Berkel VCM-44A/1 User manual

Electrical Components
1
2
3
4
5
6
7
8
9
10
11
1Control Lamp 3-Q6000-10
2Pushbutton, Start 3-Q6032-11
Pushbutton, Stop 3-Q6032-10
3Timer 3-Q4020-03
4Insulating Sleeve 1”
5Fuse Holder 3-Q0510-21
6Ground Terminal 3-Q0515-21
7/8 Terminal 3-Q0520-09
9Auxiliary Contactor - Dil 20 SM6240
10 Contactor - Dil 1M 3-Q4530-19
11 Transformer - 220 Volts 3-Q8000-56
11 Transformer - 440 Volts 3-Q8001-89
N/S Cap for Pushbutton SM6120
N/S Bulb - Control Lamp 3-Q0098-01

Main Motor
1
2
3
4
5
6
7
89
10
11
12
13
14
15
16
25
17
18
19
20
21 22
23
24
26
27
19
25
12
28
29
30

No. Description Part Number
1Sleeve 3-K0502-01
2Screw 3-S0092-02
3Splash Plate 3-K1101-05
4Screw 3-S0062-04
5Bearing Shield 3-K4614-04
6Taper Pin 3-S0275-10
7“O” Ring 3-I0001-10
8“C” Ring 3-S0290-02
9Shaft Seal Ring 3-I0050-16
10 Roller Bearing 3-S2010-01
11 Shaft Seal Ring 3-I0050-29
12 Nut 3-S0200-03
13 Bolt 3-S0121-01
14 Rotor 3-C4513-01
15 Stator
16 Bolt 3-S0122-02
17 Inner Bearing Cap 3-K4550-04
18 Ball Bearing 3-S2001-21
19 “C” Ring 3-S0290-16
20 Bearing Shield 3-K4634-04
21 Nut 3-S0203-01
22 Bearing Cover 3-K4550-02
23 Lock Washer 3-S0246-02
24 Screw 3-S0011-01
25 Key (8 x 7x 32) 3-S0280-05
26 Fan 3-C6001-01
27 Lock Washer 3-S0246-04
28 Fan Cover 3-C6055-01
29 Motor Cover 3-L0002-14
30 Screw 3-S0056-01
Main Motor

1
2
3
4
5
6
7
8
9
10
11
12
13
14
1516 17
18 1920 21
22 23
24
25
26
27
28
29
30
Bowl
No. Description Part Number No. Description Part Number
1Bowl 3-B0210-01 15 Screw 3-S0041-05
2Cable Tube 3-M0020-01 16 Lock Washer 3-S0246-01
3Guide Bushing 3-K0530-50 17 Switch 3-Q6021-01
N/S “O” Ring 3-I0001-07 18 Screw 3-S0001-03
4Guide Bushing 3-K0530-51 19 Switch Plate 3-L0806-02
5Locking Lever, Complete 3-G0025-01 20 Lock Washer 3-S0246-02
6Bolt 3-K2556-01 21 Nut 3-S0200-03
7Lid Bolt 3-K2426-01 22 Cover 3-M2282-02
8Bearing Bushing 3-K0401-04 23 Cover Seal 3-T4004-02
9Curved Disc 3-K0712-01 24 “O” Ring 3-I0001-02
10 Bushing 3-K0531-02 25 Screw 3-S0102-05
11 Torsion Spring 3-M6003-04 26 Sealing Cap w/Gasket and “O” Ring 3-K1012-03
12 Bearing Bushing 3-K0401-03 27 “O” Ring 3-I0007-04
13 Cap 3-K0307-02 28 Stud Bolt 3-S0122-07
14 Screw 3-S0102-02 29 Lock Washer 3-S0246-05
30 Nut 3-S0200-06

Lid
No. Description Part Number
1Lid Complete 3-B6220-02
2Lid Seal 3-I0100-01
3View Window Comp. 3-M4023-03
4Seal for View Window 3-I0112-02
5Crank Handle Comp. 3-G0051-02
6Nut for Handle 3-K0027-01
7Mixing Baffle 3-D2022-01

Support and Switch Housing
1
2
3
4
5
6
7
8
9
10 11
12
13
14
15
16
17 18
19 20
21
22 23
24
25
26

No. Description Part Number
1Support 3-A2010-01
2Switch Housing 3-F0030-xx
3Nut 3-S0200-05
4Lock Washer 3-S0246-04
5Door 3-F0021-01
6Rubber Seal (2.5M) 3-T4004-04
7“O” Ring 3-I0001-04
8Screw 3-S0102-08
9Bearing 3-K0530-28
10 “O” Ring 3-I0004-06
11 Bearing Bush 3-K0533-08
12 Spacer Ring 3-K0200-33
13 Spacer 3-K0530-08
14 Bolt 3-K2591-01
15 Key 3-S0284-02
16 Bearing Bush 3-K0535-03
17 Spring 3-M6001-22
18 Locking Disc 3-K0738-01
19 Disc 2.5mm 3-K0200-25
Disc 3.0mm 3-K0200-26
Disc 3.5mm 3-K0200-27
Disc 4.0mm 3-K0200-28
Disc 4.5mm 3-K0200-29
20 Locking Lever 3-M2450-02
21 Rubber Foot 3-M4057-02
22 Rubber Foot for Roller 3-M4057-04
23 Bolt 3-K2225-01
24 Roller 3-K0535-04
25 Rubber Cap 3-M4072-02
26 Rubber Bumper 3-M4065-02
Support and Switch Housing

No. Description Part Number
1Knife Shaft 3-D0150-02
2Pressure Ring 3-K0310-02
3Pin 3-K2035-03
4Pin 3-K2035-05
5Slant Ring w/Pins 3-K0315-01
62 Narrow Knives 3-D0006-01
2 Wide Knives 3-D0007-01
2 Narrow Wave Cut Knives 3-D0006-02
2 Wide Wave Cut Knives 3-D0007-02
1 Wide & 1 Angle Bent Knife 3-D0008-01
7Wing Nut 3-K0008-05
8Mixing Insert 3-D4038-03
9Stirrer, SS - Small Qty. 3-D4038-01
10 Grater 3-D4038-04
11 Stirrer/Kneader, SS 3-D4038-02
12 Open-End Wrench 3-H6002-02
13 Special Wrench 3-G6015-02
14 Dough Scraper 3-H6000-01
15 Whetstone 3-H6018-01
N/S Stirrer/Kneader, Aluminum 3-D4037-03
1
2
3
4
5
6
7
8
9
10 11
12
13 14
15
Knife Inserts and Accessories
