Target: Terror / Target: Force • Copyright 2005 • Raw Thrills Inc • All rights reserved.
1
TARGET: TERROR GOLDTM
TARGET: FORCE GOLDTM
CONVERS ION
KIT MANUAL

April 2005
Target: Terror / Target: Force • Copyright 2005 • Raw Thrills Inc • All rights reserved.
2
Target: Terror Gold
Target: Force Gold
TM
TM
For Parts or Service contact your local Distributor or:
Betson Enterprises
303 Paterson Plank Road
Carlstadt, New Jersey
Main Phone: [phone]
Toll Free Phone: [phone]
Part Phone: [phone]
CAUTION:
•The specifications of this product are subject to change without notice for reasons such
as performance.
•The content of this game, its main devices and design are protected under each federal
law concerning patent, copyright and other intellectual properties.
•Unauthorized reproduction of this document or any of its contents is strictly forbidden.

April 2005
Target: Terror / Target: Force • Copyright 2005 • Raw Thrills Inc • All rights reserved.
3
Safety Instructions
Safety instructions apply to operators and service personnel. Read these instructions before preparing the
video game video game conversion. Other safety instructions appear throughout this manual.
WARNING: TRANSPORTING THE VIDEO GAME MACHINE (VGM).
The VGM contains glass and fragile electronic devices. Use appropriate care when transporting . Avoid rough
handling when moving the VGM.
WARNING: DISCONNECT POWER.
Always turn the power OFF and unplug the VGM before attempting service or adjustments unless otherwise
instructed. Installing or repairing components with the power switched ON can damage the components and
void warranty.
WARNING: GROUND GAMES.
Avoid electrical shock! Do not plug in the VGM until you have inspected and properly grounded it. Only plug
into a grounded, three-wire outlet. Do not use a “cheater” plug, or cut off the ground pin on the line cord.
WARNING: AVOID ELECTRICAL SHOCKS.
This VGM does not utilize an isolation transformer. Internal cabinet AC is not isolated from the external AC
line.
WARNING: HANDLE FLOURESCENT TUBE AND CRT WITH CARE.
If you drop a fluorescent tube or CRT and it breaks, it will implode! Shattered glass can fly eight feet or more
from the implosion.
WARNING: CHECK POWER SELECTOR, LAMP.
Set the 115/230 VAC selector switch on the power supply for the correct line voltage on the installation site.
Verify that the lamps are also rated for the proper line voltage.
WARNING: USE PROPER FUSE.
Avoid electrical shock! Replacement fuses must be identically rated to the original fuse!
WARNING: ATTACH CONNECTORS PROPERLY.
Be sure all connectors mate properly. If connectors do not slip in easily, do not force them. Connectors are
often keyed and only connect one way. Check for correct orientation.
WARNING: USE EXTREME CARE WHEN HANDLING PC.
The PC contains sensitive components such as a hard drive. Do not handle roughly. Call your distributor
before servicing PC internal components. Ask about warranty information as it relates to the PC.

April 2005
Target: Terror / Target: Force • Copyright 2005 • Raw Thrills Inc • All rights reserved.
4
TABLE OF CONTENTS:
SECTION 1: INTRODUCTION
SECTION 2: INSTALLATION PROCEDURE
SECTION 3 : GAME TEST AND OPTIONS MENU
SECTION 4: TROUBLESHOOTING GUIDE
SECTION 5: PARTS
APPENDIX A: HARD DRIVE RECOVERY
APPENDIX B: BIOS SETTINGS
APPENDIX C: BASIC DISPLAY ADJUSTMENTS
APPENDIX D: VIOLENCE LEVEL SETTINGS
APPENDIX E: JAMMA PINOUT

