1
db1000DF dual fuel cooker
Installation & User’s instructions
Db1000DF dual fuel - Natural Gas
(Liquid Petroleum gas convertible)
Note: This appliance is supplied for use with the category of gas
specified and can be converted to LP gas with the kit provided.

2
Contents
Page
Product Specification ……………………………………………………. 3
Introduction Your Belling Cooker…………………………….. 4
Getting Help……………………………………… 4
Installation Instructions ……………………………………………………. 5-8
For Your Own Safety Never…………………………………………….. 9
Always…………………………………………… 10
Know Your Cooker ……………………………………………………. 11
Know Your Control Panel ……………………………………………………. 12
Timer Instructions …………………………………………………….. 13/17
Automatic Cooking (Large Oven) ……………………………………………………… 18
Rules to follow when cooking automatically
Using the Hob Description of Hotplates…………………………. 19
Use of Hotplates………………………………….. 19
Control Setting Guide…………………………….. 19
Cooking Chart…………………………………….. 19
Choosing Your Utensils …….. ………………….. 20
Energy Saving Tips….. ………………………….. 20
Safety Requirements for Deep Fat Frying….….. 21
Main Multifunction Oven & Grill Operation…………………………………………….. 22
(Multifunction Settings) Off Light Only.…………………………………….. 22
Fan Oven ....................................................... 23
Preparation & Roasting of Large Poultry……….. 23
Conventional Oven, Fan Grill............................. 24
Defrost, Full Grill, Half Grill, Using the Grill........ 24/25
Grill Pan & Grid, Grill Chart................................. 26
Storage & Re-heating of Food Cook –Chill Dishes……………………………….. 27
Main Multifunction Oven Cooking Guide ……………………..……………………………….. 28/29
Small Oven Cooking Guide ……………………..……………………………….. 30
Temperature Conversion Scale ……………………..……………………………….. 31
Care & Cleaning Door Removal, Cleaning (Stainless Steel)......... 32
Ovens & Grill............................................…….. 32-33
Pan Supports & Burner Caps/Burner Bodies. 33
Belling Cook-clean Panels………………………… 33
Replacing the Oven Lamp................................. 33
Is There Something Wrong With Your Cooker ……………………..……………………………….. 34
Cooking Results Unsatisfactory ……………………..……………………………….. 35
Service ……………………..……………………………….. 36
Product Specification

3
Db1000DF
Gas Type I2H
Gas Supply Pressure 20mbar for G20 28mbar for G30 37mbar for G31
Convertible to LPG, but factory set for Nat. Gas
Electrical Supply 220V –240V
Electrical Supply Frequency 50Hz
Total Heat Input (Gas) 11.0 kW (800 gms/hr –G30) (786 gms/hr –G31)
Front Left Hotplate (Rapide) 2.9 kW (218 gms/hr –G30) (215 gms/hr –G31)
Injector 115
Rear Left Hotplate (Semi-Rapide) 1.8 kW (127 gms/hr –G30) (125 gms/hr –G31) Injector
96
Centre Hotplate (Wok - Triple Ring) 3.5 kW (254 gms/hr –G30) (250 gms/hr –G31)
Injector 135
Rear Right Hotplate (Auxiliary) 1.0 kW (73 gms/hr –G30) (72 gms/hr –G31)
Injector 71
Front Right Hotplate (Semi-Rapide) 1.8 kW (127 gms/hr –G30) (125 gms/hr –G31)
Injector 96
Total Heat Input (Electric) 4.47 –4.87 kW
Light Only (Large Oven) 2 x 0.015 kW (SES)
Fan Oven Wattage (Large Oven) (Timed) 2.37 –2.58 kW
Conventional Large Oven Wattage (Timed) 2.04 –2.22 kW
Fan Grilling Wattage (Large Oven) (Timed) 2.43 –2.65 kW
Defrost (Large Oven) Wattage (Timed) 0.046 –0.050 kW
Full Grill Wattage (Electric) 2.41 - 2.62 kW
Half Grill Wattage (Electric) 1.30 - 1.42 kW
Small Conventional Oven Wattage 2.04 - 2.22 kW
Grilling Area 780 cm2
Large Oven Capacity 55 Litres
Small Oven Capacity 32 Litres
Nominal External Dimensions H 900mm –915mm
(Excluding handles) W 1000mm
D 600mm
Countries of Destination GB & IE
Introduction

