BH M2 Classic User manual

G2336U
UNIDAD ELECTRÓNICA
ELECTRONIC MONITOR
UNITÉ ÉLECTRONIQUE
ELEKTRONIKEINHEIT
UNIDADE ELECTRÓNICA
IMPIANTO ELETTRONICO
ELEKTRONISCHER MONITOR

Fig. 1 Fig. 2
Fig. 3 Fig. 4
Fig. 5 Fig. 6

3
Español
PUESTA EN MARCHA.-
Para poner en marcha el monitor en
primer lugar tiene que enchufar el
adaptador que se suministra con la
máquina a un enchufe de corriente
(220v.- 240v) y el terminal del adaptador
a la clavija situada en la parte inferior
trasera de la máquina (Fig 4).
Si durante el desarrollo del ejercicio
pulsa el botón START/STOP todas las
funciones del electrónico se pararán.
Si pulsa de nuevo START/STOP
todas las funciones se pondrán de
nuevo en funcionamiento.
El monitor se apagará automática-
mente cuando la unidad esté 4
minutos parada.
Importante: Deposite los componen-
tes electrónicos en contenedores
especiales, Fig. 1.
FUNCIONES DEL MONITOR.-
Este monitor dispone de 5 teclas: UP,
DOWN, START/ STOP; ENTER,
RESET. En el centro de la pantalla se
muestra simultaneamente el nivel del
programa que haya elegido. En la
parte inferior del display le indica la
VELOCIDAD/RPM; el TIEMPO; la
DISTANCIA; los WATIOS/CALORÍAS;
el PULSO.
Este monitor dispone también de 1
programa manual; 9 programas
predefinidos; 4 programa de usuario; 1
programa de watios; 4 programas de
control de ritmo cardiaco y 1 programa
random.
PASO DE UN MODO DE
TRABAJO A OTRO.-
Tras seleccionar el usuario
aparecerán parpadeando distintos
programas.
Este monitor tiene la posibilidad de
trabajar con 6 modos diferentes:
Manual, Programas, Watios (WATT),
Usuario (USER), Pulso (H.R.C.) y
aleatorio (Random). Para pasar de un
modo a otro hay que pulsar el botón
START/STOP para detener el
monitor, después pulsar RESET y,
usando los botones UP▲/DOWN▼
seleccionar el modo deseado.
FUNCION MANUAL.-
Pulsando las teclas UP▲/DOWN▼
seleccione la función manual y pulse
ENTER. Pulse la tecla START/STOP
para iniciar el ejercicio y con las teclas
UP▲/DOWN▼suba o baje la
resistencia del ejercicio, teniendo 24
niveles de frenada. Si en el estado
inicial pulsa la tecla START/STOP
comenzará el ejercicio en función
manual directamente.
Programación de tiempo.-
Si tras seleccionar la función manual
pulsa la tecla ENTER, le parpadeará
la ventana del tiempo. Pulsando las
teclas UP▲/DOWN▼, puede
programar el tiempo de su ejercicio
entre (5-99 Minutos). Seleccione el
tiempo y pulse START/STOP para
comenzar el ejercicio. El tiempo irá
disminuyendo hasta alcanzar el valor
“cero“, y el monitor le emitirá unos
pitidos advirtiéndole que ha llegado al
valor programado.

4
Programación de la distancia.-
Si tras seleccionar la función manual
pulsa la tecla ENTER dos veces, le
parpadeará la ventana de la distancia.
Pulsando las teclas UP/DOWN, puede
programar la distancia de su ejercicio
entre (1- 99 Km). Seleccione la
distancia y pulse START/STOP para
comenzar el ejercicio. La distancia ira
disminuyendo hasta alcanzar el valor
«cero» y el monitor le emitirá unos
pitidos advirtiéndole que ha llegado al
valor programado.
Programación de las calorías.-
Si tras seleccionar la función manual
pulsa la tecla ENTER tres veces le
parpadeara la ventana de las calorías.
Pulsando las teclas UP▲/DOWN▼,
puede programar las calorías de su
ejercicio entre (10 - 990 Cal.).
Seleccione las calorías y pulse
START/STOP para comenzar el
ejercicio. Las calorías disminuirán
hasta alcanzar el valor “cero“, y el
monitor le emitirá unos pitidos
advirtiéndole que ha llegado al valor
programado.
FUNCIÓN PROGRAMAS.-
Pulsando las teclas UP▲/DOWN▼
seleccione la función PROGRAM y
pulse ENTER. Pulse las teclas
UP▲/DOWN▼para seleccionar el
gráfico de programa (2-10) que desee
para hacer su ejercicio y pulse la tecla
ENTER. Pulse START/STOP para
comenzar el ejercicio. El tiempo de
duración del gráfico del programa es
de 10 minutos, repartidos en 10
escalas de un minuto.
Para programar tiempo, distancia y/o
calorías lleve a cabo los siguientes
pasos. Una vez seleccionado el
programa y antes de pulsar la tecla
START/STOP, pulse la tecla ENTER
para programar el tiempo utilizando
las teclas UP▲/DOWN▼. En este
caso la duración del programa será
repartido entre las 10 escalas. Pulse
ENTER para programar la distancia.
Vuelva a pulsar ENTER para
programar las calorías. Pulse la tecla
START/STOP para comenzar el
ejercicio.
Una vez comenzado el ejercicio usted
puede variar la resistencia de frenada
pulsando las teclas UP▲/DOWN▼.
PROGRAMA DE WATIOS
CONSTANTES
Pulsando las teclas UP▲/DOWN▼
seleccione la función WATT y pulse
ENTER.
Pulsando las teclas UP▲/DOWN▼,
puede programar los watios de su
ejercicio entre (70 - 310 Watt.) y pulse
ENTER para programar el tiempo.
Pulse ENTER para programar la
distancia. Vuelva a pulsar ENTER para
programar las calorías. Pulse la tecla
START/STOP para comenzar el
ejercicio.
El nivel de esfuerzo del ejercicio se
autoajustará en función de la
velocidad y los watios seleccionados.
PROGRAMA DE USUARIO.-
Pulsando las teclas UP▲/DOWN▼
seleccione la función USER y pulse
ENTER.
Seleccione el usuario con las teclas
UP▲/DOWN▼entre U1-U4 y pulse la
tecla ENTER.
Pulse la tecla ENTER durante 4
segundos.
A la izquierda de la zona central de la
pantalla aparecerá parpadenado la
primera columna de nivel del ejercicio.

