BiPAC 5102G
802.11g ADSL2+ Router
▲BiPAC 5102G
z802.11g Wireless Access Point with WEP support
zHigh speed Internet access with ADSL2/2+; backward compatible
to ADSL
zIntegrated with 4-port Ethernet Switch
zEasy Network Management
zSOHO Firewall Security with NAT Technology and Packet
Filtering
zUniversal Plug and Play (UPnP) Compliant
zDynamic Domain Name System (DDNS)
zSupport Virtual Private Network (VPN) pass-through
zIdeal for Residential Users
Benefits
Express Internet Access
The BiPAC 5102G complies with ADSL worldwide standards. It supports basic downstream rate of 8Mbps with
ADSL, capable of up to 12/24 Mbps with ADSL2 / ADSL2+, and upstream rate up to 1 Mbps. Users enjoy not
only high-speed ADSL services but also wider range of broadband multimedia applications such as interactive
gaming, video streaming and real-time audio much easier and faster than ever.
Security
Powered by NAT technology integrated in BiPAC 5102G, dozens of users not only surf Internet and share the
ADSL connection simultaneously by using one ISP account and one IP address, but are also protected by
natural NAT firewall from potential hacker attacks. In addition to NAT technology, the BiPAC 5102G supports
Packet Filtering feature for higher-level security control.
Easy Network Management
The Web-based User Interface makes the BiPAC 5102G extremely easy for users to install and manage the
network. With DHCP client and server built-in, system administrators can easily attach this security router into
existing network and manage the IP assignment without re-configuring other stations. Furthermore, future
firmware upgrade can be done via friendly Web-based User Interface.
Mobility
With integrated 802.11g Wireless Access Point in the BiPAC 5102G, the device offers quick and easy access
among wired network, wireless network and broadband connection (ADSL) with single device simplicity. In
addition to providing 54 Mbps 802.11g link rate, it can also interoperate backward with existing 802.11b
equipments. The wireless connection makes a home user to enjoy the mobility to place a PC device anywhere
they want to go online.
BiPAC 5102G
Billion’s BiPAC 5102G is an economical model of router designed with 802.11g Wireless AP for home
users to enjoy high-speed broadband access. It provides high speed Internet access with ADSL, even
faster with ADSL2+ standard for downstream speed up to 24Mbps. NAT Firewall and Packet Filtering
features help protect every data transmission against hackers’ attack. Its network management is easy
with Graphic User Interface. BiPAC 5102G makes fast net-surfing affordable and easy to go online, just
‘plug & play’.

BiPAC 5102G
Feature & Specification
ADSL Compliance
• Compliant with ADSL Standard
-Full-rate ANSI T1.413 Issue 2
-G.dmt (ITU G.992.1)
-G.lite (ITU G.992.2)
-G.hs (ITU G.994.1)
-ADSL over ISDN/U-R2
•Compliant with ADSL2 Standard
-G.dmt.bis (ITU G.992.3)
•Compliant with ADSL2+ Standard
-G.dmt.bisplus (ITU G.992.5)
Network Protocols and Features
• NAT, static routing and RIP-1/2
• NAT supports PAT and multimedia applications
• Multi-to-multi NAT
• Transparent Bridging
• Dynamic Domain Name System (DDNS)
• SNTP
• DNS relay
Firewall & Virtual Private Network (VPN)
• Built-in NAT Firewall
• Packet filtering
• Password protection for system management
• VPN pass through
Operating Environment
• Operating temperature: 0 ~ 40 ℃
• Storage temperature: -20 ~ 70 ℃
• Humidity: 20 ~ 95% non-condensing
Application Diagram
Wireless 802.11g
• Compliant with IEEE 802.11g and 802.11b
standards
• 2.4 GHz – 2.484G Hz frequency range
• Up to 54 Mbps wireless operation rate
• 64/128 bits WEP supported for encryption
ATM and PPP Protocols
• ATM Adaptation Layer Type 5 (AAL5)
• Multiple Protocol over AAL5 (RFC 2684, formerly
RFC 1483)
• Bridged or routed Ethernet encapsulation
• VC and LLC based multiplexing
• PPP over Ethernet (PPPoE)
• PPP over ATM (RFC 2364)
• OAM F4/F5
Management
• Web-based configuration
• Firmware upgraded and configuration data upload
and download via HTTP/FTP
• Embedded Telnet server for remote and local
management
• SNMP v2 MIB supported
• Support DHCP server/client/relay
Hardware Specification
Physical Interface
• WLAN: fixed antenna
• LINE: ADSL port
• LAN: 4port 10/100M auto-crossover (MDI/MDI-X)
switch
• Factory default reset button
• Power jack
• Power switch
Physical Specification
•Dimensions: 7.09" x 4.72" x 1.57”
(180mm x 120mm x 40mm)
Power Requirement
•Input: 12V DC, 1A
Billion Electric Co., Ltd.
8F, No. 192, Sec. 2, Chung Hsing Road,
Hsin Tien City, Taipei County, Taiwan
TEL: [phone]
FAX: [phone]
www.billion.com
Specifications are subject to changes without notice.
Wireless WEP
(
ADSL2/2+
)
Firewall
~The router may require firmware modification for certain
ADSL2/2+ DSLAMS.