Your belling Cooker Thank you for purchasing a new belling platinum db3 cooker. Its stylish, practical
design will enhance your kitchen and make cooking a pleasure. It features a large
multifunction oven/Grill (Closed door), a small conventional oven, a storage
compartment, 5 gas hob burners and a utensil holder. There is also an electronic
clock/timer featuring a minute minder and automatic cooking facilities (large oven
only).
Even if you have used an electric or gas cooker before, it is important that
you read these instructions thoroughly before starting to cook, paying particular
attention to the installation and safety instructions.
Getting Help If you have any problems with installing, operating, or cooking with your belling
cooker, please check through these instructions thoroughly to make sure that you
have not missed anything. If you still need help, then please contact (including a
daytime telephone number if possible):-
Customer Care Centre
Belling Appliances Limited,
Stoney Lane,
Prescot,
Merseyside,
L35 2XW
BELLING HELPLINE Tel: [phone]
Please quote the cooker model and serial number with all inquiries. This can be
found on the chassis behind the drop down storage compartment panel.
WARNING! For your own safety, make sure that these instructions on
installation, use and maintenance are followed.
We advise you to keep these instructions in a safe place for future reference.
If you sell or transfer ownership of this product, please pass on these instructions
to the new owner.
Installation Instructions
This appliance has been tested and certified by Advantica Technologies Ltd and

carries the C.E. Mark.
The installation must be in accordance with the current I.E.E. Wiring Regulations.
Gas safety (Installation & Use Regulations.)
This appliance must be installed in accordance with BS6172:
In your own interest and that of safety, it is LAW that all Gas Appliances are installed
by competent persons in accordance with Gas Safety Regulations. Failure to install
appliances correctly could lead to PROSECUTION.
Use only a CORGI registered installer.
This appliance shall be installed in accordance with the regulations in force, and
used only in a well-ventilated space. Read the instructions before installing or using
this appliance.
The use of a gas-cooking appliance results in the production of heat and moisture in
the room in which it is installed. Ensure that the kitchen is well ventilated, keep
natural ventilation holes open or install a mechanical ventilation device (mechanical
extractor hood).
Prolonged intensive use of the appliance may call for additional ventilation, for
example opening of a window, or more effective ventilation (where present).
Location The cooker may be located in a kitchen, kitchen/diner or a bed-sitting room, but not
in a room containing a bath or shower.
Provision for ventilation The room containing the cooker should have an air supply in accordance with
BS5440: Pt.2
All rooms require an opening window or equivalent, while some rooms require a
permanent vent in addition to the opening window. The cooker should not be
installed in a bed-sitting room of less than 21m3, and furthermore should not be
installed in any room of volume less than 5m3. If it is installed in a room of volume
between 5m3and 10m3 an air vent of effective area 50cm2is required., unless the
room has a door that opens directly to the outside, in which case no air vent is
required. If the room exceeds 11m3no air vent is required
If there are other fuel burning appliances in the same room BS5440:Pt.2 should be
consulted to determine the requisite air vent requirements.
Unpacking After unpacking your cooker, make sure that you remove all the packing from the
grill compartment and ovens, and any stickers from the oven doors and the hob.
Examine your cooker for any damage. If there is any damage to your cooker or
anything is missing, please contact your supplier for advice.
Siting/Moving the Cooker Your cooker is heavy, so be careful when moving or positioning it. Do not try to
move the cooker by pulling on the doors or handles or control panel. The Belling
db3 is designed to 'slot-in' between 600mm deep cabinets, spaced at least
1000mm apart. It can also be used freestanding, with a cabinet to one side, in a
corner setting or with its back to a wall. However it must not be situated with either
side closer than 50mm to a combustible wall or cupboard that is higher than the
cooker.
Installation Instructions
The wall behind the cooker and 450mm above and across the width of the cooker,
should be of an incombustible material or easy clean surface such as ceramic
5

