Bin Master BINCLOUD BCGW HCM Series User manual

Tools needed: drill and bit, phillips screwdriver, drywall/
wood screws, ethernet cable, pliers. Screws and plas-
tic plugs,A1, can be used to secure the top cover.
STEP 2
Attach mount brackets to the enclosure
with the included screws. Brackets t on
protruding screwholes on the back of
the enclosure. Then, use drywall screws
and attach unit to the wall.
STEP 1
Choose a wall location to mount your Gateway. Make sure there is access to a 120VAC outlet and, preferably, an ethernet connection.
A1
QUICK SETUP GUIDE
BINCLOUD GATEWAY
BCGW.XXXXC-HCM
STEP 3
Install 3 cable glands using a drill and bit on the HCM-100.
-One cable gland is for 110VAC positive and negative wires.
-One cable gland is for BinCloud Gateway Channel 1(A&B) to HCM-100 RX-A&B
-One cable gland for HARTcommunication wires going to NCR sensors
(Cable glands not included)
STEP 4
Attach the antenna as shown. This Gateway has been setup with multiNetwork cell connection that will
automatically connect when powered. If cell service is unavailable it is possible to connect the Gateway
ethernet plug to a network router or switch.

STEP 6 PLUG IN!
- Check wire connections and replace covers.
- Connect the Gateway ethernet plug to a network port, router or switch.
- Plug SmartBob and Gateway units into the 120VAC outlet.
- Wait 25 minutes and call BinMaster at 1-800-278-4241 to conrm the internet connection.
- BinMaster will create a custom cloud page with your specic bins, tanks, silos, sizes,
locations, etc. We’ll chat about your page during the connection verication call.
FIREWALLRULES FOR BINCLOUD GATEWAY
Direction Outbound Ports For these IPS IPAddresses
TCP 80, 433 All
UDP 5959-5961 52.38.107.102
52.25.64.249
34.221.219.221
54.218.6.237
UDP 5959-5970 52.39.255.60
54.71.174.229
52.88.4.160
34.217.159.41
34.213.84.184
52.43.176.61
35.162.54.59
52.42.122.172
44.224.165.129
44.226.176.44
44.237.66.197
44.238.4.218
54.184.44.101
44.228.115.25
44.230.239.2
44.236.20.68
44.236.200.9
44.236.76.190
44.239.243.92
44.240.35.27
Direction Outbound Ports Region IPAddresses
UDP 20000-40000 USA All
UDP 54.212.116.92
UDP 52.12.114.120
UDP 52.87.228.243
UDP 3.88.21.119
UDP 34.223.7.202
UDP Europe 54.93.100.223
UDP 18.195.88.21
UDP 18.184.70.5
UDP India 15.207.116.15
UDP 13.127.230.228
UDP SEAsia 13.212.70.205
UDP 13.212.30.222
UDP Asia 18.182.42.125
UDP 13.230.250.171
UDP 18.179.34.24
UDP Japan 52.69.206.76
UDP 18.179.57.238
BinCloud Gateway
HCM-100
NCR-80
STEP 5
Remove cover of HCM-100 and Gateway
● Connect BinCloud Gateway Channel 1(A) to HCM-100 RX-A
●Connect BinCloud Gateway Channel 1(B) to HCM-100 RX-B
●●Connect 110VAC line and neutral to HCM-100 inputs
●●Connect HCM-100 +24VDC red terminal to sensor positive and
-24VDC black terminal to sensor negative.
Daisy
Chain
110V
Power Supply
