BenQ LU9915 User manual

LU9915
Digital Projector
Installation Guide
V1.02
4J.JHG01.001

2
Table of Contents
Notice ................................................................................................................... 3
Ventilation illustration ......................................................................................................3
Exhaust vent requirements..............................................................................................3
Voltage switcher ................................................................................................................4
Caution during installation ..............................................................................................4
Product information ..................................................................................5
Packing contents................................................................................................................5
Projector specifications....................................................................................................5
Terminals ................................................................................................................................................... 6
Remote control..................................................................................................................7
Remote control ID setting ...............................................................................................7
Installation ........................................................................................................... 8
Lens specifications.............................................................................................................8
Projection table .................................................................................................................9
Lens shift.............................................................................................................................11
Installation positioning .....................................................................................................12
Dimensions .......................................................................................................... 13
Cabinet dimensions...........................................................................................................13
Ceiling mount hole dimensions.......................................................................................13
Ceiling mount dimensions (CMG6)................................................................................14
Optional lens dimensions .................................................................................................15
LED indication.............................................................................................16
Please visit below website for latest version of User Manual / Installation Guide.
http://business-display.benq.com/
10/8/18
English

3
Notice
Ventilation illustration
Air inlet
Air inlet
Air outlet
Exhaust vent requirements
For proper ventilation of the projector, make sure to leave some space around the projector as
shown in the illustration below:
11.8 in / 30 cm
or greater
11.8 in / 30 cm
or greater
AUTO CE NTER
PO WER IN P UT S Y NC ASP ECT L E NS S H UTTE R
LENS FOC US ZO OM
MENU EXIT S HIF T
D VI - D
Di s pla y P o rt
3D S y n c Out
H D MI
H D B as e T / L A N
19.7 in / 50 cm
or greater
R G B IN R G B OU T R /P r G/Y B/P b H V
RS-2 3 2 T RI G G E R US B W I R E
19.7 in / 50 cm
or greater
English

4
Voltage switcher
Please make sure the Voltage Switch is selected at the right voltage in the region where projector
is being used.
Note:
Default setting is 230V.
Caution during installation
•Please turn off projector when changing or removing lens, or it will cause the projector shut
down immediately without normal procedure.
•To avoid damaging the DLP chips, never aim a high-power laser beam into the projection lens.
Minimum
39.3 in / 100 cm
Minimum
11.8 in / 30 cm
Minimum
19.7 in / 50 cm
English

5
E NTER
MENU
EX
IT
1 2 3
4 5 6
7 8 9
0
Remote
without AA batteries
Product information
Packing contents
Carefully unpack and verify that you have the items below. Some of the items may not be available
depending on your region of purchase. Please check with your place of purchase.
Projector specifications
Specifications
LU9915
Projection system
DLP Single 0.67 WUXGA DMD Chip
Native resolution
WUXGA (1920 x 1200)
Brightness
10,000 Lumens
Aspect ratio
16:10
Light source
Laser Light Source
Power consumption
1290W@100V, 1215W@240V
Dimensions
583mm (L) x 500mm (W) x 211mm (H)
Weight
28kg / 61.7 lbs (Lens excluded)
Operation Temperature
32ºF to 104ºF (0ºC to 40ºC )
Note:
•Brightness is supplied by standard lens. The value will vary depending on lenses being installed.
•Brightness output will vary depending on each unit and actual usage.
•Please visit the local website from http://www.benq.com for the latest User Manual.
Lens hole cap
Anti-Theft screw
Wired remote cable
VGA cable
Power cable
Installation guide
Projector
without lens
English

