Billion BiPAC 5200W User manual

BiPAC 5200W
BiPAC 7300W
Wireless-N
ADSL2+ Firewall Router
Quick Start Guide

Billion BiPAC 5200W/ 7300W Wireless-N ADSL2+ Firewall Router
1
P
Pa ac ck ka ag ge e C Co on nt te en nt ts s
BiPAC 5200W/ 7300W ADSL2+ Firewall Router
CD containing the on-line manual and QSG
RJ-11 ADSL/ telephone cable
Ethernet (RJ-45) cable
Power adapter
Quick Start Guide
Splitter/ Micro-filter (Optional)
A
At tt te en nt ti io on n
W Wa ar rn ni in ng g
PLEASE READ THE QUICK START GUIDE AND FOLLOW THE
STEPS CAREFULLY. THIS QUICK START GUIDE WILL HELP YOU
INSTALL THE DEVICE PROPERLY AND AVOID IMPROPER USAGE.
IF YOU NEED MORE INFORMATION ON THIS SOFTWARE
CONFIGURATION, PLEASE REFER TO THE USER MANUAL ON
THE CD-ROM.
Do not use the router in high humidity or high temperatures.
Do not use the same power source for the router as other
equipment.
Do not open or repair the case yourself. If the router is too hot,
turn off the power immediately and have it repaired at a qualified
service center.

Avoid using this
product
and all
accessories
outdoors.
Place the router on a stable surface.
Only use the power adapter that comes with the package. Using a
different voltage rating power adaptor may damage the router.

Quick Start Guide
2
H
Ha ar rd dw wa ar re e O Ov ve er rv vi ie ew w
The Front LEDs
The Rear Ports
* Note 1. For advanced reset and restore setting, please refer to user manual.
2. For WPS configuration, please refer to the WPS section of User Manual.
Connect with the
supplied power
adapter.
Connect the supplied
RJ-11 cable to this
port when
connecting to the
ADSL/telephone
network.
(
(
i
i
P
P
A
A
C
C
7
7
3
3
0
0
0
0
W
W
O
O
n
n
l
l
y
y
)
)
(
(1 1) ) W WP PS S: : P Pr re es ss s 2 2- -6 6 s se ec co on nd ds s until W WP PS S L LE ED D
flashes green to trigger WPS function. *2
(
(2 2) ) W Wi ir re el le es ss s O ON N/ /O OF FF F S Sw wi it tc ch h: : P Pr re es ss s o ov ve er r 6 6
s
se ec co on nd ds s after WPS LED is off to switch on
wireless function. Press over 6 seconds again
for disable wireless function.
(
( i iP PA AC C 7 73 30 00 0W W O On nl ly y) )
WPS: Flash green when
WPS configuration is in
progress.
Lit red when WAN port
fails to get IP address.
Lit green when WAN
port gets IP address
successfully.
Connect your
computer to a
LAN port with
the included
Ethernet cable.
Power
ON/OFF
switch
Lit red when power is on.
Lit green when the
system is ready.
Lit when connected to an Ethernet
device. Lit green when the speed of
transmission hits 10/100Mbps;
link when data is being
Transmitted / Received.
Lit green when a wireless
connection is established.
link when data is being
sent / received.
Lit green when the device
is successfully connected
to an ADSL DSLAM. (“Line
sync”).
When the device power
is on, press to reset or to
restore its factory
default setting. *1
Antenna
(
(
i
i
P
P
A
A
C
C
7
7
3
3
0
0
0
0
W
W
O
O
n
n
l
l
y
y
)
)
E
EW WA AN N: : I It t o of ff fe er rs s i it ts s E Et th he er rn ne et t
p
po or rt t # #1 1 as a WAN port for
connecting to Cable Modem,
VDSL, fiber modem or PON
optic lines with RJ-45 cable.

Billion BiPAC 5200W/ 7300W Wireless-N ADSL2+ Firewall Router
3
H
Ha ar rd dw wa ar re e C Co on nn ne ec ct ti io on n
BiPAC 5200W
BiPAC 7300W – ADSL Router Mode
BiPAC 7300W – Broadband Router Mode

Quick Start Guide
4
H
Ha ar rd dw wa ar re e I In ns st ta al ll la at ti io on n
1. Power Connection
Plug the supplied power adapter to the wall jack and the other side to the router.
Please note that the plug type may differ according to country.
2. LAN Connection
Connect the supplied RJ-45 Ethernet cable to one of the Ethernet ports, and the other
side to the PC’s Ethernet interface.
3. ADSL Connection
Connect the supplied RJ-11 phone cable to the router’s ADSL port, and the other side
to the phone jack on the wall.
4. EWAN Connection (BiPAC 7300W only)
Connect RJ-45 Ethernet cable to the Ethernet port # 1 (EWAN), and connect the
other side to another alternative broadband device, such as Cable Modem, VDSL,
Fiber Modem or PON optic lines. Please refer to User Manual for detail instruction.