5
Seleccione el nivel deseado para esta
primera escala pulsando las teclas
UP▲/DOWN▼y luego pulse ENTER.
Repita el procedimiento para
programar las 10 escalas del
programa de usuario.
Una vez definido el programa de
usuario y antes de pulsar la tecla
START/STOP, pulse la tecla ENTER
durante 4 segundos hasta que
parpadee la función tiempo. Pulse las
teclas UP▲/DOWN▼para seleccionar
el tiempo. Pulse ENTER para
programar la distancia. Vuelva a pulsar
ENTER para programar las calorías.
Pulse la tecla START/STOP para
comenzar el ejercicio.
PROGRAMAS DEL CONTROL
DEL RITMO CARDIACO.-
Pulsando las teclas UP▲/DOWN▼
seleccione la función H.R.C. y pulse
ENTER. Deberá seleccionar el ritmo
cardiaco objetivo para el ejercicio.
Con las teclas UP▲/DOWN▼
seleccione la opción deseada (60%,
70%, 85% o Tag) y pulse la tecla
ENTER. Las tres primeras indican el
porcentaje respecto al pulso cardiaco
máximo (220-edad) y la cuarta se
utiliza para introducir el ritmo cardiaco
objetivo de forma manual. Si elige
Tag, deberá utilizar las teclas
UP▲/DOWN▼para seleccionar el
ritmo cardiaco deseado y pulsar
ENTER. Pulse START/STOP para
comenzar el ejercicio. El nivel de
frenada se ajustará automáticamente
de acuerdo al valor de pulso
seleccionado. Si el valor de pulso está
por debajo del valor objetivo, la
frenada aumentará un nivel cada 30
segundos hasta llegar al máximo de
24. Si el valor de pulso está por
encima del valor objetivo el monitor
emitirá unos pitidos de aviso y la
frenada disminuirá un nivel cada 15
segundos hasta llegar al mínimo de 1.
Si aún así el valor del pulso se
mantiene por encima del valor objetivo
durante más de 30 segundos, el
mónitor se parará por protección del
usuario y emitirá unos pitidos de aviso.
Para programar tiempo, distancia y/o
calorías lleve a cabo los siguientes
pasos. Una vez seleccionado el
programa de pulso cardiaco y antes
de pulsar la tecla START/STOP, pulse
la tecla ENTER para programar el
tiempo utilizando las teclas
UP▲/DOWN▼. Vuelva a pulsar
ENTER para programar la distancia.
Por último vuelva a pulsar ENTER
para programar las calorias. Pulse la
tecla START/STOP para comenzar el
ejercicio.
En estos programas tienen que estar
las manos colocadas en los sensores
de pulso (R).
FUNCIÓN RANDOM.-
Pulsando las teclas UP▲/DOWN▼
seleccione la función RANDOM y
pulse ENTER. Aparecerá un
programa aleatorio. Pulse
START/STOP para comenzar el
ejercicio. El tiempo de duración del
gráfico del programa es de 10
minutos, repartidos en 10 escalas de
un minuto.
Para programar tiempo, distancia y/o
calorías lleve a cabo los siguientes
pasos. Una vez seleccionado el
programa y antes de pulsar la tecla
START/STOP, pulse la tecla ENTER
para programar el tiempo utilizando
las teclas UP▲/DOWN▼. En este
caso la duración del programa será
repartido entre las 10 escalas. Pulse
ENTER para programar la distancia.

6
Vuelva a pulsar ENTER para
programar las calorías. Pulse la tecla
START/STOP para comenzar el
ejercicio.
Una vez comenzado el ejercicio usted
puede variar la resistencia de frenada
pulsando las teclas UP▲/DOWN▼.
INSTRUCCIONES - USO DEL
HAND-GRIP MEDICION DE
PULSO.-
PULSO Hand-grip.
El pulso de este modelo se mide
colocando ambas manos en los
sensores (R), que están puestos en el
manillar como se indica en la Fig.2.
Una vez colocadas ambas manos en
los sensores, comenzará a parpadear
el corazón en la parte derecha de la
pantalla que indica PULSE de la
pantalla del monitor y al cabo de unos
segundos aparecerá el valor de su
ritmo cardíaco.
Si no tiene colocadas ambas manos
correctamente como muestra la Fig.3,
el pulso no funciona.
Si en pantalla aparece una «P» o no
parpadea el corazón, asegúrese de
que tiene colocadas ambas manos en
los sensores.
PROGRAMA DE GRASA
CORPORAL.-
Este programa esta diseñado para
calcular el porcentaje de grasa corporal
del usuario. Con las teclas UP/DOWN
seleccione la función BODYFAT.
Seleccione con las teclas UP/DOWN la
altura (HEIGHT 90-210cm), pulse
ENTER, seleccione con las teclas
UP/DOWN su peso (WEIGHT 10–
150Kg), pulse ENTER, seleccione
seleccione con las teclas UP
/DOWNsu edad (AGE 10–100 años).
Pulsando las teclas UP/DOWN
seleccione el sexo (Hombre – Mujer)
pulse ENTER para confirmar.
Pulse la tecla START/STOP y coloque
las manos sobre los sensores (R) de
pulso (hand-grip) como muestra la
Fig.3 y al cabo de unos segundos le
dará el resultado en las pantallas
inferiores del display los valores FAT
% (% de grasa). Si le aparece en el
display el símbolo «ERROR», posicione
bien las manos sobre los sensores de
pulso (R) de la Fig.3.
TABLA DE REF. PORCENTAJE
GRASA CORPORAL % (BODY FAT)
GRASA% BAJA BAJA /
MEDIA MEDIA ALTA
HOMBRE < 13% 13%-
25,8% 26%-
30% >30%
MUJER <23% 23%-
35,8% 36%-
40% >40%
FUNCIONAMIENTO iOS (iPod
Touch/iPhone/iPad)
Conecte el módulo Bluetooth
(opcional) en el conector USB situado
en la parte trasera del monitor, Fig. 6.
Active la función Bluetooth en el
iPod/iPhone/iPad y realice una
búsqueda de dispositivos Bluetooth.
Seleccione su módulo BH de la lista
de dispositivos para vincularlo. A
continuación descargue una
aplicación compatible Pafers de Apple
Store y ejecútela.
FUNCIONAMIENTO CON
DISPOSITIVOS ANDROID
Conecte el módulo Bluetooth
(opcional) en el conector USB situado
en la parte trasera del monitor, Fig. 6.
Active la función Bluetooth en el
dispositivo Android.