April 2005
Target: Terror / Target: Force • Copyright 2005 • Raw Thrills Inc • All rights reserved.
5
SECTION 1: INTRODUCTION
Please read this manual carefully before you begin the installation process. Verify that the
cabinet to be used for conversion is fully functional. This kit conversion requires some
familiarity with AC voltage and safety around electronic devices. If at any point you are
uncertain as to how to proceed during this conversion, STOP and call Betson Enterprises
at 1-800-524-2343.
Please refer to the basic conversion cabinet checklist below before you continue.
1. Cabinet is structurally sound.
2. Inside cabinet is free of loose debris and exposed wiring.
3. Game currently installed is fully functional. Check to make sure that:
•Player 1 and 2 Start Buttons working.
•Coin 1 and 2 switches are working.
•Coin meter is working.
•Coin door lamp is correct voltage type and working.
•Picture is adjusted for proper linearity, brightness, contrast and color
•5 and 12 JAMMA Voltages are set correctly. They should read between 4.9 –
5.1VDC and 11.8 – 12.2VDC, respectively at the JAMMA connector while
connected to the old game CPU.
•Sound from cabinet speakers is present.
Please correct any problems found before you continue. This will help to ensure an easy
and successful Conversion Kit installation.
Kit Contents:
Please make sure that you have all the following items from your kit. If you are missing any
of these items, STOP and call Betson Enterprises at 1-800-524-2343.
1. Kit Chassis Bracket
2. Manual
3. Restore DVD
4. Hardware Kit Set
5. “Target: Terror” Marquee Graphics
6. “Target: Force” Marquee Graphics
7. Left Side Cabinet Decal
8. Right Side Cabinet Decal
9. Control Panel Overlay
10. Red Gun
11. Blue Gun
12. Holsters (Qty 2)
13. Hard Drive

April 2005
Target: Terror / Target: Force • Copyright 2005 • Raw Thrills Inc • All rights reserved.
6
SECTION 2: INSTALLATION PROCEDURE
1. Unplug the game and move it to a safe work area.
2. Remove the following items from the cabinet
•game logic PCB
•marquee graphic insert
•control panel if converting from a game other than a gun game
Note: Leave the existing power supply, JAMMA harness and all associated game wiring
harness in the cabinet. Modifications to the control panel may be required if converting from
a non-gun game.
3. Determine mounting location and orientation of the kit chassis into the cabinet. When
doing so, take into consideration the orientation of the game JAMMA connector and
harness relative to the mounting position of the kit chassis for best fit. Routing of the
game harness may need to be modified but should be minimal.
4. Use the wood screws provided to mount the chassis. The pictures below illustrate how
the kit chassis might be mounted on an Area51, Lethal Enforcers and Gauntlet Legends
dedicated game cabinet.
Area 51 Cabinet Conversion

April 2005
Target: Terror / Target: Force • Copyright 2005 • Raw Thrills Inc • All rights reserved.
7
Lethal Enforcers Cabinet Conversion
Gauntlet Legends Cabinet Conversion

April 2005
Target: Terror / Target: Force • Copyright 2005 • Raw Thrills Inc • All rights reserved.
8
Making the Electrical Connections
NOTE: Make sure the game is unplugged and with the game power switch to the OFF
position before you begin. Please refer to Fig. A “Kit Chassis Block Diagram” for
connector locations.
AC Service to Power Supply
1. Locate the AC line cord and the terminal block provided with the kit.
2. Use the terminal block as a means of connecting the stripped end of the line cord to the
game AC line. Do not bypass the game cabinet main fuse and main power switch when
making the AC connection!
3. Connect the IEC plug end of the line cord to the uATX power supply on the kit.
4. Double-check your AC connections before you proceed.
Hard Drive Installation
1. Locate the hard drive and the mounting screws from the hardware bag.
2. Mount the hard drive to the kit mounting bracket using the supplied thumbscrews.
3. Connect the ribbon cable from the motherboard to the hard drive.
4. Connect power to hard drive from the uATX power supply.
Watchdog Harness Connection
Note: The game will not be playable unless the Watchdog Harness is connected and
enabled. For stable game operation this procedure must be done correctly. The Watchdog
mechanism allows the game to automatically recover in case a problem is encountered.
Refer to Appendix E for JAMMA pin locations.
1. Locate two JAMMA pin terminated wires originating from the Watchdog Harness on the
kit chassis (Violet and Black).
2. Connect the Violet wire to pin A9 (Coin Lockout 1) on the JAMMA connector.
3. Connect the Black wire to any available ground pin on JAMMA connector at location A1,
A2, B1, B2, A27, A28, B27, B28.
4. Double-check your connection before you proceed. The game will test for this
connection the first time it boots up, and will issue an error message if it fails.
JAMMA Edge Connector
Note: JAMMA Connector should be secured with a strain relief or its harness secured by a cable
clamp close to the JAMMA connector to prevent loose connections. Take care that JAMMA
connector oriented correctly, just in case the polarizing key is missing!
Gun JAMMA I/O Input Connection

