Beltronics LP904 User manual

LASER DEFENSE SYSTEM
NEW
TM
Operating Manual
For LaserPro™904
Model LP904
Ultimate Performance. Proven Technology.
8804_LaserPro904Manual 5/2/02 1:24 PM Page 1 Rev 7 Mac

Congratulations on your
purchase of BEL LaserPro™904.
BEL LaserPro™904
is designed as the ultimate in
traffic Laser defense given that it
produces countermeasures
beyond the function of
traditional Laser detectors by
blocking the Laser beam that is
targeted at your vehicle.
LaserPro™904 is comprised
of sophisticated, exterior
mounted front and rear Laser
transceivers. You can operate
LaserPro™904 as a stand-alone
unit, and know you’re protected
beyond traditional “Laser
detectors”, or you can
supplement LaserPro™904’s
capabilities with a dash or
Remote Installation
Radar/Laser/Safety detector
from BELTRONICS.
Please Note:
Operating BEL LaserPro
™
904 is
not a license to speed. Observe
the local speed limits and laws
governing the user of a Laser
defense product. Use of
LaserPro
™
904 is prohibited in
some states. Check your local
and state laws before use or call
BELTRONICS:800-939-7373.
The Three transceivers of
LaserPro
™
904 must have a
clear view of the road in front
and behind, and must be
installed level to the road in
order to work properly. Ensure
your BEL LaserPro
™
904 is
correctly positioned after it is
installed.
IMPORTANT Notice
It is recommended that
LaserPro™904 be professionally
installed. New car dealers, and
many reputable auto shops or
car stereo stores should be able
to install LaserPro™904. Call
BEL toll-free at 800-737-9393,
for the name of an authorized
dealer near you.
Installing LaserPro™904 without
expertise in automotive
electronic installations could
cause personal injury, or damage
to the unit or your vehicle. If
your vehicle is damaged during
installation, its safety systems
may be compromised, which
could cause personal injury or
property damage.
Congratulations and Important Notice
2
8804_LaserPro904Manual 5/2/02 1:24 PM Page 2 Rev 7 Mac

Quick Overview of Functions and LED Display . . . . . . . 4
Button Functions/Explanation of LEDs
Power/Volume Button . . . . . . . . . . . . . . . . . . . . 5
Bright/Dim/Dark Modes . . . . . . . . . . . . . . . . . . . . 5
Disarm Button . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Explanation of LEDs . . . . . . . . . . . . . . . . . . . . . . 5
Power On Indicator . . . . . . . . . . . . . . . . . . . . . . . 5
Front/Rear Laser Alert Indicators . . . . . . . . . . . . . . . . . . 5
General Operation/Disarm Function . . . . . . . . . . . . . 6
How Traffic Laser (LIDAR) Operates . . . . . . . . . . . . . 7
Alert and Errors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . 10
Questions and Answers . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Consumer Warranty . . . . . . . . . . . . . . . . . . . . . . . 12
Warranty Service . . . . . . . . . . . . . . . . . . . . . . . . . 13
Post Warranty Service . . . . . . . . . . . . . . . . . . . . . 14
Table of Contents
3
8804_LaserPro904Manual 5/2/02 1:24 PM Page 3 Rev 7 Mac

Quick Overview of Functions and LED Display
4
1. P/V Button: Power and
Volume button.
2. DRK Button: Press once to “dim”
the ALERT LED display; press a second
time to cancel illumination of the
ALERT LED display. The GREEN Power
On LED will illuminate in “dim” mode
to confirm LaserPro™ 904 is
operational. Factory default is full
brightness.
3. DIS Button: Press during a Laser
encounter to stop LaserPro™ 904
from continuously blocking the
return of the Laser signal once
an alert is received.
4. Red “F” LED: illuminates to
confirm a Laser alert from the
front.
5. Red “R” LED: illuminates
to confirm a Laser alert from
the rear.
6. Three Blue LEDs: illuminate in
conjunction with the “F” or “R” LED to
confirm a Laser alert.
7. Audio Speaker: All audio alerts are
emitted from this opening.
8. Green Power On LED: Illuminates to
confirm LaserPro™ 904 is operational.
8804_LaserPro904Manual 5/2/02 1:24 PM Page 4 Rev 7 Mac

