BETCO PB21-11 User manual

PB24-13
13hp Honda
PB21-11
11hp Honda
PB21-13
13hp Honda
PB24-11
11hp Honda
Operator's Manual
Parts Schematic
Propane Powerered Floor Burnishers
© 2007 Betco Corporation. All Rights Reserved. 1001 Brown Avenue · Toledo Ohio 43607-0127· 888-GO-BETCO · www.betco.com

TABLE OF CONTENTS
COVER PAGE 1
LEFT BLANK INTENTIONALLY 2
TABLE OF CONTENTS 3
WARNING - CARBON MONOXIDE 4
CARBON MONOXIDE - SYMPTOMS AND DETECTORS 5
SAFETY INSTRUCTIONS 6 - 7
TANK USE AND STORAGE 8
BEFORE STARTING THE MACHINE 9
STARTING AND STOPPING THE ENGINE 10
BELT TENSIONING INSTRUCTIONS 11
PAD CHANGING INSTRUCTIONS 12
ENGINE MAINTENANCE 13
DECK, WHEELS, AND MORE - PARTS 14 - 15
HANDLE - PARTS 16 - 17
FLEX LOK PAD DRIVER ASSEMBLY - PARTS 18
CENTRIFUGAL CLUTCH OPTION 19
FUEL SYSTEM - PARTS 20
ELECTRICAL SYSTEM - PARTS 21
TROUBLE SHOOTING 22
WARRANTY 23

WARNING
LETHAL EXHAUST GAS
NEVER RUN THE ENGINE
IN A CLOSED BUILDING
OR CONFINED AREA
Exhaust gases contain poisonous carbon
monoxide. Carbon monoxide is odorless,
colorless, and can cause death if inhaled.
BETCO, CORP. 7/26/07 Page 4 PROPANE BURNISHER

CARBON MONOXIDE - MUST READ THIS!
Carbon Monoxide Poisoning Symptoms
Train your employees to know the warning signs of carbon monoxide
poisoning.
Mild carbon monoxide poisoning may cause any of the following:
headache, drowsiness, faintness, poor coordination, nausea, and vomiting.
Turn the engine off and immediately get to fresh air if you have any of
these symptoms. Do not run the machine until it is given an emissions test and
repairs made by a Betco Corporation distributor.
Moderate or severe carbon monoxide poisoning causes confusion, unconsciousness,
chest pain, shortness of breath, and coma. Thus, most victims are not able to move
themselves and must be rescued. Severe poisoning is often fatal.
Carbon monoxide is dangerous because a person may not recognize drowsiness as a
symptom of poisoning. Consequently, someone with mild poisoning can go to sleep and
continue to breathe the carbon monoxide until severe poisoning or death occurs. Some
people with long-standing, mild carbon monoxide poisoning caused by furnaces or
heaters may mistake their symptoms for other conditions, such as the flu or other viral
infections.
Carbon Monoxide Detectors
CO detectors are a must for safe operation of your equipment. Various types are
available. A “CO” carbon monoxide detector detects carbon monoxide before it reaches
dangerous levels. Detectors are a must for those who run propane powered equipment.
The CO Detector is for everyone’s protection against Carbon Monoxide Poisoning.
xCarbon Monoxide Detector - Passive
oEffective for 30 days after package has been opened.
oWrite the date opened on the detector.
oMount with self-adhesive strip on the machine handle.
oTrain machine operator to check detector regularly.
oIf the orange disk on the detector changes to gray or black - your Carbon
Monoxide Levels are at a Dangerous Level.
oIf the orange disk changes to gray or black you must turn your buffer off
immediately and return it to your nearest authorized Betco Corporation.
distributor for an emissions test.
oDo Not Restart the machine until the emissions have been checked and
corrected.
oThis is for your protection as well as your customers. CO detectors are a
must for safe operation and maximum efficiency of your equipment.
oFor replacement CO detectors, contact your Betco Corporation distributor.
Ask for the carbon monoxide detector, part E012426.
xCarbon Monoxide Detector - battery operated with alarm
oAvailable from various sources.
BETCO, CORP. 7/26/07 Page 5 PROPANE BURNISHER

