Billion BEC MX-1000 User manual

Last revised date: June 18, 2015
BEC MX-1000
MXConnect M2M
Advanced In-Vehicle 4G LTE
Wireless Router
User Manual
Version release: 1.01.1.8_v1

Table of Contents
Chapter 1: Introduction ..............................................................................................................................4
Introduction to your Router....................................................................................................................4
Features & Specifications........................................................................................................................6
Hardware Specifications .........................................................................................................................9
Application Diagram............................................................................................................................. 10
Chapter 2: Product Overview .................................................................................................................... 11
Important Note for Using This Router....................................................................................................11
Device Description................................................................................................................................ 12
The detail instruction in Reset Button ...................................................................................................15
Cabling................................................................................................................................................. 16
Chapter 3: Basic Installation ..................................................................................................................... 17
Network Configuration –IPv4 ............................................................................................................... 18
Configuring PC in Windows 7/8 (IPv4)..........................................................................................................18
Configuring PC in Windows Vista (IPv4)......................................................................................................20
Configuring PC in Windows XP (IPv4)..........................................................................................................22
Network Configuration –IPv6 ............................................................................................................... 23
Configuring PC in Windows 7/8 (IPv6)..........................................................................................................23
Configuring PC in Windows Vista (IPv6)......................................................................................................25
Configuring PC in Windows XP (IPv6)..........................................................................................................27
Default Settings....................................................................................................................................28
Information from Your ISP .................................................................................................................... 29
Chapter 4: Device Configuration ...............................................................................................................30
Login to your Device ............................................................................................................................. 30
Status................................................................................................................................................... 32
Device Info ...................................................................................................................................................33
System Log ...................................................................................................................................................35
3G/4G-LTE Status..........................................................................................................................................36
GPS Status....................................................................................................................................................37
Hardware Monitor .......................................................................................................................................38
Statistics.......................................................................................................................................................39
DHCP Table...................................................................................................................................................43
Disk Status....................................................................................................................................................44
IPSec Status..................................................................................................................................................45
PPTP Status ..................................................................................................................................................46
L2TP Status...................................................................................................................................................47
GRE Status....................................................................................................................................................48
Quick Start ........................................................................................................................................... 49
Configuration ....................................................................................................................................... 52

Interface Setup ............................................................................................................................................53
Internet ....................................................................................................................................................54
LAN...........................................................................................................................................................60
Wireless ...................................................................................................................................................64
Wireless MAC Filter .................................................................................................................................74
Dual WAN.....................................................................................................................................................75
General Setting ........................................................................................................................................75
Outbound Load Balance ..........................................................................................................................79
Protocol Binding.......................................................................................................................................80
Advanced Setup ...........................................................................................................................................81
Firewall ....................................................................................................................................................82
Routing.....................................................................................................................................................83
NAT...........................................................................................................................................................84
Static DNS ................................................................................................................................................89
Time Schedule .........................................................................................................................................90
Mail Alert .................................................................................................................................................92
Remote System Log..................................................................................................................................93
VPN ..............................................................................................................................................................94
IPSec.........................................................................................................................................................95
PPTP Server............................................................................................................................................105
PPTP Client.............................................................................................................................................107
L2TP........................................................................................................................................................113
GRE Tunnel.............................................................................................................................................123
Access Management..................................................................................................................................125
Device Management..............................................................................................................................126
SNMP .....................................................................................................................................................127
Universal Plug & Play .............................................................................................................................128
Dynamic DNS .........................................................................................................................................129
Access Control........................................................................................................................................131
Packet Filter ...........................................................................................................................................133
CWMP (TR-069) .....................................................................................................................................137
Parental Control.....................................................................................................................................139
SAMBA & FTP Server..............................................................................................................................140
Maintenance..............................................................................................................................................143
User Management .................................................................................................................................144
Time Zone..............................................................................................................................................150
Firmware & Configuration .....................................................................................................................151
System Restart .......................................................................................................................................152
Auto Reboot...........................................................................................................................................153
Diagnostics Tool .....................................................................................................................................154
Chapter 5: Troubleshooting .................................................................................................................... 155
Problems with the Router .........................................................................................................................155
Problem with LAN Interface ......................................................................................................................155
Recovery Procedures .................................................................................................................................155
Appendix: Product Support & Contact..................................................................................................... 157

