJack
Headset Plug
(2.5mm)

36240 English I/B version 11259B-1
11259B-1 12
OWNER＿＿S MANUAL#36240 VER. 11259B-1
PAGE: 12 English Canadian Version
Press the TALK button to answer or place a call using the headset. Refer to the
manufacturerheadset manual for more details.
POWER INSTALLATION
BASE UNIT POWER CONNECTION
CAUTION:
You must use a Class II, 120 VAC Input / 9VDC Output adapter that
delivers at least 300 milliampere. The plug must correctly fit the base unit's adapter
jack.
1. Plug the adapter into a standard AC outlet.
2. Insert the small plug into the adapter jack on the rear of the base as shown in
(Figure 9)
HANDSET BATTERY INSTALLATION
CAUTION:
Use only the Nickel Cadmium (Ni-Cd) battery type included with this unit.
Use of other battery type may cause injuries or damage.
1. Remove the battery compartment cover of the handset.
2. Connect the rechargeable Ni-Cd battery as shown on Figure 10.
9VDC
Adapter
Jack
Line
Cord
Telephone
ModularJack Telephone
ModularJack
9VDC Adapter
Plug
Inset the End of
the Battery
PackWire
BLACK WIRE
Handset
Battery
Compartment
RED WIRE

36240 English I/B version 11259B-1
13 11259B-1
OWNER＿＿S MANUAL#36240 VER. 11259B-1
PAGE: 13 English version
(Figure 10)
3. Insert the Ni-Cd battery into the battery compartment of the handset.
4. Slide the battery compartment cover firmly in its closed position.
INITIAL SETUP
Before you can use your cordless telephone, the handset must be charged for at least
20 hours. See charging instruction in the MAXIMIZING BATTERY LIFE section of this
manual.
TONE / PULSE SETTING
Select the appropriate dialing service by moving the T/P
(Tone / Pulse) switch on the side of the base unit:
•TONE for Tone service, or
•PULSE for Rotary service. (Figure 11)
RINGER ON / OFF SETTING
NOTE: Default mode is ringer on mode. RING OFF LED indicator is off.
1. Press and hold RING on/off button for about 2 seconds to set ringer off mode.
RING OFF LED indicator is on.
2. In ringer off mode, press and hold RING on/off button for about 2 seconds to set
ringer on mode. RING OFF LED indicator is off.
TELEPHONE OPERATION
TO PLACE A CALL
1. Press the TALK button on the handset. The handset IN USE LED indicator will
flash while the unit auto-scans and will light steadily when it finds a clear channel.
A confirmation tone is heard once there is a link between the baseand handset.
The base IN USE LED indicator will also light steadily when the handset is in
use.
2. Listen for a dial tone.
3. Dial the telephone number.
4. When finished with your call, press the TALK button or place the handset on the
base unit. The base IN USE indicator will turn off.
TO RECEIVE A CALL
NOTE: If you are expecting incoming calls, the ringer mode must be set to RING ON
mode. RING OFF LED indicator is off.
A. IF THE HANDSET IS ON THE BASE UNIT
1. Since the Excursion®36240 features “ Auto-Answer “, simply pick up the
handset from the base cradle when the phone rings. The base and handset IN
USE LED indicator will turn on.
2. Start your conversation.
3. To end your conversation, either press the TALK button or place the handset on
the base unit. The base IN USE LED indicator will turn off.
B. IF THE HANDSET IS OUT OF THE BASE UNIT
1. When the phone rings, press the TALK button on the handset. The unit will scan
for a clear channel until the IN USE LED indicator lights up and a confirmation
tone is heard.
T/P

36240 English I/B version 11259B-1
11259B-1 14
OWNER＿＿S MANUAL#36240 VER. 11259B-1
PAGE: 14 English Canadian Version
2. Start your conversation.
3. To end your conversation, either press the TALK button or place the handset on
the base unit. The base IN USE LED indicator will turn off.
LAST NUMBER REDIAL
A. AFTER HEARING A BUSY TONE WHEN PLACING A CALL
1. If you get a busy tone, press handset TALK button to hang up.
2. Press the handset TALK button again and listen for a dial tone.
3. Press the handset RE/PA button. This will automatically
redial the last telephone number you called (Up to 24 digits).
B. WHEN THE HANDSET IS OFF THE BASE UNIT AND IN STANDBY MODE
1. Press the TALK button on the handset and listen for a dial tone.
2. Press the RE/PA button. This will automatically redial the last telephone number
you called (Up to 24 digits).
NOTE: When the adapter power is disconnected and connected again, the unit can
not redial the last telephone number you called.
MEMORY DIALING
You can store up to 10 telephone numbers (up to 16 digits each) into memory and you
can then dial any of the stored phone numbers.
A. STORING TELEPHONE NUMBERS INTO MEMORY
1. Make sure that the handset is in the standby mode. The base and handset IN
USE LED indicator should be OFF.
2. Press and release the MEMO button. The handset will beep once.
3. Enter the telephone number you want to store (maximum of 16 digits). A key tone
is heard for every key pressed.
4. Press the MEMO button once again.
5. Press a number (0 through 9) where you want to store the phone number.
You will hear a long beep to confirm that the number was properly stored.
6. Repeat procedures 1 to 5 to store other telephone numbers.
B. RECALLING A TELEPHONE NUMBER FROM MEMORY
1. Press the TALK button.
2. Press the MEMO button.
3. Select and press one of the keypad buttons (0 to 9). The stored telephone
number will be dialed automatically.
C. CHANGING STORED TELEPHONE NUMBERS
•Follow the steps described in toring Telephone Numbers. The new phone
number will automatically replace the previous one.
MIXED MODE DIALING (Temporary Pulse to Tone Dialing)
1. If you only have pulse (rotary dialing) service in your area and want to access
Tone services (Bank by Phone, etc.), ensure that the Tone / Pulse switch is set
to the Pulse position.
2. Press the TONE ( *) button once to switch from Pulse to Tone dialing