6
Terminals
•HDBaseT/LAN
For connection to RJ45 Cat5/Cat6 Ethernet cable to input uncompressed high-definition video
(HD), control signals.
•3D Sync Out
Connection to 3D IR sync signal transmitter.
•3D Sync In
Connection to 3D sync signal input.
•DVI-D
Connection to DVI-D source.
•HDMI
Connection to HDMI source.
•DisplayPort
Connection to device or PC featuring DisplayPort.
•3G-SDI
Connection to 3G-SDI source.
•Computer 1
15-pin VGA port for connection to RGB, component HD source, or PC.
•Computer 2 (V, H, B/Pb, G/Y, R/Pr)
Connection to RGB or YPbPr/YCbCr output signal with BNC type input terminal.
•Monitor Out
Connection to other display equipment for concurrent playback display.
• RS-232
Standard 9-pin D-sub interface for connection to PC control system and projector maintenance.
•TRIGGER
3.5mm mini earphone jack, employs 350mA display relay to provide 12(+/-1.5)V output and
short circuit protection.
•Wired Remote
Connection to input Niles or Xantech compatible IR repeater system.
Note:
Make sure the port is valid before inserting a wired remote controller. The remote controller may be damaged in
case of an invalid port, e.g. a wired remote controller is connected to trigger output.
TRIGGER
RS-232
COMPUTER 2
COMPUTER 1
MONITOR OUT 3D SYNC OUT
V
H
B/Pb
G/Y
R/Pr
3G-SDI
WIRED
REMOTE HDBaseT/LAN
DVI-D
DISPLAYPORT
IN
OUT
3D SYNC IN
HDMI
English

7
Remote control
ON OFF
ZOOM +/-
TEST PATTERN
FOCUS +/-
Up
LENS-SHIFT
ENTER
Left
MENU
AUTO PC
COMPUTER 1
COMPUTER 2
HDMI 1
3G-SDI
ENTER
MENU EXIT
1 2 3
4 5 6
7 8 9
Right
Down
EXIT
BLANK
STATUS
ASPECT
DVI
HDMI 2
HDBaseT
DisplayPort
CLEAR 0
Numeric buttons
ID SET
FREEZE
Remote control ID setting
You can set the remote control ID to control the specific projector.
Please set projector ID (from 01 to 99) by using the OSD menus. After setup different ID, the
remote control will only control the matched projector .
Press ID SET + MENU keys together for 5 seconds, the remote control backlight will flash one
time, then into the ID Set mode.
Again click ID SET + MENU keys for 5 seconds (backlight will flash 1 time) to release ID SET
Mode.
After into the ID Set Mode, press ID SET key for 3 seconds.
The remote control LED light will flash and backlight will light. In the meantime, press number to
set the remote control ID.
For example, for setting remote control ID to “01”, please press 0 key for 1 second (LED light
will flash 3 times then back light off), then press 1 key for 1 second (LED light flash 3 times then
backlight off).
For setting remote control ID to “19”, please press 1 key for 1 second, then press 9 key for 1
second.
English

8
Installation
Lens specifications
Model
Name
Lens Type
BenQ Part
Number
Optical spec
Throw Ratio
Zoom Ratio
Weight*
LS1ST4
Ultra Short
Throw
5J.JCY37.002
F=2.0, f=5.64 mm
0.38:1
Fixed
2,710g
LS1ST3
Wide fix
5J.JAM37.011
F=1.85, f=11.6mm
0.76:1
Fixed
910g
LS1ST2
Ultra Wide
5J.JAM37.061
F=1.96~2.3,
f=11.3~14.1mm
0.75~0.93:1
1.25:1
1,280g
LS1ST1
Wide Zoom
5J.JAM37.021
F=1.85~2.5,
f=18.7~26.5mm
1.25~1.79:1
1.41:1
1,090g
LS1SD
Standard
5J.JAM37.001
F=1.7~1.9,
f=26~34mm
1.73~2.27:1
1.3:1
820g
LS1LT1
Semi Long
5J.JAM37.051
F=1.86~2.48,
f=32.9~54.2mm
2.22~3.67:1
1.65:1
950g
LS1LT2
Long Zoom1
5J.JAM37.031
F=1.85~2.41,
f=52.8~79.1mm
3.58~5.38:1
1.5:1
1,020g
LS1LT3
Long Zoom2
5J.JAM37.041
F=1.85~2.48,
f=78.5~121.9mm
5.31~8.26:1
1.55:1
1,350g
Note:
The values listed in the table above are average and may vary by model.
English

