Berbel BIH 100 GL User manual

EN Island hood
Glassline
EN Operating and installation instructions for the models
BIH 100 GL
6005735_0

2
6005735_0 – 31.03.2021
Document information
Operating and installation instructions for:
yGlassline island hood BIH 100 GL E02
yOriginal instructions.
yPart of the product.
yCopyright protected.
yDuplications, re-printing and distribution only with
permission.
ySubject to alteration.
Safety information
DDANGER!
Notes with the word DANGER warn of a hazardous situation
that results in serious injuries or death.
DWARNING!
Notes with the word WARNING warn of a hazardous situation
that could result in serious injuries or death.
DCAUTION!
Notes with the word CAUTION warn of a situation that could
result in minor injuries.
DATTENTION!
Notes with the word ATTENTION warn of a situation that
could result in damage to property or to the environment.
Symbol clarification - text
☞Handling requirement
yListing
DReference to another point in this document
Reference to other documents that should be observed
Symbol clarification - illustrations
x
A
B
1.
2.
Highlighting of the parts involved in the action with
shading
1. Handling steps with numbering
APart designations with upper case characters
xDimensions with lower case characters or units in mm
Movement and direction arrows

3
6005735_0 – 31.03.2021
EN
Table of contents
1. Safety information ............................ 4
1.1 Proper intended use . . . . . . . . . . . . . . . . . . . . . 4
1.2 Authorised target groups . . . . . . . . . . . . . . . . . . 4
1.3 General safety instructions . . . . . . . . . . . . . . . . . 4
2. Product information ........................... 5
2.1 Functional principle . . . . . . . . . . . . . . . . . . . . . 5
2.2 Operating modes. . . . . . . . . . . . . . . . . . . . . . . 5
2.2.1 Recirculated air mode.........................5
2.2.2 Extracted air mode ............................5
2.2.3 Hybrid mode..................................6
2.3 Product overview . . . . . . . . . . . . . . . . . . . . . . . 6
2.4 Scope of delivery . . . . . . . . . . . . . . . . . . . . . . . 7
2.5 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . 8
3. Installation .................................... 9
3.1 Safety instructions for installation. . . . . . . . . . . . . 9
3.2 Requirements for the installation location . . . . . . . 9
3.3 Requirements for individual operating modes. . . . .10
3.3.1 Requirements for recirculated air mode .....10
3.3.2 Requirements for extracted air mode........10
3.3.3 Requirements for hybrid mode..............10
3.4 Requirements for the exhaust air ducting
(only for extracted air mode or hybrid mode) . . . . .10
3.5 Installation procedure . . . . . . . . . . . . . . . . . . . .11
3.5.1 Preparation for installation ..................11
3.5.2 Unpack the device ..........................11
3.5.3 Determining the hanging position ..........12
3.5.4 Hanging the chimney stack .................14
3.5.5 Hanging the hood body ....................15
3.5.6 Connect accessories ........................16
3.5.7 Connecting the power supply...............17
3.5.8 Fit the side chimney panels .................18
3.5.9 Fit the rear panels ...........................18
3.5.10 Fitting the BackFlow port....................19
3.5.11 Installing filter (with recirculating and
hybrid operation) ...........................19
3.5.12 Connecting exhaust air ducting (with
extracted air and hybrid mode) .............20
3.5.13 Fit the front panel...........................20
3.5.14 Inserting lower section and separating unit . 21
3.5.15 Check and carry out commissioning ........21
4. Operation ....................................22
4.1 Safety instructions for operation . . . . . . . . . . . . .22
4.2 Operating the device . . . . . . . . . . . . . . . . . . . .23
4.2.1 Normal operation ...........................23
4.2.2 Extraction mode / recirculated air mode
changeover .................................24
4.2.3 Filter filling indicator ........................24
4.2.4 Window contact switch .....................24
4.2.5 Hob lighting ................................24
4.2.6 Run-on function ............................25
4.2.7 AutoRun ....................................25
4.3 Configuring the device . . . . . . . . . . . . . . . . . . .26
5. Cleaning .....................................27
5.1 Safety instructions for cleaning . . . . . . . . . . . . . .27
5.2 Cleaning procedures. . . . . . . . . . . . . . . . . . . . .27
6. Maintenance .................................29
6.1 Safety instructions for maintenance . . . . . . . . . . .29
6.2 Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . .29
6.2.1 Changing the lamps ........................29
6.2.2 Replacing filter filling (with recirculating
and hybrid mode)...........................29
6.3 Fault rectification . . . . . . . . . . . . . . . . . . . . . . .31
7. Dismounting .................................32
8. Disposal ......................................33
8.1 Dispose of packaging . . . . . . . . . . . . . . . . . . . .33
8.2 Dispose of the device . . . . . . . . . . . . . . . . . . . .33
9. Annex ........................................34
9.1 Product data sheet . . . . . . . . . . . . . . . . . . . . . .34
9.2 Contact . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35