7
A continuación descargue una
aplicación compatible Pafers de
Google Play y ejecútela.
Cuando la aplicación lo requiera
seleccione su módulo BH de la lista
de dispositivos para vincularlo.
GUÍA DE PROBLEMAS.-
Problema: Se enciende el display y
sólo funciona la función de Tiempo
Solución:
a.-Compruebe si el cable de conexión
está conectado.
Problema: Si algún segmento de
alguna función no se enciende o si se
producen indicaciones erróneas en
alguna función.
Solución:
a.- Desconecte la conexión a 220V
durante 15 segundos y vuelva a
conectarlo.
b.-Si el paso anterior no le ayuda,
reemplace el monitor electrónico.
Transformador
Problema: No se enciende el monitor.
Solución:
a.-Compruebe la conexión a 220V.
b.-Compruebe la conexión de salida
del transformador, a la máquina.
c.-Compruebe la conexión de los
cables del tubo remo.
Evite que le dé a su monitor
electrónico la luz directa del sol, pues
se puede estropear la pantalla del
cristal líquido. No lo exponga tampoco
al agua ni a golpes.
Para cualquier consulta, no dude en
ponerse en contacto con el
(S.A.T).Servicio de Asistencia
Técnica, llamando al teléfono de
atención al cliente (ver página final del
presente manual).
BH SE RESERVA EL DERECHO A
MODIFICAR LAS ESPECIFICACIO-
NES DE SUS PRODUCTOS SIN
PREVIO AVISO.

8
English
STARTING.-
To switch the monitor on first plug the
adapter, supplied with the machine,
into the mains socket (220 V – 240 V)
and the jack on the adapter into the
socket at the bottom of the machine.
(Fig. 4)
If at any time during exercise you
press the START/STOP button then
all of the unit’s functions will stop.
Pressing the START/STOP button
again will restart the machine.
The monitor will switch itself off
automatically if the unit stands idle for
more than 4 minutes.
Important: Deposit electronic
components in special containers,
Fig.1.
MONITOR FUNCTIONS.-
This electronic unit has 5 function
keys: START/STOP; RESET, ENTER;
UP▲; DOWN. The centre of the
screen will simultaneously display the
selected program level. There are five
windows that indicate the
SPEED/RPM; TIME; DISTANCE;
WATTS/CALORIES and PULSE
RATE.
This monitor also has 1 manual
program, 9 pre-set exertion level
programs; 4 user defined program and
4 Heart Rate Control programs; 1 watt
program and 1 random program.
CHANGING FROM ONE
WORK MODE TO ANOTHER.-
After selecting the user various
programs will start flashing. This
monitor allows you to work in 6
different modes: Manual, Program,
Personal, Watt, Pulse (HRC) and
Random. In order to pass from one
mode to another, press the
START/STOP button to stop the
monitor, then press RESET and, with
the help of the UP▲/DOWN▼
buttons, select the desired mode.
MANUAL FUNCTION.-
Use the UP▲/DOWN▼keys to select
the manual function and press
ENTER. Press the START/STOP key
to start exercising and use the
UP▲/DOWN▼keys to increase or
decrease the exertion level. There are
24 exertion levels. If you press the
START/STOP key while at the start
screen, exercise will begin directly in
manual mode.
Programming a time limit.-
If, after selecting manual mode, you
press the ENTER key the time window
will start flashing. By pressing the
UP▲/DOWN▼keys you can program
a time limit for the exercise (between
5-99 minutes). Select the time and
press START/STOP to begin the
exercise. The time will begin to count
down until it reaches zero and the
monitor will beep several times to
advise you that you have reached the
programmed value.
Programming a distance limit.-
If, after selecting manual mode, you
press the ENTER key twice the
distance window will start flashing. By
pressing the UP▲/DOWN▼keys you
can program a distance for your
exercise (between 1–99 km).

9
Select the distance and press
START/STOP to begin the exercise.
The distance will begin to count down
until it reaches zero and the monitor
will beep several times to advise you
that you have reached the
programmed value.
Programming a calorie limit.-
If, after selecting manual mode, you
press the ENTER key three times the
calorie window will start flashing. By
pressing the UP▲/DOWN▼keys you
can program the calories for the
exercise (between 10-990 Cal.).
Select the calories and press
START/STOP to begin the exercise.
The calories will begin to count down
until they reach zero and the monitor
will beep several times to advise you
that you have reached the
programmed value.
PROGRAM FUNCTION.-
Use the UP▲/DOWN▼keys to select
the PROGRAM function and press
ENTER. Press the UP▲/DOWN▼keys
to select the program graph (2-10) that
you wish to use and then press the
ENTER key. Press START/STOP to
start the exercise. The duration of the
program graph is 10 minutes, divided
into 10 minutes stages.
To program time, distance and/or
calories, go through the following
procedure: Once the program has
been selected and before pressing the
START/STOP key, press the ENTER
key to program the time using the
UP▲/DOWN▼keys. In this case the
time will be divided into 10 stages.
Press the ENTER key to program the
distance. Press ENTER again to
program the calories. Press
START/STOP to start the exercise.
You can vary the exertion level during
the exercise by pressing the
UP▲/DOWN▼keys.
STEADY WATT RATE
PROGRAM
Press the UP▲/DOWN▼keys to
select the WATT function and press
ENTER. By pressing the
UP▲/DOWN▼keys you can program
the watts to produce for the exercise
(between 70-310 Watt.). Select the
watts and press ENTER to program
the time. Press ENTER again to
program the distance. Press the ENTER
key one last time to program the
calories. Press START/STOP to start
the exercise.
The exertion level for the exercise is
self adjusting based on the speed and
number of watts selected.
USER PROGRAM.-
Use the UP▲/DOWN▼keys to select
the USER function and press ENTER.
Select the user, between U1-U4, using
the UP▲/DOWN▼keys and then
press ENTER.
Press and hold the ENTER key for 4
seconds.
The first column of the exercise level
will start flashing to the left of the
central area of the display. Select the
desired level for this first stage using
the UP▲/DOWN▼keys and then
press ENTER. Repeat this procedure
to program all 10 stages of the user
program.
Once the user program has been
defined and before pressing the
START/STOP key, press and hold the
ENTER key for 4 seconds until the
time function starts to flash. Press the
UP▲/DOWN▼keys to select the
time.