Button Functions
1. P/V Button: Press
once to activate power to
LaserPro™904*. Press and
hold to cycle the volume
control.
* Depending upon the type of
installation, LaserPro
™
904 may
be powered ON when your
vehicle ignition is ON; and
turned off, when your vehicle
ignition is OFF .
2. DRK (Dark) Button: Press
once to “dim” the LED display.
Press again to completely cancel
illumination of the ALERT
display. In “dark” mode, power
to the unit is confirmed by the
“dim” illumination of the GREEN
Power On LED.
3. DIS – Disarm Button: Once
a Laser alert is displayed via the
red and blue ALERT LEDs,
whether from the front or rear,
press the DIS button to disarm
LaserPro™904 from further
“blocking” traffic Laser signals.
BELTRONICS recommends that
the DIS button be pressed
within five seconds of a Laser
alert. Five seconds provides you
enough time to adjust your
vehicle speed and avoid any
undue attention you may draw
to yourself and your vehicle.
If you choose, you can rearm
LaserPro™904 by pressing
the DIS button a second time
(see page 6).
Explanation of LEDs
1.Power On Indicator:
illuminates GREEN to confirm
LaserPro™904 has power and is
operational. This same LED
illuminates in “dim” mode when
you have activated either the
“dim/dark” function.
Green LED also flashes during
the DISARM mode.
2. 3 Blue LEDs: Illuminate to
confirm a Laser alert. Distinct
patterns confirm if the alert is
from the front or rear.
3. “F” Red LED: Illuminates red
to confirm a Laser alert from the
front of your vehicle.
4. “R” Red LED: Illuminates red
to confirm a Laser alert from the
rear of your vehicle.
Button Functions/Explanation of LEDs
5
er
04
8804_LaserPro904Manual 5/2/02 1:24 PM Page 5 Rev 7 Mac

General Operation
Once you have BEL LaserPro™904
properly installed, you’re ready for
unencumbered travel. Assuming
LaserPro™904 is “hard wired” into
your vehicle’s electrical system,
each time you start your vehicle,
LaserPro™904 will start up.
Conversely, each time your shut
your vehicle off, LaserPro™will
shut down. When an alert is
received, LaserPro™904 will
confirm a traffic Laser encounter
from
the front or rear. A Laser signal
targeted at the transceivers
mounted at the front of your
vehicle will trigger an urgent
audible alert and the illumination
of the red “F” (Front) LED,
coupled with the three blue LEDs
ramping left to right; conversely, a
signal targeted at the rear
transceiver will set-off an urgent
audible alert, coupled with the
illumination of the red “R” (Rear)
LED, and the “ramping” of the
blue LEDs from right to left.
Generally, a Laser alert is very
quick. Always remember to
respond to any alert LaserPro™
904 displays.
Once an alert is received, it is
recommended that you confirm
your vehicle’s legal speed and
Disarm your LaserPro™904
from further returning a
“blocking” signal to the Laser
source. Five seconds should be
ample time for you to:
a) Verify your vehicle speed;
b) Press the DIS (DISARM)
button once you’re in
compliance with the
posted speed limit.
Disarm Function
Pressing DIS (Disarm) will
terminate the LaserPro™904
transceivers from further
returning a blocked signal to the
Laser gun, and make certain
countermeasures do not
interfere with the officer’s traffic
Laser signal.
Once the DIS (DISARM) button
has been pressed, LaserPro™
904 will display a flashing green
power LED. This flashing green
LED serves to confirm that
LaserPro is no longer “blocking”
the Laser signal. This “monitoring”
mode will last for 60 seconds.
General Operations/Disarm Function
6
8804_LaserPro904Manual 5/2/02 1:24 PM Page 6 Rev 7 Mac