Chapter 1: Introduction
Introduction to your Router
Embedded Dual 4G LTE Industrial Router
MX-1000, Embedded Dual 4G LTE Industrial Router, is integrated with the 802.11n Wireless Access
Point and Dual WAN interfaces featuring reliable connectivity and network expandability. This
cutting-edge networking device provides multi-GNSS engine for GPS, GLONASS, Galileo and QZSS
system for remotely tracking and monitoring vehicles. M1000 is uniquely installed dual 4G LTE
modules enabling an extensive range of mission-critical markets to enjoy a robust, always-on Internet
experience by plugging dual SIMs. Fallback and Failover between dual 4G LTE connections supports
a seamless wireless connection and is perfectly suitable for industrial M2M applications, ranging from
fleet management, public safety, smart bus & transportation, automotive, agriculture, construction,
and retail services.
Extraordinary Connectivity with Solid Data Protection
The MX-1000 features a rugged, compact design with integrated dual 4G LTE WAN ports, 4-port
Gigabit Ethernet switch, 802.11n Wi-Fi access point with multiple SSID supports, and two
multi-function USB 2.0 host interfaces for Storage/NAS. SPI firewall, and advanced VPN integration
provide security needed to enhance the operations of Public Safety, Energy Wellhead and Gas
Industry, Industrial M2M Segment, PoS/Kiosks/ATM, Fleet Management, and Smart
Transportation/Bus.
Vehicle Tracking System
MX-1000 is embedded with a GNSS receiver for GPS or GLONASS. To co-work with On-Board
Diagnostics(OBD) system, it eases the central control of geographically-dispersed fleets by presenting
individual vehicles' detailed information, including remaining fuel levels, rapid accelerations, and
locations.
Robust Design to Withstand in the Harshest Environments
The industrial-grade enclosure is designed to resist heat, dust, moisture and provides long-term
operation in the toughest of environments. M1000 supports an extended temperatures range from -40
to 140º F ( -40 to 60º C) for extremely challenging conditions such as industrial automation, mining
plants, wellhead & gas drilling, manufacturing factories, and virtually anywhere that requires a robust
wireless connection.
The Future of Internet Connectivity - 4G LTE
To offer an advanced network solution that meets the growing demands of M2M services, MX-1000
exclusively features dual WAN - load balance or auto-failover/failback to provide extraordinary,
always-on internet connectivity. In addition to the deployment of dual 4G LTE modules and dual SIMs,
MX-1000 broadens wireless coverage to rough terrains and rural areas and persists seamless
connectivity without interruptions.

Secure VPN Connections
The MX-1000 supports comprehensive and robust IPSec VPN (Virtual Private Network) protocols for
business users to establish private encrypted tunnels over the public Internet to secure data
transmission between headquarters and branch offices. It also supports VPN dial in from smart
phones for secure remote Internet connection via your home broadband. With a built-in DES/3DES
VPN accelerator, the router enhances IPSec VPN performance significantly.
IPv6 Supported
Internet Protocol version 6 (IPv6) is a version of the Internet Protocol that is designed to succeed IPv4.
IPv6 has a vastly larger address space than IPv4. The router is already supporting IPv6, you can use
it in IPv6 environment no need to change device. The dual-stack protocol implementation in an
operating system is a fundamental IPv4-to-IPv6 transition technology. It implements IPv4 and IPv6
protocol stacks either independently or in a hybrid form. The hybrid form is commonly implemented in
modern operating systems supporting IPv6.
Quick Start Wizard
Support a WEB GUI page to install this device quickly. With this wizard, simple steps will get you
connected to the Internet immediately.
Firmware Upgradeable
Device can be upgraded to the latest firmware through the WEB based GUI.

