BIFFI ICON3000 Series User manual

Installation, Operation and Maintenance Manual
VCIOM-16338-EN Rev. 1
March 2021
Bif ICON3000
Sleep Mode
Copyright © Bif. The information in this document is subject to change without notice. Updated data sheets can be obtained from our website www.bif.it or from your nearest Bif Center:
Bif Italia s.r.l. - Strada Bif 165, 29017 Fiorenzuola d'Arda (PC) – Italy PH: [phone] – bif_italia@bif.it

Installation, Operation and Maintenance Manual
VCIOM-16338-EN Rev. 1
Revision Details
March 2021
Revision Details
Revision Date Description Prepared Checked Approved
1 March 2021 General update (Migration to new template)
0October 2018 First issue M. Burgazzi A. Battaglia
Revision Details

i
Installation, Operation and Maintenance Manual
VCIOM-16338-EN Rev. 1
Table of Contents
March 2021
Table of Contents
Table of Contents
Section 1: Introduction
Introduction ............................................................................................................ 1
Section 2: Conditions to Activate SLEEP Function
Conditions to Activate SLEEP Function ..................................................................... 2
Section 3: Conditions to Switch to SLEEP Mode
Conditions to Switch to SLEEP Function.................................................................... 3
Section 4: Conditions to Exit from SLEEP Mode
Conditions to Exit from SLEEP Function .................................................................... 4
Section 5: SLEEP Mode Status
SLEEP Mode Status................................................................................................... 5
Section 6: Current Consumption
Current Consumption .............................................................................................. 6

Installation, Operation and Maintenance Manual
VCIOM-16338-EN Rev. 1
Notes
March 2021
This page intentionally left blank

Installation, Operation and Maintenance Manual
VCIOM-16338-EN Rev. 1 March 2021
Introduction 1
Section 1: Introduction
Section 1: Introduction
SLEEP is a new function available in the ICON3000 electric actuator which reduces power
consumption from the electronics when the actuator is not moving.
This function is useful when the actuator is powered via battery and solar panel, and if few
valve travel events are expected. In these applications, electrical power is absorbed from
the battery when the motor is running, and when the motor is off the solar panels recharge
the battery and power the actuator’s electronics.
Since the run time of the motor is a small percentage of the total time that the actuator
will spend in the eld, the energy necessary to power the electronics during the motor’s
rest phase is a high percentage of the total energy needed. Reducing energy requirements
when the motor is OFF allows a smaller solar panel to be used.
The gure below demonstrates the utility of the SLEEP function.
Figure 1
Power
Energy absorbed
when motor runs Energy absorbed
when motor runs
Energy savings with SLEEP function ON and motor OFF
Energy absorbed when motor is OFF and SLEEP function is active
Time
Energy with SLEEP function OFF and motor OFF
0

March 2021
Installation, Operation and Maintenance Manual
VCIOM-16338-EN Rev. 1
Conditions to Activate
2
Section 2: Conditions to Activate
Section 2: Conditions to Activate
SLEEP Function
The SLEEP function is activated by the following conditions:
• Parameter SLEEP in the “Actuator Setup” menu, “Restricted” section: ENABLED
• Firmware releases of microprocessors of BASE card:
— >= 9.00 for H8S
— >= 7.00 for PIC
• Firmware release of microprocessors of TERMINAL BOARD card:
— >= 6.0 for PIC
• Parameters SW TYPE in the “Actuator Setup” menu, “Restricted” section: ICON
• Parameter POSITIONER in the “Actuator Setup” menu, “Restricted” section: DISABLED
• Parameter HW CONFIG in the “Actuator Setup” menu, “Restricted” section: BASE
• Parameter BACKLIGHT in the “Actuator Setup” menu, “Restricted” section: AUTO
• Parameter POWER TYPE in the “Nameplate” menu, “Power Supply” section: DC

Installation, Operation and Maintenance Manual
VCIOM-16338-EN Rev. 1 March 2021
Conditions to Switch 3
Section 3: Conditions to Switch
Section 3: Conditions to Switch to
SLEEP Mode
The ICON3000 electronics switch to SLEEP status when:
• 30 seconds after the end of the last command (OPEN, CLOSE, ESD) via remote control
• 2 minutes after the last operation on the local interface of the actuator
(local selector and pushbuttons)
• 30 seconds after closure of Bluetooth or RS232 communication channel
(if present)
• 255 seconds after closure of IrDA communication channel (if enabled)

March 2021
Installation, Operation and Maintenance Manual
VCIOM-16338-EN Rev. 1
4Conditions to Exit
Section 4: Conditions to Exit
Section 4: Conditions to Exit from
SLEEP Mode
The ICON3000 electronics exit from SLEEP status when:
• Command via remote control OPEN, CLOSE, ESD (duration of command: > 0.7 second)
• By operating the actuator local interface (local pushbuttons or selector)
(duration of command: >1 second)
• Change of position > 5% via manual operation (handwheel)
When the ICON3000 exits from SLEEP mode, all functions are restored, and the actuator is
available for normal operation.

Installation, Operation and Maintenance Manual
VCIOM-16338-EN Rev. 1 March 2021
5SLEEP Mode Status
Section 5: SLEEP Mode Status
Section 5: SLEEP Mode Status
In SLEEP mode:
• The alphanumeric display of actuator shows the message “SLEEP”
• Auxiliary relays AS1, AS7 do not change
• Auxiliary relay AS8 is de-energized
• Monitor Relay:
— de-energized if parameter “MR in SLEEP” in “Actuator Setup” menu,
“Restricted” section is “OFF” (with local selector in REMOTE)
— energized if parameter “MR in SLEEP” in “Actuator Setup” menu,
“Restricted” section is “ON” (with local selector in REMOTE)
• Any internal heater on the electronic cards are OFF

March 2021
Installation, Operation and Maintenance Manual
VCIOM-16338-EN Rev. 1
6Current Consumption
Section 6: Current Consumption
Section 6: Current Consumption
Minimum current consumption is obtained via the following conguration:
• Actuator without 4 - 20 mA position re-transmission card
• Parameter “MR in SLEEP” in “Actuator Setup” menu, “Restricted” section in “OFF”
In the above condition, the current consumption measured by a multimeter (on average on
an ICON3000 supplied at 24 V DC) is 58 mA, corresponding to 1.4 W (at 24 V DC).
If the actuator is equipped with a 4 - 20 mA position transmitter module, the current
consumption is 78 mA.
If the parameter “MR in SLEEP” in “Actuator Setup” menu, “Restricted” section is in “ON”,
the current consumption is 98 mA (2.4 W at 24 V DC).
When actuator exits from SLEEP mode, all ICON3000 functions are restored to normal
operation and the current consumption returns to normal.
