Belnick Mesh Swivel Task Chair User manual

Mesh Swivel Task Chair
Customer Service Email: [email protected] |Phone: [phone]
BT-698-BK-GG / BT-698-DKPINK-GG / BT-698-GY-GG / BT-698-LTORNG-GG / BT-698-RYLBL-GG
Thank you for your purchase!
ASSEMBLY INSTRUCTIONS
Before You Begin:
Please identify all component parts and hardware pieces required before you begin. Carefully remove all of the
components from the packaging and set aside for assembly. Assemble on a soft surface to prevent scratching
during assembly.
Caution:
Tighten all components securely before use. Failure to do so may result in personal injury.
DO NOT use any sharp objects to open plastic wrapped components as damage to product or components may
result.
Warning:
CHOKING HAZARD - Small Parts.Adult Assembly Required.
DO NOT ALLOW CHILDREN TO CLIMB ON FURNITURE
Serious or fatal injuries can occur from furniture tipping over. You must install Tipping Restraint Hardware (where
included) to help prevent the unit from tipping and causing accidental injury, instability, death or damage. The
tipping restraint is intended only as a safety measure, it is not a substitute for proper adult supervision.
To help prevent furniture from tipping over it must be permanently attached to the wall. Anti-Tip Safety Wall
Straps suitable for the unit weight and wall materials (if not included) should be purchased and installed.
Online Assembly Instructions: http://ftp.flashfurniture.com/AssemblyInstructions/BT-698-GY-GG.pdf

Have a Question/Concern?
Quality products and first-class customer service are the cornerstone of long-lasting
consumer relationships. We strive toward excellence in all we do and want you to be
completely satisfied with your purchase.
Please contact our exceptional Customer Experience Agents at the email address or
phone number shown below to assist you with any product questions or issues before
requesting a return.
We look forward to serving you in a friendly, efficient manner to resolve any issues you may
have.
Customer Service Email: [e-mail]
Customer Service Phone: [phone]
Our Warranty Statement
This warranty covers manufacturing defects associated with your new product. The product is
warranted from the original purchase date and to the original purchaser for normal usage, according
to the below-referenced specifications and limitations.
•Non-moving metal parts are warranted for 5 years.
•Component parts including pneumatic cylinder, control mechanism, base and casters are warranted
for 2 years.
•All other items are warranted for 1 year.
Normal usage means use in compliance with the restrictions and weight limits specified for the
product. In the absence of product-specific restrictions and weight limits, normal usage means use for
no more than forty hours per week by persons weighing 250 lbs. or less. Coverage terminates if the
product is sold or otherwise transferred. Repairs made by parties other than Belnick also void this
warranty.
This warranty will not cover: (1) labor, freight, or damage from misuse, abuse, negligence, alteration,
assembly, installation, attachments, accident, vandalism, acts of nature or any other event beyond the
control of Belnick; (2) tearing, scratching, scuffing, or blemishing of leather or fabric; (3) cosmetic
damage that may result from normal usage; (4) damage attributable to use by persons exceeding
specified weight limits or commercial use exceeding forty hours per week; or (5) rust or other damage
caused by exposure to moisture. The user assumes all risk of injury resulting from use of this product.
Liability for incidental or consequential damage is excluded. Some states do not allow the exclusion or
limitation of incidental or consequential damages, so the above limitation or exclusion may not apply
to you.

⑿x1
Gas Lift Cylinder
⑴x5
Caster
⑵
x 1 Base
⑶
x 1 ⑷x1Cylinder Cover
Seat Plate
⑹
x 1 Seat
⑺
x 1 Back ⑻x1 Connector Bar
x4
Screws
⑽
x2
Screws
Bracket Set
(a* b)
Washer & Knob
⒀
x 1
PARTS
STEP 1
⑷
⑶
⑵
⑴
STEP 2
⑼
⑸
⑹
STEP 3
⑽
⑾b
⑾
a
⑻
STEP 4
STEP 5
⑸
⑶
STEP 6
⑿b
⑿
⑻
⑹
a
⑺
⑸x 1
Allen Wrench
⑼
FRONT
Insert Gas Lift Cylinder (Part 3) into the
5-Star base and press down. Place
Cylinder Cover (Part 4) over Gas Lift
Cylinder.
Insert (5) Casters (Part 1) into 5-Star
Base (Part 2).
Cylinder Cover
Gas Lift Cylinder
5-Star Base
Casters
Lay the Seat
(Part 6) face
down on a
smooth
surface.
Attach Seat
Plate (Part 5)
using (4) Short
Screws (Part
9). Tighten with
Allen Wrench.
Short Screw
Seat Plate
Seat
NOTE: Ensure front of seat
plate is facing front of seat.
Attach Connector Bar
(Part 8) using Bracket
Set (Part 11a*b) using
(2) Long Screws.
Tighten
with Allen
Wrench.
Long Screw
Bracket Set
Back Connector Bar
Lay the Back
(Part 7) face
down.
Lay Seat (Part 6) face down and slide
Connector Bar (Part 8) into the Seat
Plate. Attach using Washer and Knob
(Part 12a*b).
Washer
Knob
Connector Bar
Seat
Place Seat onto the Cylinder and align
hole in Seat Plate. Push down to firmly
attach.
Gas Lift Cylinder
Seat Plate
Ensure all screws are
securely tightened.