Features & Specifications
• Dual 4G LTE broadband connectivity (3G Fallback optional)
• Dual-WAN 4G LTE interface for network expandability and reliable connectivity
• High performance antenna for increased coverage, signal reception and efficiency
• Embedded GNSS engine for real-time asset tracking and location data-based applications
• Enterprise level routing functionality
• Gigabit Ethernet WAN (GbE WAN) for Cable/Fiber/xDSL high WAN throughput
• Gigabit Ethernet LAN
• IPv6 ready (IPv4/IPv6 dual stack)
• Multiple wireless SSIDs with wireless guest access and client isolation
• IEEE 802.11 b/g/n compliant Wireless Access Point with Wi-Fi Protected Setup (WPS)
• Wi-Fi Protected Access (WPA-PSK/ WPA2-PSK) and Wired Equivalent Privacy (WEP)
• Secured IPSec VPN with powerful DES/ 3DES/ AES
• Secured PPTP VPN with Pap/ Chap/ MPPE authentication
• Secured L2TP VPN with Pap/Chap authentication
• Secured GRE VPN tunnel
• 32 secured VPN tunnels
• Firewall Security with DoS Preventing and Packet Filtering
• Quality of Service Control for traffic prioritization management
• Universal Plug and Play (UPnP) Compliance
• Ease of Use with Quick Installation Wizard
• USB port for NAS (FTP/ SAMBA server)
• Global Navigation Satellite System (GNSS)
• Small form factor with multiple mounting options, easily installed by a single person
• Power ignition control option when mounted within vehicles
• Hardened enclosure with Industrial-graded components
• Designed to withstand hypothermia, heat and protect from shock, vibration, etc.
High-speed Mobile Wireless Communication
• Embedded Dual 4G LTE module
• High performance external antenna
Global Navigation Satellite System (GNSS)
• Embedded Dual 4G LTE module

• High performance external antenna
Network Protocols and Features
• IPv4, IPv6 or IPv4/IPv6 Dual Stack
• NAT, Static Routing and RIP-1/2
• DHCPv4/v6
• Universal Plug and Play (UPnP) Compliant
• Dynamic Domain Name System (DDNS)
• Virtual Server and DMZ
• SNTP, DNS proxy
• IGMP snooping and IGMP proxy
• MLD snooping and MLD proxy
Firewall
• Built-in NAT Firewall
• Stateful Packet Inspection (SPI)
• DoS attack prevention including Land Attack, Ping of Death, etc
• Access control
• IP&MAC filter, URL Content Filter
• Password protection for system management
• VPN pass-through
Quality of Service Control
• Traffic prioritization management based-on Protocol, Port Number and IP Address (IPv4/IPv6)
IPTV Applications*2
• IGMP proxy and IGMP snooping
• MLD proxy and MLD snooping
• Interface Grouping (VLAN)
• Quality of Service (QoS)
Wireless LAN
• Compliant with IEEE 802.11 b/g/n standards
• 2.4 GHz - 2.484GHz radio band for wireless
• Up to 300 Mbps wireless operation rate
• 64/128 bits WEP supported for encryption
• WPS (Wi-Fi Protected Setup) for easy setup

• Wireless Security with WPA-PSK, WPA2-PSK support
• WDS repeater function support
• Multiple SSID
• Wireless client isolation
USB Application Server
• Storage/NAS: SAMBA Server, FTP Server
Virtual Private Network (VPN)
• IPSec VPN Tunnels
• PPTP VPN Tunnels
• L2TP VPN Tunnels
• GRE VPN Tunnels
Management
• Quick Installation wizard
• Web-based GUI for remote and local management
• Firmware upgrades and configuration data upload and download via web-based GUI
• Supports DHCP server / client / relay
• Supports SNMP v1, v2, v3, MIB-I and MIB-II
• TR-069*1 supports remote management
1. On request for Telco / ISP projects
2. IPTV application may require subscription to IPTV services from a Telco / ISP.
3. Specifications on this datasheet are subject to change without prior notice.

