bemodern Juliette Assembly instructions

Instructions for Assembly & Installation
Juliette Wall Hung Suites
200857R1-06/2023

1
Contents
Technical Specification 2
What’s in the Boxes 2-3
Installation Introduction 3
Installation Preparation 4
Installation- Wall Mounted Suite 5-11
Fuel Bed Layout & Log Positioning 12
Replacing the Glass 13
Maintenance 14
200857R1-06/2023

2
Technical Specification
200857
Fire/ Surround escription Logs
imensions (mm) Unboxed
Weight
A B C E (Kg)
INVISION 1000L
FIRE/ JULIETTE SUITE Timber Suite 5 SML 1211 260 1211 300 596 13.5
INVISION 1250L
FIRE/ JULIETTE SUITE Timber Suite 5 SML & 2 LRG 1461 260 1461 300 596 14.4
FIRE Visible Flame Area (mm)
INVISION 1000L FIRE W1008X H296
INVISION 1250L FIRE W1258 x H296
R1-06/2023
What Is In The Boxes?
Fire/
Surround
escription
Surround Box
Qty escription
INVISION
1000L FIRE
/ JULIETTE
SUITE
1 Surround Top
2 Column Sides
1 Surround Hearth
2 40mm Angle Bracket -fitted
4 16mm Screws -fitted
2 Wall Hooks
4 30mm Dome head Screws
Fire/
Surround
escription
Surround Box
Qty escription
INVISION
1250L FIRE
/ JULIETTE
SUITE
1 Surround Top
2 Column Sides
1 Surround Hearth
2 40mmAngle Brackets -fitted
4 16mm Screws -fitted
2 Wall Hooks
4 30mm Dome head Screws

3
200857
What Is In The Boxes? Continued……..
Please ensure that everything is present before commencing the installation. If anything is missing please call
Customer Services on 01914300901 or email us at [e-mail]
Fire/
Surround
escription
Boxed Inside the Fire
Quantity escription
INVISION
1000L FIRE
/ JULIETTE
SUITE
5 Small Logs
1 Bag Of Crystals
1 Bag Of Pebbles
Bagged Separately
1 Remote
Control
2 AAA Batteries
1 Fire Operating
Instruction
1 Foam Strip
Supplied Fixed to Fire Rear
1 Wall Hanging
Bracket
Fire/
Surround
escription
Boxed Inside the Fire
Quantity escription
INVISION
1250L FIRE
/ JULIETTE
SUITE
2 Large Logs
5 Small Logs
1 Bag Of Crystals
1 Bag Of Pebbles
Bagged Separately
1 Remote Control
2 AAA Batteries
1 Fire Operating
Instruction
1 Foam Strip
Supplied Fixed to Fire Rear
1 Wall Hanging
Bracket
R1-06/2023
Installation- Introduction
Do not attempt to lift from the centre of the fire, instead lift from under the fire base and front edge of the fire.
See iagram 1.
Note: The Suite is a two adult person lift. A second person will be required to lift and support the pre-assembled
parts during installation.
Before the suite can be installed, consideration will need to be given to routing the power supply to the fire. This
will affect the stages of the installation process. We advise a qualified electrician to conduct any electrical parts of
the installation.
Note: A single socket is required for the operation of the suite.
iagram 1

4200857
Once the 2x Screws and 2x Glass Brackets are removed the Glass can be tilted forward (1) from the top of the fire
and lifted out of the channel at the base of the glass. (2) See diagram 4.
Note: Place the Glass, 2x Glass Brackets and 2x Screws in a safe place, as these will be required later.
Note: Before proceeding further ensure there is power to the Fire (Suite), and it is operating correctly.
Follow the separate fire operating instructions.
The next step is to decide on the installation location and before starting the installation ensure that there is
enough space to install the Suite - See P2, for the product overall sizes.
iagram 4
R1-06/2023
Installation- Preparation
Note: O NOT dispose of the packaging until you have checked and made sure all the parts and fixings listed on
P2 & P3, are present..
Unpack your new Suite & Fire which are boxed separately and require some light assembly. Once the fire is
unpacked the Cardboard Boxes inside the fire need to be removed and the contents checked, as listed on P3.
To do this, unscrew the 2x Screws holding the 2x Glass Brackets in place. There is 1x Screw either side of the fire.
See iagrams 2 & 3.
Note: The instructions are detailed for both 1000 and 1250 Suites- Please familiarise yourself with the model
you have purchased before proceeding further.
iagram 2 iagram 3