10
Press the ENTER key to program the
distance. Press ENTER again to
program the calories. Press
START/STOP to start the exercise.
HEART RATE CONTROL
PROGRAMS.-
Use the UP▲/DOWN▼keys to select
the H.R.C function and press ENTER.
Use the UP▲/DOWN▼keys to select
the desired option (60%, 70% 85% or
Tag) and press the ENTER key. The
first three represent the percentage with
respect to maximum heart rate (220-
age) and the fourth is used to specify
the target heart rate manually. If you
choose Tag then you should use the
UP▲/DOWN▼keys to select the
desired heart rate and then press
ENTER. Press START/STOP to start
the exercise. The exertion level will
adjust automatically in accordance with
the selected hart rate value. If the pulse
rate is below the target value then the
exertion setting will increase by one
level every 30 seconds until it reaches
the maximum 24. If the pulse rate is
above the target value the monitor will
give out warning beeps and reduce the
exertion settings by one level every 15
seconds until it reaches the minimum 1.
If the pulse rate still stays above the
target value for more than 30 seconds
the monitor will beep and stop in order
to protect the user.
To program time, distance, and/or
calories, go through the following
procedure: Once the heart rate program
has been selected and before pressing
the START/STOP key, press the
ENTER key to program the time limit
using the UP▲/DOWN▼keys. Press
ENTER again to program the distance.
Press the ENTER key one last time to
program the calories.
Press START/STOP to start the
exercise. Your hands must be placed
on the pulse sensors (R) when using
these programs.
RANDOM FUNCTION.-
Use the UP▲/DOWN▼keys to select
the RANDOM function and press
ENTER.
You will see a random program profile.
Press START/STOP to start the
exercise. The duration of the program
graph is 10 minutes, divided into 10
minutes stages.
To program time, distance and/or
calories, go through the following
procedure: Once the program has
been selected and before pressing the
START/STOP key, press the ENTER
key to program the time using the
UP▲/DOWN▼keys. In this case the
time will be divided into 10 stages.
Press the ENTER key to program the
distance. Press ENTER again to
program the calories. Press
START/STOP to start the exercise.
You can vary the exertion level during
the exercise by pressing the
UP▲/DOWN▼keys.
HAND-GRIP PULSE
MEASUREMENT INSTRUCTIONS
–USE.-
PULSE Hand-grip.
On this model the pulse rate is
measured by placing both hands on
the sensors (R), located on the
handlebar, as shown in Fig.2.
When both hands are placed on the
sensors the heart symbol on the right-
hand side of the screen, marked
PULSE, will begin to flash and after a
few seconds a heart rate reading will
be displayed.

11
If both hands are not placed correctly
as shown in Fig.3 then the pulse
function will not work. If a «P» appears
on the screen or the heart symbol does
not flash, make sure that both hands
are placed correctly on the sensors.
BODY FAT PROGRAM.-
This program is designed to calculate
the user’s body fat percentage.
Press the UP/DOWN keys to select the
BODYFAT function and press ENTER.
Use the UP/DOWN keys to select your
HEIGHT (90-210cm), press ENTER to
confirm. Use the UP/DOWN keys to
select your WEIGHT (10-150cm), press
ENTER to confirm. Use the UP/DOWN
keys to select your AGE (10-100 years).
Press ENTER and then use the
UP/DOWN keys to select your sex
(Male–Female). Press ENTER to
confirm.
Press the START/STOP key and place
your hands on the pulse sensors (R)
(Hand-grips), as shown in Fig.3, and
after a few seconds the lower screens
on the display will show your FAT%.
If the error code “ERROR” appears,
position your hands correctly on the
pulse sensors (R). Fig 3.
REFERENCE TABLE: BODY FAT
PERCENTAGE %
SEX /
FAT% LOW LOW /
AVERAGE AVERAGE
HIGH
MALE <
13%
13%-
25,8%
26%-30% >30%
FEMALE <23% 23%-
35,8% 36%-40% >40%
iOS OPERATION (compatible
iPhone, iPad and iPod Touch)
Download a Pafers App from the App
Store (Check compatible apps at the
BH website: www.bhfitness.com).
Then connect the USB Bluetooth
module (purchased separately) into
the USB port on the back of the
monitor (Fig. 6.) Turn Bluetooth to
“ON” in settings on the iOS device and
the device will begin to search for
active Bluetooth equipment in range.
Select the appropriate BH Module
from the list displayed on the iOS
device to pair. Open the Pafers app to
run it.
ANDROID OPERATION
(compatible Android devices)
Download a Pafers App from Google
Play (Check compatible apps at the
BH website: www.bhfitness.com).
Then connect the USB Bluetooth
module (purchased separately) into
the USB port on the back of the
monitor (Fig. 6.) Turn Bluetooth to
“ON” in settings on the Android
device. Open the Pafers app to run it.
When prompted by the app, select the
appropriate BH Module from the list
displayed on the Android device to
pair.
TROUBLESHOOTING GUIDE.-
Problem: The display comes on but
only the Time function works.
Solution:
a.- Make sure that the connection
cable is connected.
Problem: Display segments of a
function read-out are not visible or
error messages for a particular
function appear.
Solution:
a.- Unplug it from the 220 V mains
socket for 15 seconds and then plug it
back in.
b.- If the above steps do not help then
replace the electronic monitor.

