Art. 8066
Air Brake Bleeder
1 Air Outlet (Muffler)
2Suction Hose (Rigid)
3Bleeding Hose (Flexible)
4Trigger
5Air Inlet
6Container
7Bleeding Adapter
8Hose Connector (8 3)
TECHNICALDATA
Working Pressure: 6-12bar
Noise Level: LwA = 77,2 dB(A)
LpA = 88,2 dB(A)
Vibration Level: ahd = 0,026 m/s²
K = 0,498 m/s²
•Brake systems shouldbe maintained by qualified personnel only!
•Secure your vehicle against unintended movement.
•Always follow the manufacturer’s recommendations.
•Do not leave brake fluid out in the open. Brake fluid is hygroscopic which means it will absorb
humidity out of the air. The existence of water in brake fluid will decrease its boiling point and may
causea total malfunction of your brake system.
•Always use new and unused brake fluid; used and worn out brake fluid maycausea total malfunction
INSTRUCTION
1. Connect the professional brake bleeder to the compressedair supply.
Note: Do not operate the brake pedal while bleeding the brake.
2. Apply bleeding adapter to the nozzleon the brake caliper respectively on the wheel cylinder and open
the nozzle slowly. Note: When opening the nozzle too far, surrounding air might be suckedinto the
system via the nozzlethread. Whenopening the nozzlenot far enough, the brake fluid might not flow
well or maybe not at all.
3. By activating the bleeder’s trigger you create a vacuum and the brake fluid will be suckedinto the drain
canister. Note: Whenworking on vehicles with a load-dependent brake system on the rear axle, the
brake fluid might not flow well or maybenot at all. In this casefollow the manufacturer’s advice.
4. As soon as the brake fluid flows bubble-free through the clear hose, closethe nozzleand take off the
bleeding adaptor.
5. Repeat these steps on each brake caliper or wheel cylinder. Note: Whilebleeding the brake, there
mustbe a sufficient amount of freshbrake fluid in the refilling canister. Otherwise air will be suckedinto
the brake system andyou will have to bleed the brake again.
6. Checkthe filling level in the brake fluid reservoir of your vehicle after finishing the bleeding and refill if
necessary. Close and seal the reservoir and checkall nozzles for impermeability.
MAINTENANCE
We recommenda thorough cleaning after each use.
