Billion BiPAC 5210S User manual

BiPAC 5210S
Dual-Port
ADSL2+ Modem/Router
User’s Manual

Chapter 1 ................................................................................................ 1
1.1 Introducing the BiPAC 5210S ................................................1
1.2 Features of the BiPAC 5210S................................................3
Chapter 2 ................................................................................................ 6
2.1 Important note for using the BiPAC 5210S............................6
2.2 Package Contents .................................................................6
2.3 The Front LEDs .....................................................................7
2.4 The Rear Ports ......................................................................8
2.5 Cabling ..................................................................................9
Chapter 3 .............................................................................................. 10
3.1 Before Configuration............................................................10
3.2 Factory Default Settings ......................................................23
3.3 LAN and WAN PortAddresses............................................24
3.4 Information from your ISP....................................................24
3.5 Configuring with your Web Browser ....................................25
Chapter 4 .............................................................................................. 26
4.1 Quick Start...........................................................................27
4.2 Interface Setup ....................................................................32
4.3 Advanced Setup...................................................................38
4.4 Access Management ...........................................................47
4.5 Maintenance........................................................................53
4.6 Status...................................................................................58
Chapter 5 .............................................................................................. 63
APPENDIX.............................................................................................65
ii

Chapter 1
Introduction the BiPAC 5210S
1.1 Introducing the BiPAC 5210S
Welcome to the BiPAC 5210S. Your router is an “all-in-one” unit, combining an ADSL
modem, ADSLrouter and Ethernet network switch, providing everything you need to get the
machines on your network connected to the Internet over your ADSLbroadband connection.
The BiPAC 5210S complies with ADSL2+ standards for worldwide deployment and supports
downstream rates of up to 24 Mbps and upstream rates of up to 1 Mbps. It is designed for
small office, home office and residential users, enabling even faster speed Internet
connections. User can enjoy ADSLservices and broadband multimedia applications such as
interactive gaming, video streaming and real-time audio much easier and faster than ever
before.
The product supports PPPoA (RFC 2364 – PPP (Point-to-Point Protocol) over ATM
Adaptation Layer 5), RFC 1483 encapsulation over ATM (bridged or routed), PPP over
Ethernet (RFC 2516), and IPoA (RFC1577) to establish a connection with ISP. The product
also supports VC-based and LLC-based multiplexing.
It is the perfect solution to connect a small group of PCs to a high-speed broadband Internet
connection. Multi-users can have high-speed Internet access simultaneously.
This product also serves as an Internet firewall, protecting your network from being
accessed by outside users. Not only provide the natural firewall function (NetworkAddress
Translation, NAT), it also provides rich firewall features to secure user’s network.All
incoming data packets are monitored and filtered. Besides, it can also be configured to
block internal users from accessing to the Internet.
The product provides two levels of security support. First, it masks LAN users’IPaddresses
which are invisible to outside users on the Internet, making it much more difficult for a hacker
to target a machine on your network. Secondly, it can block and redirect certain ports to limit

the services that outside users can access. For example, to ensure that games and other
Internet applications will run properly, user can open some specific ports for outside users to
access internal services in network.
Integrated DHCP (Dynamic Host Control Protocol) services, client and server, allow multiple
users to get their IP addresses automatically on boot up from the product. Simply set local
machines as a DHCP client to accept a dynamically assigned IP address from DHCP server
and reboot. Each time local machine is powered up; the router will recognize it and assign
an IP address to instantly connect it to theLAN.
For advanced users, Virtual Service function allows the product to provide limited visibility to
local machines with specific services for outside users. An ISP (Internet Service Providers)
provided IP address can be set to the product and then specific services can be rerouted to
specific computers on the local network. For instance, a dedicated web server can be
connected to the Internet via the product and then incoming requests for HTML that are
received by the product can be rerouted to the dedicated local web server, even though the
server now has a different IP address. In this example, the product is on the Internet and
vulnerable to attacks, but the server is protected.
Virtual Server can also be used to re-task services to multiple servers. For instance, the
product can be set to allow separated FTP, Web, and Multiplayer game servers to share the
same Internet-visible IP address while still protecting the servers and LAN users from
hackers.
2