Hardware Specifications
Physical interface
• 4G LTE module: 2 Embeded 4G LTE modules
• Ethernet: 4-port 10 / 100 / 1000Mbps auto-crossover (MDI / MDI-X) Switch
• EWAN: Ethernet port #4 can be configured as an EWAN port for connecting to
Cable/Fiber/xDSL modem for Broadband connectivity.
• GNSS: Embeded GNSS
• SIM card slot: 2 mini-SIM(2FF) card slots
• USB: 2 USB 2.0 Type A Host port for storage service
• Mini USB: 2 mini USB connectors for 4G LTE module debug
• 4G LTE antenna: 4 detachable antennas (2 antennas for each 4G LTE module)
• GPS antenna: 1 active GPS antenna
• WiFi antenna: 2 detachable wireless antennas
• Factory default reset button
• Wireless on/off and WPS push button
• 4-pin power connector

Application Diagram
The MX-1000 is specifically designed to provide outstanding network efficiency and internet security
for a wide range of applications and vertical M2M market segments.
Public Safety:
Fleet Management / Smart Bus:
Energy Industry Segment:

Chapter 2: Product Overview
Important Note for Using This Router
 Do not use the router in high humidity or high temperature.
 Do not open or repair the case yourself. If the device becomes
too hot, turn off the power immediately and have it repaired at
a qualified service center.
 Avoid using this product and all accessories outdoors.
Warning

Device Description
Index
Item
Description
1
WiFi antenna
Screw the supplied WiFi antennas onto the antenna connectors
2
WiFi/WPS LED
The single-colour LED behaves as follows:
Green
Wireless connection established
Green blinking
Data being transmitted / received
3
WiFi On/Off
& WPS button
By controlling the pressing time, users can achieve two different effects:
(1) WiFi On/Off: Press & hold the button for more than 6 seconds to On/Off the
wireless.
(2) WPS: Press &hold the button for less than 6 seconds to trigger WPS function.
4
Reset button
After the device is powered on, press it 6 seconds or above: to restore to factory
default settings (this is used when you cannot login to the router, e.g. forgot your
password)
5
Mini USB port
Connecting to a USB dongle or a hard drive.
6
SIM card slot
Insert the mini SIM card(2FF) with the gold contact facing up.
Push the mini SIM card(2FF) inwards to eject it
Warning: Before inserting or removing the SIM card, you must disconnect the
router from the power adapter.
1
1
6
2
3
4
5

Index
Item
Description
1
4G LTE 1 antenna
Screw the supplied 4G LTE antennas onto the antenna connectors for 4G LTE module
1.
2
4G LTE 2 antenna
Screw the supplied 4G LTE antennas onto the antenna connectors for 4G LTE module
2.
3
GPS antenna
Screw the supplied GPS antenna onto the antenna connectors.
4
Power Jack
Connect the supplied Power cable to this jack
5
USB port
The USB can support setup for storage/file sharing. Connect an external USB dongle /
hard drive for storage.
6
Gigabit Ethernet
(LAN 1 ~ LAN 4)
Connect a UTP Ethernet cable (Cat-5 or Cat-5e) to one of the four LAN ports when
connecting to a PC or an office/home network of 10Mbps/ 100Mbps/ 1000Mbps
1
2
3
1
2
4
5
6

Index
Item
Description
1
Power LED
The Power dual-colour LED behaves as shown below.
Green
System is up and ready
Red
Boot failure
2
Internet LED
The Internet dual-colar LED behaves as shown below.
Green
IP connected and traffic is passing through the device.
Red
IP request failed.
Off
Either in bridged mode or WAN connection not present.
3
USB LED
The single-colar LED behaves as shown below.
Green
Connecting to a USB dongle or a hard drive.
4
GPS LED
The single-colar LED behaves as shown below.
Green
GPS active
5
WAN LED
(Received Signal
Strength Indicator)
The 4G LTE received signal dual-colar LED behaves as shown below.
Green
RSSI greater than -69 dBm. Excellent signal condition.
Green Flashing quickly
RSSI from -81 to -69 dBm. Good signal condition
Red Flashing quickly
RSSI from -99 to -81 dBm. Fair signal condition.
Red Flashing slowly
RSSI less than -99 dBm. Poor signal condition.
Red
No signal and the 4G LTE module is in service
Off
No LTE module or LTE module fails
6
Ethernet LED
The dual-colour LED behaves as shown below.
Green
Transmission speed is at Gigabit speed (1000Mbps)
Orange
Transmission speed is at 10/100Mbps
Blinking
Data being transmitted/received
1
2
3
4
5
5
6