4
Safety information
6005735_0 – 31.03.2021
1. Safety information
1.1 Proper intended use
The device serves to extract cooking vapours.
The device is intended exclusively for private domestic use.
The device must only be used with original filters from the
manufacturer.
It is only permitted to use the device when it is in technically
flawless condition and after correct installation.
Any other use shall be considered improper use.
Reading and observing this manual are also part of the
proper use of the device.
1.2 Authorised target groups
Electrical work only to be undertaken by qualified electricians
per DIN VDE 0100. Requirements on qualified electricians:
yKnowledge of the basics of electrics.
yKnowledge of country-specific regulations and standards
(e.g. in Germany, DIN VDE 0100, part 701).
yKnowledge of the applicable safety regulations.
yKnowledge of the relevant legal requirements for gas
installations (e.g. in Germany the technical rules for gas
installations TRGI).
yKnowledge of this manual.
Installation and repair only by qualified specialist personnel.
Requirements on qualified specialist personnel:
yKnowledge of the regulations on safety at work.
yKnowledge of fastening systems.
yBasic knowledge of ventilation systems.
yExperienced in using electrical and mechanical tools.
yAbility to read technical drawings.
yKnowledge of this manual.
Operation, cleaning and maintenance by the user.
Requirements for the user:
yKnowledge of this manual.
There are separate requirements for the following users:
yChildren from 8 years and older.
yPersons with restricted physical, sensory or mental
capabilities.
yPersons with a lack of experience and knowledge.
These users are only permitted to carry out operation,
cleaning and maintenance. Special requirements:
yUsers are supervised.
yUsers are instructed with regard to safe use of the device.
yUsers understand the hazards involved with the device.
yChildren may not play with the device.
1.3 General safety instructions
DWARNING!
Hazard through a disregard of the operating and
installation instructions!
This manual contains important information for the safe
handling of the device. Separate reference is made to
possible hazards.
☞Read through this manual thoroughly.
☞Follow the safety instructions in this manual.
☞Store the manual in an accessible location.
Naked flames can damage the device and can cause fires.
yGas operation only with low gas flames (not rising above
the edge of the base of the pots).
yDo not flambé underneath the device.
yNo unattended deep frying underneath the device.
The use of the device is forbidden under the following
circumstances:
yIf necessary safety devices are missing (e.g. with
simultaneous use of a heating point which uses air from
the room as its oxygen supply).
yIf essential approvals are missing (e.g. from chimney
sweeps).
yIn potentially explosive atmospheres.
yIf the device or individual components are damaged.
yIn the event of unauthorised alterations or changes to the
device.
yIf liquid has penetrated the device.
yWhen heavily soiled.
yFor children under 8 years old and persons who would
not be able to properly assess the hazards associated with
handling the device.
The manufacturer accepts no liability for damage occurring in
the following circumstances:
yDisregard of this manual.
yImproper use of the device.
yImproper installation and handling of the device.
yUse of the device by unauthorised target groups.
yBypassing safety equipment on the device.
yThe use of spare parts (e.g. mains cables) that were not
produced or approved by the manufacturer.
Further safety instructions can be found in the respective
relevant chapters of this manual.
D“3.1 Safety instructions for installation” (page 9).
D“4.1 Safety instructions for operation” (page 22).
D“5.1 Safety instructions for cleaning” (page 27).
D“6.1 Safety instructions for maintenance”(page 29).