1.2 Features of the BiPAC 5210S
ADSL Multi-Mode Standard
supports downstream rates of up to 24 Mbps and upstream rates of up to 1 Mbps. It
also supports rate management that allowsADSL subscribers to select an Internet
access speed suiting their needs and budgets. It is compliant with Multi-Mode standard
(ANSI T1.413, Issue 2; G.dmt(G.992.1); G.lite(G992.2)), G.hs (G994.1), G.dmt.bis
(G.992.3), G.dmt.bisplus (G.992.5)). The Annex Aand B are supported in different H/W
platforms.
Fast Ethernet Switch
A 10/100Mbps fast Ethernet switch is built in with automatic switching between MDI
and MDI-X for 10Base-T and 100Base-TX ports. An Ethernet straight or cross-over
cable can be used directly for auto detection.
Multi-Protocol to Establish A Connection
Supports PPPoA (RFC 2364 - PPP over ATM Adaptation Layer 5), RFC 1483
encapsulation overATM (bridged or routed), PPP over Ethernet (RFC 2516) and IPoA
(RFC1577) to establish a connection with the ISP. The product also supports
VC-based and LLC-based multiplexing.
Quick Installation Wizard
Supports a WEB GUI page to install this device quickly. With this wizard, end users can
enter the information easily which they get from their ISP, then surf the Internet
immediately.
Universal Plug and Play (UPnP) and UPnP NAT Traversal
This protocol is used to enable simple and robust connectivity among stand-alone
devices and PCs from many different vendors. It makes network simple and affordable
for users. UPnP architecture leverages TCP/IP and the Web to enable seamless
proximity networking in addition to control and data transfer among networked devices.
With this feature enabled, users can now connect to Net meeting or MSN Messenger
seamlessly.
Network Address Translation (NAT)
Allows multi-users to access outside resources such as the Internet simultaneously
with one IP address/one Internet access account. Many application layer gateway
(ALG) are supported such as web browser, ICQ, FTP, Telnet, E-mail, News,
Net2phone, Ping, NetMeeting, IP phone and others.
Firewall
3

Supports simple firewall with NAT technology and provides option for blocking access
from Internet, like Telnet, FTP, TFTP, WEB, SNMP and IGMP.
Domain Name System (DNS) relay
Provides an easy way to map the domain name (a friendly name for users such as
www.yahoo.com) and IP address. When a local machine sets its DNS server with this
router’s IP address, every DNS conversion request packet from the PC to this router
will be forwarded to the real DNS in the outside network.
Dynamic Domain Name System (DDNS)
The Dynamic DNS service allows you to alias a dynamic IP address to a static
hostname. This dynamic IP address is the WAN IP address. For example, to use the
service, you must first apply for an account from a DDNS service like
http://www.dyndns.org/.
PPP over Ethernet (PPPoE): Provides embedded PPPoE client function to establish a
connection. Users can get greater access speed without changing the operation
concept, sharing the same ISP account and paying for one access account. No PPPoE
client software is required for local computer. The Automatic Reconnect and Disconnect
Timeout (Idle Timer) functions are provided, too.
Virtual Server: User can specify some services to be visible from outside users. The
router can detect incoming service request and forward it to the specific local computer
to handle it. For example, user can assign a PC in LAN acting as WEB server inside and
expose it to the outside network. Outside user can browse inside web server directly
while it is protected by NAT. A DMZ host setting is also provided to a local computer
exposed to the outside network, Internet.
Users can specify some services to be visible from outside users. The router can
detect incoming service requests and forward either a single port or a range of ports to
the specific local computer to handle it. For example, a user can assign a PC in the
LAN acting as a WEB server inside and expose it to the outside network. Outside users
can browse inside web servers directly while it is protected by NAT. ADMZ host setting
is also provided to a local computer exposed to the outside network, Internet.
Dynamic Host Configuration Protocol (DHCP) client and server
In the WAN site, the DHCP client can get an IP address from the Internet Service
Provider (ISP) automatically. In the LAN site, the DHCP server can allocate a range of
client IP addresses and distribute them including IP address, subnet mask as well as
DNS IP address to local computers. It provides an easy way to manage the local IP
network.
4

RIP1/2 Routing
Supports RIP1/2 routing protocol for routing capability.
Simple Network Management Protocol (SNMP)
It is an easy way to remotely manage the router via SNMP.
Web based GUI
Supports web based GUI for configuration and management. It is user-friendly and
comes with on-line help. It also supports remote management capability for remote
users to configure and manage this product.
Firmware Upgradeable
Device can be upgraded to the latest firmware through the WEB based GUI.
5

Chapter 2
Installing the BiPAC 5210S
2.1 Important note for using the BiPAC 5210S
Warning
 Do not use the BiPAC 5210S in high humidity or high
temperatures.
 Do not use the same power source for the BiPAC 5210S as
other equipment.
 Do not open or repair the case yourself. If the BiPAC 5210S is
too hot, turn off the power immediately and have it repaired a
t
a qualified service center.

A
void usin
g
this
p
roduct and all accessories outdoors.
Attention
 Place the BiPAC 5210S on a stable surface.
 Only use the power adapter that comes with the package. Using
a different voltage rating power adaptor may damage the router.
2.2 Package Contents
BiPAC 5210S ADSL2+ Modem/Router
CD-ROM containing the online manual
RJ-11 ADSL/telephone Cable (1.8M)
Ethernet (CAT-5 LAN) Cable (2M Straight)
USB Cable (1.5M)
AC-AC power adapter (12V AC, 1A)
Quick Start Guide (105*150*mm)
6

2.3 The Front LEDs
LED Meaning
1 PPP : Lit steady when there is a PPPoA / PPPoE connection.
2 ADSL: Lit when successfully connected to an ADSL DSLAM (“linesync”)
3 USB: Lit when the USB port is connected to the PC and working properly
4 LAN Port :
Lit when connected to an Ethernet device.
Green for 100Mbps; Orange for 10Mbps.
Blinking when data is Transmitted / Received.
5 SYS : Lit when the system is ready.
6 PWR : Lit when power is ON.
7

