Billion BiPAC 7402R2 User manual

BiPAC 7402R2
ADSL2+ VPN Firewall Router
Quick Start Guide

Billion BiPAC 7402R2 ADSL2+ VPN Firewall Router
For more detailed instructions on configuring and using
the ADSL2+ VPN Firewall Router, please refer to the on-
line manual.
Package Contents
BiPAC 7402R2 ADSL2+ VPN Firewall Router
CD-ROM containing the online manual
RJ-11 ADSL/telephone Cable
Ethernet (CAT-5 LAN) Cable
Console (PS2-RS232) Cable
AC-DC power adapter (12VDC, 1A)
This Quick Start Guide
A
ttention
 Place this router on a stable surface.
 Only use the power adapter that comes with the package.
Using a different voltage rating power adaptor may damage
this router.
Warning
 Do not use this router in high humidity or high
temperatures.
 Do not use the same power source for this router as othe
r
equipment.
 Do not open or repair the case yourself. If this router is too
hot, turn off the power immediately and have it repaired at a
qualified service center.
 Avoid using this product and all accessories outdoors.
1

Quick Start Guide
The Front LEDs
LED Meaning
PPP / MAIL
Lit steady when there is a PPPoA / PPPoE connection.
Lit and flashed periodically when there is email in the Inbox.
ADSL When lit, it indicates that the ADSL (Line) port is connected to the DSLAM
and working properly.
LAN Port
1X — 4X
(RJ-45 connector)
Lit when the LAN link is connected to an Ethernet device.
Green for 100Mbps; Orange for 10Mbps.
Blinking when data is Transmitted / Received.
SYS Lit when the system is ready.
PWR Lit when power is ON.
2

Billion BiPAC 7402R2 ADSL2+ VPN Firewall Router
The Rear Ports
3
1
43
5 2
6
Port Meaning
1 Power Switch Power ON/OFF switch
2 PWR Connect the supplied power adapter to this jack.
3 RESET
After the device is powered on, press it to reset the device or
restore to factory default settings.
0-3 seconds: reset the device
6 seconds above: restore to factory default settings (this is used
when you can not login to the router, e.g. forgot the password)
4 LAN 1X — 4X
(RJ-45 connector)
Connect a UTP Ethernet cable (Cat-5 or Cat-5e) to one of the
four LAN ports when connecting to a PC or an office/home
network of 10Mbps or 100Mbps.
5 CONSOLE Connect a PS2/RS-232 cable to this port when connecting to a
PC’s RS-232 port (9-pin serial port).
6 LINE Connect the supplied RJ-11 (“telephone”) cable to this port when
connecting to the ADSL/telephone network.

Quick Start Guide
Connecting Your ADSL Router
1. Connect the Router to a LAN (Local Area Network) and the ADSL/telephone (LINE) network.
2. Power on the device.
3. Make sure the PWR and SYS LEDs are lit steadily and that the relevant LAN LED is lit.
4

Billion BiPAC 7402R2 ADSL2+ VPN Firewall Router
Configuring PC in Windows XP
1. Go to Start / Control Panel (in Classic
View). In the Control Panel, double-click on
Network Connections
2. Double-click Local Area Connection.
3. In the Local Area Connection Status
window, click Properties.
4. Select Internet Protocol (TCP/IP) and click
Properties.
5. Select the Obtain an IP address
automatically and the Obtain DNS server
address automatically radio buttons.
6. Click OK to finish the configuration.
5

Quick Start Guide
Configuring PC in Windows 2000
1. Go to Start / Settings / Control Panel. In the
Control Panel, double-click on Network and
Dial-up Connections.
2. Double-click Local Area Connection.
3. In the Local Area Connection Status window
click Properties.
4. Select Internet Protocol (TCP/IP) and click
Properties.
5. Select the Obtain an IP address
automatically and the Obtain DNS server
address automatically radio buttons.
6. Click OK to finish the configuration.
6

Billion BiPAC 7402R2 ADSL2+ VPN Firewall Router
Configuring PC in Windows 98/Me
1. Go to Start / Settings / Control Panel. In the
Control Panel, double-click on Network and
choose the Configuration tab.
2. Select TCP/IP ->
NE2000 Compatible, or the name of your
Network Interface Card (NIC) in your PC.
3. Select the Obtain an IP address
automatically radio button.
4. Then select the DNS Configuration tab.
5. Select the Disable DNS radio button and click
OK to finish the configuration.
7

Quick Start Guide
Configuring PC in Windows NT4.0
1. Go to Start / Settings / Control Panel. In the
Control Panel, double-click on Network and
choose the Protocols tab.
2. Select TCP/IP Protocol and click Properties.
3. Select the Obtain an IP address from a
DHCP server radio button and click OK.
8

Billion BiPAC 7402R2 ADSL2+ VPN Firewall Router
Configuring Your ADSL2+ VPN Firewall Router
To configure this device, you must have IE 5.0
/
Netscape 4.5 or above installed
Connecting to the Router
1. Open the web browser and type
http://192.168.1.254 in the browser’s
address box. This number is the default IP
address for this router. Press Enter.
2. A user name and password window will
appear. The default User Name and
Password are “admin” and” admin”.
Press OK to logon to the router.
3.
You will get a status report web page and main menu screen.
9
Navigation panel

Quick Start Guide
At the main menu screen, the left navigation panel where bookmarks are provided links you
directly to the desired setup page, including:
 Status (ARP Table, Routing Table, DHCP Table, PPTP Status, IPSec Status, L2TP Status,
Email Status, Event Log, Error Log, NAT Sessions and UPnP Portmap)
 Quick Start
 Configuration (LAN, WAN, System, Firewall, VPN, QoS, Virtual Server, Time Schedule
and Advanced)
 Save Config to FLASH
 Language (provides user interface in English and French languages).
Please see the relevant sections of on-line manual for detailed instructions
on how to configure your router.
Verifying Your Local Network Connection with the Device
To see if this ADSL Router is
visible on the local network, go
to Start / Run.In the Run dialog
box, type “ping 192.168.1.254”
then press OK.
A command prompt window will
pop out. If your ping is
successful which means your
local network is able to reach to
the device, then the command
prompt window will close up
automatically.
Connection fails, when you see
“Request timed out” in the
command prompt window. You
may need to check your set up.
10

Billion BiPAC 7402R2 ADSL2+ VPN Firewall Router
Product Support and Contact Information
Most problems can be solved by referring to the Troubleshooting section in the User’s
Manual.If you cannot resolve the problem with the Troubleshooting chapter, please contact
the dealer where you purchased this product.
Contact Billion
AUSTRALIA
http://www.billion.com.au
©
2005 Billion Electric Co Ltd., PC Range P/L. All Rights Reserved.
WORLDWIDE
http://www.billion.comT
11