5
Product information
6005735_0 – 31.03.2021
EN
2. Product information
2.1 Functional principle
Centrifugal force
yCooking vapours are drawn through a gap and into the
hood where they are accelerated and routed through
bends.
yThe resultant centrifugal force ejects particles of dirt
(e.g. particles or grease and oil) out of the air.
yThe dirt particles are separated out and collected on the
lower section and at the separating unit.
BackFlow technology (optional)
yCondensate or droplet formation on the extractor hood
(e.g. if steam touches the cold surface) is prevented by
the ventilation of the hood underside.
yPart of the vented air quantity is blown in at the sides
over the hood underside and directed into the suction
gap.
2.2 Operating modes
The device is suitable for the following operating modes:
yRecirculated air mode
yExtracted air mode
yHybrid mode
2.2.1 Recirculated air mode
The filter filling in the recirculated air filter neutralises any
smelly odours present. The odour-free, cleaned room air is
fed back into the room. The humidity in the room can be
reduced with the fresh air feed.
In recirculated air mode, it is necessary to use the run-on
function so that the device can remove the remaining
odours. Using the run-on function increases the life of the
filter filling. The filter filling must be replaced at regular
intervals.
2.2.2 Extracted air mode
The cleaned room air can be routed to the outside via the
building structure (e.g. ducting, chimney).
With extracted air mode an adequate fresh air supply is
required. The device can only extract the amount of air to the
outside that is present in the room or which is drawn into the
room.

6
Product information
6005735_0 – 31.03.2021
2.2.3 Hybrid mode
In hybrid mode, it is possible to select flexibly between
recirculated air mode and extracted air mode.
In extracted air mode, the cleaned room air is routed to the
outside through the wall box which opens automatically.
Extracted air mode is recommended in summer or with
particularly intensive frying.
In recirculated air mode the wall box remains closed. The
filter filling in the hybrid filter neutralises any smelly odours
present. The odour-free, cleaned room air is fed back into the
room.
The recirculated air mode is recommended in winter if no
warm room air is to be surrendered to the outside.
2.3 Product overview
E
D
F
G
A
B
CH
A Chimney stack with panelling
B Hood body
C Control panel
D Lower section of the hood body
E Lower section (removable)
F Separating unit (removable) consisting of centrifugal
separation and catchment screen (“Capillar Trap”)
G Ratings plate (in the air induction shaft of the separating
unit)
H Hob lighting
F
C
D
G
J
E
A
B
H
I
A Ceiling mounting panel
B Corner connections with height adjustment
C Knurled nuts for front panel
D Mains cable with Wieland plug and cold device plug
E BackFlow port (with use of the BackFlow technology)
F Sockets for accessories
G Cable connectors
H Brackets for side cladding panels
I Brackets for rear panel
J Brackets for front panel

7
Product information
6005735_0 – 31.03.2021
EN
2.4 Scope of delivery
P
I
K
H
C
A
N
O
G
B
L
M
F
D
E
J
A Chimney stack
B 2 side chimney panels 1
C Rear panel with mounting bracket and round head
screw M4
D Front panel with arrestor cable
E BackFlow port 2
F Drilling template
G Wieland plug (plugged into chimney stack)
H Hood body
I 2 cladding panels for the underside of the hood body
J Mounting aid for cladding panels
K 4 galvanised steel bolt anchors 8 mm with nuts (size 13)
and washers
L 2 round head screws M4 x 6 mm
M 4 round head screws M4 x 4 mm
N Separating unit
O Lower section
P Operating and installation instructions
1Ventilation slots are only present in versions for recirculated
air and hybrid operation.
2Assembly only with use of the BackFlow technology.
The fastening materials are only suitable for solid walls and
ceilings.
Further accessories may be required depending on the
operating mode.

