Billion BiPAC 8900X R3 User manual

BiPAC 8900X R3
3G/4G LTE VDSL2/ADSL2+ VPN
Firewall Router
User Manual
Version Released: 2.52.d3 Last revised date: Sept. 21, 2018

Table of Contents
Chapter 1: Introduction .................................................................................................................................. 1
Introduction to your Router..................................................................................................................... 1
Features ................................................................................................................................................... 3
VDSl2/ADSL2 Compliance ............................................................................................................... 3
Network Protocols and Features ...................................................................................................... 4
Firewall.............................................................................................................................................. 4
Quality of Service Control ................................................................................................................. 4
ATM, PTM and PPP Protocols ........................................................................................................... 5
IPTV Applications ............................................................................................................................. 5
USB Application Server ..................................................................................................................... 5
Virtual Private Network (VPN) .......................................................................................................... 5
Management..................................................................................................................................... 5
Hardware Specifications .......................................................................................................................... 7
Physical Interface.............................................................................................................................. 7
Power Requirements ........................................................................................................................ 7
Operating Environment .................................................................................................................... 7
Chapter 2: Installing the Router...................................................................................................................... 8
Package Contents..................................................................................................................................... 8
Important note for using this router ....................................................................................................... 9
Device Description ................................................................................................................................. 10
The Front LEDs ................................................................................................................................ 10
The Rear Ports................................................................................................................................. 11
Cabling.................................................................................................................................................... 12
Chapter 3: Basic Installation ......................................................................................................................... 13
Connecting Your Router......................................................................................................................... 14
Network Configuration .......................................................................................................................... 16
Configuring a PC in Windows 7/ 8/ 10............................................................................................ 16
Configuring a PC in Windows Vista................................................................................................. 19
Configuring a PC in Windows XP..................................................................................................... 22
Factory Default Settings......................................................................................................................... 24
Information from your ISP ..................................................................................................................... 26
Easy Sign On (EZSO) ...................................................................................................................................... 27
Chapter 4: Configuration .............................................................................................................................. 31
Configuration via Web Interface............................................................................................................ 31
Status ..................................................................................................................................................... 33
Summary ......................................................................................................................................... 34
WAN ................................................................................................................................................ 35
Statistics .......................................................................................................................................... 36
LAN........................................................................................................................................... 36
WAN Service............................................................................................................................. 37
xTM .......................................................................................................................................... 38
xDSL.......................................................................................................................................... 39
Bandwidth Usage ............................................................................................................................ 42
LAN........................................................................................................................................... 42
WAN Service............................................................................................................................. 44
3G/4G LTE Status ............................................................................................................................ 46
Route............................................................................................................................................... 47
ARP.................................................................................................................................................. 48
DHCP ............................................................................................................................................... 49

VPN.................................................................................................................................................. 50
IPSec......................................................................................................................................... 50
PPTP ......................................................................................................................................... 51
L2TP.......................................................................................................................................... 52
OpenVPN.................................................................................................................................. 53
GRE........................................................................................................................................... 54
Log................................................................................................................................................... 55
System Log ............................................................................................................................... 55
Security Log.............................................................................................................................. 56
Load Balance Status ................................................................................................................. 57
Quick Start.............................................................................................................................................. 58
Quick Start....................................................................................................................................... 58
Configuration ......................................................................................................................................... 62
LAN - Local Area Network ............................................................................................................... 63
Ethernet ................................................................................................................................... 63
IPv6 Autoconfig........................................................................................................................ 66
Interface Grouping................................................................................................................... 70
LAN VLAN Setting..................................................................................................................... 73
Eth Port Control ....................................................................................................................... 74
WAN-Wide Area Network............................................................................................................... 75
WAN Service............................................................................................................................. 75
 DSL .............................................................................................................................. 75
 Ethernet ...................................................................................................................... 86
 3G/4G LTE ................................................................................................................... 93
DSL............................................................................................................................................ 96
Failover..................................................................................................................................... 97
SNR........................................................................................................................................... 98
System............................................................................................................................................. 99
Internet Time ........................................................................................................................... 99
Firmware Upgrade ................................................................................................................. 100
Backup / Update .................................................................................................................... 101
Access Control........................................................................................................................ 102
Mail Alert ............................................................................................................................... 103
SMS Alert................................................................................................................................ 104
Configure Log ......................................................................................................................... 105
USB................................................................................................................................................ 106
Storage Device Info................................................................................................................ 106
User Account.......................................................................................................................... 107
Print Server ............................................................................................................................ 112
DLNA ...................................................................................................................................... 117
IP Tunnel ....................................................................................................................................... 119
IPv6inIPv4............................................................................................................................... 119
IPv4inIPv6............................................................................................................................... 121
Security ......................................................................................................................................... 122
IP Filtering Outgoing .............................................................................................................. 122
IP Filtering Incoming .............................................................................................................. 125
MAC Filtering ......................................................................................................................... 127
Blocking WAN PING ............................................................................................................... 128
Time Restriction ..................................................................................................................... 129
URL Filter................................................................................................................................ 131
Parental Control Provider ...................................................................................................... 134
QoS - Quality of Service ................................................................................................................ 135
Quality of Service ................................................................................................................... 135