tiles. Please note, when positioning your cooker against a wall, ensure there is
sufficient clearance for the screw heads on the back panel.
This appliance is designed not to project in front of standard 600mm worktops
(excluding handles). To achieve the best fit the cooker must be pushed against the
wall. If the wall mounted adapter back-plate (Fig.1) is to be fitted behind the
appliance then the suitable area for this fitting is shown as the area in (Fig.2).
Note: The adapter back-plate requires chasing into the wall if it protrudes
more than 40mm. This is to allow the cooker to be pushed back to the wall.
Fig. 1 Fig. 2
Any overhanging surface or cooker hood should be at least 760mm (30") above the
cooker hob. We do not recommend positioning the cooker below wall cupboards, as
the heat and steam from the cooker may cause damage to the cupboard and its
contents.
Excess steam from the oven, vents out at the top back edge of the cooker, so make
sure that the walls behind and near the cooker are resistant to heat, steam and
condensation.
Your cooker must stand on a flat surface so that when it is in position the hob is
level. The cooker is fitted with rear wheels and will slide into position easily.
Movement of your cooker is most easily achieved by lifting the front, as follows.
Open the oven doors sufficiently to allow a comfortable grip on the underside front
edge of the oven roofs, avoiding grill elements or oven furniture.
Adjust the cooker at the rear to the required height, using the 2 jacking screws
situated behind the rear access cover and secure with the lock-nuts. Position the
cooker and adjust the height at the front with the 2 jacking screws situated at the
front underside. Check that the cooker is level by using a spirit level (adjusting the
jacking screws if necessary). It is important that the cooker is stable and level for
the overall cooking performance.
Installation Instructions
ADAPTER BACKPLATE
ELBOW
ELBOW BAYONET
SOCKET
15mm COPPER
PIPE
MAINS INLET ON
APPLIANCE
6

Stability Chain The cooker should be fitted with a stability device such as a proprietary stability
chain as shown in Figure 3 and firmly secured to the fabric of the building.
Whatever the position, remember to leave enough room for the cooker to be pulled
out for cleaning and service.
Connect to Gas Supply Connection to the appliance should be made with an approved appliance flexible
connection to BS669. A length of 1200mm is recommended.
The temperature at the rear of the appliance, which is likely to come into contact
with the flexible hose, does not exceed 70 C.
A Rp 1/2elbow is fitted to the cooker.
If the position of the wall connection is within 250mm of the oven inlet, the loop of
hose will give maximum movement to the cooker.
Fig.3
Connecting to Electrical For your own safety, we recommend that your cooker is installed by a suitably
Supply qualified person.
The cooker should be installed in accordance with the latest edition of the
IEE Regulations.
WARNING: THIS APPLIANCE MUST BE EARTHED!
The cooker must be connected to the correct electrical supply as stated on the
rating plate, through a suitable cooker control unit incorporating a double pole
switch having a contact separation of at least 3mm in all poles, adjacent to (but not
above) the cooker. We recommend that the cooker circuit is rated to 30 Amps.
We also recommend that 4mm² P.V.C. (minimum 2.5mm² - maximum 6.0mm²)
Insulated twin and earth cable is used to connect the cooker control unit.
The power supply cable should conform to BS6004
IMPORTANT:
For access to the mains terminal block and for supply cable connection, it is
necessary to remove the access cover situated at the bottom of the back panel.
The live and neutral positions are marked with the letters L and N respectively,
marked in front of the terminal block. The earth terminal is marked by the earth
symbol. Secure the mains cable using the cable clamp.
Connect the mains cable as follows:-
Live to terminal L.
Neutral to terminal N
Earth to the earth stud.
Installation Instructions
7