Billion BiPAC 5200W/ 7300W Wireless-N ADSL2+ Firewall Router
5
5. Splitter/ Micro-filter Connection
Splitter / Micro-filter are important for ADSL installation. High-frequency signals are
directed to the ADSL modem, and low-frequency signals are directed to the
telephone or other analog voice-channel device to prevent inter-modulation
distortion and also to get good speed and stable ADSL sync rate.
a) Splitter connection
If the installation has only a single telephone and a single ADSL modem, then a
splitter can be employed.
b) Micro-filter connection
If the installation has several telephones or other analog devices, then an internal
micro-filter can be employed at each analog device.
S
Se et tu up p U Ut ti il li it ty y ( (B Bi iP PA AC C 5 52 20 00 0W W O On nl ly y) )
After you complete the hardware installation insert CD into the CD Drive to run the setup utility.
The setup utility will auto-run. Follow the step-by-step configuration wizard and it will guide you
to setting up the basic network configuration.
E
Ea as sy y S Si ig gn n- -O On n ( (B Bi iP PA AC C 7 73 30 00 0W W O On nl ly y) )
Make sure power on the device, Ethernet cable is connected to your PC and ADSL line is in
sync. Then open up a web browser and you will automatically be directed to the step-by-step
easy sign on configuration wizard which will guide you to complete the basic network
configuration to connect to the internet.

Quick Start Guide
6
C
Co on nn ne ec ct ti in ng g t to o t th he e R Ro ou ut te er r
1. Open the web browser and type h ht tt tp p: :/ // /1 19 92 2. .1 16 68 8. .1 1. .2 25 54 4in the browser's address box. This
number is the default IP address for this router. Press Enter.
2. A username and password window will appear. The default u us se er rn na am me e i is s “ “a ad dm mi in n” ”,
p
pa as ss sw wo or rd d i is s “ “a ad dm mi in n” ”. Press OK to proceed.
3. You will get a status report web page and main menu screen.
Please see the relevant sections of user manual for detailed instructions on how to
configure your router.
T
Tr ro ou ub bl le es sh ho oo ot ti in ng g
1. None of the LEDs are on when you turn on the router.
Check the connection between the adapter and the router. If the error persists, you may have
a hardware problem. In this case you should contact technical support.
2. Can’t ping any PCs on the LAN.
Check the Ethernet LEDs on the front panel. The LED should be on for a port that has a PC
connected. If it is off, check the cables between your router and the PC. Make sure you have
uninstalled any software firewall for troubleshooting. Verify that the IP address and the subnet
mask are consistent between the router and the workstations.
3. Frequent loss of ADSL line sync (disconnections).
Ensure that all other devices connected to the same telephone line as your router (e.g.
telephones, fax machines, analogue modems) have a line filter connected between them and
the wall socket (unless you are using a Central Splitter or Central Filter installed by a qualified
and licensed electrician), and ensure that all line filters are correctly installed and the right
way around. Missing line filters or line filters installed the wrong way around can cause
problems with your ADSL connection, including causing frequent disconnections. If you have
a back-to-base alarm system you should contact your security provider for a technician to
make any necessary changes.
P
Pr ro od du uc ct t S Su up pp po or rt t a an nd d C Co on nt ta ac ct t I In nf fo or rm ma at ti io on n
Most problems can be solved by referring to the Troubleshooting section in the User Manual.If
you cannot resolve the problem with the Troubleshooting chapter, please contact the dealer
where you purchased this product.
C
Co on nt ta ac ct t B Bi il ll li io on n
WORLDWIDE
http://www.billion.com
B
Bi il ll li io on n P Pr ro od du uc ct t R Re eg gi is st tr ra at ti io on n
Billion is committed to before and after sales customer services. You will get the most out of your Billion's products
after registration. Please register online at http://www.billion.com/register to receive valuable services and
support from us.