8
Product information
6005735_0 – 31.03.2021
2.5 Technical data
BIH100GLE02
Connection voltage 230 V / 50 Hz
Total power 188 W
Fan power consumption 170 W
Lighting LED 17.2 W,
637 lx
Colour temperature hob lighting,
setting 2700 - 6500 K
Width 1000 mm
Depth 670 mm
Height in recirculated air mode with
recirculated air filter BUF 150 + 745 - 995 mm
Height in recirculated air mode with
recirculated air filter permalyt 895 - 995 mm
Height in extracted air mode 645 - 995 mm
Height in hybrid mode 945 - 995 mm
Net weight (with a chimney length of
900 mm) 39 kg
Information about energy consumption can be found in the
product data sheet.
D“9.1 Product data sheet” (page 34).
Specifications for the model (e.g. serial number, year of
construction) can be found on the ratings plate.
D“2.3 Product overview” (page 6).

9
Installation
6005735_0 – 31.03.2021
EN
3. Installation
3.1 Safety instructions for installation
DWARNING!
Hazard through disregard of the installation instructions!
This chapter contains important information for the safe
installation of the device.
☞Read through this chapter carefully before installing the
device.
☞Follow the safety instructions.
☞Carry out the installation as described.
yInstallation only by qualified specialist personnel.
D“1.2 Authorised target groups”(page 4).
yElectrical work must only be undertaken by qualified
electricians.
D“1.2 Authorised target groups”(page 4).
yInstallation requires two persons.
yWhen working at heights, ensure good stable footing
(e.g. stable stepladder).
yThe hob and other parts that can be touched must be
allowed to cool prior to installation.
yStore the film or other parts of the packaging in a location
which is inaccessible to children.
yThe device must be in an undamaged and fault-free
condition prior to installation.
yCables must not be kinked, crushed or damaged.
yNever open the fan housing.
yIt is not permissible to attach further components
(e.g. panels, air ducts) to the device.
yThe power supply voltage must match the voltage
information quoted on the ratings plate.
D“2.5 Technical data”(page 8).
yEnsure that the power supply is stable and remains so
prior to the installation.
Connect the power supply only when instructed to do so
in the installation instructions.
3.2 Requirements for the installation location
DWARNING!
Risk of death due to improper installation!
Disregard of the ambient conditions can lead to hazardous
situations, e.g. in the handling of electrical power or gas.
☞Make sure that the requirements for the installation
location are complied with.
yDo not install in potentially explosive atmospheres.
yWith simultaneous use of a heating point which uses air
from the room as its oxygen supply (e.g. chimneys):
yA safety device is absolutely essential.
yThe safety device must prevent gases being drawing
to the room.
yIt is essential to ensure that the negative pressure in
the heating point installation room does not exceed
4 Pa.
yAn approval for commissioning (e.g. from a chimney
sweep) must be available.
yInstallation is only permitted on structural building
elements capable of bearing the load (solid structure).
yThe ceiling must be level and horizontal.
yIf it is necessary to break through the wall:
A wall break-through influences the structural integrity
of the building. This work must only be carried out by a
specialist.
yIf installed above fireplaces that use solid fuels (e.g. coal
stove):
The fireplace must have a sealed cover which cannot be
removed. Otherwise there is a fire risk due to flying sparks.
Applicable legal and country-specific regulations must be
observed.
yThe air flowing out must be able to dissipate unimpeded.
Do not impede the air flow, e.g. through the installation of
objects on or at the device.
yMake sure that the building electrical supply is properly
earthed.
yThe power supply voltage present must match the
voltage information quoted on the ratings plate.
yFor the supply of power, the customer must provide an
approx. 80 cm long connection cable in the vicinity of the
hood installation.
yThe mains plug must be accessible after the installation
of the hood. Alternatively, all-pole isolating device (with a
contact gap of at least 3 mm) must be provided.
Country-specific, legal provisions must be observed.