”
Any signal received while in this
mode will result in an alert –
BUT NO “BLOCKING” OF THE
LASER SIGNAL WILL OCCUR.
When no Laser signal has been
detected for 60 seconds, a
short “beep” will be heard,
coupled with FULL illumination
of the green power on LED. This
FULL illumination of the power
on LED confirms that the front
and rear transceivers have been
re-armed and are ready to
“block” future Laser
encounters.
Re-arming LaserPro 904
Once you have pressed the DIS
button, you can “rearm” the
blocking function without
waiting the 60 second time
period. To “rearm” LaserPro™
904 BEFORE the automatic 60
second time out expires, simply
press the DIS button a second
time. LaserPro™904 will be
ready to “block” the Laser
signals.
Note: If the LaserPro™904 is not
disarmed during a Laser encounter
it will continue to return blocking
signals whenever receiving further
Laser transmissions.
How Laser (LIDAR) Operates
Laser speed detection is actually
LIDAR (Light Detection and
Ranging). LIDAR guns project a
narrow beam of invisible,
infrared light. The signal is a
series of very short infrared light
energy pulses that move in a
straight line, reflecting off your
car and returning to the gun.
LIDAR use the light pulses to
measure the distance to a
vehicle. A very accurate speed
reading is calculated by
comparing the change in
distance over time.
LIDAR (or Laser) is a newer
traffic monitoring technology
and is not as widespread as
conventional radar; therefore,
you may not encounter Laser on
a daily basis. And unlike radar
detection, Laser detection is not
prone to “false” alarms.
Because LIDAR transmits a much
narrower beam than does radar,
it is much more accurate in its
ability to distinguish between
targets and is also more difficult
to detect. As a result, even the
briefest Laser alert should be
How Traffic Laser Operates
7
8804_LaserPro904Manual 5/2/02 1:24 PM Page 7 Rev 7 Mac

taken seriously. There are
limitations to LIDAR equipment.
LIDAR is much more sensitive to
inclement weather conditions
than RADAR, and a LIDAR gun’s
range will be decreased by
anything affecting visibility such
as rain, fog, or smoke. A LIDAR
gun cannot operate through
glass and it must be stationary to
get an accurate reading. Because
LIDAR must have a clear line of
sight and is subject to cosine
error (an inaccuracy which
increases as the angle between
the gun and vehicle increases)
police typically use LIDAR
equipment parallel to the road or
from an overpass within 500-
1000 feet from targeted vehicle.
LIDAR can be used day or night.
Loss Of Connection Alert
BEL LaserPro™904 comes
complete with built-in self-
diagnostic circuitry, and error
indications.
During the start-up sequence,
the display will make certain
that all components are
connected and communicating
properly to ensure optimum
performance.
On initial start-up, a power-on
test sequence occurs. During
this time communications
between the front transceivers,
the interface (the “hub”
installed under your vehicle’s
dash which the transceivers and
control display are connected)
and the rear transceiver are
tested. Finally, the interface and
control display communications
are tested. If everything is
working correctly, the green
power-on indicator
will remain “on”.
Error Indications
LaserPro™904 is in constant
communication with each of its
components. If at anytime a
problem occurs that could
impede performance, (i.e. cable
is disconnected) an error
message will occur.
8
Alerts and Errors
8804_LaserPro904Manual 5/2/02 1:24 PM Page 8 Rev 7 Mac