April 2005
Target: Terror / Target: Force • Copyright 2005 • Raw Thrills Inc • All rights reserved.
9
1. Connect the Player 1/Red Gun connector to JAMMA I/O board at connector labeled
“Player 1 Gun”.
2. Connect the Player 2/Blue Gun connector to JAMMA I/O board at connector labeled
“Player 2 Gun”.
3. Double-check your connections before you proceed.
Set DIP Settings for Correct Display Resolution
Note: Game display output resolution is determined by two DIP switch settings on the
JAMMA I/O board. The Kit supports VGA, Medium (EGA) and Standard (CGA) resolutions.
Sync polarity is also determined by two DIP switch settings. Do not use objects that could
damage the DIPswitches such as sharp metal objects.
1. Locate the DIP switch on the JAMMA I/O board.
2. Set DIPSW1, DIPSW2, and DIPSW3 according to the chart in Figure A (next page)
3. Set the initial sync polarity settings (these may need to be altered later)
a. For a VGA monitor, leave both HSYNC and VSYNC in the OFF position.
b. If using CGA or EGA, set both HSYNC and VSYNC to the ON position.
4. Compare your settings to the chart for accuracy.
Fully Assembled Kit Chassis

April 2005
Target: Terror / Target: Force • Copyright 2005 • Raw Thrills Inc • All rights reserved.
10
PC uATX 270W
POWER SUPPLY
Audio
JAMMA I/O
Board
DIP SWITCH GunInputs
HARD DRIVE
Nforce Motherboard (Biostar)
AMD SEMPRON 2500
256MB RAMPC3200
Dongle Audio
VGA USB
USB USB VGA
RESET PCB
(WATCHDOG HARNESS)
Motherboard Power
P
1
P
2
J
A
M
M
A
E
D
G
E
Main JAMMA
Harness
AC Power
& Power Switch
Note 1: Connect Purple Wire
From Reset PCBto Pin A9of
JAMMA Connector
Note 2: Connect Black Wire
From Reset PCBto Ground pin
of JAMMA Connector
**See Notes 1,2 for
JAMMA
Connection
HARD DRIVE POWER
Connect to
Red/”Reset”
Connector
FIGURE A: Kit Chassis Block Diagram
PC Reset Signal
IDE1
IDE2
JAMMA I/O DIP SWITCH SETTING:
8 Watchdog Defeat (Important: Always set to OFF for normal operation)
7 OFF
6 OFF
5 VSYNC POLARITY
4 HSYNC POLARITY
3 DIPSW3 (see below)
2 DIPSW2 “
1 DIPSW1 “
DIPSW1 DIPSW2 DIPSW3 DISPLAY RESOLUTION
OFF OFF OFF VGA (640x480)
ON OFF OFF MEDRes (EGA 400x256)
ON ON ON STDRes (CGA 320x240)