10
Installation
6005735_0 – 31.03.2021
3.3 Requirements for individual operating modes
Further accessories may be required depending on the
operating mode.
3.3.1 Requirements for recirculated air mode
yRecirculated air fan on the fan outlet.
yCross-section of the ventilation slot in the superstructure
larger than 300 cm2.
yFilter filling freely accessible for changing.
3.3.2 Requirements for extracted air mode
yExhaust air ducting at the fan outlet.
D“3.4 Requirements for the exhaust air ducting
(only for extracted air mode or hybrid mode)”
(page 10).
yDiameter of the exhaust air ducting at least 150 mm
(corresponds to a surface area of approx. 177 cm2).
yAdequate fresh air supply is assured through the
installation of the necessary accessories.
yWindow contact switch.
yWall box BMK-F / BMK-Z.
3.3.3 Requirements for hybrid mode
yHybrid filter at the fan outlet.
yConnection of the exhaust air ducting to the hybrid filter.
D“3.4 Requirements for the exhaust air ducting
(only for extracted air mode or hybrid mode)”
(page 10).
yCross-section of the ventilation slot in the superstructure
larger than 300 cm2.
yDiameter of the exhaust air ducting at least 150 mm
(corresponds to a surface area of approx. 177 cm2).
yFilter filling freely accessible for changing.
yAdequate fresh air supply is assured through the
installation of the necessary accessories.
yWindow contact switch.
yWall box BMK-F / BMK-Z.
3.4 Requirements for the exhaust air ducting
(onlyforextracted air mode or hybrid mode)
DWARNING!
Fire hazard and asphyxiation hazard due to improper
installation!
When using the exhaust air ducting with other devices
or when connecting an active exhaust air channel (e.g.
chimney), gases or smoke can be drawn into the room.
☞Make sure that the requirements for the exhaust air
ducting are complied with.
yThe exhaust air ducting is used exclusively by this device.
yThe exhaust air ducting is made of non-combustible
material in accordance with DIN 4102 class 1.
yWhen using a chimney as the exhaust air duct:
yThe chimney must not be used by other devices.
yThe extracted air must be introduced into the
chimney using a 90° bend pointing upwards.
yApproval by a master chimney sweep.
yWhen routing the exhaust air ducting through the roof or
the outside wall:
yThe cross-section must not be smaller than that of the
fan outlet.
yInstallation of condensed water collector in the
exhaust air ducting in order to prevent water damage
inside the device. The condensed water collector must
be adequately dimensioned.
The cross-section, length, type and course of the exhaust
pipe affect the extraction efficiency. Changing the direction
of the air too severely leads to a loss of performance and to
noise.
To optimise the device performance:
yKeep the exhaust air ducting as short as possible and
route it directly to the outside.
yThe stipulated cross-section of the exhaust air ducting is
complied with.
D“3.3 Requirements for individual operating modes”
(page 10).
yExclusive use of ducts and bends with smooth inner
surfaces.
In order to avoid turbulence or backpressure in the
transported air - do not use:
ySpiral hoses.
yFlexible tubes.
yFlat deflection pieces.
ySharp-edged exhaust air channels.
The exhaust air ducting must be in place before installing the
device.