SAFETY
lmportant Safety Information
All LPG (Liquid Propane Gas) powered engines, including this engine,
produce Carbon Monoxide (CO). It is a LETHAL POISON that is colorless,
odorless, tasteless, and non-irritating gas. You must read “Danger: Lethal
Exhaust Gas” information below.
Keep hands, feet, and loose clothing away from all moving parts while the
machine is in operation. The exhaust system gets very hot so keep hands,
clothing and any items that can burn away from the engine, engine manifold, and
muffler.
Betco machines are built tough and durable, however do not abuse the
machine. With proper care and maintenance this unit will give you years of
trouble free operation.
Danger: Lethal Exhaust Gases
Engine exhaust gases contain poisonous carbon monoxide. Carbon
monoxide is odorless, colorless, tasteless, and can cause death if inhaled.
Failure to provide proper venting of CO, failure to properly maintain the
engine, or failure to properly train personnel of the dangers and warning signs of
carbon monoxide exposure may result in SERIOUS INJURY OR DEATH to the
operator and others in the area.
xAny equipment with the potential to produce carbon monoxide presents a
significant hazard when used indoors. They must be used with great caution.
Opening a door or window, or running an exhaust fan will not necessarily
supply adequate ventilation. Avoid inhaling exhaust fumes and never run the
engine in a closed building or confined area without proper ventilation.
xDo not allow engine to run unattended.
xIf you have any indication that the engine is not running properly, immediately
shut the machine off and have it checked over and repaired by qualified
maintenance personnel.
xWorkers should be trained to recognize the hazards of carbon monoxide and
the early symptoms of carbon-monoxide poisoning.
xA carbon-monoxide detector and alarm should be available to alert workers of
emissions.
xHave a carbon monoxide detector attached to machine handle or have
machine operator wear a carbon monoxide detector. (See carbon monoxide
detector page).
BETCO, CORP. 7/26/07 Page 6 PROPANE BURNISHER

SAFETY
continued from previous page
xUse only as described in this manual.
xUse only manufacturer’s recommended components.
xMaintenance and repairs must be done by qualified personnel.
xOnly trained operators should be allowed to operate propane powered floor
machines.
xIf the machine is not working properly, have it serviced by an authorized
service center.
xInstall fuel cylinder in a well ventilated place.
xBe aware of possible leaks of propane gas if odor is present.
xIf the machine is stored inside a building, remove the fuel cylinder and store
properly outside.
xSecure fuel cylinders when being transported.
xIf tank is left attached to the machine then valve should be OFF.
xNever store fuel cylinders in a vehicle, building, or area where they may
exposed to high temperature.
xDo not operate the machine with any openings blocked.
xKeep openings free of debris that may reduce airflow.
xRemove fuel cylinder and disconnect battery before servicing.
BETCO, CORP. 7/26/07 Page 7 PROPANE BURNISHER

TANK USE AND STORAGE
We use the Worthington gas cylinders designed for vapor
withdrawal. The fuel lock offs, regulators, and engines are also designed
for vapor withdrawal.
xUse the OPD (Overflow Protection Device) vapor withdrawal type
cylinder. These style tanks have a triangle shaped valve handle.
xDo not overfill - the best gauge is a scale - never allow tank to weigh
over 36 pounds for an aluminum tank and 43 pounds for a steel tank.
xStore tanks outside in a well-ventilated area.
xNever store fuel cylinders in a vehicle, building, or area where they
may exposed to high temperature.
xIf the machine is stored inside a building, remove the fuel cylinder and
store properly outside.
xConnect fuel cylinder to machine in a well ventilated place.
xBe aware of possible leaks of propane gas if odor is present.
xSecure fuel cylinders when being transported.
xIf tank is left attached to the machine then valve should be OFF.
xStore tanks in the upright position (valves up).
BETCO, CORP. 7/26/07 Page 8 PROPANE BURNISHER