Front Transceiver Error
If one, or both of the front-
mounted transceivers are not
communicating properly or
become disconnected, the red
“F” LED (front) on the display
will illuminate fully coupled with
an audible tone. This alert will
continue until the unit is turned
off, indicating that service is
required.
Rear Transceiver Error
If the rear transceiver is not
communicating properly, or
becomes disconnected, the
red “R” LED (rear) on the
display will illuminate fully,
coupled with an audible tone.
This alert will continue until
the unit is turned off. Contact
your installer for servicing.
Specifications
Operating Band
Laser 904nm, 33 MHz bandwidth
Laser Detection
Quantum Limited Video Receiver
Multiple Laser Sensor Diodes (6F, 3R)
Laser Transmitter
Multiple Laser-Blocking Diodes (16F,
8R)
Display Type
Hi-visible LED indicators
Power Requirement
12VDC, Negative Ground
Dimensions (inches)
Display/Controller: 2.25 x 2.0 x
.66
Front Laser units: 4.65 x 1.8 x
.08
Rear Laser unit: 6.0 x 1.0 x .65
Specifications
9
8804_LaserPro904Manual 5/2/02 1:24 PM Page 9 Rev 7 Mac

Problem
LaserPro™ 904 does not appear
to be ON
Solution:
• Check that the P/V control is
turned ON.
• Check that the vehicle ignition is ON.
• Check all connections.
Problem
LaserPro™ 904 gave no alert
when a police car was in sight
Solution:
• Officer may not have the Laser
unit turned on
• Officer may have been targeting
another vehicle
• Officer may be using a radar
gun, not a Laser gun.
Problem
The control display feels warm to
the touch.
Solution:
• It is normal for the display to
feel warm
Problem
LaserPro™ 904’s power-on
sequence reoccurs while you are
driving
Solution:
• A loose power connection can
cause LaserPro™ 904 to be
briefly disconnected, and will
trigger the power-on sequence.
Problem
During the start-up sequence, the
LED labeled “F” continues to flash,
and a warning sound is heard.
Solution:
• The front transceivers are not
communicating to the interface.
Check all connections, or
contact your installer.
Problem
During the start-up sequence, the
“R” indicator (LED) flashes and a
warning tone is heard.
Solution:
• The rear transceiver is not
communicating with the
interface. Check all connections,
or contact you local installer.
10
Troubleshooting
8804_LaserPro904Manual 5/2/02 1:24 PM Page 10 Rev 7 Ma

Q. Is LaserPro™904 theft-Proof?
A. Generally yes. Although
LaserPro™904 is relatively visible
on the exterior of your vehicle, it
is deemed fairly “useless” to
anyone wanting the transceivers
themselves. Any “thief” would
have to cut the cables in order to
remove the transceivers, which
would render them useless to
anyone.
Q. Can LaserPro™904 be used on
a Motorcycle?
A.Yes, providing the Laser
transceivers are adequately
shielded from the elements.
Q. Is LaserPro 904 weather-
proof?
A. Yes. All three transceivers are
completely sealed against the
elements. Their unique design
guards against water, moisture
and dust.
Q. Is LaserPro™904 a legal
device?
A. Generally yes. While the FCC
governs RF devices that would
“interfere” with law
enforcement’s traffic Radar, Laser
on the other hand, is comprised
of infrared wavelengths of light,
and therefore not governed by
the FCC, but rather the FDA,
which has no regulations
concerning interference with
traffic Laser signals. LaserPro
904 is legal to use in most states
except for California, Utah,
Virginia, and Minnesota. Check
with your local code before use,
or call BELTRONICS at: 800-
737-9393.
Q. Can I use a traditional
dash mounted Radar/Laser
detector with LaserPro™904?
A. Yes. As discussed throughout
this manual, LaserPro™904 only
detects Laser signals and
provides a warning alert coupled
with Laser countermeasures
LaserPro™904 does not detect
traffic Radar signals. You can
purchase any BEL detector to
complement the protection
obtained with a LaserPro™904.
Simply operate the dash-
mounted detector in tandem
with LaserPro™904 for the best
protection possible. You may
also consider a BEL remote
installation radar/Laser detector.
Visit you local BEL retailer or
call BELTRONICS to inquire
at 800-737-9393.
11
Questions and Answers
8804_LaserPro904Manual 5/2/02 1:24 PM Page 11 Rev 7 Ma