Ensure clamping nuts are tightened sufficiently. Allow sufficient cable length for
the cooker to be pulled out for cleaning, but do not let it hang closer than 50mm
(2”) to the floor. The cable can be looped if necessary, but make sure that it is not
kinked or trapped when the cooker is in position.
Both ovens, grill and clock will not operate unless the mains control unit is live and
switched on.
Check for Gas Soundness
Gas pressure should be checked on a semi-rapid hob burner. Remove the injector
and fit the pressure test nipple supplied. Light the other four burners and then note
the pressure. This should be as stated on the rating label.
Note: Replace the injector after checking.
Retain the test nipple in a safe place for future use.
Check the operation of the cooker
Check that the five hotplate electrodes spark correctly. The hotplate burners should
be checked for a steady flame (when turned down to the smallest flame setting
marked on the control panel).
Before you cook for the first time, we recommend that you turn on each element and
hotplate in turn to burn off any odors remaining from manufacture. Simply operate
each hotplate and the grill on maximum for a few minutes and each oven for about
30 minutes.
User
Instruct the user in the operation of the appliance and hand over the instructions.
For Your Own Safety
8

When used properly your Belling Cooker is completely safe, but as with any cooker
there are some precautions you must take in its use.
NEVER Never allow anyone except an authorized Belling Service Agent to service or repair
your cooker.
Never remove any part of the cooker other than those intended in normal use, or
attempt to modify the cooker in any way.
Never use the cooker for commercial catering. It is designed for domestic use.
Never allow young children to operate or play with the cooker.
Never use a chip pan or deep fat fryer more than 1/3full of oil, or use a lid while
frying and do not leave a fryer unattended while cooking.
Never line the shelves, floor, or sides of the ovens or grill with aluminum foil as
overheating and damage may result.
Never place anything which might catch fire, such as towels or tea towels, near to
the burners or over the flue outlet even when the cooker is not in use.
Never use an asbestos mat, trivet or rack of any kind under pans on any hotplate.
Never store anything which might catch fire in the oven, grill compartment or storage
compartment.
Never allow aluminum foil or plastic to touch any hotplate when it is hot.
Never store flammable liquids, aerosols, etc. in adjacent cabinetry.
Never dry clothes or place other items over or near to the hotplate or oven or grill
doors.
Never use large preserving pans or fish kettles across two hotplates as this will
damage the hob.
Never use cooker as a room heater.
Never wear garments with long flowing sleeves whilst cooking.
Never leave burners lit when not in use.
For Your Own Safety
9

Never use the hotplates with the burner caps removed.
Never use badly designed or misshapen pans which may be unstable.
Never allow pan handles to stick out beyond the hotplate (where they can be
knocked) or over another burner.
IF YOU SMELL GAS turn off all gas controls on the hob, open windows and turn off
gas supply at the mains. Do not operate any electrical switches and contact your
local gas supplier immediately.
ALWAYS
Always make sure you understand the controls prior to use.
Always take care when touching any part of the cooker that may be hot. Use good
quality dry oven gloves when removing or replacing food or dishes.
Always stand back when opening the oven door to allow any build-up of heat or
steam to disperse.
Always keep the oven and grill doors closed when not in use to prevent accidents.
Always make sure that the roof, side and back panels, and shelves are fitted
correctly before using the oven or grill.
Always keep your cooker clean, as a build-up of grease or fat from cooking may be
a fire hazard.
Always switch off at the mains supply before cleaning your cooker.
Always supervise children and pets, particularly when grilling, as exposed parts of
the grill may become hot.
Always place pans centrally over the hotplate burners and make sure that they are
stable.
Always keep handles away from the edge of the hob and any other burners. For
added safety you should consider using a suitable hob guard.
Always make sure that all the controls are switched off when you finish cooking.
Always remember that your cooker may stay hot for a time even after you have
finished cooking.
Always keep ventilation slots at the rear of the cooker clear of obstructions.
10

11
conventional oven
Centre hotplate
(Wok-Triple Ring)
Small electric
KNOW YOUR COOKER
(Behind storage panel)
Rating label on chassis
Cookclean side & rear panels
Large Timed Electric Multifunction Oven
glass door
main oven
Easyfit
2 Oven shelves
PLinth
multi-function
Front left hotplate
Control panel
(Not shown)
detachable handle
food support grid &
Cookclean roof liner
Meat/grill pan c/w
Electric grill
(Closed door)
Rear left hotplate
(Semi-Rapide)
(Rapide)
Easyfit small oven glass door
Drop down storage panel
Cookclean side panels
large oven programmer
Electronic digital timer &
Utensil holder
Baking tray
1 Oven shelf
(Auxiliary)
Rear right hotplate
(Semi-Rapide)
Front right hotplate
stop