2.4 The Rear Ports
6
5
4
3
1
2
Port Meaning
1 Power Switch Power ON/OFF switch
2 POWER Connect the supplied power adapter to this jack.
3 RESET
After the device is powered on, press it to reset the device or
restore to factory default settings.
0-3 seconds: reset the device
6 seconds above: restore to factory default settings (this is used
when you can not login to the router, e.g. forgot the password)
4 LAN Connect a UTP Ethernet cable (Cat-5 or Cat-5e) to the LAN ports
when connecting to a PC or an office/home network of 10Mbps or
100Mbps.
5 USB Connect the supplied USB cable to this port when connecting to the
PC
6 ADSL Connect the supplied RJ-11 (“telephone”) cable to this port when
connecting to the ADSL/telephone network.
8

2.5 Cabling
Through USB Port
The product can be used as a Network Adapter on your PC. That means you do not have to
install a network adapter first on your PC before connecting theADSL Modem/Router. Just
connect the supplied USB cable to the USB port of the ADSL2+ Modem/Router and connect
the other end to the PC.
Make sure that your ADSLModem/Router and PC are turned on. On the front of the product
is a bank of LEDs. As a first check, please verify that the PWR, SYS, USB and ADSL LEDs
are lit.
So long as the cables are connected and the LEDs are lit normally, follow section “Installing
the USB Driver” below to setup this device.
Through Ethernet Port
The product’s LAN port is wired just like a NetworkAdapter’s port. From the product directly
to a PC, the cable should be an Ethernet crossover cable. From the product to a hub or
switch, the cable should be an Ethernet straight through cable to a normal hub/switch port,
or an Ethernet crossover cable to an uplink port.
The most common problem associated with Ethernet is bad cabling or ADSLline. Make sure
that all connected devices are turned on. On the front of the product is a bank of LEDs. As a
first check, please verify that the PWR, LAN LNK and ADSLSYN LEDs are lit. If they are not,
verify that you are using the proper cables.
So long as the cables are connected and the LEDs are lit normally, follow section
“Configuring the Network Properties” below to modify the network settings.
Attention
 Since the product cannot auto-detect whether your cable is
correct or not, please make sure you are using the right
cable to a PC or a Hub..
9

Chapter 3
Basic Installation
The router can be configured with your web browser. A web browser is included as a
standard application in the following operating systems: Windows 98/NT/2000/XP/Me, etc.
The product provides a very easy and user-friendly interface for configuration.
3.1 Before Configuration
PCs must have an Ethernet interface installed properly and be connected to the router either
directly or through an external repeater hub, and have TCP/IP installed and configured to
obtain an IP address through a DHCP server or a fixed IP address that must be in the same
subnet as the router. The default IP address of the router is 192.168.1.254 and the subnet
mask is 255.255.255.0 (i.e. any attached PC must be in the same subnet, and have an IP
address in the range of 192.168.1.1 to 192.168.1.253). The best and easiest way is to
configure the PC to get an IP address automatically from the router using DHCP. If you
encounter any problems accessing the router’s web interface it may also be advisable to
uninstall any kind of software firewall on your PCs, as they can cause problems accessing
the 192.168.1.254 IP address of the router. Users should make their own decisions on how
to best protect their network.
Please follow the steps below for your PC’s network environment installation. First of all,
please check your PC’s network components. The TCP/IP protocol stack and Ethernet
network adapter must be installed. If not, please refer to your Windows-related or other
operating system manuals.
A
ny TCP/IP capable workstation can be used to communicate with o
r
through the ADSL2+ Modem/Router. To configure other types o
f
workstations, please consult the manufacturer’s documentation.
10

Installing the USB Driver
If you connect the device through USB port instead of Ethernet port, for the first time the
USB cable is connected to the PC, Windows will automatically detect the device. Follow the
steps to install the USB driver.
For Windows XP & 2000：
1. Start Windows. Then insert the installation CD into the CD-ROM drive. In next window,
to specify the driver directory such as “G:\USB Driver\setupXP2K_En_De_Fi” and to
continue.
2. To choose the setup language. ”and click “Next >”. (There are three languages that
user can choose: English. German and French)
11

3. Then follow screen.
4. To click the type of setup you prefer, then click Next >.
12

5. To setup enough information of coping the program files then click Next >.
6. Please plug USB cable into ADSL USB Modem.
13

7. Then, click “Finish”.
14

For Windows 98 & Me：
1. Start Windows. Then insert the installation CD into the CD-ROM drive. In next window,
to specify the driver directory such as “G:\USB Driver\setup98 Me_En_De_Fi” and to
continue.
2. To choose the setup language. ”and click “Next >”. (There are three languages that
user can choose: English. German and French)
15

3. Then follow screen.
4. To click the type of setup you prefer, then click Next >.
16

5. To setup enough information of coping the program files.
6. Select “Want to restart my computer now” and click OK>
17

7. Then, click “Finish”.
18