9
Projection table
Wide Fix Lens, Wide Zoom Lens, STD Lens, Semi Long Zoom1,
Long Zoom 1 Lens, Long Zoom 2 Lens, Ultra Wide Zoom Lens
Lens center
Distance (A)
SCREEN
Height (B)
LU9915
Screen Size
5J.JAM37.011
5J.JAM37.021
5J.JAM37.001
5J.JAM37.051
Wide Fix Lens
Wide Zoom Lens
STD Lens
Semi long Zoom1
Diagonal
Width
Height (B)
Distance (A)
Fixed
Wide
Tele
Wide
Tele
Wide
Tele
(inch)
(m)
(inch)
(m)
(inch)
(m)
(inch)
(m)
(inch)
(m)
(inch)
(m)
(inch)
(m)
(inch)
(m)
(inch)
(m)
(inch)
(m)
40
1.02
34
0.86
21
0.54
25.1
0.64
41.4
1.05
59.9
1.52
57.2
1.45
75.8
1.93
73.6
1.87
124.1
3.15
50
1.27
42
1.08
26
0.67
31.8
0.81
52.3
1.33
75.4
1.92
72.1
1.83
95.5
2.42
92.9
2.36
155.9
3.96
60
1.52
51
1.29
32
0.81
38.5
0.98
63.1
1.60
90.9
2.31
87.1
2.21
115.1
2.92
112.1
2.85
187.8
4.77
80
2.03
68
1.72
42
1.08
52.0
1.32
84.9
2.16
121.8
3.09
117.0
2.97
154.3
3.92
150.5
3.82
251.4
6.39
100
2.54
85
2.15
53
1.35
65.5
1.66
106.6
2.71
152.7
3.88
147.0
3.73
193.5
4.92
188.9
4.80
315.0
8.00
120
3.05
102
2.58
64
1.62
78.9
2.01
128.4
3.26
183.6
4.66
176.9
4.49
232.8
5.91
227.6
5.78
378.6
9.62
150
3.81
127
3.23
79
2.02
99.1
2.52
161.0
4.09
230.0
5.84
221.8
5.63
291.6
7.41
285.0
7.24
474.1
12.04
180
4.57
153
3.88
95
2.42
119.3
3.03
193.6
4.92
276.4
7.02
266.7
6.77
350.5
8.90
342.6
8.70
569.5
14.47
200
5.08
170
4.31
106
2.69
132.8
3.37
215.3
5.47
307.3
7.81
296.6
7.53
389.7
9.90
381.0
9.68
633.1
16.08
300
7.62
254
6.46
159
4.04
200.1
5.08
324.0
8.23
461.9
11.73
446.3
11.34
585.9
14.9
573.2
14.56
951.2
24.16
400
10.16
339
8.62
212
5.38
267.4
6.79
432.7
10.99
616.6
15.66
595.9
15.14
782.3
19.87
765.3
19.44
1269.7
32.25
500
12.70
424
10.77
265
6.73
334.8
8.50
541.5
13.75
771.2
19.59
745.6
18.94
978.3
24.85
957.4
24.32
1587.8
40.33
Screen Size
5J.JAM37.031
5J.JAM37.041
5J.JAM37.061
Long Zoom 1 Lens
Long zoom 2 Lens
Ultra Wide zoom Lens
Diagonal
Width
Height (B)
Distance (A)
Wide
Tele
Wide
Tele
Wide
Tele
(inch)
(m)
(inch)
(m)
(inch)
(m)
(inch)
(m)
(inch)
(m)
(inch)
(m)
(inch)
(m)
(inch)
(m)
(inch)
(m)
40
1.02
34
0.86
21
0.54
118.7
3.01
181.0
4.60
173.9
4.42
277.7
7.05
24.5
0.62
31.1
0.79
50
1.27
42
1.08
26
0.67
149.7
3.80
227.6
5.78
220.2
5.59
350.0
8.89
31.1
0.79
39.2
1.00
60
1.52
51
1.29
32
0.81
180.7
4.59
274.1
6.96
266.6
6.77
422.3
10.73
37.6
0.96
47.4
1.20
80
2.03
68
1.72
42
1.08
242.7
6.16
367.3
9.33
359.4
9.13
567.0
14.40
50.8
1.29
63.8
1.62
100
2.54
85
2.15
53
1.35
304.3
7.73
460.4
11.70
452.1
11.48
711.6
18.07
63.9
1.62
80.2
2.04
120
3.05
102
2.58
64
1.62
366.7
9.31
553.6
14.06
544.9
13.84
856.2
21.75
77.1
1.96
96.6
2.45
150
3.81
127
3.23
79
2.02
459.4
11.67
693.3
17.61
684.0
17.37
1073.1
27.26
96.8
2.46
121.1
3.08
180
4.57
153
3.88
95
2.42
552.4
14.03
833.0
21.16
823.1
20.91
1290.1
32.77
116.5
2.96
145.7
3.70
200
5.08
170
4.31
106
2.69
614.7
15.6
926.4
23.53
915.9
23.26
1434.7
36.44
129.7
3.29
162.1
4.12
300
7.62
254
6.46
159
4.04
924.0
23.47
1392.1
35.36
1379.6
35.04
2157.8
54.81
195.4
4.96
244.0
6.20
400
10.16
339
8.62
212
5.38
1233.9
31.34
1857.9
47.19
1843.3
46.82
2880.9
73.18
261.2
6.63
325.9
8.28
500
12.70
424
10.77
265
6.73
1543.7
39.21
2323.6
59.02
2307.1
58.60
3604.0
91.54
326.9
8.30
407.7
10.36
English