1 Year Limited Warranty
1. This warranty covers all defects in material and workmanship. This
warranty does not apply if the unit has been subject to physical abuse,
improper installation, modification, or if the housing or serial number
of the unit has been removed.
2. The enforceability of this warranty is limited to the original
consumer purchaser and is not transferable to, or enforceable by, any
subsequent owner.
3. In the event of a defect, malfunction or other failure to consumer
to this warranty, BELTRONICS will, at is sole discretion, repair or
replace the unit at no charge. You are responsible for all shipping
costs in connection with warranty service pursuant to this warranty.
4. This warranty commences on the date of retail purchase and shall
be effective for a period of one year.
5. There are not express warranties covering the unit other than those
set forth in this warranty. All implied warranties are limited to the
period of this warranty and no warranties are limited to the period of
this warranty and not warranties expressed or implied, extend beyond
this period. Some states do not allow limitation on how long an
implied warranty lasts, so the above may not apply to you.
6. BELTRONICS will in no event be liable for any consequential,
incidental, indirect or special damages (including, but not limited to,
lost profits) arising out of or in connection with the use, misuse, or
function of the unit. Some states do not allow the exclusion of
limitation of incidental or consequential damages, so the above
limitation or exclusion may not apply to you.
7. This warranty gives you specific legal rights, and you may also have
other rights which vary from state to state.
8. You must provide a copy of a dated sales receipt for your unit in
order to receive service under warranty.
12
Consumer Warranty
8804_LaserPro904Manual 5/2/02 1:24 PM Page 12 Rev 7 Ma

Warranty Service
If you feel your LaserPro™904 is not operating properly, please
review this manual, particularly the section on Troubleshooting.
If you still feel service is required, please follow the instructions
below:
1. To obtain service during the warranty period, please call the
appropriate number below to obtain an RA number and shipping
instructions. Remember to return your detector postage paid, insured
and in suitable packaging:
800-341-2288 USA
800-268-3994 CAN
2. For your own protection, obtain a proof of delivery receipt.
Shipping costs are your responsibility.
3. Enclose with your unit the following information:
a) Your name, complete return address and written description of
the problem. (No P.O. Box Please)
b) A telephone number where you can be reached during regular
business hours.
c) A copy of your dated sales receipt.
13
Warranty Service
8804_LaserPro904Manual 5/2/02 1:24 PM Page 13 Rev 7 Ma

The following arrangements apply if the warranty period has expired
or you are not able to provide a copy of your dated sales receipt
indicating purchase within the last 12 months.
1. Return your unit to the appropriate address under Warranty
Service and follow steps 1 through 3(b) outlined in that section.
2. Enclose with your unit $85 US or $115 CAN to cover inspection
and postage return. Prices subject to changes without notice.
For replacement parts and costs, please call:
1-800-341-2288 USA
1-800-268-3994 CAN
14
Post Warranty Service
8804_LaserPro904Manual 5/2/02 1:24 PM Page 14 Rev 7 Ma

15
8804_LaserPro904Manual 5/2/02 1:24 PM Page 15 Rev 7 Ma

Head Office
2422 Dunwin Drive
Mississauga, Ontario
Canada L5L 1J9
Tel: [phone] Fax: [phone]
www.beltronics.com
This product is subject to one or more of the following patents:
United States
#4,571,593 #4,625,210 #4,630,054 #4,939,521
#4,952,936 #4,961,074 #5,402,087 #5,446,923
#5,587,916 #5,600,132
Canada
#1,187,586 #1,187,602 #1,295,714 #1,295,715
Other Patents Pending
is a registered trademark of BELTRIONCS USA, Inc. LaserPro 904
is a trademark of BELTRONICS USA, Inc.
Printed in Canada 273004-12
TM
Ultimate Performance. Proven Technology.
8804_LaserPro904Manual 5/2/02 1:24 PM Page 16 Rev 7 Ma