BEFORE STARTING THE MACHINE
Before the machine is operated, you first should read your Engine Operation Manual and your
Owner’s Manual.
xYour machine is shipped ready operation; however there is no fuel in the tank. When having
the tank filled, you must make sure the tank is never over filled.
oThe best way to do this is to tell the filling station to weigh the tank full. On an aluminum
tank, it should weigh no more than 36 pounds and on a steel tank no more than 43
pounds. (See more information at “Tank Storage and Maintenance” page.)
xAdjust the handle for comfortable operation. Remove hairpin cotter pins from clevis pins,
remove pins, and adjust to the hole alignment that gives the most comfortable height.
Replace clevis pins and hairpin cotter pins. Tighten nuts and bolts if needed.
xMake sure pad is not torn, pad is well attached and centering device is tightened.
xCheck Oil Level: Starting the engine without the proper amount of oil will cause severe
engine damage. Always keep the engine oil level between the full and add marks on the
dipstick. Do not loosen oil fill cap or remove dipstick while engine is running.
oPark your burnisher on a level surface.
oTurn the oil fill cap counter clockwise and then lift from the fill tube.
oWipe the dip stick clean and push it back into the oil fill tube until the cap seats and then
withdraw it to check: the oil level. (Do not screw cap on to check oil). Add if necessary. If
the oil level is low, add API Class SM oil having a SAE viscosity grade appropriate for
the expected temperatures as indicated in the Operators Manual (Usually a HD30 or
10W30).
oImportant Note: DO NOT OVERFILL
oReplace oil cap.
xInspect fuel hoses and fittings for wear and leaks. Have all worn hoses and leaks repaired
before operating..
xLook and listen for exhaust leaks. Have all leaks repaired before operating.
xCheck the carburetor filter and air filter for debris. Clean and replace if necessary.
xConnect fuel hose to tank by screwing the hose fitting to tank. You must tighten all the way
down to make fuel connection. Turn tank knob slowly until you hear the flow of fuel into fuel
system.
BETCO, CORP. 7/26/07 Page 9 PROPANE BURNISHER

STARTING AND STOPPING
THE HONDA ENGINE
STARTING THE HONDA ENGINE
The Honda engine is equipped with a 110 volt AC starter.
1) Install tank.
2) Attach propane hose coupling and fully tighten.
3) Tilt machine back so that pad is off the floor.
4) Open propane tank valve (turn counterclockwise). Hose will fill.
Must not be any leaks.
5) Put throttle cable into the “fast” position.
6) Hook cord to starter connection and plug into wall outlet.
7) Push red start button and hold until the engine starts. Do not
crank for more than 20 seconds at a time and wait at least one
minute between tries when cranking. See troubleshooting guide if
the engine does not start after several tries.
8) After engine starts, unplug cord and return to storage position on
handle.
9) Set throttle to a slow operating speed until the motor warms up.
Can increase engine speed after 3 to 5 minutes.
STOPPING THE HONDA ENGINE
1) Turn propane tank valve to the closed position (turn clockwise)
and allow the engine to continue running until it runs out of fuel.
BETCO, CORP. 7/26/07 Page 10 PROPANE BURNISHER

SHOWN TO PUSH INSIDE OF BELT OUT
TO TIGHTEN TENSIONER IN DIRECTION
USE 15/16 SOCKET WITH EXTENSION
TEST TENSION BY
PUSHING OR
PULLING ON
BELT. WITH BELT
PROPERLY
TENSIONED, THE
PULLEY ON THE
TENSIONER ARM
SHOULD MOVE
ONLY ABOUT
AN INCH.
TO TIGHTEN THE BELT TENSIONER
(Tensioner may have slipped, or belt may have stretched)
Tilt machine back onto rear caster.1.
Using a 3/4" open end wrench, secure the top of the shaft and remove pad driver2.
assembly. (see "Pad Changing Instructions" page)
On the top of the deck, use a 9/16” wrench to loosen tensioner bolt. Leave a little snug to3.
help hold tensioner in place after adjustment.
Using a 15/16” socket with an extension, fully tighten tensioner from the underside of4.
deck, and back off 10 to 15 degrees. This will be about 2 inches at the end of the socket
handle. (Note: This is about one mark on the tensioner. There are five marks on the side
of the tensioner, which are difficult to see with the tensioner in place. Each mark is equal
to about 15 degrees. This leaves the tensioner at about 60 degrees of tightness.)
While holding position tensioner in this proper location, fully tighten the tensioner bolt5.
from the top. TIGHTEN SECURELY!
Make sure tensioner did not slip by pushing or pulling on side of belt away from6.
tensioner. Belt should be tight and move the tensioner arm 10 to 15 degrees (about 1 ").
BELT TENSIONING INSTRUCTIONS
TENSIONER BOLT
USE 9/16"
WRENCH
BELTS FOR PROPANE POWERED FLOOR BURNISHERS
ENGINE PAD SIZE PART DESCRIPTION PART NUMBER
KAWASAKI OR HONDA 21” BX41 V-BELT E010294
HONDA 24” BX48 V-BELT E010303
KAWASAKI 24” BX53 V-BELT E010475
KAWASAKI 28” BX51 V-BELT E010472
PULLEYS FOR PROPANE POWERED FLOOR BURNISHERS
PAD SIZE PART DESCRIPTION PART NUMBER
21” 10.0” PULLEY E010428
24” 8.5” PULLEY E012403
28” 7.5” PULLEY E012401
BETCO, CORP. 7/26/07 Page 11 PROPANE BURNISHER