11
Installation
6005735_0 – 31.03.2021
EN
3.5 Installation procedure
Short overview:
1. Preparation for installation
2. Unpack the device
3. Determining the hanging position
4. Hanging the chimney stack
5. Hanging the hood body
6. Connect accessories
7. Connecting the power supply
8. Fit the side chimney panels
9. Fit the rear panels
10. Fitting the BackFlow port
11. Installing filter (with recirculating and hybrid operation)
12. Connecting exhaust air ducting (with extracted air and
hybrid mode)
13. Fit the front panel
14. Inserting lower section and separating unit
15. Check and carry out commissioning
3.5.1 Preparation for installation
☞Familiarise yourself with the installation situation and the
associated documents.
yDevice and instructions.
yAccessories.
yInstallation location.
yIntended operating mode.
☞Assemble the tools and materials required:
yStable stepladder
yFolding rule or measuring tape
yPencil
ySpirit level
yPlumb line
yPhillips screwdriver PH2
y2.5 mm Allen key
ySlotted screwdriver SL 2.5 x 0.4
y13 mm spanner
yØ 8 mm masonry bit
yHammer drill
yCutter blade
yProtective material (e.g. thick cardboard) for the hob
and the worktops
☞Keep the installation area free of objects that could be in
the way or that could be damaged.
☞Make sure that the hob and other parts that could be
touched have cooled down.
☞Protect the hob and other surfaces in the installation area
(e.g. with thick cardboard).
☞Ensure that the power supply is switched off and remains
so. Connect the power supply only when instructed to do
so in the installation instructions.
If accessories (e.g. wall box, window contact switch) are
required for the installation:
Observe the instructions for the accessories.
☞Ensure that the accessories are correctly installed and
ready for connection.
☞Ensure that the connection cables from accessories are
correctly routed and accessible.
3.5.2 Unpack the device
DATTENTION!
Hazard of glass breaking or other damage due to
incorrect handling!
The device and its surfaces can be damaged when being
unpacked or transported.
☞Do not cut into the protective cardboard packaging.
☞Keep objects that could scratch the device far away from
it (e.g. tools, belt buckles).
☞Unpack the device and all accompanying parts carefully.
☞Set the device down on a firm, clean and protective
surface (e.g. thick cardboard).
☞Check the device and its constituent parts for damage.
☞Check the delivery is complete.
D“2.4 Scope of delivery” (page 7).
If parts are missing or damaged:
☞Please consult your dealer or customer services.
☞Remove the packaging material and the protective film.
D“8.1 Dispose of packaging” (page 33).

12
Installation
6005735_0 – 31.03.2021
3.5.3 Determining the hanging position
The device is designed to be hung on ceilings.
When mounting on a solid ceiling:
☞Make sure that the ceiling has sufficient load bearing
capacity.
☞Use the fastening materials provided.
With different installation situations:
☞Enquire about alternative fastening systems (e.g. consult
with your architect).
☞Only use fastening hardware suitable for the type of
ceiling.
Front panel, rear panel and side chimney panels have been
adjusted to the respective ceiling height in the factory.
The chimney stack is preassembled in the factory to a height
of 750 mm.
In order to adjust the height of the chimney stack to the
assembly situation, perform the following steps:
☞Unscrew the screws and nuts for the corner connections.
☞Adjust to the desired height in 50 mm steps.
☞Secure the corner connections once more with the
screws and nuts.
☞Make sure that the chimney stack is bolted tight.
View from the front
x
==
Safety distance (x):
yRecommendation 700 mm.
yWith electric hobs, at least 600 mm.
yWith gas hobs, at least 650 mm.
Observe the specifications for the cooking appliances
(e.g. installation above a solid fuel stove).
☞Make sure that the safety distance is complied with.
View from above
272
= =
220
= =
☞Determine the hanging position.
☞Mark the centre point of the device on the ceiling.

13
Installation
6005735_0 – 31.03.2021
EN
DWARNING!
Risk of death due to explosions or electric shock!
Drilling through gas, water or electrical lines can lead to
hazardous situations.
☞Ensure that there are no lines in the ceiling at the
fastening points.
☞Align the drilling template parallel with the front of the
device.
☞Determine the locations of the fastening points and mark
them with the help of the drilling template.
Ø 8
☞Drill the holes in the ceiling.
☞Insert the bolt anchors into the holes.
☞Ensure that the bolt anchors are tight in the holes.
6
☞Screw the nuts and the washers onto the bolt anchors in
the position of the two lock holes.
☞Ensure that there is an approx. 6 mm gap between the
ceiling and the washer.

