SIM Card Installation
Instructions
Version 2.0
Last Revised October 18, 2012

www.javad.com
© JAVAD GNSS Inc., 2012

7www.javad.com
SIM CARD INSTALLATION
INSTRUCTIONS
The SIM card provides communication for data transfer between two GSM-capable receivers. The SIM
card can be purchased at your local cellular phone supply store. Once installed, the card generally
remains installed.
The SIM card must support Circuit Switched Data to communicate directly between receivers. The SIM
card must have GPRS support to communicate with a GPS Network IP address.
Note: Both the Base and Rover receivers must have a SIM card installed (supporting Circuit Switched Data) and
have subscriptions to the same service provider for proper communication.
Once the receiver is turned on, the receiver board will detect the SIM card and it will be ready to use as
needed.
TRIUMPH-VS Optional SIM Cards Installation
TRIUMPH-VS is equipped with two SIM card slots, to allow using two SIM cards and switching between
two different cell providers. The SIM card can be purchased at your local cellular phone supply store.
The SIM card must have GPRS support to provide an Internet connectivity in the field, where WiFi is not
available. The SIM card must support Circuit Switched Data to establish the direct communication
between GSM-capable receivers.
Note: Before SIM card installing in TRIUMPH-VS, it is recommended to remove PIN code using your cell
phone.
1. Ensure the receiver is turned off.

SIM Card Installation Instructions
TRIUMPH-VS Optional SIM Cards Installation
8www.javad.com
2. Using both hands, gently push the battery pack upward, to remove it. Rest your thumbs against
the receiver case, with other fingers push the battery up.
Figure 1. TRIUMPH-VS battery removing
3. Open the SIM1 or SIM2 card cover.
Note: If you intend to insert only one SIM card, always insert it to the SIM1 slot.
Figure 2. SIM card slots
4. Gently insert the SIM card contacts facing up into SIM card holder until it clicks.
5. Close the cover.
6. Place the battery pack back into the receiver, make sure it is firmly established.
SIM1
SIM2

SIM Card Installation Instructions
TRIUMPH-1 Optional SIM Cards Installation
9www.javad.com
TRIUMPH-1 Optional SIM Cards Installation
First SIM Card Installation
1. Ensure the receiver is turned off.
2. Open the small SIM card door.
Figure 3. TRIUMPH-1 SIM card door
3. Push SIM card holder to OPEN.
4. Insert SIM card into SIM card holder label side up.
5. Close the holder (Figure 4).
Figure 4. Installing SIM card
6. Push the SIM card holder to LOCK to close it tightly (Figure 4).
7. Close the door and tighten screws.
1
2

SIM Card Installation Instructions
TRIUMPH-1 Optional SIM Cards Installation
10 www.javad.com
Second SIM Card Installation
1. Ensure the receiver is turned off.
2. Open the bottom of the case screwing off 4 self taping screw (Figure 5)
Figure 5. TRIUMPH-1 SIM Card installation
3. Push SIM card holder to OPEN.
4. Insert SIM card into SIM card holder, label side up, and close the holder.
Figure 6. Installing SIM card
5. Push the SIM card holder to LOCK to close it tightly (Figure 4).
6. Close the case and tighten screws.
SIM Card
1
2

SIM Card Installation Instructions
SIGMA Optional SIM Card Installation
11www.javad.com
SIGMA Optional SIM Card Installation
1. Ensure the receiver is turned off.
2. Open small SIM card door on the back side of the case screwing off 2 self taping screws.
Figure 7. SIM Card Installation
3. Carefully insert the SIM into the SIM card holder, label side down, and push it forward to lock
close it tightly.
4. Close the SIM card door.
SIM card

SIM Card Installation Instructions
ALPHA Optional SIM Card Installation
12 www.javad.com
ALPHA Optional SIM Card Installation
1. Ensure the receiver is turned off.
2. Open the front of the case screwing off 2 self taping screw (Figure 8)
Figure 8. SIM Card Installation
3. Carefully insert the SIM card into the SIM card holder, label side up, and push it forward to lock
to close it tightly.
4. Close the case and tighten screws.
SIM Card
Push

SIM Card Installation Instructions
GISmore SIM Card Installation
13www.javad.com
GISmore SIM Card Installation
1. Ensure the receiver is turned off.
2. Open the bottom of the case screwing off 9 self taping screw (Figure 9).
Figure 9. GISmore SIM Card installation
3. Carefully insert the SIM into the SIM card holder, label side down, and push it to lock to close it
tightly.
4. Close the case and carefully tighten the screws.
SIM Card
Screw
Push
