Barron Games X-Putt Manual

operator guide
Version XP0.1 Page 1
© World Golf Systems ltd
IT IS THE RESPONSIBILITY OF THE OPERATOR TO MAINTAIN CUSTOMER SAFETY AT ALL TIMES, AND IT IS IMPERATIVE THAT
THE DETAILS SET OUT IN THIS MANUAL AND ANY OTHER MANUAL SUPPLIED WITH THIS MACHINE SHOULD BE FOLLOWED
PRECISELY AND ADHERED TO AT ALL TIMES
Operator Guide
Please Note Barron Games X-Putt Models Cannot Be Used For Money Prizes, Only Free Play
or Ticket Redemption. Please disregard all information in this manual pertaining to Cash Prizes

operator guide
Version XP0.1 Page 4
© World Golf Systems ltd
Playing the Game ....................................................................................................................6!
Putt for Cash..............................................................................................................................................................7!
Putt for Fun ...............................................................................................................................................................7!
Putt for Cash: The Game Challenge and Leader boards.................................................................................................9!
Gaming Screen Explanation.......................................................................................................................................10!
Game Scoring Bar ....................................................................................................................................................11!
Full Game Rules .......................................................................................................................................................12!
Operator Mode ......................................................................................................................13!
Calibration of the Touch screen.................................................................................................................................13!
Cashing up Process - Summary................................................................................................................................14!
Cashing Up Process - Detailed...................................................................................................................................15!
Edit the Leader board...............................................................................................................................................19!
Set Volume..............................................................................................................................................................20!
Test Menu..............................................................................................................................21!
Test Coin Mechanism................................................................................................................................................21!
Test Note Mechanism ...............................................................................................................................................21!
Test Hopper.............................................................................................................................................................21!
Test Holes ...............................................................................................................................................................22!
Test Lights...............................................................................................................................................................22!
Test Ball in Play Sensors...........................................................................................................................................23!
Options ...................................................................................................................................................................24!
Editing Options ........................................................................................................................................................25!
Regular Operational Maintenance .............................................................................................................................26!
Cleaning:.................................................................................................................................................................26!
Troubleshooting ....................................................................................................................27!
Support..................................................................................................................................28!

operator guide
the game
Version XP0.1 Page 6
manufactured under licence in the UK by Active Design Automatics ™
Playing the Game
Putt for Fun or Putt for Cash
1. Touch screen to activate game selection
2. Insert Coins to play game
£1 for Putt for Fun or £2 for Putt for Cash
3. The game selection screen will now be
activated (based on amount of money
previously entered). Press the button to start
the game.
In the above example Putt for Fun has been
selected

operator guide
the game
Version XP0.1 Page 7
World Golf Systems Ltd
Putt for Cash
Putt for Fun
•The Putt for Fun gaming screens are essentially the same in design however rather than play for cash the objective is to accumulate the highest score. All
references to cash and monetary amounts are also removed from the game screens
Play your first shot, the hole to hit will be
illuminated (e.g. No 1 above). The number of
points which will be awarded if successful will be
displayed
Each game has 10 shots with a maximum timing
of 20 seconds per shot, with the exception of the
10th ball which can be replayed until a hole is hit
If the putt is successful the amount of points
awarded will be displayed at the top of the
screen
If the ball misses all holes and returns to be
player, it becomes the next shot and a new hole
will be illuminated
Based on the amount of points scored the
amount of cash available to win will be displayed
as ‘winnings’
According to points scored and accuracy of
putting, the ‘bonus hole pot’ will also accumulate
for the opportunity to win with the 10th ball

operator guide
the game
Version XP0.1 Page 8
World Golf Systems Ltd

operator guide
the game
Version XP0.1 Page 9
World Golf Systems Ltd
Putt for Cash: The Game Challenge and Leader boards
At the end of the game The X-Putt Challenge
gives the player the opportunity to collect or play
on to increase their winnings (up to a maximum
of £50)
The X-Putt Challenge screen is only available
when you have winnings banked in the game
Note – The X-Putt Challenge is not available on
the Play for Fun game
If amongst the highest 10 scores, the players will
then be given the opportunity to enter their
initials (up to 3 characters) for their score and
initials to appear on the leader board
Note – the leader board will be automatically
reset on the first of every month