QoS Port Shaping ................................................................................................................... 140
NAT................................................................................................................................................ 141
Exceptional Rule Group.......................................................................................................... 141
Virtual Servers........................................................................................................................ 143
DMZ Host ............................................................................................................................... 147
One-to-One NAT .................................................................................................................... 148
Port Triggering ....................................................................................................................... 149
ALG ......................................................................................................................................... 152
Wake On LAN ................................................................................................................................ 153
VPN....................................................................................................................................................... 154
IPSec.............................................................................................................................................. 154
VPN Account ................................................................................................................................. 164
Exceptional Rule Group................................................................................................................. 165
PPTP .............................................................................................................................................. 167
PPTP Server............................................................................................................................ 167
PPTP Client ............................................................................................................................. 168
L2TP............................................................................................................................................... 180
L2TP Server ............................................................................................................................ 180
L2TP Client ............................................................................................................................. 182
OpenVPN....................................................................................................................................... 197
OpenVPN Server .................................................................................................................... 197
OpenVPN CA .......................................................................................................................... 199
OpenVPN Client ..................................................................................................................... 200
GRE................................................................................................................................................ 207
Advanced Setup ................................................................................................................................... 208
Routing.......................................................................................................................................... 209
Default Gateway .................................................................................................................... 209
Static Route............................................................................................................................ 210
Policy Routing ........................................................................................................................ 211
RIP .......................................................................................................................................... 212
Load Balance .......................................................................................................................... 213
DNS................................................................................................................................................ 216
DNS......................................................................................................................................... 216
Dynamic DNS.......................................................................................................................... 218
DNS Proxy............................................................................................................................... 221
Static DNS............................................................................................................................... 222
Static ARP ...................................................................................................................................... 223
UPnP.............................................................................................................................................. 224
Certificate...................................................................................................................................... 230
Trusted CA.............................................................................................................................. 230
Multicast ....................................................................................................................................... 233
Management................................................................................................................................. 235
SNMP Agent ........................................................................................................................... 235
TR- 069 Client......................................................................................................................... 236
HTTP Port ............................................................................................................................... 238
Remote Access ....................................................................................................................... 239
Mobile Networks ................................................................................................................... 240
3G/4G LTE Usage Allowance.................................................................................................. 241
Power Management .............................................................................................................. 242
Time Schedule........................................................................................................................ 243
Auto Reboot........................................................................................................................... 244
Diagnostics .................................................................................................................................... 245
Diagnostics Tools ................................................................................................................... 245

Push Service ........................................................................................................................... 248
Diagnostics ............................................................................................................................. 249
Fault Management................................................................................................................. 250
Ethernet OAM ........................................................................................................................ 251
Restart.................................................................................................................................................. 252
Chapter 5: Troubleshooting........................................................................................................................ 253
Appendix: Product Support & Contact ....................................................................................................... 255