The detail instruction in Reset Button
Recovery procedures for non-working routers (e.g. after a failed firmware upgrade flash):
Power on the router, once the Power LED lit red, please press this reset button using the end of paper
clip or other small pointed object immediately.
The router’s emergency-reflash web interface will then be accessible via http://192.168.1.1 where you
can upload a firmware image to restore the router to a functional state.
Please note that the router will only respond with its web interface at this address (192.168.1.1), and
will not respond to ping request from your PC or other telnet operations.
Note:
Before starting recovery process, please configure the IP address of the PC as 192.168.1.100 and
proceed with the following step-by-step guide.
1. Power the router off.
2. Press reset button and power on the router, once the Power lights Red, keeping press reset button
over 6 seconds.
3. Internet led flashes Green, router entering recovery procedure and router's IP will reset to
Emergency IP address (Say 192.168.1.1).
4. Open browser and access http://192.168.1.1 to upload the firmware.
5. Internet led lit Red, and router starts to write firmware into flash. Please DO NOT power off the
router at this step.
6. Internet led lit Green when successfully upgrade firmware.
7. Power the router off and then on.

Cabling
One of the most common causes of problems is bad cabling. Make sure that all connected devices are
turned on. On the front panel of the product is a bank of LEDs. Verify that the LAN Link and LEDs are
lit. If they are not, verify that you are using the proper cables.

Chapter 3: Basic Installation
The router can be configured with your web browser. A web browser is included as a standard
application in the following operating systems: Windows XP / Vista / 7 / 8, Linux, Mac OS, etc. The
product provides an easy and user-friendly interface for configuration.
PCs must have an Ethernet interface installed properly and be connected to the router either directly
or through an external repeater hub, and have TCP/IP installed and configured to obtain an IP address
through a DHCP server or a fixed IP address that must be in the same subnet as the router. The
default IP address of the router is 192.168.1.254 and the subnet mask is 255.255.255.0 (i.e. any
attached PC must be in the same subnet, and have an IP address in the range of 192.168.1.1 to
192.168.1.253). The best and easiest way is to configure the PC to get an IP address automatically
from the router using DHCP. If you encounter any problems accessing the router’s web interface it may
also be advisable to uninstall any kind of software firewall on your PCs, as they can cause problems
accessing the 192.168.1.254 IP address of the router. Users should make their own decisions on how
to best protect their network.
Please follow the steps below for your PC’s network environment installation. First of all, please check
your PC’s network components. The TCP/IP protocol stack and Ethernet network adapter must be
installed. If not, please refer to your Windows-related or other operating system manuals.
Any TCP/IP capable workstation can be used to communicate with or
through the MX-1000. To configure other types of workstations,
please consult the manufacturer’s documentation.

Network Configuration – IPv4
Configuring PC in Windows 7/8 (IPv4)
1. Go to Start. Click on Control Panel.
2. Then click on Network and Internet.
3. When the Network and Sharing
Center window pops up, select and
click on Change adapter settings on
the left window panel.
4. Select the Local Area Connection,
and right click the icon to select
Properties.

5. Select Internet Protocol Version 4
(TCP/IPv4) then click Properties.
6. In the TCP/IPv4 properties window,
select the Obtain an IP address
automatically and Obtain DNS
Server address automatically radio
buttons. Then click OK to exit the
setting.
7. Click OK again in the Local Area
Connection Properties window to
apply the new configuration.

Configuring PC in Windows Vista (IPv4)
1. Go to Start. Click on Network.
2. Then click on Network and Sharing
Center at the top bar.
3. When the Network and Sharing
Center window pops up, select and
click on Manage network
connections on the left window
pane.
4. Select the Local Area Connection,
and right click the icon to select
Properties.