operator guide
the game
Version XP0.1 Page 10
World Golf Systems Ltd
Gaming Screen Explanation
Total score
achieved so far
Remaining time
left to play the
shot (max 20secs)
Number of balls
left to play
Instant cash win of £1 if the
indicated hole (e.g. hole 7) is hit
Total amount of
winnings achieved
so far
Next hole to play for
e.g. hole 7
The Bonus Hole cash pot. This amount
(e.g. £4) will be won if shot 10 is
successful (bonus hole shot)
Number points that can be achieved
if the shot is successful e.g. 1400
points if hole 7 is hit
The scoring bar indicates what the score will be if the next
shot is successful (current score + potential score = total)

operator guide
the game
Version XP0.1 Page 11
World Golf Systems Ltd
Game Scoring Bar
The scoring bar is touch sensitive and can be moved
to the left and right. By moving the bar to the right
the player is able to view the next ‘Cash Win’ position
In the above example the player will win £1 once
they reach 5000 points
They are also able to view the various Bonus Hole
Pot cash positions. Once the player reaches this
position the cash amount displayed will be added to
the Bonus Hole Pot, this amount can then be won on
the 10th shot

operator guide
the game
Version XP0.1 Page 12
World Golf Systems Ltd
Full Game Rules

operator guide
operator mode
Version XP0.1
Page 13
World Golf Systems Ltd
Operator Mode
•To gain access to the Operator Mode push the ‘Operators button’ (located inside the bay pod, please refer to photo)
•The operator screen will be displayed. There are six options, View Counters, Dump Hopper, Edit Leader board,
Setup Volume, Test Menu and Options
•View Counters – Used as part of the cashing up process, this function provides the Net Takings that the unit has
taken since installation. This function will also provide information on the amounts players have gambled and lost and
the total prize fund paid out
•Dump Hopper – This function is also used as part of the cashing up process in order to dump the contents of the
hopper to determine the amount taken and to check the current float total
•Edit Leader board – To be used to remove “unsuitable” initials from public view or game scores that have been
accumulated but not in accordance with the game rules
•Set Volume - This function is used to change the audio settings e.g. turn the volume up, down or totally mute the
sound
•Test Menu – Used as a test facility to check the coin mechanism, coin hopper, game holes, game lights and ball in
play sensors
•Options – Used to change the configuration of the game unit
Calibration of the Touch screen:
•The calibration of the screen can be carried out by holding down the Operator button for three seconds
•Follow the instructions on the screen
Open the game pod door, the
operator switch is located next
to the coin hopper

operator guide
cashing up
Version XP0.1
Page 14
World Golf Systems Ltd
Cashing up Process - Summary:
`
Push Operator button to
access Operator Mode
Select View Counters
Note down Net Takings
Amount
Return to Operator
screen
Select Dump Hopper,
ensure payout area is
empty
Select Start to begin
emptying the hopper
Hopper runs out of coins
before it has counted the
full value of the float
Hopper dispenses full
float amount
Add extra coins to the
hopper to bring up the
float to the correct value
Place the £140 float back
into the hopper
Any extra coins should be
added to the cashbox
Remove the coins from
the cashbox and notes
from Note reader
Hopper dispenses full
float amount
Cashup complete

operator guide
cashing up
Version XP0.1
Page 15
World Golf Systems Ltd
Cashing Up Process - Detailed
•Open the Bay Pod door and push the Operator Switch, the Operators screen will now be displayed
•Step 1: From the Operators screen select View Counters
•The View Counters screen will now be displayed:
•Note down the Net Takings figure then press the Back button to return Operator Mode screen