14
Installation
6005735_0 – 31.03.2021
3.5.4 Hanging the chimney stack
DWARNING!
Danger of injuries through improper handling!
Hanging the device requires a great deal of physical exertion
due to its size and weight. If the device falls down, serious
injuries are possible.
☞Two persons are required to hang the device.
☞Ensure stable footing when hanging the device.
☞Ensure that no other people are in the working area.
DATTENTION!
Danger of property damage through improper handling!
Hanging the device requires a great deal of physical exertion
due to its size and weight. If the device falls, the device,
kitchen furnishings and other objects could be damaged.
☞Cover the cooled hob.
☞Keep the installation area clear.
☞Arrange the chimney stack with the front side facing the
front side of the cooking surface.
☞Lift the chimney stack.
☞Attach the chimney stack to the ceiling with the bolt
anchors.
☞Twist the chimney stack so that it is held in the position of
the two lock holes by the nuts.
☞Make sure that the chimney stack is held in this position.
☞Align the front side of the chimney stack parallel to the
front side of the cooking surface.
☞Firmly tighten the nuts at the lock holes.
☞Screw the nuts and washers onto both bolt anchors and
firmly tighten the nuts.
☞Ensure that all nuts are fully tightened.
☞Remove the cover from the cable compartment on the
chimney stack.
The hood body cables are secured for transport.
☞Remove the transport protection from the cable before
attachment.

15
Installation
6005735_0 – 31.03.2021
EN
3.5.5 Hanging the hood body
DWARNING!
Danger of injuries through improper handling!
Hanging the device requires a great deal of physical exertion
due to its size and weight. If the device falls down, serious
injuries are possible.
☞Two persons are required to hang the device.
☞Ensure stable footing when hanging the device.
☞Ensure that no other people are in the working area.
DATTENTION!
Danger of property damage through improper handling!
Hanging the device requires a great deal of physical exertion
due to its size and weight. If the device falls, the device,
kitchen furnishings and other objects could be damaged.
☞Cover the cooled hob.
☞Keep the installation area clear.
☞Arrange the hood body with the front side facing the
front side of the cooking surface.
☞Lift the hood body from below up to the chimney stack
until the four metal clips have latched.
☞Make sure that the hood body is held in this position.
☞Secure the hood body to the brackets on the chimney
stack with screws.
☞Connect the cable from the control panel and the hob
lighting to the chimney stack connections.
☞Screw the cover back on the cable compartment.

16
Installation
6005735_0 – 31.03.2021
☞Insert the mounting aid centrally in the flue.
☞Align the mounting aid flush with the underside of the
hood body.
☞Push the holding clips of the cladding panels into the side
slots on the hood body.
☞Fold the cladding panels up.
☞Secure the cladding panels to the flue with a screw.
☞Remove the mounting aid.
3.5.6 Connect accessories
Depending on the installation situation, available accessories
may be connected to the hood, e.g.:
yWall box
yWindow contact switch
yControl flap
yRecirculated air filter permalyt
Observe the instructions for the accessories.
DATTENTION!
Danger of damage due to improper connection!
Applied voltage or defective connections can result in
damage to the electronics.
☞Ensure that the power supply is switched off and remains
so.
☞Ensure correct assignment of the connections.
☞Make sure that the accessories plugs are fully inserted.
ABC
A Jack socket - for connection of wall box, control flap or
recirculated air filter permalyt.
B DC power socket - for connecting a window contact
switch.
C Connection socket (RJ45) – BUS interface for connection
with special accessories of the manufacturer.
Connection with a PC or other devices is not permitted.

17
Installation
6005735_0 – 31.03.2021
EN
Wall box
yThe wall box is closed when the control contacts are
open.
yThe wall box is open when the control contacts are
closed.
Window contact switch
yThe hood‘s fan is only operational when the window is
open.
Safety device
yThe hood‘s fan is only operational when no critical under-
pressure is determined in the room.
☞Connect any available accessories.
☞Route the cable such that it is not kinked, crushed or
damaged and so that it will not get in the way when
replacing the filter filling.
3.5.7 Connecting the power supply
DWARNING!
Risk of death due to electric shock!
Touching live parts can cause an electric shock, burns or death.
☞Ensure that the power supply is switched off and remains
so.
☞Observe the voltage specifications on the ratings plate.
☞Connect the power supply cable to the Wieland plug.
☞Plug the connection cable with the Wieland plug into the
Wieland socket on the device.
☞Route the cable such that it is not kinked, crushed or
damaged and so that it will not get in the way when
replacing the filter filling.
☞Make sure that the device can be disconnected on all
poles from the electricity supply after installation.

