Bernafon Compact Power Plus BTE Assembly instructions

Compact Power Plus BTE
Compact Power BTE
Micro BTE
Power BTE
Nano BTE
BEHIND-THE-EAR
HEARING INSTRUMENTS
Fitting Guide

COMPACT POWER PLUS, COMPACT POWER, MICRO, POWER, NANO
3
Fitting Guide
Compact Power Plus, Compact Power,
Power, Micro and Nano BTE Hearing Systems
Table of Contents
Hearing Systems Overview 4
Selection Chart for Acoustic Options 6
Fitting Ranges 7
Attaching and Removing the Earhook or Thin Tube Adapter 8
Changing the Dome 9
Installation of Right/Left Indicators 9
Replacing the Battery Door 11
DAI and FM Adapters 13
Attaching and Removing the DAI and FM Adapters 13
Using the FM Adapter 14
Using the DAI Adapter 14
Fitting a BTE with Oasis 15
Attaching the Programming Cables 15
FittingLINK 17
Ordering Information 19

4
Behind-the-ear (BTE) hearing instruments are available in different styles and with various acoustic
options, depending on the patient’s degree of hearing loss, the anatomy of the client’s ear,
and individual style preferences. This guide is designed to help you t and manage BTE hearing
instruments.
Compact Power Plus (CPx) and Compact Power (CP) BTE with Earhook
(also available with thin tube system)
Micro BTE with Thin Tube System
(also available with earhook)
Bernafon Veras IFU micro BTE
VR_ILU_microBTEwithHook_BW_HI
2a
1
4
3
2
56
1
1 Multi control
2 Microphone
2a Second microphone
3 Earhook
4 Sound outlet
5 Battery door
6 Direct Audio Input
(with an optional
DAI adapter)
1 Multi control
2 Microphone
2a Second microphone
3 Adapter
4 Thin tube
5 Sound outlet
6 Dome
7 Concha clip
8 Battery door
9 Direct Audio Input
(with an optional
DAI adapter)
Bernafon Veras IFU micro BTE
VR_ILU_microBTEwithSpira_BW_HI
15
4
3
2
2a
6
7
89
1
Hearing Systems Overview

COMPACT POWER PLUS, COMPACT POWER, MICRO, POWER, NANO
5
Power BTE with Earhook
(also available with thin tube system)
Nano BTE with Thin Tube System
(also available with earhook)
Bernafon nano BTE IFU
VR_ILU_nanoBTEwithSpira_BW_HI
2a
8
1
7
6
5
4
2
31 Push button
2 Microphone
2a Second microphone
3 Adapter
4 Thin tube
5 Sound outlet
6 Dome
7 Concha clip
8 Battery door
1NE_ILLU_P_Earhook_front_BW
2a
1
1
6
5
4
231 Multi control
2 Microphone
2a Second microphone
3 Earhook
4 Sound outlet
5 Battery door
6 Direct Audio Input
(with an optional
DAI adapter)

6
Selection Chart for Acoustic Options
All BTE models covered in this Fitting Guide can either be tted with a conventional earhook or with a
thin tube system. Traditional earhooks are used with a custom earmold.
The thin tube systems can be combined with a variety of different domes and customized earpieces.
All Compact Power Plus, Compact Power, Power, Micro and Nano BTEs can be tted with the Spira
Flex and the miniFit thin tube system.
Please note that, for each BTE model, in the tting software only one set of options (either Spira Flex
or miniFit) is given. However, the table below will help you make the appropriate selection when you
wish to use the other set of options.
Spira Flex miniFit
Thin Tube 0.9 mm
Thin Tube 1.3 mm
Thin Tube 0.9 mm
Thin Tube 1.3 mm
Open Dome
(6, 8, 10 mm)
Open Dome
(6, 8, 10 mm)
Tulip Dome n.a.
Dome, Large Vent
(8, 10, 12 mm)
Bass, Double Vent
(6, 8, 10, 12 mm)
Dome, Small Vent
(8, 10, 12 mm)
Bass, Single Vent
(6, 8, 10, 12 mm)
Power Dome
(6, 8, 10 mm)
Power Dome
(6, 8, 10, 12 mm)
Canal Mold Micro Mold
Custom Tip n.a.
n.a. Lite Tip
Note: Never attach a Spira Flex earpiece onto a miniFit thin tube and vice versa, as it could fall off in
the client’s ear canal.