April 2005
Target: Terror / Target: Force • Copyright 2005 • Raw Thrills Inc • All rights reserved.
11
Power Up and Startup Sequence
1. Double check all your connections before turning the game on.
2. Turn the game ON.
3. The start up sequence is as follows:
NOTE: All video output is VGA during this sequence. Your monitor may display a
scrambled image, no image, or “NO SIGNAL” if it is CGA or EGA)
a. BIOS screen appears.
b. Boot splash screen “Loading Please Wait” approx. 30 sec.
c. Error Message Screen if any error present. Refer to troubleshooting
guide to message definition and fix.
4. Display blanks out for approximately 30 seconds as resolution is being detected and
setup. Monitor may display “No Signal” message.
5. Black/Gray screen with X at the center appears briefly.
6. “Loading Please Wait” with version information and build date appears for 45 seconds.
NOTE: At this time the image should be visible on the monitor if the DIPswitch
settings are correct.
7. Either the game’s attract mode or the Hard Drive CRC check will come up. The CRC
check takes approximately 2.5 minutes. The game then tests the watchdog connection
and reboots.
NOTE: If the video image is scrambled, scrolling, or absent after four minutes, try
different combinations of the VSYNC and HSYNC DIPswitch settings.
Calibration and Functional Test
Note: If the game has a slide or toggle switch for the Test Button, activate switch and return
to OFF position. The game may exit the Test Menu if the Test Button is active or left on the
ON position for more that 3 seconds.
1. Perform gun calibration. Please refer to Section 3.5 of this manual.
2. Perform Switch Test. Please refer to Section 3.4 of this manual.
SECTION 3: TEST AND OPTIONS MENU
Press the TEST button to access the Test Menu.
Menu Navigation:
Button Action
Service, Left Start Button Cycle Through Menu/Options
Test, Right Start Button Enter Item

April 2005
Target: Terror / Target: Force • Copyright 2005 • Raw Thrills Inc • All rights reserved.
12
The gun can also be used to perform the above functions. Shoot the menu item to Select
and shoot twice to Enter. The selected item is highlighted.
SECTION 3.1: MAIN MENU
The Main Menu appears when the TEST button is pressed.
SECTION 3.2: GAME SETTINGS
From the Main Menu, select Game Settings and Enter to view options.
Default Settings Default Settings
NORMAL NORMAL JUSTICE JUSTICE
DIFFICULTY 1(Easiest)-10(Hardest) Easier(4) 1(Easiest)-10(Hardest) Medium(5)
INITIAL LIFE 1-6 HITS 5 HITS 1-6 HITS 5 HITS
MAXIMUM LIFE 1-6 HITS 6 HITS 1-6 HITS 6 HITS

April 2005
Target: Terror / Target: Force • Copyright 2005 • Raw Thrills Inc • All rights reserved.
13
SECTION 3.2.1: MORE OPTIONS
From the Game Settings menu, select More Options and enter to view more options.
Return to Game Settings by selecting Previous Options.
Default Settings
GAMEPLAY DURING ATTRACT Disabled- Enabled Enabled
VIOLENCE LEVEL Red Label(1-5), Yellow Label Red Label LV5
HIGH SCORE NAME LENGTH 3-6 Characters 6 Characters
GAME TITLE
Target: Terror
Target: Force Target: Terror
SECTION 3.3: PRICING OPTIONS
Select Pricing Options from the Main Menu and enter to view options.

April 2005
Target: Terror / Target: Force • Copyright 2005 • Raw Thrills Inc • All rights reserved.
14
Default Settings
FREE PLAY OFF-ON OFF
MONETARY UNIT Select Currency Dollars
ONE UNIT EQUALS Select Unit 0.25$
REGULAR START 1-10 UNITS 2 UNITS (0.50$)
REG. CONTINUE 1-10 UNITS 2 UNITS (0.50$)
JUSTICE START 1-10 UNITS 2 UNITS (0.50$)
JUSTICE CONTINUE 1-10 UNITS 2 UNITS (0.50$)
MAX CREDITS 10-200 50 Credits (100 UNITS)
SECTION 3.3.1: CHUTE SETUP AND BONUS UNITS
From the Pricing Options menu, select and enter Chute Setup and Bonus Units to view
options. Select Exit twice to return to the Main Menu.
Customize individual chute
and bill validator values
independently. Select from
1-10 units.
Reward volume purchase by
setting bonus to purchase
ratio.
SECTION 3.4: SWITCH TEST
From the Main Menu select and enter Switch Test. Verify proper switch input function
using this menu. Each switch activated will be indicated on the test screen in yellow text
and will be accompanied by a switch active sound indicator.
Press and hold the Test Button for three seconds to return to the Main Menu.