18
Installation
6005735_0 – 31.03.2021
3.5.8 Fit the side chimney panels
DATTENTION!
Danger of damage due to improper handling
The body of the hood and the chimney could be damaged
by movements during the installation.
☞Keep a distance between the chimney and the body of
the hood.
☞Keep objects that could scratch the device far away from
it (e.g. tools, belt buckles).
☞Loosen the mounting screws on the chimney stack.
☞Make sure that an approx. 3 mm wide gap remains
between the chimney panel and screw head.
☞Bring the chimney panel against the side of the chimney
stack.
☞Slide the holding clips beneath the screw heads.
☞Tighten the mounting screws again.
3.5.9 Fit the rear panels
☞Bring the rear panel with the lower edge against the
chimney stack.
☞Insert the brackets on the bottom edge in the mounting
studs on the chimney stack.
☞Press the rear panel into the top third on the chimney
stack.

19
Installation
6005735_0 – 31.03.2021
EN
☞Secure the rear panel from the inside with a screw.
☞Make sure that the rear panel is bolted tight.
3.5.10 Fitting the BackFlow port
The BackFlow port is installed with the following operating
modes:
yRecirculated air mode
yExtracted air mode with BackFlow technology
yHybrid mode
Use of the BackFlow port has effects on the energy efficiency
of the device.
D“2.1 Functional principle”(page 5).
2.
1.
☞Fit the BackFlow port on the fan outlet on the chimney
stack.
☞Secure the BackFlow port by turning slightly to the right.
3.5.11 Installing filter (with recirculating and hybrid
operation)
The BackFlow port (Ø 150 mm) is located on the fan housing
as an aid for the installation of the filter.
The filter is placed correctly when the bottom edge of the
filter is parallel to the top edge of the fan‘s housing and the
gap is approximately 3 mm wide.
If accessories are connected, the filter must be positioned at
a slight angle so that connector interference does not arise
when it is fitted.
Recirculated air mode
3
☞Place the recirculated air filter on the BackFlow port from
above.
☞Ensure that the recirculated air filter is correctly installed.
Hybrid mode
3
☞Place the hybrid filter on the BackFlow port from above.
☞Ensure that the hybrid filter is correctly installed.

20
Installation
6005735_0 – 31.03.2021
3.5.12 Connecting exhaust air ducting (with extracted
air and hybrid mode)
Extracted air mode without BackFlow technology
The BackFlow port is not used. When connecting a
flexible hose, it is possible to use a tight-fitting pipe as an
intermediate piece.
2.
☞Establish a chamfer on the inside of the exhaust air
ducting.
☞Fit the exhaust air ducting directly onto the outlet in the
fan housing from above.
Extracted air mode with BackFlow technology
The BackFlow port is used.
D“3.5.10 Fitting the BackFlow port” (page 19).
2.
1.
2.
☞Fit the exhaust air ducting onto the BackFlow port from
above.
☞Seal the transition between the exhaust air ducting and
the BackFlow port with sealing tape (accessory).
Hybrid mode
2.
☞Fit the exhaust air ducting onto the collar of the hybrid
filter from above.
All variants
☞Ensure that the exhaust air duct is correctly fitted.
3.5.13 Fit the front panel
☞Unscrew the knurled nut from the chimney stack.
☞Make sure that the closure on the front panel is open.
☞Attach the front panel to the hood body at the bottom
on the bolts.
☞Fit the free end of the retaining rope onto the threaded
bolt on the chimney stack.
☞Screw the knurled nut to the chimney stack until hand-
tight.
☞Press the front panel up between the side parts until the
closure can be heard to latch. If necessary, the closure can
be adjusted via slotted holes.
