Beyond diplomat User manual

INSTRUCTION

2
Followings are the safety instructions & rules. Prior to using the safe,
please read the instructions carefully.
Cautions when placing the safe.
Place the safe on flat floor.
The safe is so heavy that it is to be handled very carefully.
Never move the safe in door open.
Cautions when using the safe.
Be careful not to close the door roughly.
As a safe is heavy and operated with a smart digital lock, we
recommend children not to touch it.
Be careful not to forget the user code, and keep the instruction
outside of the safe.
Be careful not to hurt hands or fingers when closing door.
This fire safe is for storing paper documents, not for data media.
Data media such as CDs or Diskettes are to be stored in data safes.
High value items such as cash or jewelries must be stored in certified
security safes.
FOR SAFETY

Prior to using safe,
1) Hold digital lock and turn it counter-clockwise to open.
2) Load 4pcs of AA Alkaline batteries.
(LED flickers, Bi Bi Bi sound, Melody rings 1 second)
*
Battery life span : 1year ( Average openings 3 times a day )
*
Even though batteries completely exhausted,
the registered codes and finger-prints are not erased.
1.
Batteries
Memory Button
Optional Alarm
LED Light
Digital Lock
Door Panel
Front Interior
3
BEYOND User Manual
Components
Nomenclature
Instruction
1.5V Alkaline
AA Batteries
(4pcs)
9V Battery
for Alarm
(Optional)
Override
Key
(Optional)
Drawer Shelf Shelf Clips
(4pcs)
Alarm
(Optional)
Overview
In following cases, the batteries must be replaced.
1) When touching the pad, LobAtt appears on FND.
2) The battery icon alights on the pad.

4
1) Touch Pad 2) Touch User Code 3) Touch
# 4) Open the door
(Bi sound, Pad lighted)(Bi sound)
(Factory Code 1 2 3 4)
(Melody, OPEnd on FND)
2. Open with Code
2) Enter New Code
(4 ~16 digits)
3. Set User Code
Keep door open.
1) Press M Button on door back.
(Bi sound)
3) Touch #
(Melody, good on FND)
* NOTE : If a wrong code entered, bi-ric sound and ErrOr on FND.
* Paralysis : If wrong codes entered 5 times, the lolck gets paralyzed 5 minutes.
1) No response against pad touch.
2)
Paralysis Rest Time is indicated on FND as Min-Sec.
In case of paralysis rest time 4 minutes and 29 seconds, 4_29 indicated on FND.
3) After 5 minutes, paralysis gets released.
* Scramble Numbers :
When opening a safe, scramble numbers can be put
before and/or after the real code to avoid peeps. User code should be
touched consecutively.
32 numbers are acceptable including the real code.
* NOTE : 1) Prior to closing the door, please confirm with 2. Open with Code
if the New Code registered correctly.
2) It is not recommended to enter the specific user code such as telephone number,
birthday, consecutive number, and etc. for security reasons.
(Ex) In case of user code ‘ 1 2 3 4 ’, touch ‘ xxx1234 ’, ‘ 1234xxx ’ or ‘ xxx1234xxx ’.
#
User Code
Touch Pad Open the Door
#
New Code

5
BEYOND User Manual
Keep door open.
4. Register Finger-prints
* 32 finger-prints are acceptable.
* NOTE : 1) Prior to closing the door, please confirm with 5. Open with Finger-print if the finger-print
correctly registered.
2) Worn-out finger-print can’t be entered.
Please put user’s finger
on sensor while
blue lamp flickering,
3) Touch #
5) Touch #
4) Touch User Code
6) Put Finger-print three times on sensor.
(Bi sound)
(Blue light flickers)(Melody rings, 1st , 2nd , good on FND)
2) Touch 3
(Bi sound)
1) Press M Button on door back.
(Bi sound)(Bi sound)
1) Touch Pad 2) Put Finger-print on sensor 3)
Open the door
(Bi sound, Blue light flickers)(Melody, OPEnd on FND)
5. Open with Finger-print
* NOTE : If a unregistered finger-print entered, bi-bi-bi sound and ErrOr on FND.
* Paralysis : If unregistered finger-prints entered 5 times, the lolck gets paralyzed 5 minutes.
1) No response against pad touch.
2)
Paralysis Rest Time is indicated on FND as Min-Sec.
In case of paralysis rest time 4 minutes and 29 seconds, 4_29 indicated on FND.
3) After 5 minutes, paralysis gets released.
User Code
Touch Pad Finger - print Open the Door
#
#
3
Finger - print 3 times

6
LED turns on 15 seconds.
When touch Pad , LED turns on 15 seconds again.
Close the door. Door locks automatically.
*
If door is unlocked when closed the door, Error sign on FND
and sounding Bi Bi Bi Bi.
Keep door open.
7.
Locking
8.
LED Light
6. Delete Finger-prints
*
If one finger-print is removed, all the registered finger-prints are erased simultaneously.
(
CLOSEd on FND)
1) Press M Button on door back.
(Bi sound)
4) Touch # . 3) Touch 3
(Melody, CLEAr on FND)
2) Touch #
(Bi sound)
Touch Pad
Close the Door
# #3