COMPACT POWER PLUS, COMPACT POWER, MICRO, POWER, NANO
7
BTE hearing instruments offer a variety of different styles which are appropriate for mild to severe
hearing losses. Expected tting ranges of each hearing instrument style are shown below.
Fitting Ranges
250 500 1. 000 2.000 4.000 8.000
0
20
40
60
80
100
120
dB HL
Frequency (Hz)
250 500 1. 000 2.000 4.000 8.000
0
20
40
60
80
100
120
dB HL
Frequency (Hz)
0
20
40
60
80
100
120
250 500 1. 000 2.000 4.000 8.000
dB HL
Frequency (Hz)
0
20
40
60
80
100
120
250 500 1. 000 2.000 4.000 8.000
dB HL
Frequency (Hz)
0
20
40
60
80
100
120
250 500 1. 000 2.000 4.000 8.000
dB HL
Frequency (Hz)
Compact Power Plus BTE Power BTE
Compact Power BTE Micro BTE
Nano BTE

8
Attaching and Removing the Earhook or
Thin Tube Adapter
All BTE hearing instruments are available with either the thin tube system or
a conventional earhook.
Compact Power Plus, Compact Power, Power, and Micro BTE
1 Use the pointed end of the disassembly tool to push the lock pin free
2 Replace the hook or adapter with the desired part
3 Replace the lock pin (tweezers make this easier)
Nano BTE
1 Pull the adapter or the hook upwards from the instrument
2 Replace with a new hook or an adapter by pushing the desired part rmly onto the instrument
Use the pointed end of the disassembly tool
to push the lock pin.
VR_ILU_MicroCompactBTERemovePin_CMYK_HI
Remove hook or adapter.
VR_ILU_MicroCompactBTERemoveHook_BW_HI
VR_ILU_NanoBTERemoveSpira_BW_HI
VR_ILU_NanoBTERemoveHook_BW_HI

COMPACT POWER PLUS, COMPACT POWER, MICRO, POWER, NANO
9
Installation of Right/Left Indicators
Changing the Dome
The soft domes are a disposable part.
The client should be supplied with spare
domes and shown how to change them.
1 Open the battery door and insert the marker end into slot as shown
2 Twist and rotate the stick to break off the marker
3 Close the battery door
Micro BTE
Nano BTE
1 Pull the used dome off the thin tube and
discard
2 With clean hands, rmly push a new dome
onto the thin tube as far as it will go
If the dome is not pushed all the way onto the
thin tube, it could fall off in the ear canal.
VR_ILU_MicroCompactBTEInstMarking1_CMYK_HI
VR_ILU_MicroCompactBTEInstMarking2_CMYK_HI
VR_ILU_MicroCompactBTEInstMarking3_CMYK_HI
VR_ILU_NanoBTEInstMarking1_BW_HI
VR_ILU_NanoBTEInstMarking2_CMYK_HI
VR_ILU_NanoBTEInstMarking3_CMYK_HI

10
Compact Power Plus and Compact Power BTE
1 Open the battery door
2 Insert the marker end into the slot as shown
3 Twist and rotate the stick to break off the marker
4 Close the battery door
Power BTE
1 Open the battery door
2 Insert the marker end into the slot as shown
3 Rotate the stick to break off the marker
4 Close the battery door

COMPACT POWER PLUS, COMPACT POWER, MICRO, POWER, NANO
11
Power and Nano BTE
1 Push out the metal pin with the disassembly tool
2 Pull the pin out with a pair of tweezers
3 When replacing the battery door, snap in the new door (closed position) and use the tweezers
to place the pin into the hole
4 Use the at end of the tweezers to push the pin completely in
VR_ILU_NanoBTEbatteryDrawerRemove1_CMYK_HI
VR_ILU_NanoBTEbatteryDrawerRemove2_BW_HI
VR_ILU_NanoBTEbatteryDrawerMounting_BW_HI
Replacing the Battery Door
Compact Power Plus, Compact Power, and Micro BTE
1 Open the battery door and place the battery removal tool as shown
2 Gently pull the battery door off
3 Snap the new battery door in place and close