5
Installation – Wall Mounted Suite
200857
Once the desired installation height has been determined, lightly mark the position of the bottom edge of the Suite
centrally on the on the wall. Measure up a further 60mm from this position (This is so the line can’t been seen once
the Suite is installed) and lightly mark a vertical line in the centre of the installation area at a length of
approximately 510mm. See iagram 15.
Note: Consider once installed the distance from the bottom edge of the Suite to the top of the Wall Mount
Bracket is 526mm. The top of the surround is approx. 71mm above this. See iagram 5.
iagram 6
iagram 5
Suite Positioning - The Wall Mounted Suite may be positioned at any desired height on the wall.
R1-06/2023
526 71
INSTALLATION AREA
CEILING LEVEL
FLOOR LEVEL
CENTRE LINE
BOTTOM E GE
OF THE SUIT
510
60

60
6
Installation- Wall Mounted Suite Continued……..
200857
Working from the previously marked line indicating the bottom edge of the Suite and using a straight edge lightly
mark a horizontal line approx. 300mm either side of the previously marked centre line at a height of 466mm.
See iagram 7.
Once marked, drill the fixing positions. Depending on the wall medium, it may be necessary to plug the drilled holes.
See P14 ‘Important Note’.
Finally screw and secure the Wall Mount Bracket to the wall using suitable screws. See P14 ‘Important Note’.
See iagram 9.
Locate the Wall Mount Bracket- (screwed to the rear of the fire). Measure and lightly mark the centre of the Wall
Mount Bracket and offer the top of the Wall Mount Bracket up to the previously drawn horizontal line, level and
mark the fixing positions in the bracket on the wall behind. See iagram 8.
iagram 8 iagram 9
iagram 7
R1-06/2023
INSTALLATION AREA
CEILING LEVEL
FLOOR LEVEL
CENTRE LINE
BOTTOM E GE
OF THE SUIT
466
300 300

Note: The Fire is a two adult person lift.
Note: The power cable needs be routed to the rear of the Suite. Care must be taken not to crush or damage the
cable when positioning the Suite. Before proceeding further ensure the power cable is connected to a power
supply. See iagram 18.
7
Installation- Wall Mounted Suite Continued……..
200857
Lifting the Fire as described on P3, offer the Fire back to the wall approx. 90mm above the top of the Wall Mount
Bracket and lower the Fire parallel with the wall into position. When lowering try to make sure the ‘prongs’ on the
Wall Mount Bracket engage with the slots on the back of the Fire. See iagram 12 & 13.
If necessary, repeat this step, until you are confident the Fire is fully engaged on the Wall Mount Bracket and if
required centralise in the installation location, there will be some slight adjustment left and right.
iagram 10
iagram 13iagram 12
iagram 11
R1-06/2023
Before hanging the Fire on the wall mount bracket. The two L- Brackets need to be repositioned from the transit
position to the base of the Fire. Unscrew the L-Brackets and refit them as indicated in iagram 10 & 11, onto the
bottom of the Fire.

8
Installation- Wall Mounted Suite Continued……..
200857
Finally, loosen the 4x Screws holding the bottom two L- Brackets, so that the L- Brackets can be positioned up
against the wall. The brackets will hold the fire parallel with the wall. Marking the fixing positions. See iagram 14.
Use a spirit level on the front of the fire to ensure it is plumb.
Mark the fixings positions of the L- Brackets and remove the two L- Brackets from the fire. See iagram 15.
Once removed, drill the fixing positions. Depending on the wall medium, it may be necessary to plug the drilled
holes. See P14 ‘Important Note’.
iagram 15
iagram 14
R1-06/2023

9
Installation- Wall Mounted Suite Continued……..
200857
Finally screw and secure the 2-off L- Brackets back on the fire and then to the wall using suitable screws. See P14
‘Important Note’. See iagrams 16 & 17
To aid the installation of the suite parts. We advise that the fires power cable should be routed neatly down the
side of the fire. See iagram 18
iagram 16 iagram 17
R1-06/2023
iagram 18 iagram 19
Power Cable Routing
The fire installation is now complete. Locate the previously unpacked surround top, base and sides.
The suite base/hearth, will be fitted to the wall mounted fire first. To aid fitment loosen the 4x M6 Hex head screws
which will be installed on the fire at the factory. These need to be backed off fully to allow the hearth top panel to
slide on to the mount brackets without resistance. See iagram 19 & 20