Know Your Control Panel
Control Knobs & Switches The hob (Gas hotplates) control knobs can only be rotated anti-clockwise from
the off position.
The ovens thermostat control knobs can only be rotated clockwise from the off
position.
The multifunction selector switch knob can be rotated in either direction from
the off position.
The spark ignition switch is operated as follows.
Depress and hold in the push-button. This will provide a repetitive spark to the
burners.
Timer Instructions
(5) Gas Hotplate Controls
Main Oven Neon
Multifunction Selector
(Programmable Timing Option)
Large Elec Multifunction Oven Thermostat
Switch (Main Oven)
200
230
150 100
70
200
230
m
100
150
and Large Elec Oven Timer
Electronic Digital Clock, Minute Minder
Spark Ignition Switch
stop
Small Oven Neon
Small Conventional Elec Oven Thermostat
12

To set the Time of Day Step 1 Make sure all the oven controls are turned off.
Step 2 Check that the electricity supply to the oven is switched on.
Step 3 When switched on the display will show 0.00 and Auto flashing
intermittently.
Step 4 Press and hold the and buttons together (the display
shows 12.00). At the same time press either the “+” or “-“ button to set
the correct time of day.
RELEASE AND THE TIME OF DAY IS NOW SET.
To set Timer to switch (This allows you to cook immediately for a chosen period of time OFF Automatically
before the oven switches OFF Automatically)
Step 1 Ensure the time of day is set correctly.
Step 2 Place food onto the correct shelf position in the oven.
Step 3 Turn the oven control to the required temperature (The oven should
now be operating).
Step 4 Press and release the button. The display will read 0.00 with the
cook-pot lit.
Within 2 seconds press and hold the “ Up ” or “Down “ button until the required
cooking period is set.
(Adjustment can be made by pressing the “ -“ button)
The timer display will revert to the time of day with the Auto symbol and Cook-
pot lit.
At the end of the cooking period the Auto symbol will flash and an intermittent
bleeping sound will be heard. This will continue for approximately 2 minutes
unless the timer is reset within this period (See step 6).
The oven will no longer operate until the timer has been reset to manual
operation (See steps 5 & 6 on the next page).
Timer Instructions
12
Cook pot
symbol
Cook pot symbol
disappears

To set Timer to switch OFF Step 5 Turn off the oven control
Automatically (Continued)
Step 6 Press the button to cancel the bleeping (If 2 minutes has not
elapsed)
Press button again to return to manual operation.
To set Timer to switch ON (This allows you to cook at a specified time for a chosen period
& OFF Automatically before the oven switches OFF Automatically
Step 1 Ensure the time of day is set correctly.
Step 2 Place food onto the correct shelf position in the oven.
Step 3 Press and release the “ “ button. The display will read 0.00 with
the cook-pot lit. Within 2 seconds press and hold the “ Up ” button
until the required cooking period is set.
(Adjustment can be made by pressing the “ Down “ button).
The timer display will revert to the time of day with the Auto symbol
and cook-pot lit.
Step 4 Press and release the “ “ button. The display will read the
earliest possible end time with the cook-pot and Auto symbol lit.
Within 2 seconds press and hold the “ Up ” to set the time you require
the food to be ready, with only the Auto symbol lit.
(Adjustment can be made by pressing the “ Down “ button).
Step 5 Turn the oven control to the required temperature.
(The oven will now switch on later at the designated time, cook for the
required period and switch off automatically at the stop setting).
At the end of the cooking period the Auto symbol will flash and an intermittent
bleeping sound will be heard. This will continue for approximately 2 minutes
unless the timer is reset within this period (See Step 7).
The oven will no longer operate until the timer has been reset to manual operation (See steps 6 & 7 on the next page).
Timer Instructions
13