1
Chapter 1: Introduction
Introduction to your Router
The Billion BiPAC 8900X R3, a multi service VDSL2 (17a) Router. It features fibre-ready triple-WAN
VDSL2 supports backward compatibility to ADSL2+ for a longer reach distance, an all-in-one
advanced device including Gigabit Ethernet, 3G/4G LTE, and NAS (Network Attached Storage) in
one unit. As well as being IPv6-capable, the BiPAC 8900X R3 VDSL2 router supports super-fast
fibre connections via a Gigabit Ethernet WAN port. It also has one USB port, allowing the device to
act as a print server as well as a NAS (Network Attached Storage) device with DLNA (Digital Living
Network Alliance) and FTP (File Transfer Protocol) access. Moreover, the USB port can host a
3G/4G LTE modem connecting to the 3G/4G LTE network for Internet access. With an array of
advanced features, the Billion BiPAC 8900X R3 delivers a future-proof solution for VDSL2
connections, super-fast FTTC and ultra-speed FTTH (Fibre-To-The-Home) network deployment
and services.
Very High-speed Connectivity for Internet Access
The BiPAC 8900X R3 complies with VDSL2 and ADSL2+ worldwide standards and it can support
the downlink data rate of up to 100Mbps and uplink data rate of up to 50Mbps in VDSL2. It’s also
integrated with 4-port 10/100/1000Mbps switch, 1-port Gigabit switch, and 802.11n wireless AP,
enabling users to connect to multiple computers or devices easily.
3G/4G LTE Mobility and Always-on Connectivity
With 3G/LTE-based Internet connection (requires an additional 3G/LTE USB modem),
communication via the BiPAC 8900X R3 is becoming more convenient and widely available -
allowing you to watch movies, download music on the road, or access e-mail no matter where you
are. You can even share your Internet connection with others, no matter if you're in a meeting, or
speeding across the country on a train. The auto fail-over feature ensures optimum connectivity and
minimum interruption by quickly and smoothly connecting to a 3G/4G LTE network in the event that
you xDSL/Fibre/Cable line fails. The BiPAC 8900X R3 will then automatically reconnect to the
ADSL/Fibre/Cable connection when it is restored, reducing connection costs. These features are
perfect for office situations when a constant and smooth WAN connection is critical.
Secure VPN Connections
The BiPAC 8900X R3 supports all currently popular secure VPNs, including embedded IPSec VPN,
PPTP, L2TP, OpenVPN, GRE, which satisfies different users’ needs, allowing users to establish
encrypted private connections over the Internet with your optimum VPN options. You can access
your corporate Intranet and transmit sensitive data between branch offices and remote sites
anytime; even when you are out of office, thus enhancing productivity.
IPv6 supported
Internet Protocol version 6 (IPv6) is a version of the Internet Protocol that is designed to succeed
IPv4. IPv6 has a vastly larger address space than IPv4. This results from the use of a 128-bit
address, whereas IPv4 uses only 32 bits. The new address space thus supports 2
128
(about
3.4×10
38
) addresses. This expansion provides flexibility in allocating addresses and routing traffic
and eliminates the primary need for network address translation (NAT), which gained widespread

2
deployment as an effort to alleviate IPv4 address exhaustion.
IPv6 also implements new features that simplify aspects of address assignment (stateless address
autoconfiguration) and network renumbering (prefix and router announcements) when changing
Internet connectivity providers. The IPv6 subnet size has been standardized by fixing the size of the
host identifier portion of an address to 64 bits to facilitate an automatic mechanism for forming the
host identifier from Link Layer media addressing information (MAC address).
Web Based GUI
It supports web based GUI for configuration and management. It is user-friendly and comes with
online help. It also supports remote management capability for remote users to configure and
manage this product.
Firmware Upgradeable
Device can be upgraded to the latest firmware through the WEB based GUI.