TIGHT.
TILT MACHINE ON SIDE.•
HONDA MACHINE MUST BE TILTED TO•
THE RIGHT, AS VIEWED FROM THE REAR.
DO NOT TILT AIR FILTER DOWN. RIGHT IS
RIGHT.
DOES NOT MATTER WHICH SIDE TO TILT•
KAWASAKI, SINCE AIR FILTER IS IN THE
FRONT.
REMOVE PAD CENTERING DEVICE.•
REPLACE PAD. BE SURE IT IS CENTERED WELL.•
REPLACE PAD CENTERING DEVICE. SCREW•VIEWED FROM FRONT
TILT THE MACHINE BACK ON CASTER.•
REMOVE PAD CENTERING DEVICE BY•
UNSCREWING.
REMOVE OLD PAD.•
REPLACE WITH NEW PAD OF CORRECT•
SIZE. BE SURE PAD IS CENTERED.
REPLACE PAD CENTERING DEVICE•
AND FULLY TIGHTEN.
SPIN PAD DRIVER THIS
DIRECTION TO REMOVE
•
NEED TO LAY ON FLOOR TO GET THREADS STARTED.
•
SPIN PAD DRIVER ON SHAFT (CLOCKWISE AS VIEWED FROM BOTTOM). MAY
TILT MACHINE BACK•
PLACE 3/4" OPEN END WRENCH ON FLATS ON TOP OF SHAFT•
SPIN PAD DRIVER IN DIRECTION SHOWN TO REMOVE (COUNTER-CLOCKWISE•
AS VIEWED FROM BOTTOM)
REPLACE PAD AS DESCRIBED ABOVE
SEE DETAIL
THERE ARE THREE WAYS TO CHANGE THE PAD
AIR FILTER MUST BE TILTED UP.
DO NOT TILT
AIR FILTER DOWN.
PAD CHANGING INSTRUCTIONS
BETCO, CORP. 7/26/07 Page 12 PROPANE BURNISHER

PERIODIC MAINTENANCE
PLEASE REFER TO ENGINE OWNERS MANUAL
FOR MORE INFORMATION
BEFORE
EACH
USE
EVERY
25
HOURS
EVERY
50
HOURS
EVERY
100
HOURS
EVERY
200
HOURS
x Check engine oil level and add if needed
x Check and clean engine bonnet filter
x replacement for 11HP is E010944
x replacement for 13HP is E010942
x General check for loose or lost nuts and
screws, oil leakage, etc…
x Check fuel hose and connections
*
*
*
*
x Clean air cleaner foam element
x Clean air cleaner paper element
x Check belt tensions
x Check battery electrolyte level
*
*
*
*
x Change engine oil (1) *
x Clean dust and dirt from cylinder and
cylinder head cooling fins
x Tighten nuts and screws
x Clean and reset gap on spark plugs
*
*
*
x Replace air cleaner paper element
x Carburetor filter E012279
x Replace air cleaner foam element
x Pre-carb filter E012278
x Replace spark plug
x Spark plug E010964
x Check and adjust valve clearance
x Clean combustion chamber
x Clean and lap valve seating surface
*
*
*
*
*
*
IMPORTANT NOTES:
x (1) Change engine oil after first 8 hours of operation
x PLEASE REFER TO ENGINE OWNERS MANUAL FOR MORE INFORMATION
MAINTENANCE SHOULD BE DONE
BY QUALIFIED PERSONNEL ONLY
ENGINE MAINTENANCE
HONDA GXV340 11 HP AND GXV380 13 HP
BETCO, CORP. 7/26/07 Page 13 PROPANE BURNISHER