12
Transformer
Problem: The monitor does not switch
on.
Solution:
a.- Check the 220 V mains connection
b.- Check the output connection from
the transformer to the machine.
c.- Check the cable connections for
the main post.
Avoid leaving the electronic monitor in
direct sunlight as this might damage
the liquid crystal display. Similarly, do
not expose it to water or knocks.
Do not hesitate to get touch with the
Technical Assistance Service if you
have any queries by phoning customer
services (see last page in manual)
BH RESERVES THE RIGHT TO
MODIFY THE SPECIFICATIONS OF
ITS PRODUCTS WITHOUT PRIOR
NOTICE

13
Français
MISE EN MARCHE.-
Pour mettre en marche le moniteur
brancher d’abord l’adaptateur fourni
avec la machine, dans une prise de
courant (220 v.- 240 v) et le
connecteur de l’adaptateur à la fiche
qui se trouve en-bas derrière la
machine. (Fig. 4)
Si durant le déroulement de l'exercice,
vous appuyez sur le bouton
START/STOP, toutes les fonctions de
l'électronique s’arrêteront. Si vous
appuyez à nouveau sur
START/STOP, toutes les fonctions se
mettront à nouveau en marche.
Si l’unité est 4 minutes arrêtée, l’écran
s’éteint automatiquement.
Remarque importante: Les
composants électroniques hors
d’usage doivent être déposés dans
des conteneurs spécialement prévus à
cet effet. Fig.1.
FONCTIONS DU MONITEUR.-
Ce moniteur dispose de 5 touches:
START/STOP; RESET, ENTER; UP▲;
DOWN▼. Le niveau du programme
sélectionné s’affiche simultanément au
milieu de l’écran. En-bas du display
cinq fenêtres s’affichent indiquant: la
VITESSE/TPM, la DUREE, la
DISTANCE, les WATTS/CALORIES, le
POULS.
Ce moniteur dispose également d'un
programme manuel, de 9 programmes
prédéfinis des niveaux de freinage,
d’un programme d’utilisateur, de
quatre programmes pour le contrôle
de la fréquence cardiaque, d’un
programme watt et d’un programme
aléatoire.
POUR PASSER D’UN MODE
DE TRAVAIL À L’AUTRE.-
Après choix de l'utilisateur, les LED
associées aux différents programmes
clignoteront. Ce moniteur peut
travailler avec 6 modes différents:
Manuel, Programmes, Watt,
Utilisateur (PERSONAL) Pouls
(H.R.C) et aléatoire (RANDOM).
Pour passer d’un mode à l’autre,
appuyer sur le bouton START/STOP
pour arrêter le moniteur puis sur
RESET et sélectionner le mode
souhaité avec les boutons
UP▲/DOWN▼.
FONCTION MANUELLE.-
Avec les touches UP▲/DOWN▼
sélectionner la fonction manuel et
appuyer sur ENTER. Appuyer sur la
touche START/STOP pour démarrer
l’exercice et avec les touches
UP▲/DOWN▼augmenter ou baisser
la résistance de l’exercice. L’appareil
dispose de 24 niveaux de freinage. Si
dans l’état initial, vous appuyez sur la
touche START/STOP l’exercice
commencera directement en mode
manuel.
Programmation de la durée.-
Si après avoir sélectionné la fonction
manuel, vous appuyez sur la touche
ENTER, la fenêtre durée clignotera.
En appuyant sur les touches
UP▲/DOWN▼, vous pourrez
programmer la durée de l’exercice
entre 5 et 99 minutes. Pour
commencer l’exercice, sélectionner la
durée et appuyer sur la touche
START/STOP.

14
La durée diminuera jusqu'à atteindre
la valeur "zéro" et le moniteur émettra
un signal sonore pour indiquer que la
valeur programmée a été atteinte.
Programmation de la distance.-
Si après avoir sélectionné la fonction
manuel, vous appuyez deux fois sur la
touche ENTER, la fenêtre distance
clignotera. En appuyant sur les
touches UP/DOWN, vous pourrez
programmer la distance de l’exercice
entre 1 et 99 km. Pour commencer
l’exercice, sélectionner la distance et
appuyer sur la touche START/STOP.
La distance diminuera jusqu'à
atteindre la valeur "zéro" et le
moniteur émettra un signal sonore
pour indiquer que la valeur
programmée a été atteinte.
Programmation des calories.-
Si après avoir sélectionné la fonction
manuel, vous appuyez trois fois sur la
touche ENTER, la fenêtre calories
clignotera. En appuyant sur les
touches UP▲/DOWN▼, vous pourrez
programmer les calories de l’exercice
entre 10 et 990 calories. Pour
commencer l’exercice, sélectionner
les calories et appuyer sur la touche
START/STOP. Les calories
diminueront jusqu'à atteindre la valeur
"zéro" et le moniteur émettra un signal
sonore pour indiquer que la valeur
programmée a été atteinte.
FONCTION PROGRAMMES.-
Avec les touches UP▲/DOWN▼
sélectionner la fonction PROGRAM et
appuyer sur ENTER. Appuyer sur les
touches UP▲/DOWN▼pour
sélectionner le graphique du
programme (2-10) souhaité pour
réaliser l’exercice puis appuyer sur la
touche ENTER. Pour commencer
l’exercice, appuyer sur la touche
START/STOP. La durée du graphique
du programme est de 10 minutes
divisées en 10 étapes de 1 minute.
Pour programmer la durée, la distance
et/ou les calories, faire comme indiqué
ci-après: Après avoir sélectionné le
programme et avant d’appuyer sur la
touche START/STOP.
Appuyer sur ENTER pour programmer
la durée avec les touches
UP▲/DOWN▼. Dans durée du
programme seront ainsi répartie dans
les 10 étapes. Pour programmer la
distance, appuyer sur ENTER. Pour
programmer les calories, appuyer à
nouveau sur ENTER. Pour
commencer l’exercice, appuyer sur la
touche START/STOP. Après avoir
commencé l'exercice, vous pouvez
modifier la résistance de freinage en
appuyant sur les touches
UP▲/DOWN▼.
PROGRAMME WATTS
CONSTANTS.
En appuyant sur les touches
UP▲/DOWN▼sélectionner la
fonction WATT et appuyer sur
ENTER. En appuyant sur les touches
UP▲/DOWN▼, vous pourrez
programmer les watts de l’exercice
entre 70 et 310 watts.
Pour programmer la dureé appuyer
sur ENTER. Pour programmer la
distance, appuyer sur ENTER. Pour
programmer les calories, appuyer à
nouveau sur ENTER. Pour
commencer l’exercice, appuyer sur la
touche START/STOP.
Le niveau de l’effort de l’exercice se
réglera automatiquement d’après la
vitesse et les watts sélectionnés.
PROGRAMMES DE