To set Timer to switch ON & Step 6 Turn off the oven control
OFF Automatically (Continued)
Step 7 Press the button to cancel the bleeping
(If 2 minutes has not elapsed)
Press button again to return to manual operation.
Other Notes On Timer 1. When cooking Automatically the cook period can be checked at Operation
any time simply by pressing the “ “ button.
2. When cooking Automatically the stop time can be checked at any time
simply by pressing the “ “ button. (This also can be altered at any time
by following Step 4 previously).
3. Having set a cooking period and stop time an electronic device stores the
information. The device within the timer will switch the oven on at the
required start time.
4. If a mistake is made and is not easily rectified, alter the cook period to show
0.00 (As per step 3 above) then press the “ “ button (See step 7
above).
5. After an automatic sequence the bleeping sound can be switched off by
pressing any of the following three buttons.
However, the large oven cannot be operated until the timer has been set to
manual. Press the Button (See Step 7 above).
6. If at any time the display shows three flashing zeros 0.00. It is likely that the
electricity supply to the oven has been interrupted. Reset the timer to the
correct time of day. If there is any food in the oven, make sure that it has
been cooked thoroughly before serving.
7. To give yourself more time to set each function press and hold the required
function button and at the same time press “ +“ or “ -“ button.
Note: Between the hours of 10.00 p.m. and 6.00 a.m. the intensity of the display
reduces.
Timer Instructions
14

To Set the Minute Minder Step 1 Ensure the time of day is set correctly
Step 2 Press and release the “ “ button. Within 5 seconds press and
hold the “ Up ” button until the required time is set (A bell symbol
will light).
This can be adjusted by pressing the “ Down “ button.
On releasing the buttons the timer will revert back to the time of day.
At the end of the set time a bleeping sound will be heard and the bell symbol will
flash.
This can be cancelled by pressing the “ “.
Note: If necessary the Minute Minder can be cancelled before the tone sounds by
pressing the “ “ button and then press the “Down“ button until 0.00 appears
in the display window.
Automatic Cooking (Large Oven)
Rules to follow when When planning your meal, remember that the oven control setting
cooking automatically refers to the center of the oven - it is warmer above and cooler below.
15

1. Food should be as cold as possible when it goes into the oven, ideally straight
from the refrigerator.
2. Frozen meat and poultry should be thawed thoroughly before it is put into the
oven.
3. The automatic timer should not be used in hot weather because of the
possible growth of food poisoning organisms.
4. NEVER use the automatic timer to re-heat Cook-Chill dishes.
5. Never leave food in the oven to cool slowly after cooking.
Serve immediately or refrigerate.
6. Dishes containing left over cooked meat or poultry, for example shepherds
pie, dishes containing eggs, cooked rice or seafood should not be cooked
automatically if there is to be a delay period.
7. Warm food should never be placed in the oven if there is to be a delay period.
Stews prepared by frying the meat and vegetables should be cooked as soon
as possible or refrigerated until loading the oven.
8. Try to set the stop time for a period beyond your anticipated return.
9. DO NOT leave food for an automatic program in a warm oven, i.e. one that
has just been used manually.
10. It is advisable to cover dishes where possible either with a lid or foil to
prevent the transfer of odours. If the food is to be served golden brown, it
may be uncovered or have the lid removed for a quick browning before
serving.
11. Dishes containing liquid should not be filled too full to prevent boiling over.
12. To prevent discoloration of certain fruit and vegetables such as apples,
pears, turnips and parsnips, a little lemon juice should be added to the
cooking liquid.
2. Potatoes should be par-boiled or brushed with fat to prevent discoloration
during delay time.
3. Wine or beer may ferment and cream may curdle during the delay period, so
it is best to add these ingredients just before serving.
Using The Hob
Description of The hob is made of enamelled mild steel and fitted with five gas
Hotplate Burners hotplate burners.
The left front hotplate burner (Rapide) is rated at 3.0kW.
18