12
Tamper-Resistant Battery Door
The following models have an optional tamper-resistant battery door that can be ordered separately.
A tamper-resistant door should be used for small children and vulnerable persons.
Compact Power Plus and Compact Power, and Micro BTE
Lock the door
1 To lock the door, close the battery door completely
2 Use a small screwdriver to turn the lock so that the line is horizontal (Micro BTE only)
Unlock the door
1 Use a small screwdriver to turn the lock so that the line is vertical (Micro BTE only)
2 Insert the screwdriver into the slit in the bottom of the instrument and push to open
Micro BTE Compact Power/Compact Power Plus BTE
Power BTE
1 Open the tamper-resistant battery door
2 Insert the special left/right marker into the slot
3 Close the tamper-resistant battery door. The battery door is now locked.
4 To unlock the battery door, insert the tip of the blue tool into the small hole at the back
5 Move the tool to the right side. While holding this position, open the battery door.
Bernafon Veras IFU micro BTE
VR_ILU_TamperResitantBatteryDrawerCompactBTE_BW_HI
Bernafon Veras IFU micro BTE
VR_ILU_TamperResitantBatteryDrawerMicroBTE_BW_HI
Bernafon Veras IFU micro BTE
VR_ILU_TamperResitantBatteryDrawerMicroBTE2_BW_HI
1
2

COMPACT POWER PLUS, COMPACT POWER, MICRO, POWER, NANO
13
Attaching and Removing the DAI and FM Adapters
DAI and FM Adapters
Power BTE
Before you attach the FM or DAI adapter to the hearing instrument, the standard battery door must
be replaced with the one dedicated for these adapters. Refer to page 11 to see how to change the
battery door.
1 Replace the battery door
2 With the battery in place, plug the DAI or FM adapter as shown
3 Close the battery door
4 To remove the DAI or FM adapter, open the battery door and unplug
Compact Power Plus, Compact Power, and Micro BTE
1 Open the battery door fully
2 With the battery in place, slide the DAI or FM adapter into the slot until it lines up with the
hearing instrument
3 Close the battery door
4 To remove the DAI or FM adapter, open the battery door and slide out
12 NE_ILLU_P_AttachingDAIFMAdapter1_BW
13 NE_ILLU_P_AttachingDAIFMAdapter2_BW
14 NE_ILLU_P_AttachingDAIFMAdapter3_BW

14
Using the FM Adapter
The Compact Power Plus, Compact Power, and Power BTE hearing instruments are compatible with
all commonly available ear level FM systems (FM receivers). The connection is established via the
Europlug.
Choose the FM adapter also when attaching a CROS microphone unit to the hearing instrument.
Using the DAI Adapter
Direct Audio Input (DAI) enables the hearing aid to receive signals directly from external sources such
as a TV, personal stereo, PC audio output, MP3 player, etc.
The DAI Adapter offers a Euro-
plug connection to establish a
wired coupling via the DAI cord
to an external source.
The DAI Adapter comes with two adjustable trimmers.
Use the trimmer on the front to
adjust the individual volume.
The trimmer on the top selects
the input impedance.
22
14
14
HI
LO
Position HI: TV, stereo, MP3
player, PC, etc.
Position LO: Bodyworn FM
solutions