15
L'UTILISATEUR.-
Avec les touches UP▲/DOWN▼
sélectionner la fonction USER et
appuyer sur ENTER. Sélectionner
l’utilisateur avec les touches
UP▲/DOWN▼entre U1-U4 et
appuyer sur la touche ENTER.
Appuyer quatre secondes sur ENTER.
La première colonne du niveau de
l’exercice sera affichée au milieu à
gauche de l’écran. Sélectionner le
niveau souhaité pour cette première
étape en appuyant sur les touches
UP▲/DOWN▼puis sur ENTER.
Répéter cette procédure pour
programmer les 10 étapes du
programme de l’utilisateur.
Après avoir sélectionné le programme
et avant d’appuyer sur la touche
START/STOP, appuyer quatre
secondes sur ENTER jusqu’au
clignotement de la fonction temps.
Appuyer sur les touches
UP▲/DOWN▼pour sélectionner la
durée. Pour programmer la distance,
appuyer sur ENTER. Pour
programmer les calories, appuyer à
nouveau sur ENTER. Pour
commencer l’exercice, appuyer sur la
touche START/STOP.
PROGRAMMES POUR LE
CONTROLE DE LA
FREQUENCE CARDIAQUE.-
Avec les touches UP▲/DOWN▼
sélectionner la fonction H.R.C. et
appuyer sur ENTER. Avec les touches
UP▲/DOWN▼sélectionner l’option
voulue (60%, 70%, 85% ou Tag) et
appuyer sur ENTER.
Les trois premières indiquent le
pourcentage concernant le pouls
cardiaque maximum (220-âge) et la
quatrième est utilisée pour introduire
manuellement la fréquence cardiaque
cible. Si vous choisissez Tag, il faudra
utiliser les touches UP▲/DOWN▼
pour sélectionner la fréquence
cardiaque voulue puis appuyer sur
ENTER. Pour commencer l’exercice,
appuyer sur la touche START/STOP.
Le niveau de freinage sera
automatiquement réglé d’après la
valeur du pouls sélectionnée. Si la
valeur du pouls est en dessous de la
valeur cible, le freinage augmenter un
niveau toutes les 30 secondes jusqu’à
atteindre le maximum de 24. Si la
valeur du pouls dépasse la valeur
cible, le moniteur émettra un signal
sonore et le freinage baissera d’un
niveau toutes les 15 secondes jusqu’à
atteindre le minium de 1. Si malgré
cela, la valeur du pouls dépasse
encore la valeur cible pendant plus de
30 secondes, le moniteur s’arrêtera
pour éviter tous risques à l’utilisateur
et il émettra un signal sonore
d’avertissement.
Pour programmer la durée, la distance
et les calories, faire comme indiqué ci-
après: Après avoir sélectionné le
programme du pouls cardiaque et
avant d’appuyer sur la touche
START/STOP, appuyer sur ENTER
pour programmer la durée avec les
touches UP▲/DOWN▼. Pour
programmer la distance, appuyer à
nouveau sur ENTER. Enfin, pour
programmer les calories, appuyer à
nouveau sur ENTER. Pour
commencer l’exercice, appuyer sur la
touche START/STOP.
Pour pouvoir réaliser les exercices
avec ces programmes, les mains
doivent être bien posées sur les
senseurs de pouls (R).
FONCTION RANDOM.-

16
Avec les touches UP▲/DOWN▼
sélectionner la fonction RANDOM et
appuyer sur ENTER.
Vous verrez un
programme aléatoire. Pour commencer
l’exercice, appuyer sur la touche
START/STOP. La durée du graphique
du programme est de 10 minutes
divisées en 10 étapes de 1 minute.
Pour programmer la durée, la distance
et/ou les calories, faire comme indiqué
ci-après: Après avoir sélectionné le
programme et avant d’appuyer sur la
touche START/STOP, appuyer sur
ENTER pour programmer la durée
avec les touches UP▲/DOWN▼.
Dans durée du programme seront
ainsi répartie dans les 10 étapes. Pour
programmer la distance, appuyer sur
ENTER. Pour programmer les
calories, appuyer à nouveau sur
ENTER. Pour commencer l’exercice,
appuyer sur la touche START/STOP.
Après avoir commencé l'exercice,
vous pouvez modifier la résistance de
freinage en appuyant sur les touches
UP▲/DOWN▼.
MODE D’EMPLOI DU HAND-
GRIP MESURE DU POULS.-
POULS Hand-grip.
Sur ce modèle, le pouls se mesure en
posant les deux mains sur les
senseurs (R) placés sur le guidon,
comme indiqué dans la Fig.2.
Dès que vos mains seront posées sur
les senseurs, un cœur commencera à
clignoter sur la droite de l’écran
PULSE de l’écran du moniteur et votre
fréquence cardiaque sera affichée
dans les secondes suivantes.
Si vos deux mains ne sont pas posées
correctement comme indiqué dans la
Fig.3, la fonction pouls ne
fonctionnera pas.
Si la lettre «P» s’affiche à l’écran ou si
le cœur ne clignote pas, vérifier que
vos mains sont bien posées sur les
senseurs.
PROGRAMME GRAISSE
CORPORELLE .-
En appuyant sur les touches UP/DOWN
sélectionner la fonction BODYFAT et
appuyer sur ENTER.
Avec les touches UP/DOWN,
sélectionnez la taille (HEIGHT 90-
210cm), appuyez sur ENTER. Avec les
touches UP/DOWN, sélectionnez votre
poids (WEIGHT 10-150kg), appuyez sur
ENTER. Avec les touches UP/DOWN,
sélectionnez votre âge (AGE 10-
100ans). Appuyez alors sur ENTER puis
sur les touches UP/DOWN pour
sélection-ner le sexe (Homme-Femme),
et sur ENTER pour accepter.
Ensuite appuyez sur la touche
UP/DOWN et posez les mains sur les
senseurs (R) de pouls (hand-grip)
comme indiqué dans la Fig.3 et dans les
secondes qui suivent, les résultats
seront affichés sur les écrans inférieurs
du display, à savoir: valeurs FAT % (%
de graisse).
En cas le message “ERROR” affiché à
l’écran, vous devrez alors poser
correctement les mains sur les senseurs
de pouls (R) de la Fig 3.
TABLEAU DE RÉFÉRENCE TAUX DE
GRAISSE CORPORELLE % (BF)
SEXE /
GRAISSE
%
FAIBLE
FAIBLE
/
MOYEN
MOYEN
ÉLEVÉ
HOMME < 13% 13%-
25,8% 26%-
30% >30%
FEMME <23% 23%-
35,8% 36%-
40% >40%
FONCTIONNEMENT IOS