36240 English I/B version 11259B-1
15 11259B-1
OWNER＿＿S MANUAL#36240 VER. 11259B-1
PAGE: 15 English version
temporarily. Pulse dialing mode resumes when the call is ended.
PAUSE FUNCTION
•In some cases, such as PABX or long distance service, a pause may be needed
in the dialing sequence. Pressing the handset RE / PA button inserts a four-
second delay between dialed numbers.
•Each four-second pause occupies one digit of the available 16 digits per memory
location.
FLASH FUNCTION
•Used to access custom calling features such as Call Waiting or Three-Way
Calling provided by your local phone company. Consult your local phone
company for more details.
CHANNEL SELECTION (40 Channels)
A. AUTO CHANNEL SCAN
•When you place or receive a call and handset TALK button is pressed, the
Excursion®36240 auto-scans for the best channel available.
•Once it finds a clear channel, the base unit and handset IN USE LED indicator
will light up.
B. MANUAL CHANNEL SCAN
•If the existing channel becomes noisy or starts having interference, press the
SCAN button on the handset repeatedly until a clear channel is found.
OUT OF RANGE WARNING
•The handset and base unit communicate up to a certain maximum range. The
distance can be affected by weather, power lines, or even other cordless
telephone
•If you are far away from the base unit, the handset emits three beeps every 2
seconds to warn you that the background noise level is too high for proper
communication between the handset and the base unit.
•When you hear this sound, you should move closer to the base unit to reduce the
noise level. Otherwise, the call will automatically cut off after 28 seconds.
NOTE: Excessive static for more than 28 seconds can cause the handset to lose link
with the base. Return the handset to the cradle to re-establish the security link.
LOW BATTERY WARNING
•When the handset battery voltage level is low, the handset will beep every 8
minutes and the handset BATT LOW LED indicator will flash in talk mode.
In standby mode, the handset BATT LOW LED indicator will flash.
•Return the handset on the base cradle to charge.
PAGING FUNCTION
•Press the PAGE button on the base unit. The page tone will be heard on the
handset. The handset IN-USE LED indicator will flash indicating the paging
period. Page is also useful to help locate a misplaced handset.
RESETTING SECURITY CODE AND CHANNEL INFORMATION
Communication between the handset and base unit may not be possible in any of the
following situation:

36240 English I/B version 11259B-1
11259B-1 16
OWNER＿＿S MANUAL#36240 VER. 11259B-1
PAGE: 16 English Canadian Version
•After a power failure.
•After relocating the base unit by disconnecting the adapter.
•After replacing the handset battery.
To reset, place the handset on the charge cradle of the base unit for 5 seconds.
IMPROVING CORDLESS RECEPTION
Follow these guidelines to improve cordless sound quality:
•Select an area to install the Excursion®36240 where it is closest to the center of
your home or office. This will improve the operating range of the unit.
•Keep the Excursion®36240 base unit away from electrical equipment. Radio
Frequency Interference (RFI) is sometimes generated by these appliances, which
can cause a degradation in cordless reception.
•Keep the handset batteries charged as much as possible. Weak handset
batteries can limit the range of cordless operation.
MAXIMIZING BATTERY LIFE
Repeated use or recharge of Ni-Cd batteries without periodic full discharge results in
reduced useable charge time. When you notice the usable charge duration
decreasing, fully discharge the Ni-Cd battery and recharge as described:
DISCHARGING
1. Unplug the telephone line cord from the Excursion®36240 .
2. Make sure that the adapter is connected.
3. Lift the handset out of the base cradle.
4. Press the TALK button of the handset (IN USE LED indicator should light) and
start discharging.
Once the BATT LOW LED indicator starts flashing, it means that the battery level is
low. Let it fully discharge for 12 hours. Once the Ni-Cd battery is fully discharged, you
may now charge the battery to its full capacity.
CHARGING
1. Make sure the adapter and telephone line cord are connected to the Excursion®
36240.
2. Place the handset on the base cradle. The CHARGE LED indicator of the base
unit will light steadily.
3. Leave the handset charging on the base for 20 hours continuously to get a