7
BEYOND User Manual
ㆍTwo users can independently open safe with each other’s own user code.
* Multi mode and dual mode can not be used simultaneously.
9. Multi mode
1) Touch Pad 2) Touch 1st Code or
2nd Code
3) Touch # 4) Open the door
(Bi sound, Pad lighted)(Bi sound) (Melody, OPEnd on FND)
* NOTE : If multi mode unsets, 2nd code is removed automatically. 1st code cannot be removed.
Set
Unset
Open
* NOTE : 1) 2nd user code must be different from 1st code.
2)
Prior to closing door, confirm as shown in 9. Multi mode
▶
Open if 2nd Code registered correctly.
3) 2nd code can be changed in the same way as 9. Multi mode
▶
Set .
4) For setting or changing 1st code, please do as shown in 3. Set User Code .
(4 ~16 digits)
1) Press M Button on
door back.
(Bi sound) (Bi sound) (Bi sound)
5) Touch # 2) Touch 2
3) Touch #
4) Enter 2nd Code
(Melody, good on FND)
1) Press M Button on
door back.
(Bi sound) (Bi sound)(Bi sound)
4) Touch # 3) Touch 2
2) Touch #
(Melody, CLEAr on FND)
Open the Door
2nd Code
2 ##
2 ##
#
1st Code
or
2 nd Code
Touch Pad

8
10. Dual mode (Finger-print + Code)
ㆍCode and finger-print should be entered in a row for opening.
* Dual mode and multi mode can not be used simultaneously.
* NOTE :
If dual mode unsets, registered finger-print is removed automatically. User code cannot be removed.
* NOTE : 1)
Prior to closing door, confirm as shown in 10. Dual mode(Finger-print+Code)
▶
Open if Finger-print registered correctly.
2) Finger-print can be changed in the same way as 10. Dual mode(Finger-print+ Code)
▶
Set .
3) For setting or changing user code, please do as shown in 3. Set User Code .
Set
Unset
Open
5) Open the door
1) Touch Pad
(
Bi sound, Pad lighted
)(Melody)
2) Put Finger-print
on sensor
3) Touch User Code
4) Touch #
(Melody, OPEnd on FND)
1) Press M Button on
door back.
(Bi sound) (Bi sound)(Bi sound)
4) Touch # 3) Touch 5
2) Touch #
(Melody, CLEAr on FND)
1) Press M Button on
door back.
(Bi sound) (Bi sound) (Bi sound)
2) Touch 5
3) Touch #
4) If there is no registered fingerprint
put Finger-print on sensor
(Melody, good on FND)
Finger - print User Code
5 #
5 ##
Finger - print
Pad
#
Open the Door

9
BEYOND User Manual
11. Dual mode (Code + Code)
ㆍTwo different codes should be entered in a row for opening.
* Dual mode and multi mode can not be used simultaneously.
* NOTE : If dual mode unsets, 2nd code is removed automatically. 1st code cannot be removed.
* NOTE : 1) 2nd code must be different from 1st code.
2)
Prior to closing door, confirm as shown in 11. Dual mode(Code+Code)
▶
Open if 2nd Code registered correctly.
3) 2nd code can be changed in the same way as 11. Dual mode(Code+Code)
▶
Set .
4) For setting or changing 1st code, please do as shown in 3. Set User Code .
* NOTE : 1)
Prior to closing door, confirm as shown in 10. Dual mode(Finger-print+Code)
▶
Open if Finger-print registered correctly.
2) Finger-print can be changed in the same way as 10. Dual mode(Finger-print+ Code)
▶
Set .
3) For setting or changing user code, please do as shown in 3. Set User Code .
Set
Unset
Open
1) Touch Pad 2) Touch 1st Code
3) Touch #
6) Open the door
(Bi sound, Pad lighted)
4) Touch 2nd Code
5) Touch #
(Melody, OPEnd on FND)
1) Press M Button on
door back.
(Bi sound) (Bi sound)(Bi sound)
4) Touch # 3) Touch 9
2) Touch #
(Melody, CLEAr on FND)
(4 ~16 digits)
1) Press M Button on
door back.
(Bi sound) (Bi sound) (Bi sound)
5) Touch # 2) Touch 9
3) Touch #
4) Enter 2nd Code
(Melody, good on FND)
Open the Door Pad
9 ##
##
1st Code 2nd Code
2nd Code
9 ##

10
Press BUTTON
(On / Off )
(LED turns on/off, 10 seconds required)
3) Touch #
1) Press M Button on door back. 2) Touch 7 .
(Bi sound) (Bi sound)
*
Battery life span : 1year (in alarm setting)
*
In following cases, 9V battery must be replaced.
- If alarm horns more than 1 hour
- When LED light is not bright enough
Set
Button
Battery Housing Cover
LED Light
Set/Unset
Installing Place alarm loaded with 9V battery on doorback.
Push down to open.
12. Code and Sound Hide
Unset
ㆍ Once safe is shocked or tilted, alarm horns immediately.
13.
Alarm Setting
(Melody, Hide on FND)
1) Press M Button on door back.
(Bi sound)
4) Touch #
3) Touch 7
(Melody, CLEAr on FND)
2) Touch #
(Bi sound)
#
7
# #7

11
BEYOND User Manual
1) Hold and adjust panel to let position guide
go down to fixing hole.
2) Attach panel inside door frame.
1) Put finger into hinge hole on upper right side of
door frame and push panel outward to detach.
2) Lift it up to detach.
When changing panel, fingers may squeeze in between panel and door frame.
Therefore, when replacing panel with new one, please to wear gloves.
13.
Changing Door Panel
Attach Panel
Detach Panel
Position
Guide
Fixing
Hole
Hinge
Hole

1) Detach Panel. (See previous page.)
Then you can find the key hole.
2) Turn override key clockwise and open the door.
*
Please keep override key apart from your safe.
If you forget your code, you may open your safe
using override key.
14.
Open with Override Key(Optional)
Door(without Panel)
Key Hole
Printed in Korea, June 20, 2019
19 NoksanSandan 261Ro 60Gil Gangseo-gu Busan, Korea TEL [phone] FAX [phone]
Email : [email protected] www.dsafe.kr