10
Ultra Short Reflection
Screen
L1: Screen to the point of mirror
L2: Screen to projector front
L3: Screen to project back
H1: Screen bottom to projector top side
H2: Screen bottom to projector bottom
Screen size
5J.JCY37.001
Ultra Short Reflection
Diagonal
Width
Height
H1
H2
L1
L2
L3
inch
mm
inch
mm
inch
mm
inch
mm
inch
mm
inch
mm
inch
mm
inch
mm
100
2540
85
2166
53
1355
19
485
28
701
33
849
22
564
-1
-24
120
3048
102
2599
64
1627
23
596
32
812
39
1000
28
715
5
127
150
3810
128
3247
80
2032
30
763
39
979
48
1227
37
942
14
354
200
5080
170
4330
107
2711
41
1041
49
1257
63
1606
52
1321
29
733
250
6350
213
5415
133
3391
52
1320
60
1536
78
1984
67
1699
44
1111
300
7620
256
6500
160
4071
63
1598
71
1814
93
2362
82
2077
59
1489
350
8890
299
7585
187
4752
74
1877
82
2093
108
2741
97
2456
74
1868
Note:
•For more visualized instructions, please go to BenQ calculator website http://projectorcalculator.benq.com/.
•Precise installation is prefered to be done by professionals. Contact your dealer for more information.
•When UST lens is installed to the projector, it is recommended to loosen the screw on the support kit and make
the arm movable before adjustment.
•The User Manual for UST Lens installation is available from local BenQ website.
L1
L
2
H1
H2
㻸㻟
285
873
English
120
216

11
Lens shift
Lens shift adjustable range
The adjustable range for lens shift is tabulated below and subject to the conditions listed.
Model Name
Lens Type
BenQ Part Number
Lens Shift Range
LS1ST4
Ultra Short Throw
5J.JCY37.001
-3% ~ +7% Vertical; -5% ~ +5% Horizontal
(Central position at 56.5%)
LS1ST3
Wide fix
5J.JAM37.011
NA
LS1ST2
Ultra Wide
5J.JAM37.061
0 ~ +50% Vertical; -6.7% ~ +6.7% Horizontal
LS1ST1
Wide Zoom
5J.JAM37.021
0 ~ +50% Vertical; -10% ~ +10% Horizontal
LS1SD
Standard
5J.JAM37.001
0 ~ +50% Vertical; -10% ~ +10% Horizontal
LS1LT1
Semi Long
5J.JAM37.051
0 ~ +50% Vertical; -10% ~ +10% Horizontal
LS1LT2
Long Zoom1
5J.JAM37.031
0 ~ +50% Vertical; -10% ~ +10% Horizontal
LS1LT3
Long Zoom2
5J.JAM37.041
0 ~ +50% Vertical; -10% ~ +10% Horizontal
Note:
The drawings above apply to the standard lens only.
Max
0.5V
Desktop-front projection
Vertical Shift area
Vertical Shift
Max
0.5V
Height of projected image
1V
0.1H
1H
0.1H
Ceiling mount-front projection
Width of projected image
Height of projected image 1V
Horizontal Shift
to Left
Horizontal Shift
to Right
Vertical Shift
English

