Operation Manual
IMPORTANT

World Soccer D&B Manual
05/06/2019
1
WE ARE HERE TO ASSIST
For parts and service
Have Questions? Contact us!
UNIS SERVICE CENTER
Tel: [phone]
Email: [e-mail]
When contacting Service, you will need the following information
and the name of your authorized distributor.

World Soccer D&B Manual
05/06/2019
2
CONTENT
IMPORTANT SAFETY INSTRUCTIONS.......................................................................3
1. SPECIFICATIONS....................................................................................................5
2. CONTENTS OF THE ACCESSORY KIT................................................................... 7
3. PART NAME............................................................................................................8
4. SET UP & INSTALLATION...................................................................................... 9
5. HOW TO PLAY......................................................................................................18
6. GAME OPTION....................................................................................................20
7. TROUBLE SHOOTINGS........................................................................................ 23
8. MAINTENANCE & INSPECTION..........................................................................26
9. OVERALL CONSTRUCTION................................................................................. 30
10.WIRING DIAGRAM............................................................................................. 49

World Soccer D&B Manual
05/06/2019
3
Thank you for purchasing World Soccer. We hope you enjoy the product.
This manual contains valuable information about how to operate and maintain your game
machine properly and safely. It is intended for the owner and/or personnel in charge of
product operation. Carefully read and understand the instructions.
If you need any help during installation and setup please utilize this manual and
troubleshooting guide. If the product fails to function properly, non-technical personnel
should under no circumstance attempt to service the machine. Contact your distributor or
manufacturer for help.
Before use, please read IMPORTANT SAFETY INSTRUCTIONS.
IMPORTANT SAFETY INSTRUCTIONS
To ensure the safe usage of this product, carefully read and
understand these instructions before operating your game.
Save these instructions for future reference.
Use this product only as described in this manual. Other uses not recommended may
cause fire, electric shock or personal injury. Unplug the game from the outlet when not in
use, when moving from one location to another, and before cleaning/servicing.
Explanations which require special attention are indicated by signs of warning. Depending
on the potential hazardous degree, the terms: NOTE,NOTICE, and WARNING are used.
NOTE: A NOTE indicates useful hints or information about product usage.
NOTICE: A NOTICE indicates potential damage to product and how to avoid the problem.
WARNING: A WARNING indicates a potential for product damage or serious personal Injury.
It is important to understand the meaning of the following HAZARD SIGNS before
continuing:
High Voltage and Shock Hazard:
High voltage can cause electric shock.
Turn off/unplug power before servicing.
High Temperature Hazard:
This part may cause scalding.
Do not touch. Surface may be hot.
No Touching Hazard:
This part may be hot or can cause electric shock.
Do not touch.

World Soccer D&B Manual
05/06/2019
4
Use the following safety guidelines to help ensure your own personal safety and to help
protect your equipment and surrounding environment from potential damage.
This product is an indoor game machine. Do not install outdoors.
Avoid installing in the following places to prevent fire, electric shock, injury
and/or machine malfunctioning:
Places subject to rain/moisture, or places subject to high humidity.
Places subject to direct sunlight, or places subject to extremely hot or cold
temperatures to ensure that it is used within the specified operating range.
Places where inflammable gas may be present or in the vicinity of highly
inflammable/volatile chemicals or items that can easily catch fire.
On unstable or sloped surfaces. The machine may topple or cause unforeseen
accidents.
Vicinity of fire exits, fire extinguishers etc that may block/prevent safety measures.
IMPORTANT NOTE:
ALL REPAIRS MUST BE DONE TO ORIGINAL MANUFACTURER SPECIFICATIONS.
FAILURE TO DO SO VOID ALL WARRANTIES AND OPERATOR ASSUMES ALL
RISKS.
Note: The contents of this manual may be updated without notice.

World Soccer D&B Manual
05/06/2019
5
1. SPECIFICATIONS
Rated power supply: AC110V~ 50/60Hz; AC220V-240V~ 50/60Hz
Min. Power consumption: 330W
Max. Power consumption: 580W
Dimension: W74.75×D67.20×H103.42 in
W1898.6×D1706.9×H2626.8 mm
Weight: Approximately 767 lb
Approximately 348 kg
Part No: W119
Model No: C-545
NOTICE: After turning off the game, please wait at least 1 minute
before restarting again.
Note: Game specifications are subject to change without notice.

World Soccer D&B Manual
05/06/2019
6
Back Cabinet: W65.11×D27.60×H103.42 in
W1653.6×D701.1×H2626.8 mm
Connective part: W31.50×D18.98×H15.59 in
W800×D482.1×H396 mm
Control panel: W74.75×D30.20×H42.98 in
W1898.6×D767.1×H1091.6 mm

World Soccer D&B Manual
05/06/2019
7
2. CONTENTS OF THE ACCESSORY KIT
Open the package and make sure all the items are included:
1. Following accessories
No.
Part No.
Code
Name
Qty
1
W119-801-000
25300171002
Key
2
2
W119-411-000
21901000013
Fuse
2
3
W119-803-000
40613160031
Spanner
1
4
W119-804-000
41440000254B
Manual
1
5
W119-805-000
23301010020
Power cord
1

World Soccer D&B Manual
05/06/2019
8
3. PART NAME
Key Components
Ball assembly
Marquee assembly
Monitor
Control panel
assembly
Joystick
Top monitor
Ready for
card reader
Speaker