3
Features
• IPv6 ready (IPv4/IPv6 dual stack)
• Flexible WAN approach – VDSL2/ADSL2+, 3G/4G LTE mobile connection, and Ethernet
WAN for Broadband Connectivity
• High-speed Internet Access via VDSL2/ADSL2 / 2+; Backward Compatible withADSL
• Fibre (FTTC/FTTP/FTTH) ready with high WAN throughput
• Gigabit Ethernet WAN and LAN
• NBN (National Broadband Network) ready
• Auto fail-over
• USB port for print server, NAS, DLNA media server, and 3G/4G LTE USB modem
•SNR adjustments to achieve highest sync speeds
• Monitoring of individual LAN ports
• QoS for traffic prioritization and bandwidth management
• SOHO Firewall Security with DoS Preventing and Packet Filtering
• Quality of Service Control for traffic prioritization and Bandwidth management
• 16 Secured IPSec VPN tunnels with powerful DES/ 3DES/ AES
• PPTP VPN with Pap/ Chap/ MS-CHAPv2 authentication
• Pure L2TP and L2TP over IPSec
• OpenVPN with CA authentication and extensive OpenSSL encryption
• GRE tunnel
• Universal Plug and Play (UPnP) Compliance
• Supports IPTV Application
*
2
• Ease of Use with Quick Installation Wizard (EZSO)
• Ideal for SOHO and office users
VDSl2/ADSL2+ Compliance
• Compliant with xDSL Standard
- ITU-T G.993.2 (VDSL2)
- ITU-T G.998.4 (G.inp)
- ITU-T G.993.5 (G.vector)
- ITU-T G.992.5 (G.dmt.bis plus, Annex M )
- ITU-T G.992.3 (G.dmt.bis, Annex M)
- Full-rate ANSI T1.413 Issue 2
- ITU-T G.992.1 (G.dmt)
- ITU-T G.992.2 (G.lite)
- ITU-T G.994.1 (G.hs)

4
• Supports VDSL2 band plan: 997 and 998
• Supports VDSL2 profiles: 8a, 8b, 8c, 8d, 12a, 12b, and 17a
• ADSL/2/2+ fallback modes
• SupportsATM and PTM modes
Network Protocols and Features
• IPv4 or IPv4 / IPv6 Dual Stack
• NAT, static (v4/v6) routing and RIP-1 / 2
• IPv6 Stateless / Stateful Address Auto-configuration
• IPv6 Router Advertisement
• IPv6 over PPP
• DHCPv6
• IP Tunnel IPv6 in IPv4(6RD)
• IP Tunnel IPv4 in IPv6(DS-Lite)
• Universal Plug and Play (UPnP) Compliant
• Dynamic Domain Name System (DDNS)
• Virtual Server, DMZ and one-to-one NAT
• SNTP, DNS relay, IGMP snooping and IGMP proxy for video service
• MLD snooping and MLD proxy for video service
• Management based-on IP protocol, port number and address
• SMTP client with SSL/TLS
• Supports port-based interface grouping (VLAN)
Firewall
• Built-in NAT Firewall
• Stateful Packet Inspection (SPI)
• DoS attack prevention
• Packet Filtering (v4/v6) - port, source IP address, destination IP address
• URL Content Filtering (v4/v6) – string or domain name detection in URL string
• MAC Filtering
• Remote access control for web-based access
• Password protection for system management
Quality of Service Control
• Supports the DiffServ approach
• Traffic prioritization and bandwidth management based-on IPv4/IPv6 protocol, port
number and address

5
ATM, PTM and PPP Protocols
• ATM Adaptation Layer Type 5 (AAL5)
• Multiple Protocol over ALL5 (RFC 268, formerly RFC 1483)
•Bridged or routed Ethernet encapsulation
• VC and LLC based multiplexing
• PPP over Ethernet (PPPoE)
• PPP over ATM (RFC 2364)
• Classical IP over ATM (RFC 1577)
• MAC Encapsulated Routing (RFC 1483 MER)
• OAM F4 / F5
IPTV Applications
*2
• IGMP Snooping and IGMP Proxy
• MLD Snooping and MLD Proxy
• Interface Grouping (VLAN)
• Quality of Service (QoS)
USB Application Server
• 3G/4G LTE dongle support
• Storage: FTP server, Samba server，DLNA
• Printer Server
Virtual Private Network (VPN)
• 16 IPSec VPN tunnels
• IKE key management
• DES, 3DES and AES encryption for IPSec
• L2TP over IPSec
• Pap/ Chap/ MS-CHAPv2 authentication for PPTP
• IPSec pass-through
• GRE tunnel
Management
• Easy Sign-on (EZSO)
• Web-based GUI for remote and local management (IPv4/IPv6)
• Firmware upgrades and configuration data upload and download via web-based GUI
• Embedded Telnet server for remote and local management
• Supports DHCP server / client / relay
• Supports SNMP v1,v2, MIB-I and MIB-II