The left rear and right front hotplate burners (Semi –Rapide) are rated at
1.75kW.
The centre hotplate burner (Wok –Triple Ring) is rated at 3.5Kw.
The right rear hotplate burner (Auxiliary) is rated at 1.0kW.
Use of Hotplates Check that the electricity supply is switched on. Select the burner to be used.
Push in and turn the control knob anti-clockwise to the large flame symbol:-
Press the ignition button until the burner lights. Turn the control knob to the
required setting.
A simmer position is achieved when the control knob is turned fully anti-
clockwise.
To turn off, turn the control knob fully clockwise to the „0‟ symbol.
Under certain conditions a slight „popping‟ noise can be heard from the
hotplates. This is perfectly normal and will not affect the performance of the
appliance.
Control Setting Guide There are four sizes of hotplate burners on the hob and all are easily
Hotplates adjusted to any rate of cooking required.
The chart given below is provided as a guide only and personal experience will
soon familiarise you with the correct burner and setting to use. This depends on
the size, thickness, material of saucepans and the quantity and type of
ingredients being cooked.
COOKING CHART
Using The Hob
Choosing Your Utensils Any type of flat based kettle or pan from 100mm (4in.) to 230mm (9in.) base
Burner Control Knob Uses Type of Food
position
Simmering Stews of fish, poultry and meet.
Milk puddings –steamed puddings.
Soups - boiled joints of meat e.g.
Ham, mutton, beef, scrambled egg.
SMALL FLAME Apple sauce.
Steady Boiling Vegetables.
Boiling jam after the sugar has been
added.
Shallow Frying Burgers, pancakes, omelettes, bacon
Eggs and raw fish.
LARGE FLAME Fast Boiling Bringing vegetables to the boil,
stir frying battered fruits fish and pasta.
19

diameter may be used. Do not use pans which are unstable when placed on a flat
work-top. The use of split pans, i.e. those comprising two or more pans designed
to fit together over a single burner, is not recommended as these can be unstable
on the hotplate. Asbestos mats should not be used on the pan supports because
they may impede burner performance or damage the pan support.
In order to get best value out of your hob, the following economy tip is
recommended. Choose the correct burner for the size of pan.
Energy Saving Tips 1 Do use saucepans with lids
2 Place pans centrally over burner.
3 Do not allow flames to lick up the sides of the pan.
4 Only fill kettles or pans with the amount of liquid needed.
5 Turn down the gas as soon as the contents of the pan boil.
6 Do not light the burner until the pan is in position and turn off before removing
the pan.
7 Cut vegetables into smaller pieces so that they cook quicker and cook more
than one vegetable in the same pan, e.g. carrots and potatoes.
8 In hard water areas descale kettles regularly.
9 Consider using a pressure cooker.
Using The Hob
Safety Requirements for IMPORTANT:
20

Deep Fat Frying As there could be some fire risk attached to the heating of oil,
particularly for deep fat frying, cooking utensils containing oil must not be
left unattended (e.g. to answer the telephone) or in close proximity to hotplates.
In the unfortunate event of a fire it will assist in smothering the flames if the pan lid
is replaced, and the power supply is switched OFF.
1 Use a deep pan, large enough to completely cover the appropriate heating
area.
2. Never fill the pan more than one-third full of fat or oil.
3. Never leave oil or fat unattended during the heating or cooking period.
4. Do not try to fry too much food at a time, especially frozen food. This only
lowers the temperature of the oil or fat too much, resulting in greasy food.
5. Always dry food thoroughly before frying, and lower it slowly into the hot oil or
fat. Frozen foods, in particular, will cause frothing and spitting, if added too
quickly.
6. Never heat fat, or fry, with a lid on the pan.
7. Keep the outside of the pan, clean and free from streaks of oil or fat.
Utensil Holder Adjacent to the hotplates on the right hand side is a “Utensil holder”
This provides a handy location for the resting of mixing spoons and utensils
whilst using the hob. The tray is removable for cleaning (see cleaning enamel).
Please note that as this tray is located close to burners it may become hot.
Care must be taken when removing. If in doubt, remove using oven gloves.
Main Multifunction Oven & Grill
Operation The main oven, on the left hand side of the cooker, is multifunctional and
incorporates both fan and conventional oven/grill facilities.
21