COMPACT POWER PLUS, COMPACT POWER, MICRO, POWER, NANO
15
Fitting a BTE with Oasis
Attaching the Programming Cables
BTE hearing systems are programmed with Oasis using new standard (no. 2) programming cables.
Some BTE models need a battery to be programmed. Please always insert a fresh battery prior to
programming.
Compact Power Plus, Compact Power, and Micro BTE
Power BTE
Bernafon Veras IFU micro BTE
VR_ILU_DaiFMAdapterOnMicroBTE_BW_MOD_HI
VR_ILU_MicroCompactBTEprogramAdapter_BW_HI
1 Open the battery door fully. There is no need
to insert a battery when programming.
2 Plug the cable into the connector
1 Open the battery door fully and slide the
programming adapter into the slot until
it lines up with the instrument
2 Close the battery door again and plug in
the cable as shown
15 NE_ILLU_P_AttachingProgrammingCable1_BW
16 NE_ILLU_P_AttachingProgrammingCable2_BW

16
VR_ILU_NanoBTEprogRemoveCover1_BW_HI
VR_ILU_NanoBTEprogConnectCable_BW_HI
VR_ILU_NanoBTEprogRemoveCover2_BW_HI
Nano BTE
1 Remove the cover with the small tool as shown
2 Plug the cable into the connector
3 To replace the cover, hook the top end under the shell rst, then snap it in place

COMPACT POWER PLUS, COMPACT POWER, MICRO, POWER, NANO
17
FittingLINK
Programming with FittingLINK
FittingLINK is a wireless programming interface which allows tting of all wireless hearing
instruments. FittingLINK is connected to the PC via the provided dedicated Bluetooth®dongle or USB
cable.
The FittingLINK Instructions for Use, provided in the packaging contains important information about
the product, its functions and pairing it with the PC. Please read the Instructions for Use carefully
before using FittingLINK with Oasis.
Getting Started
Please prepare FittingLINK and pair it with your PC, as described in the FittingLINK Instructions for
Use.
When opening Oasis the rst time after FittingLINK has been installed on the PC, it will automatically
be detected as a programming interface. A dialog will offer to change your preferred programming
interface to FittingLINK. This can be done any time later in Preferences – Communication. Thereafter
FittingLINK can be used in Oasis.

18
Detecting and Programming Hearing Instruments
Make sure that FittingLINK is paired with your PC, fully charged, and switched on (steady green light
on the top LED indicator). For safety reasons the hearing instruments should not be in the client’s ear
during detection. To ensure a good connection, make sure that the hearing instruments are aligned
the correct way towards the FittingLINK neck loop antenna. Refer to the FittingLINK Instructions for
Use.
Open Oasis and click Detect. If FittingLINK is not selected as the default programming interface,
select the FittingLINK option from the pull down menu besides the Detect button.
Verify Right and Left Hearing Instruments
In the Detect Hearing Instruments dialog, you can play a tone in each hearing instrument to identify
to which side it is currently assigned. If the assignment is correct, click “Next”. If you would like to
change the assignment, click “Exchange” and then click “Next”.
Thereafter the tting process is the same.
For troubleshooting, please also refer to the FittingLINK Instructions for Use.

COMPACT POWER PLUS, COMPACT POWER, MICRO, POWER, NANO
19
Ordering Information
. Fitting Kits
Part Number Description Comments
163095 miniFit Thin Tube Kit Containing all miniFit parts and tools
890-80-060-00 Spira Flex Fitting Kit Containing all Spira Flex parts and
tools
Thin Tubes .3 mm – miniFit
Part Number Description Comments
156533 miniFit Thin Tube, 1.3 mm size 0 left
Clamshell containing:
– 5 miniFit thin tubes 1.3 mm
– 5 eargrips for miniFit tubes
156534 miniFit Thin Tube, 1.3 mm size 1 left
156535 miniFit Thin Tube, 1.3 mm size 2 left
156536 miniFit Thin Tube, 1.3 mm size 3 left
156537 miniFit Thin Tube, 1.3 mm size 0 right
156538 miniFit Thin Tube, 1.3 mm size 1 right
156539 miniFit Thin Tube, 1.3 mm size 2 right
156540 miniFit Thin Tube, 1.3 mm size 3 right
Thin Tubes 0.9 mm – Spira Flex
Part Number Description Comments
589-25-070-00 Spira Flex Thin Tube, 0.9 mm size 0 left
Clamshell containing 5 Spira Flex
thin tubes 0.9 mm
589-25-071-00 Spira Flex Thin Tube, 0.9 mm size 1 left
589-25-072-00 Spira Flex Thin Tube, 0.9 mm size 2 left
589-25-073-00 Spira Flex Thin Tube, 0.9 mm size 3 left
589-25-060-00 Spira Flex Thin Tube, 0.9 mm size 0 right
589-25-061-00 Spira Flex Thin Tube, 0.9 mm size 1 right
589-25-062-00 Spira Flex Thin Tube, 0.9 mm size 2 right
589-25-063-00 Spira Flex Thin Tube, 0.9 mm size 3 right
2. Thin Tubes
Thin Tubes 0.9 mm – miniFit
Part Number Description Comments
156522 miniFit Thin Tube, 0.9 mm size 0 left
Clamshell containing:
– 5 miniFit thin tubes 0.9 mm
– 5 eargrips for miniFit tubes
156523 miniFit Thin Tube, 0.9 mm size 1 left
156524 miniFit Thin Tube, 0.9 mm size 2 left
156525 miniFit Thin Tube, 0.9 mm size 3 left
156526 miniFit Thin Tube, 0.9 mm size 0 right
156527 miniFit Thin Tube, 0.9 mm size 1 right
156528 miniFit Thin Tube, 0.9 mm size 2 right
156529 miniFit Thin Tube, 0.9 mm size 3 right