17
(IPOD TOUCH / IPHONE /
IPAD)
Connectez le module Bluetooth
(optionnel) dans le connecteur USB
situé à l’arrière du moniteur, Fig 6.
Activez alors la fonction Bluetooth de
votre IPOD/IPAD/IPHONE et réalisez
une recherche de dispositifs
Bluetooth.
Selectionnez votre module BH dans la
liste des dispositifs pour les relier.
Téléchargez ensuite une application
compatible PAFERS via Apple Store
et exécutez-la.
FONCTIONNEMENT AVEC
DISPOSITIFS ANDROID
Connectez le module Bluetooth
(optionnel) dans le connecteur USB
situé à l’arrière du moniteur, Fig 6.
Activez alors la fonction Bluetooth de
votre dispositif ANDROID.
Téléchargez ensuite une application
compatible PAFERS via Google Play
et exécutez-la. Lorsque l’application
vous le demande, sélectionnez votre
module BH dans la liste des dispositifs
pour les relier.
GUIDE DES PROBLÈMES.-
Problème: Le display s’allume bien
mais seule fonctionne la fonction
durée.
Solution:
a- Vérifier si le cordon de connexion
est bien connecté.
Problème: Si un segment d’une
fonction ne s’allume pas ou si les
informations affichées sont faussées
Solution:
a.- Déconnecter 15 secondes, la
connexion 220V puis connectez-la à
nouveau.
b- Si les problèmes persistent après
avoir suivi l’instruction précédente,
remplacer le moniteur électronique.
Transformateur
Problème: Le moniteur ne s’allume
pas.
Solution:
a. Vérifier la connexion sur 220V.
b.- Vérifier la connexion de sortie du
transformateur à la machine.
c.- Vérifier la connexion des câbles du
tube rameur.
Garder le moniteur électronique à
l’abri du rayonnement direct du soleil
car cela risquerait d’endommager le
verre liquide. Tenir le moniteur à
l’écart de l’eau et éviter les coups.
Pour toute information complémentaire
et en cas de doute sur le bon état de
l’une quelconque partie de la machine,
l’hésitez pas à appeler le Service
d’Assistance Technique (SAT) au
numéro de téléphone d’Assistance
Clientèle qui figure à la dernière page
de cette notice.
BH SE RÉSERVE LE DROIT DE
MODIFIER LES
CARACTÉRISTIQUES DE SES
PRODUITS SANS PRÉAVIS.

18
Deutsch
ANSTELLEN.-
Um den Monitor anzustellen, müssen
Sie zuerst den Adapter in eine
Steckdose (220 V- 240 V) einstecken,
der mit der Maschine geliefert wird und
das Adapterterminal an den Stecker,
der sich im unteren hinteren Bereich der
Maschine befindet. (Abb. 4)
Wenn Sie während der Ausübung die
Taste START/STOP drücken, werden
alle Funktionen des Geräts gestoppt.
Wenn Sie erneut START/STOP
drücken, werden alle Funktionen
wieder aufgenommen.
Der Monitor geht automatisch aus,
wenn die Einheit mehr als 4 Minuten
still steht.
Wichtig: Entsorgen Sie elektronische
Komponenten in speziellen
Containern Fig.1.
FUNKTIONEN DES MONITORS.-
Dieser Monitor verfügt über 5 Tasten:
START / STOP; RESET, ENTER;
UP▲; DOWN▼. In der Mitte des
Displays erscheint gleichzeitig das
Niveau des Programms, das Sie
gewählt haben. Im unteren Bereich
des Monitors sieht man fünf Fenster
die Ihnen Folgendes angeben:
GESCHWINDIGKEIT/RPM, die ZEIT;
die DISTANZ; die WATT/KALORIEN;
PULS.
Dieser Monitor verfügt auch über ein
manuelles Programm: 9 vordefinierte
Programme mit unterschiedlichem
Widerstand; 4 Nutzerprogramm 4
Programm zur Kontrolle der
Herzfrequenz, 1 Watt Programm und
ein beliebiges Programm.
ÜBERGANG VON EINEM
ARBEITSMODUS ZUM
NÄCHSTEN.-
Nach der Benutzer vorgewählt worden
ist blinken die den verschiedenen
Programmen entsprechenden LEDs.
Dieser Monitor bietet die Möglichkeit
mit 6 verschiedenen Modi zu arbeiten:
Manuell, Programm, Watt, Nutzer
(USER) Puls (H.R.C.) und beliebiges
(RANDOM).
Um von einem Modus zum nächsten
zu wechseln, drücken Sie die Taste
START/STOP, um den Monitor
anzuhalten, drücken Sie danach
RESET und wählen Sie mit den
Tasten UP▲/DOWN▼den
gewünschten Modus.
MANUELLE FUNKTION.-
Mit den Tasten UP▲/DOWN▼
wählen Sie die manuelle Funktion und
drücken Sie ENTER. Drücken Sie die
Taste START/STOP, um die Übung
zu beginnen und mit den Tasten
UP▲/DOWN▼erhöhen oder
verringern Sie den Widerstand der
Übung, wobei Ihnen 24 verschiedene
Niveaus zur Verfügung stehen. Wenn
Sie zu Beginn die Taste START/STOP
drücken, beginnt die Übung direkt in
der manuellen Funktion.
Programmierung der Zeit.-
Wenn Sie nach dem Wählen der
manuellen Funktion die Taste MODE
drücken, blinkt das Fenster der Zeit.
Sie können die Zeit Ihrer Übung
programmieren, indem Sie die Tasten
UP▲/DOWN▼drücken (5-99
Minuten).