12
Installation positioning
Ceiling mount installation
X C
Screen Top 0.1H
Shift Range
Screen Center H
Desktop installation
Screen Center H
Shift Range
C 0.1H
Note:
•Lens Shift function is not available to LS1ST3 (Fixed Lens). This lens should be used for "zero degree"/"no-offset"
applications. See below:
C
117.4
Screen Center
FOR USE WITH LS1ST3 (FIXED LENS) ONLY
English

13
Dimensions
Cabinet dimensions
AIR IN
RELEASE BUTTON
220 95
FRONTRING
FRONTCOVER
AIR IN
BASE COVER
100 300
AIR OUT
500
TOP COVER REAR IR WINDOW
MODEL LOGO
NAME PLATE
FRONT IR
LED STATUS Unit: mm
Ceiling mount hole dimensions
REAR COVER
216
6-CEILING MOUNT HOLE
M4*0.7 SCREW L=16 mm (MAX.)
100
300
English
547.26
L
SIDE
COVE
R
AIR IN
582.80
R
S
ID
E
COVE
R
AC IN
ADJ. FOOT
ADJ. FOOT
28
300
152.50 150
152.5 150
150

14
Ceiling mount dimensions (CMG6)
300
150
150
302.5
582.8
English
483.60
710.70
300
483.60
498.60

15
Optional lens dimensions
Optional Lens (UST: LSIST4) Optional Lens (WIDE FIX: LSIST3)
Optional Lens (UWZ: LSIST2) Optional Lens (WIDE: LSIST1)
Optional Lens (STD: LSISD) Optional Lens (SEMI: LSILT1)
Optional Lens (LONG1: LSILT2) Optional Lens (LONG2: LSILT3)
582.80
872.5
582.80
610.16
582.80
639.4
582.8
616.5
582.80
590.7
582.80
609.90
582.80
626.7
582.80
667.3
English
SEMI LONG LENS
WIDE
FIX
LENS
WIDE
LENS
LONG2 LENS
UST
LENS
UWZ LENS
LONG 1LENS
STD LENS
500

16
LED indication
Indicator messages
Several indicator messages are used by the projector to alert users about problems with setup or
system error. The LEDs on top cover of the projector illustrated below.
TEMP LED
LED display
Projector status
Operation tips
Off
Normal status
Flashing
Red
Over temperature error
Contact with your nearest authorized dealer or service
center.
LIGHT SOURCE LED
LED display
Projector status
Operation tips
Off
Light source is off
Flashing
Green
Projector is turning on
Red (Cycles of
6)
Light source is end-of-life
Please call the local service center.
On
Red
Light source problem
Please call the local service center.
Green
Light source is on
STATUS LED indicator
LED display
Projector status
Operation tips
Close
Normal
Flashing
Red (once)
Safety switch error
Please check whether the top cover is well assembled
or lens is well installed or not. If the problem persists,
call the local service center.
Red
(quadruple)
Fan error
Call the local service center.
Lights up
Red
System error
Call the local service center.
English

17
POWER LED indicator
LED display
Projector status
Operation tips
Close
AC power turned off
Check AC power source and power on the projector.
Flashing
Green
Ready to power on the
projector
Wait until the projector starts projecting.
Orange
The projector is cooling
down
Lights up
Red
Standby mode
To power on the projector, press the ON key on the
remote controller or the Power key on the control
panel.
Green
Projector powered on
English