10
Installation- Wall Mounted Suite Continued……..
200857
Position the hearth centrally on the fire, touching the rear wall. Take great care when sliding the hearth in place to
prevent scratching the top surface of the hearth. Lightly tighten the 4x M6 Hex head screws which will be installed
on the fire at the factory. See iagram 21 & 22.
The next step to the suite installation is to fit the suite top section wall hooks. The wall hooks should be positioned
as detailed in iagram 23 (dependant on the fire option installed).
iagram 21
R1-06/2023
iagram 23iagram 22
REAR VIEW
A-A
B-B
C-C
D-D
Fire/ Surround
imensions (mm)
A-A B-B C-C -
INVISION 1000L FIRE/ JULIETTE SUITE 1050 525 18 312
INVISION 1250L FIRE/ JULIETTE SUITE 1300 650 18 312
iagram 20

11
Installation- Wall Mounted Suite Continued……..
200857
Locate the suite top and 2-off column sides. Screw the lefthand and righthand columns to the inside rear of the
suite top, using 4-off 30mm Dome Head Screws provided. The columns must be touching the top under side face, in
line with the rear face of the suite top. See iagram 24.
The fire installation is now complete. The fuel bed
can now be dressed and the logs positioned.
See iagrams 27-31, P12.
iagram 25
iagram 26
R1-06/2023
80mm
iagram 24
Once the suite top is assembled. With the help of a second person, the suite top should carefully positioned down
behind the fire. Great care should be taken when lowering the suite top on to the suite base, locating the suite top
on to the previously installed wall hooks. See iagram 25 & 26.
96mm

Tip: Before dressing the fuel bed- position the foam
strip (supplied) in the channel in the base of the fire,
this will help to stop the smaller fuel bed material
falling into the channel during installation.
See iagram 27.
The dressing of the fuel bed can be fully tailored to the
customers individual tastes. A sufficient amount of
each fuel bed finishing material has been provided to
cover the fuel bed in a single type of material.
iagram 30 - Above shows an example of the 7-off log set up for the 1250L Fire .
12
Fuel Bed Layout & Log Positioning
200857
iagram 27
Fuel Bed ressing- As a starting point follow the example below:
iagram 28 - Place a large amount of crystals in the centre of the fuel bed- leaving a gap around the edges.
Tip- The crystals pick up light from the under bed lights to give you a realistic glowing ember effect, so we
recommend using a generous amount.
iagram 29 - Fill the space around the edges of the crystals with the pebbles, as well as randomly in between the
crystals.
iagram 31 - Above shows an example of the 5-off log set up for the 1000L Fire .
Positioning the logs- As a starting point follow the example below:
Large Log Large Log
R1-06/2023

13
Replacing the Glass
200857
With the rear of the Glass clean and angled forward slightly position the Glass in the channel in the base of the fire
(1), and carefully push back into position. (2) See iagrams 32 & 33.
Finally the Glass and 2x Glass Brackets can be refitted, using the previously removed 2x Screws.
Note- Before proceeding further remove the foam strip and check the channel in the base of the fire is free of
any fuel bed material.
Tip- Ensure the rear of the glass is clean before fixing in place.
Once in the correct position secure with the 2x Screws and 2x Glass Brackets. 1x Screw and 1x Glass Bracket either
side of the fire. See iagram 34.
The installation is now complete.
Note: Consult the separate Fire Operating Instructions for manual and remote operation.
iagram 32 iagram 33
iagram 34
R1-06/2023

14
WARNING: Before any maintenance or whilst cleaning the exterior of the fireplace, the unit should
be disconnected from the power supply until it has cooled down.
Cleaning the Fire
Cleaning or polishing products are not recommended. Fingerprints or other marks on the front glass
panel can be removed by a piece of soft, damp, lint-free cloth with a good quality household glass
cleaner. The front glass panel should always be completely dried with a clean, lint-free cloth or paper
towel.
CAUTION: Abrasive cleaners should not be used on the glass panel. Liquids should not be sprayed
directly onto any surface of the unit.
200857
Troubleshooting
Should you have any queries regarding this product please contact Customer Services on 0191 4300901
(option 4) or email us at customerservi[email protected]k
Recycling
All cardboard packing is recyclable
Maintenance
IMPORTANT NOTE:
Wall fixings (i.e. screws/wall plugs etc.) are not supplied as these are crucially dependent upon the type of wall and
surface the Suite is going to be fixed too.
The installer is therefore responsible for ensuring that suitable fittings are used as well as individual fitting situations
and environments. All mechanical fixings, for holding the Suite in position, must be secured to a solid wall or
structure.