20
Thin Tubes .3 mm – Spira Flex
Spira Flex Domes
3. Domes
miniFit Domes
Part Number Designation Comments
589-25-090-00 Spira Flex Thin Tube, 1.3 mm size 0 left
Clamshell containing 5 Spira Flex
thin tubes 1.3 mm
589-25-091-00 Spira Flex Thin Tube, 1.3 mm size 1 left
589-25-092-00 Spira Flex Thin Tube, 1.3 mm size 2 left
589-25-093-00 Spira Flex Thin Tube, 1.3 mm size 3 left
589-25-080-00 Spira Flex Thin Tube, 1.3 mm size 0 right
589-25-081-00 Spira Flex Thin Tube, 1.3 mm size 1 right
589-25-082-00 Spira Flex Thin Tube, 1.3 mm size 2 right
589-25-083-00 Spira Flex Thin Tube, 1.3 mm size 3 right
Part Number Designation Comments
570-07-410-00 Open Dome, 6 mm
Open Domes
Bag including 10 domes
570-07-411-00 Open Dome, 8 mm
570-07-412-00 Open Dome, 10 mm
589-25-100-00 Dome, Tulip Tulip Domes
Bag including 10 domes
123310 Dome, Large Vent, 8 mm
Double vented domes
Bag including 10 domes
123311 Dome, Large Vent, 10 mm
123312 Dome, Large Vent, 12 mm
123307 Dome, Small Vent, 8 mm
Single vented domes
Bag including 10 domes
123308 Dome, Small Vent, 10 mm
123309 Dome, Small Vent, 12 mm
123293 Power Dome 6 mm
Power Domes
Bag including 10 domes
123305 Power Dome 8 mm
123306 Power Dome 10 mm
Part Number Designation Comments
149303 Open Dome miniFit 6 mm
Open Domes
Clamshell including 10 domes
149304 Open Dome miniFit 8 mm
149305 Open Dome miniFit 10 mm
149306 Bass Dome Double Vent miniFit 6 mm
Bass domes with double vent
Clamshell including 10 domes
149307 Bass Dome Double Vent miniFit 8 mm
149308 Bass Dome Double Vent miniFit 10 mm
149309 Bass Dome Double Vent miniFit 12 mm
149310 Bass Dome Single Vent miniFit 6 mm
Bass domes with single vent
Clamshell including 10 domes
149311 Bass Dome Single Vent miniFit 8 mm
149312 Bass Dome Single Vent miniFit 10 mm
149313 Bass Dome Single Vent miniFit 12 mm
149314 Power Dome miniFit 6 mm
Power Domes
Clamshell including 10 domes
149315 Power Dome miniFit 8 mm
149316 Power Dome miniFit 10 mm
149317 Power Dome miniFit 12 mm