BETCO, CORP. 7/26/07 Page 14 PROPANE BURNISHER

DECK, WHEELS, AND MORE
ITEM NO. PART NO. DESCRIPTION
1 E012282 HOUR METER P15387
2 E010111 RIVET, AAP48
3 E012366 WASHER, FLAT, 5/16"
4 E010112 BOLT, 5/16-18 x 1.25
5 E012445 NUT, LOCK, 5/16"
6 E010113 BOLT, 1/2-13 x 1-1/4
9 E010116 BOLT, 7/16-14 x 1.25
10 E010117 WASHER, LOCK, 7/16"
11 E012447 WASHER, FLAT, 7/16"
12A E011281 DECK, 21"
12B E011281 DECK, 24"
12C E011840 DECK, 28"
13A E012356 BUMPER GUARD, 52" (FOR 21" DECK)
13B E012391 BUMPER GUARD, 63" (FOR 24" DECK)
13C E012296 BUMPER GUARD, 76" (FOR 28" DECK)
14 E010902 BOLT, 5/16-18 x 2-1/2, GRADE 8
15 E012365 WHEEL BRACKET, ADJUSTABLE
16 E010141 NUT, JAM, 5/16"
17 E012284 FRONT END HOUSING, COMPLETE
18 E010459 BELT TENSIONER
20 E012285 WHEEL, 6", WITH BUSHING
21 E012368 NUT, JAM, 3/8-16
22 E012367 WASHER, FLAT, 5/16"
23 E012283 CASTER, SWIVEL WITH POST (PREDATOR MODEL ONLY)
24 E010135 WASHER, FLAT, 3/8"
(
PREDATOR MODEL ONLY
)
25 E012470 NUT, LOCK, 3/8"
(
PREDATOR MODEL ONLY
)
26 E010462 CASTER, SWIVEL, PLATE MOUNT
27 E010710 SCREW, FLAT HD SOCKET, 5/16-18 x 1
28 E012444 WASHER, FLAT, SAE, 5/16"
29 E010199 NUT, ELASTIC JAM, 5/16-18
BETCO, CORP. 7/26/07 Page 15 PROPANE BURNISHER

BETCO, CORP. 7/26/07 Page 16 PROPANE BURNISHER

HANDLE PARTS FOR HONDA
ITEM NO. PART NO. DESCRIPTION
1 E012390 HAND GRIP (24") (NOT ON PREDATOR)
2A E010861 UPPER HANDLE, HONDA 110V START
3 E012406 BOLT, 1/2-13 x 1.75
4 E010723 WASHER, LOCK, 1/2
5 E012407 WASHER, FLAT, SAE, 1/2
6A E012281 THROTTLE CABLE, HONDA, 38"
7 E010724 NUT, LOCK, 1/4-20
8 E012408 WASHER, LOCK, STAR, 1/2
9 E010266 SCREW, 10-32 x 1.75 PPHMS
10 E012410 NUT, LOCK, 1/2-13
11 E010725 BOLT, 1/4-20 x 1.75
12A E012293 LOWER HANDLE, HONDA 110V START
13 E012294 LATCH SCREW
14 E010726 FELT, 24"
15 E010727 FELT, 13"
16 E012366 WASHER, FLAT, 5/16"
17 E012445 NUT, LOCK, 5/16"
18 E010112 BOLT, 5/16-18 x 1.25
19 E010120 NUT, LOCK, 10-32
20 E012290 KEY FOR KEY SWITCH
21 E012291 SWITCH, KEY SWITCH
22 E010768 KEY SWITCH BOX AND COVER
23 E012466 RIVET, AAP54
24 E010724 NUT, LOCK, 1/4-20
BETCO, CORP. 7/26/07 Page 17 PROPANE BURNISHER