operator guide
cashing up
Version XP0.1
Page 16
World Golf Systems Ltd
•Step 2: The next step is to Dump the contents of the hopper
•Select the Dump Hopper button
•The Dump Hopper screen will be displayed. Select the Start button to start emptying the hopper
Please Note – Ensure the payout area is empty before starting the dump process
•The hopper will stop dispensing once it reaches £140 (total float amount), or when it runs out of coins

operator guide
cashing up
Version XP0.1
Page 17
World Golf Systems Ltd
•The unit will now count how many coins have been dispensed into the payout area
•If the unit runs out of coins before it has dispensed the full float amount (normally £140) the following message will be
displayed (see screen below):
•If the message appears then the number of required coins should be removed from the cashbox and placed back
into the hopper. In the above example six pound coins should be taken out of the cashbox and placed into the
hopper
•Select the Continue button, the hopper should now count out the remaining required coins
Amount
dispensed
Amount still to
be dispensed

operator guide
cashing up
Version XP0.1
Page 18
World Golf Systems Ltd
•Once the float (£140) has been dispensed remove it from the payout area. Select the Continue button
•The hopper will now attempt to dump any remaining coins left until it is empty. If any additional coins are dispensed
then the following screen and message will be displayed. These coins should be added to the cash box
•Select the Back button to return to the Operator Mode
•Place the float back into the hopper, remove the coins from the cashbox and any notes from the note reader, the
cashing up procedure has now been completed

operator guide
leaderboards
Version XP0.1
Page 19
World Golf Systems Ltd
Edit the Leader board
•Select the Leader board to remove the initials from e.g. Putt for Fun or Putt for Cash (if available)
•Select the option 'Delete' against the initials to remove
•The initials will now be removed from the selected Leader board
•Select Back to return to the Operator menu
Select Leader
board
Select initials to
delete

operator guide
volume control
Version XP0.1
Page 20
World Golf Systems Ltd
Set Volume
•From the Operator menu select the Volume button
•This function is used to change the audio settings e.g. turn the volume up or down or totally mute the sound.
10 % = lowest sound level
Max = highest sound level
•The sound level may be tested by selecting a volume level followed by one of the preset music buttons at the top of
the screen

operator guide
test menu
Version XP0.1
Page 21
World Golf Systems Ltd
Test Menu
•From the Operator menu select the Test button
Test Coin Mechanism
•This function is used to test that the coin mechanism is operating correctly
•Insert one of every coin denomination that the unit accepts. If the coin is successfully read it will be displayed within
the appropriate graphic
•If a coin is not read try once again, if it is still not reading touch the appropriate graphic to record the failure
Test Note Mechanism
•This function is used to test that the note reader mechanism is operating correctly
•Insert one of each of the applicable notes (£5, £10 and £20 only). If successfully read it will be displayed within the
appropriate graphic
•If a note is not read try once again, if it is still not reading touch the appropriate graphic to record the failure
Test Hopper
•This function is used to test that the hopper mechanism is operating correctly
•Insert a number of pound coins e.g. five, the coins will be counted on the screen
•Select the Dispense button to check that the unit will dispense the same number of coins back

operator guide
test menu
Version XP0.1
Page 22
World Golf Systems Ltd
Test Holes
•This function is used to test the functionality of the putting holes. Every time a ball is read it will be recorded
numerically within the appropriate graphic
•If a hole fails to read a ball touch the appropriate graphic to record the failure. A new ball will now be issued to test
the hole again
•If the trigger mechanism fails to issue a ball touch the Trigger graphic (bottom right) to record the failure and issue a
new ball
Test Lights
•This function is used to test the lights within the X-Putt module. If a light fails to illuminate touch the appropriate
graphic to record the failure

operator guide
test menu
Version XP0.1
Page 23
World Golf Systems Ltd
Test Ball in Play Sensors
•This function is used to test the ‘Ball in Play’ sensors at the front of the X-Putt gaming unit
•If two green lights are illuminated then both sets of sensors are aligned correctly
•If a red light is illuminated then a sensor is not aligned or the beam has been broken (to rectify please refer to the
troubleshooting section at the end of this document)