World Soccer D&B Manual
05/06/2019
9
Leveler
Leveler
4. SET UP & INSTALLATION
This product is an indoor game machine. Do not install outdoors.
Refer to IMPORTANT SAFETY INSTRUCTIONS (Pg. 3) for places to avoid.
Place the unit on a dry level surface.
Ventilation openings in the back of the unit must not be obstructed by objects or by
wall.
4.1 Transporting the Game
If you need to move the game, adjust the levelers back to an “up” position.
NOTICE
Be careful not to damage the machine during transport.
Always unplug the game before moving.
Keep the machine in upright position during transport.
For longer distance transport, package the game properly to prevent damages.
4.2 Level Adjustment
Install this game on a flat surface. If the game is installed on an unsuitable floor, it could
cause game malfunction.
To secure the game, loosen the nut, utilize wrench to adjust the leveler down until it
touches the floor, lifting the casters off the ground by 0.2 in. Repeat the same for all
levelers.
We do not recommend using power tools as they may cause damage.
NOTICE
Make sure the machine is level.
NOTICE

World Soccer D&B Manual
05/06/2019
10
4.3 Play Zone
This machine requires space for playing and for maintenance as shown below.
Leave space around the game upon installation:
Service area: 40 in
4.4 Remove the Packing Support plate
Please remove the packing support plates before operating the game.
Before processing the following steps, assure you have the following tools:
No.
Name
1
Phillips
screwdriver
Step 1 Remove the external packing and locate the packing support plate at the bottom.
Step 2 Utilize the Phillips screwdriver to loosen two screws on the packing support plate to
take the plates out. Same steps on the other packing support plate.
Screws
Packing
support
plate
Packing
support
plate
Service area
Play area

World Soccer D&B Manual
05/06/2019
11
4.5 Machine Installation
4.5.1 Connective Part
Before processing with assembly assure you have the following tools.
1) Utilize the Phillips screwdriver to tighten four screws to fix L Connective Box B to Box A.
2) Put the Woofer Assembly into L Connective Box B as shown.
Route the cable to L Connective Box B. (Take caution to prevent pinching the cable of the
Woofer Assembly.)
No.
Part No.
Code
Name
Qty
1
W119-349-000
20104023004
Cross recessed hexagon bolt
14
2
/
/
Phillips screwdriver
1
Box A
L Connective
Box B
L Connective
Box B
Woofer Assembly

World Soccer D&B Manual
05/06/2019
12
3) Put the R Connective Box B together and utilize the Phillips screwdriver to tighten four
screws to fix it to Box A.
Utilize the Phillips screwdriver to tighten two screws to fix the L&R Connective Box B
together.
Utilize the Phillips screwdriver to tighten four screws to fix the Woofer Assembly to L&R
Connective Box B.
R Connective
Box B
two screws on each side
Woofer
Assembly
L Connective
Box B
Box A
Woofer
Assembly

World Soccer D&B Manual
05/06/2019
13
4.5.2 Control Panel Assembly
1) Align the three sub-assemblies of the Control Panel as shown below.
No.
Part No.
Code
Name
Qty
1
W119-347-000
20104020004
Cross recessed hexagon
screw set(M6×25)
10
2
W119-345-000
20104010004
Cross recessed hexagon bolt
16
3
/
/
Phillips screwdriver
1

World Soccer D&B Manual
05/06/2019
14
2) Open the middle two back door plates.
Utilize the Phillips screwdriver to tighten five screws(M6×25) indicated on each side to fix
the three sub-assemblies together.
back door
plate
back door
plate

World Soccer D&B Manual
05/06/2019
15
3) Route the cables at the bottom of the Control Panel through L&R Connective Box B to
connect the cables to the Box A.
4) Align Control Panel and Box B and fix the metal brackets indicated by the circles on both
sides.
5) Connect the connector of the Woofer Assembly to the connector of the cables.
Woofer
Assembly
Cables from the
Control Panel
Box B
Box A

World Soccer D&B Manual
05/06/2019
16
4.5.3 Marquee Assembly
1) Raise the marquee upright by following pictures 1-4.
2) Utilize Phillips screwdriver to tighten 6 screws indicated by circles to fix the marquee.
Note: The marquee is high, please be careful when installing.
Finish!
No.
Part No.
Code
Name
Qty
1
W119-345-000
20104010004
Cross recessed hexagon
bolt
6
2
/
/
Phillips screwdriver
1

World Soccer D&B Manual
05/06/2019
17
4.6 Voltage Conversion (110V convert to 220V)
Power off the machine.
Step 1 Locate the power supply and the PC inside the back box.
Step 2 Toggle the switches from 115V to 230V on the power supply and PC.
4.7 Card Reader Installation Safety Notice
Take precaution to assure that all wring voltages are confirmed prior to installation
of card reader. All warranties are void if not properly installed resulting in logic board
damage.

World Soccer D&B Manual
05/06/2019
18
5. HOW TO PLAY
1. Tap card and press any button to start.
2. Control the joystick to move the player.
3. Kick the ball with your feet to shoot and tackle.
4. Press SWTICH PLAYERS to switch your own side available player.

World Soccer D&B Manual
05/06/2019
19
5. Press ACCELERATE to speed up the player.
6. To ensure customers’ safety, please pay attention to this Caution.
Game Rules:
1. 1-4 player(s) compose the USA team to compete with other teams.
2. Player(s) can win the champion after wining the Quarter Final, Semi-final and Final.
3. New player can join at any time when game playing.
4. Player can tap card to revive to continue playing.