36240 English I/B version 11259B-1
17 11259B-1
OWNER＿＿S MANUAL#36240 VER. 11259B-1
PAGE: 17 English version
maximum charge.
4. The Excursion®36240 is now ready for regular use. Discharge and charge the Ni-
Cd battery again once you noticea decrease in the useable charge time.
MAINTENANCE
1. Your phone should be situated away from heat sources such as radiators,
heaters, stoves or any other appliance that produces heat.
2. Use a slightly damp cloth to clean the plastic cabinet. A mild soap will help to
remove grease or oil. Never use polish, solvents, abrasives or strong detergents
since these can damage the finish.
TROUBLESHOOTING
SYMPTOMS POSSIBLE SOLUTION / CAUSE
No dial tone •Check for the telephone line cord connectors at both
ends that they are pushed in firmly until they click.
•Check if another telephone line (sharing with the same
line as the Excursion®36240) is off-hook or in use.
•If you had a power failure or had unplugged the base
unit, replace the handset on the base unit for two to five
seconds to reset the system.
Does not ring •Check the ringer mode on the handset. Change to RING
ON mode to enable the handset ringer.
•Check for the telephone line cord connectors at both
ends that they are pushed in firmly until they click.
•You may have exceeded the Ringer Equivalence Number
(REN) limit of how many phones can be connected to
the same line. The REN total of all devices (printed on
the bottom label of each unit) should not exceed five (5).
Disconnect the appropriate units to lower the REN total.
No power on the
handset unit •Check for the Ni-Cd battery pack for proper connection inside the battery compartment on the handset.
•The handset rechargeable Ni-Cd battery pack may need
charging.
Does not charge •Check for the Ni-Cd battery pack for proper connection
inside the battery compartment on the handset.
•The charging contacts and terminals may need cleaning
with an alcohol-dampened swab.
Range is limited •Move the base unit so that it is centrally located in your
residence or office and make sure that the base unit is
not located near appliances.
•The handset Ni-Cd battery may be weak. Recharge the
Ni-Cd battery.
•Refer to the section "Improving Cordless Reception".
Interference on
reception •Choose an alternate channel using the SCAN button on the handset.
•Refer to the section "Improving Cordless Reception".

36240 English I/B version 11259B-1
11259B-1 18
OWNER＿＿S MANUAL#36240 VER. 11259B-1
PAGE: 18 English Canadian Version
Excessive static
•Ensure that the antenna is not touching another metal object.
•Refer to the section "Improving Cordless Reception".
TECHNICAL INFORMATION
This cordless phone uses radio frequencies to allow mobility. There are certain
difficulties in using radio frequencies with a cordless telephone. while these are
normal, the following could affect the operation of your system.
NOISE: Electric pulse noise is present in most homes at one time or another. This
noise is most intense during electrical storms. Certain kinds of electric equipment
such as light dimmers, fluorescent bulbs, motors, and fans also generate noise
pulses. Because radio frequencies are susceptible to these noise pulses, you may
occasionally hear them in your handset. Generally they are a minor annoyance and
should not be interpreted as a defect in your system.
RANGE: Because radio frequencies are used, location of the base unit can affect
operating range. Try several locations in your home or business and pick the one that
gives you the clearest signal.
INTERFERENCE: Some electronic devices operate in and/or generate interference
near the operating frequencies of your cordless telephone. while several protection
circuits are used to prevent unwanted signals, there may be periods when these
unwanted signals cause interference. If interference occurs frequently, it can be
minimized or eliminated by lowering the height of your base antenna or by relocating
the base unit. You can check for interference before selecting the final base unit
location by plugging in the phone.
GLOSSARY
1,000,000 COMBINATION SECURITY CODING -A digital code (up to 1,000,000
random combinations) that is automatically generated to prevent use of your telephone
line by other cordless phones nearby.
AUTO-SCAN -Upon picking up the handset and pressing the TALK button, the
Excursion automatically scans for the best channel. There are 40 channels available.
AUTO-STANDBY -The handset automatically goes into standby mode (on-hook)
when the handset is returned to the base unit.
COMPANDER NOISE REDUCTION-Reduces background noise.

36240 English I/B version 11259B-1
19 11259B-1
OWNER＿＿S MANUAL#36240 VER. 11259B-1
PAGE: 19 English version
FLASH -If you subscribe to phone company special services like Call Waiting or Call
Forwarding, pressing the FLASH button will momentarily hang up the phone to access
these services.
HEARING AID COMPATIBLE -Allows hearing aid devices to function properly while
using the handset.
LAST NUMBER REDIAL -The Excursion®36240 always emembers" the last
phone number dialed up to 24 digits.
MIXED MODE DIALING (Temporary Pulse to Tone Dialing)-The Excursion®
36240 can provide tone dialing while using a pulse dial service to access automated
banking services or any other service requiring tone dialing.
PAUSE -A 4-second delay between dialed numbers for use in PABX systems or long
distance services.
RINGER EQUIVALENCE NUMBER (REN) -This is a number located underneath the
base of your phone(s) or phone-related device. The REN is used to determine how
many phones can be connected to the same telephone line while still having all those
devices ring when you receive a call. In most areas, but not all areas, the REN total of
all devices should not exceed five (5). Call your local phone company to determine the
maximum REN for your calling area.