April 2005
Target: Terror / Target: Force • Copyright 2005 • Raw Thrills Inc • All rights reserved.
15
SECTION 3.5: GUN CALIBRATION
From the Main Menu, select and enter Gun Calibration. Follow the instructions as they
appear on the screen. Press Left Start or Service to accept the calibration. If gun
calibration is unsuccessful, the game automatically returns to the calibration screen. If
successful, a verification screen will appear. Move the cross hairs about the screen to verify
proper gun calibration.
NOTE: If the screen flashes when shooting the screen but the “Shoot Gun X Here”
sequence does not advance, try switching both the HSYNC and VSYNC DIPswitches
to their opposite positions. This can be done while in the Gun Calibration screen.
SECTION 3.6: WATCHDOG TEST
From the Main Menu, select and enter Watchdog Test. The test will begin automatically
and will reset the CPU if successful. An error message will appear if the test fails.

April 2005
Target: Terror / Target: Force • Copyright 2005 • Raw Thrills Inc • All rights reserved.
16
SECTION 3.7: COIN METER TEST
From the Main Menu,select and enter Coin Meter Test. Press the Service button to
advance the mechanical coin meter. Press Test or Start to return to the Main Menu.
SECTION 3.8: AUDIO/VIDEO OPTIONS
From the Main Menu, select and enter Audio/Video Options. Select Increase or
Decrease to change volume setting.

April 2005
Target: Terror / Target: Force • Copyright 2005 • Raw Thrills Inc • All rights reserved.
17
SECTION 3.8.1: COLOR BARS AND PURITY
From the Audio/Video Options menu, select and enter Color Bars & Purity. Verify
correct color and purity for Red, Blue and Green screens.
SECTION 3.8.2: CONVERGENCE TEST
From the Audio/Video Options menu, select and enter Convergence Test. Verify proper
screen contrast and size.

April 2005
Target: Terror / Target: Force • Copyright 2005 • Raw Thrills Inc • All rights reserved.
18
SECTION 3.9: VIEW AUDITS
From the Main Menu, select and enter View Audits. Press Service Left Start or Service
to cycle through Audits Page 1 to 5.
Audit Page 1:
Audit Page 2:

April 2005
Target: Terror / Target: Force • Copyright 2005 • Raw Thrills Inc • All rights reserved.
19
Audit Page 3:
Audit Page 4:
Audit Page 5:

April 2005
Target: Terror / Target: Force • Copyright 2005 • Raw Thrills Inc • All rights reserved.
20
SECTION 3.10 OTHER OPTIONS
From the Main Menu, select and enter Other Options.
OPTION DESCRIPTION
Clear High Score Clear high score tables
Auto HS Clear Adjust number of games before high
score tables get cleared
Clear Credit Zero any existing game credits
Clear Audits Zero all game play statistics
Restore Default Settings Resets game & pricing settings, high
score tables, gun calibration, audits
Perform Disk Integrity Check Performs hard drive test
Factory Restore **See notes below
Autopilot Auto Game Play / Burn-In Test
**Factory Restore: This option will clear all credit, audit, calibration and game settings
information. The game hard drive will be in the state that it was shipped from the factory.
After reset, the game will commence with the process described in the START UP
SEQUENCE section of the manual.
SECTION 4: TROUBLESHOOTING GUIDE
PROBLEM POSSIBLE CAUSE SOLUTION
Game will not power
up. Game not plugged in. Plug game into receptacle.
Game not turned on. Turn ON main power switch.
Game fuse is blown. Check game fuse.
No power to receptacle. Plug game into powered receptacle.
PC power switch is OFF. Turn PC power switch ON.
PC BIOS set incorrectly. See Appendix B.
“No Signal” Message Video cable not secure. Check and secure video connector.
PC not turned ON. Turn ON power to PC.