19
Wählen Sie die Zeit und drücken Sie
START/STOP, um die Übung zu
beginnen. Die Zeit wird zurücklaufen,
bis der Wert „Null“ erreicht wird und
der Monitor piept, um anzuzeigen,
dass der programmierte Wert erreicht
ist.
Programmierung der Entfernung.-
Wenn Sie nach dem Wählen der
manuellen Funktion die Taste MODE
zwei Mal drücken, blinkt das Fenster
der Entfernung. Sie können die
Distanz Ihrer Übung programmieren,
indem Sie die Tasten UP▲/DOWN▼
drücken (1- 99 Km). Wählen Sie die
Distanz und drücken Sie
START/STOP, um die Übung zu
beginnen. Die Distanz wird
zurücklaufen, bis der Wert „Null“
erreicht wird und der Monitor piept, um
anzuzeigen, dass der programmierte
Wert erreicht ist.
Programmierung der Kalorien.-
Wenn Sie nach dem Wählen der
manuellen Funktion die Taste ENTER
drei Mal drücken, blinkt das Fenster
der Kalorien. Sie können die Kalorien
Ihrer Übung programmieren, indem
Sie die Tasten UP▲/DOWN▼
drücken (10 - 990 Kalorien). Wählen
Sie die Kalorien und drücken Sie
START/STOP, um die Übung zu
beginnen. Die Kalorien werden
zurücklaufen, bis der Wert „Null“
erreicht wird und der Monitor piept, um
anzuzeigen, dass der programmierte
Wert erreicht ist.
FUNKTION PROGRAMME.-
Mit den Tasten UP▲/DOWN▼
wählen Sie die Funktion PROGRAM
und drücken Sie ENTER. Drücken Sie
die Tasten UP▲/DOWN▼, um die
Graphik des Programms (2-10) zu
wählen, das Sie für Ihre Übung
wünschen und drücken Sie ENTER.
Drücken Sie START/STOP, um die
Übung zu beginnen. Die Dauer der
Graphik des Programms beträgt 10
Minuten, die sich in 10 Skalen von 1
Minute aufteilen.
Zum Programmieren von Zeit, Distanz
und/oder Kalorien folgen Sie diesen
Schritten: Nachdem Sie das
Programm gewählt haben und bevor
Sie die Taste START/STOP drücken,
drücken Sie ENTER, um die Zeit mit
den Tasten UP▲/DOWN▼zu
programmieren. In diesem Fall wird
die Programmdauer zwischen den 24
Niveaus aufgeteilt. Drücken Sie
ENTER, um die Distanz zu
programmieren. Drücken Sie erneut
ENTER, um die Kalorien zu
programmieren. Drücken Sie
START/STOP, um die Übung zu
beginnen.
Nach Beginn der Übung können Sie
den Widerstand regulieren, indem Sie
UP▲/DOWN▼drücken.
PROGRAMM MIT
KONSTANTER WATTZAHL
Wählen Sie die Funktion WATT mit
den Tasten UP▲/DOWN▼und
drücken Sie ENTER/MODE. Sie
können die Wattzahl Ihrer Übung
programmieren, indem Sie die Tasten
UP▲/DOWN▼drücken (70 - 310
Watt). Drücken Sie ENTER, um der
Zeit zu programmieren. Drücken Sie
ENTER, um die Distanz zu
programmieren. Drücken Sie erneut
ENTER, um die Kalorien zu
programmieren. Drücken Sie
START/STOP, um die Übung zu
beginnen.

20
Das Niveau der Anstrengung bei der
Übung passt sich automatisch in
Abhängigkeit von der gewählten
Geschwindigkeit und Wattzahl an.
NUTZERPROGRAMM.-
Mit den Tasten UP▲/DOWN▼
wählen Sie die Funktion USER und
drücken Sie ENTER. Wählen Sie den
Nutzer mit den Tasten UP▲/DOWN▼
zwischen U1-U4 und drücken Sie die
Taste ENTER. Drücken Sie die Taste
ENTER 4 Sekunden lang.
Links der Mitte des Displays erscheint
blinkend die erste Säule des
Übungsniveaus. Wählen Sie das
gewünschte Niveau für diese erste
Skala, indem Sie die Tasten
UP▲/DOWN▼drücken und drücken
Sie dann ENTER. Wiederholen Sie
den Vorgang, um die 10 Skalen des
Nutzerprogramms zu programmieren.
Ist das Nutzerprogramm definiert und
vor dem Drücken der Taste
START/STOP drücken Sie die Taste
ENTER 4 Sekunden lang, bis die
Funktion Zeit blinkt. Drücken Sie die
Tasten UP▲/DOWN▼, um die Zeit zu
wählen. Drücken Sie ENTER, um die
Distanz zu programmieren. Drücken
Sie erneut ENTER, um die Kalorien zu
programmieren. Drücken Sie
START/STOP, um die Übung zu
beginnen.
PROGRAMME ZUR
KONTROLLE DER
HERZFREQUENZ.-
Mit den Tasten UP▲/DOWN▼
wählen Sie die Funktion H.R.C und
drücken Sie ENTER. Wählen Sie mit
den Tasten UP▲/DOWN▼die
gewünschte Option (60%, 70%, 85%
oder Tag) und drücken Sie die Taste
ENTER. Die ersten drei geben den
Prozentsatz hinsichtlich der höchsten
Herzfrequenz (220 – Alter) an und die
vierte wird verwendet, um die
Zielfrequenz manuell einzugeben.
Wenn Sie Tag wählen, müssen Sie
die Tasten UP▲/DOWN▼benutzen,
um die gewünschte Herzfrequenz zu
wählen und ENTER drücken. Drücken
Sie START/STOP, um die Übung zu
beginnen. Der Widerstand wird
automatisch gemäss der gewünschten
Pulsfrequenz eingestellt. Ist der
Pulswert unter dem Zielwert, wird der
Widerstand automatisch alle 30
Sekunden erhöht bis zu einem
Höchstwert von 24. Ist der Pulswert
über dem Zielwert, piepst der Monitor
und der Widerstand verringert sich alle
15 Sekunden bis zu dem niedrigsten
Wert 1. Wenn selbst so noch der Puls
länger als 30 Sekunden über dem
Zielwert liegt, stellt sich der Monitor
zum Schutz des Nutzers aus und piept
zur Warnung.
Zum Programmieren von Zeit, Distanz
und Kalorien folgen Sie diesen
Schritten: Nachdem Sie das
Programm der Herzfrequenz gewählt
haben und bevor Sie die Taste
START/STOP drücken, drücken Sie
ENTER, um die Zeit mit den Tasten
UP▲/DOWN▼zu programmieren.
Drücken Sie erneut ENTER, um die
Distanz zu programmieren. Drücken
Sie erneut ENTER, um die Kalorien zu
programmieren. Drücken Sie
START/STOP, um die Übung zu
beginnen.
Bei diesen Programmen müssen die
Hände auf den Pulssensoren (R)
liegen.
Table of contents
Languages:
Other BH Monitor manuals
