Model CC34
Features
Berkel Model CC34 combination food processor is a
high-performance and versatile machine that quickly
and conveniently chops, slices, dices, blends and
mixes vegetables, fruits, cheese and virtually any
other product. Constructed of heavy-duty aluminum
with integrated handles, the compact CC34 is easy
to move from one location to another. Stainless steel
bowl provides superior durability and long life. The
continuous feed attachment includes an automatic
start/stop function, feed tube and design that allows
the operator to load product with both hands for the
fastest possible processing. The exclusive SureSense™
speed setting automatically senses whether the feed
head or bowl is attached for perfect processing results.
The dual interlock boosts operator protection. The
CC34 has a variety of cutting plates to optimize the
versatility and productivity of this superior machine.
Item #______________________________
Model CC34
Combination Food Processor
Standard Features
Slices, dices, shreds, grates and juliennes fruit,
vegetables, dry bread, cheese, nuts, etc.
Chops and grinds meat, fish, fruit, vegetables and nuts.
Blends and mixes sauces, aromatic butter, mayonnaise,
soups, dressing, thickenings, desserts, etc.
Prepares up to 4.4 lbs (2 kg) per minute with the
continuous feed attachment.
4-speed, 1-1/2 HP, thermal motor protection with
automatic reset.
Furnished in 120/60/1, UL listed.
The exclusive SureSense™ speed setting ensures
optimal speed settings and perfect cutting results for
the required applications.
Pulse function for precise operator control.
Continuous feed attachment includes feed head and
ejector plate.
Furnished with 5/64” (2 mm) shredder plate and
5/32” (4 mm) slicing plate.
Cutter/Mixer attachment includes 3.2 Quart (3 liter)
stainless steel bowl, knife unit, lid and scraper.
Cutter/Mixer knife unit with serrated blades for faster
processing.
Bowl scraper for uniform mixing that is removable for
easy cleaning.
Aluminum machine base and stainless steel bowl for
increased durability.
Options
Unit without slicing and shredding plates.
Accessories
Slicing Plates – 1/32” (1 mm), 5/64” (2 mm), 5/32” (4
mm), 1/4” (6 mm) and 3/8” (10 mm)
Crimping Plate – 3/16” (4.5 mm)
Shredder Plates – 5/64” (2 mm), 3/16” (4.5 mm),
1/4” (6 mm) and 5/16” (8 mm)
Fine Grater Plate
Julienne Plate – 5/64 x 5/64” (2x2 mm) and 3/16 x
3/16” (4.5x4.5mm)
Dicing Grid – 3/8” x 3/8” (10x10 mm) and 5/8” x 5/8”
(15x15 mm)
Replacement Blades - Slicing and Crimping
Wall Rack
h
h
h
h
h
h
h
h
h
h
h
h
h
h









Form #SPC38-0907N
Approved By:
Date
Combination Food Processor Model CC34

Combination Food Processor Model CC34
Berkel Company • 4406 Technology Drive • South Bend, IN 46628-9700
574-232-8222 • 800-348-0251 • FAX [phone] • www.berkel.com
Form #SPC38-0907N ©2007 Berkel Company Litho in USA
Specifications
Motor: 1-1/2 hp, 4-speed, thermal motor protection with
automatic reset.
Electrical: Furnished in 120/60/1, 9 amps, UL Listed, 3-
wire electrical cord and plug. Cord is 6’ in length.
Finish/Construction: Machine base of aluminum.
Cutter/Mixer attachment bowl of stainless steel, lid and
scraper of polycarbonate. Continuous feed attachment and
ejector plate of polycarbonate. Cutting plates and knife hub
of polycarbonate and aluminum. All blades of stainless
steel.
Controls: Sealed dial controls with integrated pulse
function.
Speeds: 4 speeds with SureSense™ automatic speed
settings: 2 high speeds (1,450/2,650 rpm) for chopping
and blending, 2 low speeds (500/800 rpm) for slicing,
dicing, shredding and grating.
Operator Protection: Dual interlocks keeps machine from
operating unless attachments are in the proper position.
Capacity: 3.2 quart stainless steel cutter/mixer bowl. 4.4
lbs./minute with continuous feed attachment.
Warranty: Parts, labor and travel coverage for two years,
exclusive of wear items.
As we continually strive to improve our products, specifications are
necessarily subject to change without notice.
Continuous Feed
Cutter/Mixer (Bowl)
C
C
Model
No. Capacity Product Dimensions Weight Width A Depth B Height C
CC34
Cont. Feed - 4.4 lbs./min.
(2 kg/min.)
Cont.
Feed
11”
(280 mm)
13-3/4”
(350 mm)
23”
(585 mm) Net 23 lbs. (11 kg)
Ship 33 lbs. (15 kg)
Bowl - 3.2 quarts (3 liters) Bowl 11”
(280 mm)
13”
(330 mm)
17”
(432 mm)
Motor Electrical Cutting
Speeds
Box Dimensions
Width A Depth B Height C
1-1/2 HP 120/60/1
9 amps
Cont. Feed - 500/800 rpm
Bowl - 1,450/2,650 rpm
16-1/4”
(413 mm)
16-1/4”
(413 mm)
27”
(686 mm)