FLEX-LOC PAD DRIVER ASSEMBLY
8
1B
2
5
7
3
4
1A
6
1C
ITEM NO. PART NO. QTY. DESCRIPTION
1 E010250 1 FLEX-LOC 21
1B E010250 FLEX-LOC 24
1C E010251 FLEX-LOC 28
2 E010586 1 SHAFT TO PAD DRIVER COUPLING
3 E012517 1 CENTER-LOC 2 (COMES AS A SET 1 OF 2)
4 E012517 1 CENTER-LOC 2 (COMES AS A SET 2 OF 2)
5 E012247 6 BOLT, HEX, 5/16-18 x 1.25
6 E011505 6 WASHER, LOCK, 5/16
7 E011176 6 NUT, NYLOC, 5/16-18
8 E010118 3 RIVET, AAP64
COMPLETE PAD DRIVER ASSEMBLED (ALL PARTS SHOWN)
BURNISHER SIZE PART DESCRIPTION PART NUMBER
21” 21” FLEX LOK COMPLETE ASSEMBLY PE50028
24” 21” FLEX LOK COMPLETE ASSEMBLY PE50027
28” 21” FLEX LOK COMPLETE ASSEMBLY PE50039
BETCO, CORP. 7/26/07 Page 18 PROPANE BURNISHER

THE BOTTOM OF THE CLUTCH.
UNTIL THEY ARE ALMOST EVEN WITH
4
3
THE LARGER WASHERS ARE PUT ON
2
7
THE INSIDE OF THE CLUTCH IS
6
5
CENTRIFUGAL CLUTCH OPTION
FILLED WITH 7/16 FLAT WASHERS
1
FROM MACHINE TO MACHINE.
THE KEY IS INSTALLED
AND THE CLUTCH IS
PUSHED ON THE SHAFT.
THE ENGINE SHAFT SO THE CLUTCH
IS PARALLEL TO THE TENSIONER AND
PULLEY. THIS CAN VARY A LITTLE
THE LARGER WASHER,
FLAT WASHER, LOCK
WASHER, AND BOLT ARE
INSTALLED TO SECURE
THE CLUTCH.
5
ITEM NO. PART NO. QTY. DESCRIPTION
1 E012427 15 WASHER, BUSHING, 1" ID x 14 GA
2 E012409 1 WASHER, LOCK, 7/16
3 E010598 1 BOLT, HEX HEAD, 7/16-20 x 1.75 UNF GR5
4 E011289 1 KEY 1/4 x 1/4
5 E012447 13 WASHER, FLAT, 7/16 SAE 68
6 E012434 1 CLUTCH, CENTRIFUGAL
7 E011501 1 WASHER, FLAT, 7/16 USS
BETCO, CORP. 7/26/07 Page 19 PROPANE BURNISHER

FUEL SYSTEM
HONDA STANDARD MODEL
10
4
3
2
1
6
7
12
8
7
3
9
11
12
12
13
5
ITEM NO. PART NO. QTY. DESCRIPTION
1 E010746 1 FUEL REGULATOR MODEL T60-F-N
2 E010741 1 FUEL LOCK OFF, MODEL VFF30-2-4
3 E012359 2 STANDARD FUEL HOSE
4 E010751 1 TANK COUPLING, 7141F
5 E010082 1 UNION, HALF UNION, .375 x.25
6 E010083 1 ELBOW, STREET ELBOW, 0.125
7 E010077 2 HOSE BARB, 1/8 x 1/8
8 * 1 FITTING COMES WITH REGULATOR
9 E010081 1 HOSE BARB, BRASS, 90, .375 x .375
10 E010074 1 FUEL HOSE, 6 LOLA, 1.67 FT.
11 E010119 1 FITTING, PLASTIC, VACUUM TEE
12 E010752 3 VACUUM HOSE
13 E010084 1 ELBOW, BRASS, .375 x .25
BETCO, CORP. 7/26/07 Page 20 PROPANE BURNISHER
